Stihl HS 81 R User guide

{
Hedge Trimmer Safety Manual

Original Instruction ManualPrinted on chlorine-free paper
Printing inks contain vegetable oils, paper can be recycled.
© ANDREAS STIHL AG & Co. KG, 2011 0457-189-3021. M0-5.J11.PM. 0000000558_004_GB
Hedge Trimmer Safety Manual
English
1
{
Contents
This manual contains the safety
precautions and recommended cutting
techniques outlined in STIHL instruction
manuals for gasoline-powered hedge
trimmers. Even if you are an
experienced hedge trimmer user, it is in
your own interest to familiarize yourself
with the latest instructions and safety
precautions regarding your hedge
trimmer.
Please note that the illustrations in the
chapters "Using the Unit" and "Main
Parts and Controls" in this manual show
the hedge trimmer STIHL HS 81.
Other hedge trimmer models may have
different parts and controls. You should
therefore always refer to the instruction
manual of your particular hedge trimmer
model.
Contact your STIHL dealer or the STIHL
distributor for your area if you do not
understand any of the instructions in this
manual.
Safety Precautions and Working
Techniques 2
Using the Unit 10
Maintenance and Care 12
Main Parts 14

Hedge Trimmer Safety Manual
English
2
Have your STIHL dealer show you how
to operate your power tool. Observe all
applicable local safety regulations,
standards and ordinances.
Use your hedge trimmer only for cutting
hedges, shrubs, scrub, bushes and
similar material.
Most of these safety precautions and
warnings apply to the use of all STIHL
hedge trimmers. Different models may
have different parts and controls. See
the appropriate section of your
instruction manual for a description of
the controls and the function of the parts
of your model.
Safe use of a hedge trimmer involves
1. the operator
2. the power tool
3. the use of the power tool.
THE OPERATOR
Physical Condition
You must be in good physical condition
and mental health and not under the
influence of any substance (drugs,
alcohol, etc.) which might impair vision,
dexterity or judgment. Do not operate
this machine when you are fatigued.
These conditions reduce the hand's
ability to feel and regulate temperature,
produce numbness and burning
sensations and may cause nerve and
circulation damage and tissue necrosis.
All factors which contribute to
whitefinger disease are not known, but
cold weather, smoking and diseases or
physical conditions that affect blood
vessels and blood transport, as well as
high vibration levels and long periods of
Safety Precautions and
Working Techniques
Because a hedge trim-
mer is a high-speed, fast-
cutting power tool with
sharp cutting blades,
special safety precau-
tions must be observed to
reduce the risk of per-
sonal injury.
It is important that you
read, fully understand
and observe the following
safety precautions and
warnings. Read the
instruction manual and
the safety precautions
periodically. Careless or
improper use may cause
serious or fatal injury.
Warning!
Do not lend or rent your power tool with-
out the instruction manual. Be sure that
anyone using it understands the infor-
mation contained in this manual.
Warning!
The use of this machine may be hazard-
ous. If the cutting tool comes in contact
with your body, it will cut you.
Warning!
Do not use it for other purposes, since
misuse may result in personal injury or
property damage, including damage to
the machine.
Warning!
Minors should never be allowed to use
this power tool. Bystanders, especially
children, and animals should not be
allowed in the area where it is in use.
Warning!
To reduce the risk of injury to bystand-
ers and damage to property, never let
your power tool run unattended. When it
is not in use (e.g. during a work break),
shut it off and make sure that unauthor-
ized persons do not use it.
Warning!
Be alert – if you get tired, take a break.
Tiredness may result in loss of control.
Working with any power tool can be
strenuous. If you have any condition
that might be aggravated by strenuous
work, check with your doctor before
operating this machine.
Warning!
Prolonged use of a power tool (or other
machines) exposing the operator to
vibrations may produce whitefinger dis-
ease (Raynaud's phenomenon) or
carpal tunnel syndrome.

Hedge Trimmer Safety Manual
English
3
exposure to vibration are mentioned as
factors in the development of whitefinger
disease. In order to reduce the risk of
whitefinger disease and carpal tunnel
syndrome, please note the following:
–Most STIHL power tools are
available with an anti-vibration
("AV") system designed to reduce
the transmission of vibrations
created by the machine to the
operator's hands. An AV system is
recommended for those persons
using power tools on a regular or
sustained basis.
–Wear gloves and keep your hands
warm.
–Keep the AV system well
maintained. A power tool with loose
components or with damaged or
worn AV elements will tend to have
higher vibration levels.
–Maintain a firm grip at all times, but
do not squeeze the handles with
constant, excessive pressure. Take
frequent breaks.
All the above-mentioned precautions do
not guarantee that you will not sustain
whitefinger disease or carpal tunnel
syndrome. Therefore, continual and
regular users should closely monitor the
condition of their hands and fingers. If
any of the above symptoms appear,
seek medical advice immediately.
Proper Clothing
Be particularly alert and cautious when
wearing hearing protection because
your ability to hear warnings (shouts,
alarms, etc.) is restricted.
Avoid loose-fitting jackets, scarfs,
neckties, jewelry, flared or cuffed pants,
unconfined long hair or anything that
could become caught on branches,
brush or the moving parts of the unit.
Secure hair so it is above shoulder level.
THE POWER TOOL
For illustrations and definitions of the
power tool parts see the chapter on
"Main Parts".
Warning!
The ignition system of the STIHL unit
produces an electromagnetic field of a
very low intensity. This field may inter-
fere with some pacemakers. To reduce
the risk of serious or fatal injury, persons
with a pacemaker should consult their
physician and the pacemaker manufac-
turer before operating this tool.
Warning!
To reduce the risk of injury, the operator
should wear proper protective apparel.
Warning!
To reduce the risk of
injury to your eyes never
operate your power tool
unless wearing goggles
or properly fitted protec-
tive glasses with
adequate top and side protection com-
plying with ANSI Z 87.1 (or your
applicable national standard.) To
reduce the risk of injury to your face
STIHL recommends that you also wear
a face shield or face screen over your
goggles or protective glasses.
Power tool noise may damage your
hearing. Wear sound barriers (ear plugs
or ear mufflers) to protect your hearing.
Continual and regular users should
have their hearing checked regularly.
Always wear gloves
when handling the
machine and the cutting
tool. Heavy-duty, nonslip
gloves improve your grip
and help to protect your
hands.
Clothing must be sturdy
and snug-fitting, but allow
complete freedom of
movement. Wear long
pants made of heavy
material to help protect
your legs. Do not wear
shorts, sandals or go
barefoot.
Good footing is very
important. Wear sturdy
boots with nonslip soles.
Steel-toed safety boots
are recommended.

Hedge Trimmer Safety Manual
English
4
If this tool is subjected to unusually high
loads for which it was not designed (e.g.
heavy impact or a fall), always check
that it is in good condition before
continuing work. Check in particular that
the fuel system is tight (no leaks) and
that the controls and safety devices are
working properly. Do not continue
operating this machine if it is damaged.
In case of doubt, have it checked by your
STIHL servicing dealer.
THE USE OF THE POWER TOOL
Transporting the Power Tool
It may be carried only in the horizontal
position. Grip the front handle and keep
the hot muffler away from your body and
the cutter blades behind you.
Fuel
Your STIHL power tool uses an oil-
gasoline mixture for fuel (see the
chapter on "Fuel" of your instruction
manual.)
Fueling Instructions
In order to reduce the risk of burns and
other personal injury from escaping gas
vapor and fumes, remove the fuel filler
cap on your power tool carefully so as to
allow any pressure build-up in the tank
to release slowly. Never remove the fuel
filler cap while the engine is running.
Select bare ground for fueling and move
at least 10 feet (3 m) from the fueling
spot before starting the engine. Wipe off
any spilled fuel before starting your
machine.
Warning!
Never modify this power tool in any way.
Only attachments supplied by STIHL or
expressly approved by STIHL for use
with the specific STIHL model are
authorized. Although certain unauthor-
ized attachments are useable with
STIHL power tools, their use may, in
fact, be extremely dangerous.
Warning!
To reduce the risk of injury from blade
contact, never carry or transport your
power tool with the cutter blades
moving.
Warning!
Always switch off the engine and fit the
scabbard over the cutter blades before
transporting the power tool over long
distances. When transporting it in a
vehicle, properly secure it to prevent
turnover, fuel spillage and damage to
the unit.
Warning!
Gasoline is an extremely
flammable fuel. If spilled
and ignited by a spark or
other ignition source, it
can cause fire and seri-
ous burn injury or
property damage. Use extreme caution
when handling gasoline or fuel mix. Do
not smoke or bring any fire or flame near
the fuel or the power tool. Note that
combustible fuel vapor may escape
from the fuel system.
Warning!
Fuel your power tool in well-ventilated
areas, outdoors. Always shut off the
engine and allow it to cool before refu-
eling. Gasoline vapor pressure may
build up inside the fuel tank depending
on the fuel used, the weather conditions
and the tank venting system.

Hedge Trimmer Safety Manual
English
5
Different models may be equipped with
different fuel caps.
Toolless cap with grip
To do this with this STIHL cap, raise the
grip on the top of the cap until it is upright
at a 90° angle. Insert the cap in the fuel
tank opening with the raised positioning
marks on the grip of the cap and on the
fuel tank opening lining up. Using the
grip, press the cap down firmly while
turning it clockwise as far as it will go
(approx. 1/4 turn).
Misaligned, damaged or broken cap
NIf the cap does not drop fully into the
opening when the positioning marks
line up and/or if the cap does not
tighten properly when twisted, the
base of the cap may be prematurely
rotated (in relation to the top) to the
closed position. Such misalignment
can result from handling, cleaning
or an improper attempt at
tightening.
NTo return the cap to the open
position for installation, turn the cap
(with the grip up) until it drops fully
into the tank opening. Next, twist the
cap counterclockwise as far as it will
go (approx. 1/4 turn) – this will twist
the base of the cap into the correct
position. Then, twist the cap
clockwise, closing it normally.
NIf your cap still does not tighten
properly, it may be damaged or
broken; immediately stop use of the
unit and take it to your authorized
STIHL dealer for repair.
Screw Cap
See also the "Fueling" chapter in your
Instruction Manual for additional
information.
Warning!
Check for fuel leakage
while refueling and dur-
ing operation. If fuel
leakage is found, do not
start or run the engine
until the leak is fixed and
any spilled fuel has been wiped away.
Take care not to get fuel on your cloth-
ing. If this happens, change your
clothing immediately.
Warning!
In order to reduce the risk of fuel spill-
age and fire from an improperly
tightened fuel cap, correctly position
and tighten the fuel cap in the fuel tank
opening.
001BA220 KN
Fold the grip flush with
the top of the cap. Grip
the cap and check for
tightness. If the grip does
not lie completely flush
with the cap and the
detent on the grip does
not fit in the correspond-
ing recess in the filler
opening, or if the cap is
loose in the filler opening,
the cap is not properly
seated and tightened and
you must repeat the
above steps.
Left: Base of cap in closed posi-
tion (with open space)
Right: Base of cap correctly posi-
tioned for installation
001BA227 KN
Warning!
Unit vibrations can cause
an improperly tightened
fuel filler cap to loosen or
come off and spill quanti-
ties of fuel. In order to
reduce the risk of fuel
spillage and fire, tighten the fuel filler
cap by hand as securely as possible.
001BA226 KN

Hedge Trimmer Safety Manual
English
6
Before Starting
Keep the handles clean and dry at all
times; it is particularly important to keep
them free of moisture, pitch, oil, fuel mix,
grease or resin in order for you to
maintain a firm grip and properly control
your power tool.
STIHL recommends that you always
spray the cutter blades with STIHL resin
solvent before starting work – with the
engine stopped! You can obtain this
protective spray from your dealer. Apply
generously.
Starting
Start the engine at least 10 feet (3 m)
from the fueling spot, outdoors only.
For specific starting instructions, see the
appropriate section of your manual.
Place the power tool on firm ground or
other solid surface in an open area.
Maintain good balance and secure
footing.
Once the engine has started,
immediately blip the throttle trigger,
which should release the starting throttle
and allow the engine to slow down to
idle.
Important Adjustments
Warning!
Always check your power tool for proper
condition and operation before starting,
particularly the throttle trigger, throttle
trigger lockout, stop switch and cutting
tool. The throttle trigger (if applicable)
must move freely and always spring
back to the idle position. Never attempt
to modify the controls or safety devices.
Warning!
Never use a power tool that is damaged
or not properly maintained.
Warning!
Check that the spark plug boot is
securely mounted on the spark plug – a
loose boot may cause arcing that could
ignite combustible fumes and cause a
fire.
Warning!
The cutting tool must be properly tight-
ened and in safe operating condition.
Inspect for loose parts (nuts, screws,
etc.) and for cracked, bent, warped or
damaged blades. Regularly check the
condition and tightness of the cutter
blades – with the engine stopped!
Replace damaged cutter blades before
using the power tool. Always keep
blades sharp.
Warning!
To reduce the risk of injury from blade
contact, be absolutely sure that the cut-
ting tool is clear of you and all other
obstructions and objects, including the
ground, because when the engine starts
at starting-throttle, engine speed will be
fast enough for the clutch to engage and
move the blades on the cutting tool.
Warning!
Your power tool is a one-person
machine. Do not allow other persons in
the general work area, even when
starting.
Warning!
To reduce the risk of injury from loss of
control, do not attempt to "drop start"
your power tool.
Warning!
When you pull the starter grip, do not
wrap the starter rope around your hand.
Do not let the grip snap back, but guide
the starter rope to rewind it properly.
Failure to follow this procedure may
result in injury to your hand or fingers
and may damage the starter
mechanism.
Warning!
To reduce the risk of personal injury
from loss of control or contact with the
running cutting tool, do not use your unit
with incorrect idle adjustment. At correct
idle speed, the cutting tool should not
move. For directions on how to adjust
idle speed, see the appropriate section
of your instruction manual.

Hedge Trimmer Safety Manual
English
7
If you cannot set the correct idle speed,
have your STIHL dealer check your
power tool and make proper
adjustments and repairs.
During Operation
Holding and Controlling the Power Tool
Always hold the unit firmly with both
hands on the handles while you are
working. Wrap your fingers and thumbs
around the handles.
Right-hand Use
Put your right hand on the rear handle,
left hand on the front handle.
Operate the machine so that the cutting
blades are always away from your body.
Left-hand Use
Put your left hand on the rear handle,
right hand on the front handle.
Working Conditions
Operate and start your power tool only
outdoors in a well ventilated area.
Operate it under good visibility and
daylight conditions only. Work carefully.
Warning!
Never attempt to operate
your power tool with one
hand. Loss of control of
the power tool resulting in
serious or fatal injury may
result. To reduce the risk
of cut injuries, keep hands and feet
away from the cutting tool. Never touch
a moving cutting tool with your hand or
any other part of your body.
Warning!
Do not overreach. Keep proper footing
and balance at all times. Special care
must be taken in slippery conditions
(wet ground, snow) and in difficult, over-
grown terrain. Watch for hidden
obstacles such as tree stumps, roots
and ditches to avoid stumbling. For bet-
ter footing, clear away fallen branches,
scrub and cuttings. Be extremely cau-
tious when working on slopes or uneven
ground.
Warning!
To reduce the risk of injury from loss of
control, never work on a ladder, in a tree
or any other insecure support. Never
hold the machine above shoulder
height.
Warning!
As soon as the engine is
running, this product gen-
erates toxic exhaust
fumes containing chemi-
cals, such as unburned
hydrocarbons (including
benzene) and carbon monoxide, that
are known to cause respiratory prob-
lems, cancer, birth defects, or other
reproductive harm. Some of the gases
(e.g. carbon monoxide) may be color-
less and odorless. To reduce the risk of
serious or fatal injury / illness from inhal-
ing toxic fumes, never run the machine
indoors or in poorly ventilated locations.
Warning!
If the vegetation being cut or the sur-
rounding ground is coated with a
chemical substance (such as an active
pesticide or herbicide), read and follow
the instructions and warnings that
accompanied the substance at issue.

Hedge Trimmer Safety Manual
English
8
Operating Instructions
In the event of an emergency, switch off
the engine immediately – move the slide
control / stop switch to 0 or STOP.
Accelerating the engine while the blades
are blocked increases the load and will
cause the clutch to slip continuously.
This may result in overheating and
damage to important components (e.g.
clutch, polymer housing components) –
which can then increase the risk of injury
from the blades moving while the engine
is idling.
Take particular care when cutting
hedges next to or against wire fences.
Do not touch the wire with the cutting
blades. When working close to the
ground, make sure that no sand, grit or
stones get between the cutter blades.
Striking solid foreign objects such as
stones, fence wire or metal could
damage the cutting attachment and may
cause blades to crack, chip or break.
STIHL does not recommend the use of
your power tool when cutting in areas
where the blades could contact such
objects.
Check the cutting blades at regular short
intervals during operation, or
immediately if there is a noticeable
change in cutting behavior:
–Shut off the engine.
–Wait until the cutting blades have
come to a complete standstill.
–Check condition and tightness, look
for cracks.
–Check sharpness.
–Replace damaged or dull cutting
tools immediately, even if they have
only superficial cracks.
Warning!
Inhalation of certain dusts, especially
organic dusts such as mold or pollen,
can cause susceptible persons to have
an allergic or asthmatic reaction. Sub-
stantial or repeated inhalation of dust
and other airborne contaminants, in par-
ticular those with a smaller particle size,
may cause respiratory or other ill-
nesses. Control dust at the source
where possible. Use good work prac-
tices, such as operating the unit so that
the wind or operating process directs
any dust raised by the power tool away
from the operator. Follow the recom-
mendations of EPA / OSHA / NIOSH
and occupational and trade associa-
tions with respect to dust ("particulate
matter".) When the inhalation of dust
cannot be substantially controlled, i.e.,
kept at or near the ambient (back-
ground) level, the operator and any
bystanders should wear a respirator
approved by NIOSH / MSHA for the type
of dust encountered.
Warning!
Do not operate your power tool using
the starting throttle lock, as you do not
have control of the engine speed.
Warning!
The cutter blades continue to move for a
short period after the throttle trigger is
released (flywheel effect.)
Warning!
Before you start work, examine the
hedge area for stones, fence wire, metal
or other solid objects which could dam-
age the cutter blades.
Warning!
Observe the cutting blades at all times –
do not cut any areas of the hedge that
you cannot see. When cutting the top of
a taller hedge, check the other side of
the hedge frequently for bystanders,
animals and obstructions.
Danger!
Your power tool is not
insulated against electric
shock. To reduce the risk
of electrocution, never
operate this power tool in
the vicinity of any wires or
cables (power, etc.) which may be car-
rying electric current.
Warning!
If the cutting tool becomes clogged or
stuck, always turn off the engine and
make sure the cutting tool has stopped
before cleaning. Grass, weeds, etc.
should be cleaned off the cutting tool at
regular intervals.
Warning!
The gearbox becomes hot during oper-
ation. To reduce the risk of burn injury,
do not touch the gear housing when it is
hot.

Hedge Trimmer Safety Manual
English
9
After Finishing Work
Always clean dust and dirt off the
machine – do not use any grease
solvents for this purpose.
Spray the blades with STIHL resin
solvent. Start and run the engine briefly
so that the solvent is evenly distributed.
MAINTENANCE, REPAIR AND
STORING
Maintenance, replacement, or repair of
the emission control devices and
systems may be performed by any
nonroad engine repair establishment or
individual. However, if you make a
warranty claim for a component which
has not been serviced or maintained
properly or if nonapproved replacement
parts were used, STIHL may deny
coverage.
Strictly follow the maintenance and
repair instructions in the appropriate
section of your instruction manual.
Please refer to the maintenance chart in
this manual.
Wear gloves when handling or
performing maintenance on blades.
Warning!
The muffler and other parts of the
engine (e.g. fins of the cylinder, spark
plug) become hot during operation and
remain hot for a while after stopping the
engine. To reduce risk of burns do not
touch the muffler and other parts while
they are hot.
Warning!
To reduce the risk of fire and burn injury,
keep the area around the muffler clean.
Remove excess lubricant and all debris
such as pine needles, branches or
leaves. Let the engine cool down sitting
on concrete, metal, bare ground or solid
wood (e.g. the trunk of a felled tree)
away from any combustible substances.
Warning!
Never modify your muffler. The muffler
could be damaged and cause an
increase in heat radiation or sparks,
thereby increasing the risk of fire and
burn injury. You may also permanently
damage the engine. Have your muffler
serviced and repaired by your STIHL
servicing dealer only.
Warning!
Use only identical STIHL replacement
parts for maintenance and repair. Use of
non-STIHL parts may cause serious or
fatal injury.
Warning!
Always stop the engine and make sure
that the cutting tool is stopped before
doing any maintenance or repair work or
cleaning the power tool. Do not attempt
any maintenance or repair work not
described in your instruction manual.
Have such work performed by your
STIHL servicing dealer only.
Warning!
Use the specified spark plug and make
sure it and the ignition lead are always
clean and in good condition. Always
press spark plug boot snugly onto spark
plug terminal of the proper size. (Note: If
terminal has detachable SAE adapter
nut, it must be securely attached.) A
loose connection between spark plug
terminal and the ignition wire connector
in the boot may create arcing that could
ignite combustible fumes and cause a
fire.
Warning!
Never test the ignition system with the
ignition wire boot removed from the
spark plug or with a removed spark
plug, since uncontained sparking may
cause a fire.
Warning!
Do not operate your power tool if the
muffler is damaged, missing or modi-
fied. An improperly maintained muffler
will increase the risk of fire and hearing
loss. If your muffler was equipped with a
spark-arresting screen to reduce the
risk of fire, never operate your power
tool if the screen is missing or damaged.
Remember that the risk of forest fires is
greater in hot or dry weather.
Warning!
Never repair damaged cutting attach-
ments by welding, straightening or mod-
ifying the shape. This may cause parts
of the cutting tool to come off and result
in serious or fatal injuries.

Hedge Trimmer Safety Manual
English
10
Keep the cutting tool sharp. Tighten all
nuts, bolts and screws, except the
carburetor adjustment screws, after
each use.
Do not clean your machine with a
pressure washer. The solid jet of water
may damage parts of the machine.
Store the power tool in a dry and high or
locked location out of reach of children.
Before storing for longer than a few
days, always empty the fuel tank. See
chapter "Storing the machine" in this
manual.
HS 81 R
The HS 81 R is designed for cutting
hedges and shrubs with thicker stems
and branches.
HS 81 T
The HS 81 T is designed for shaping
and trimming hedges and shrubs with
thinner branches.
Use the HS 81 R hedge trimmer for
cutting hedges with thicker branches.
Cutting Season
Observe country-specific or municipal
rules and regulations for cutting hedges.
Do not use your power tool during other
people's rest periods.
Cutting Sequence
Use lopping shears or a chain saw to cut
out thick branches first.
Cut both sides of the hedge first, then
the top.
Disposal
Do not throw cuttings in the garbage can
– they can be composted!
Using the Unit

Hedge Trimmer Safety Manual
English
11
Working Technique
Vertical Cut
Swing the cutting blade from the bottom
upwards in an arc – lower the nose of the
blade, move along the hedge and then
swing the blade up again in an arc.
Any working position above head height
is tiring. To minimize the risk of
accidents, work in such positions for
short periods only.
Horizontal Cut
Hold the cutter bar at an angle of 0° to
10° as you swing the hedge trimmer
horizontally.
Swing the cutting blade in an arc
towards the outside of the hedge so that
the cuttings are swept to the ground.

Hedge Trimmer Safety Manual
English
12
Maintenance and Care
The following intervals apply to normal operating conditions only. If your daily work-
ing time is longer or operating conditions are difficult (very dusty work area, etc.),
shorten the specified intervals accordingly.
before starting work after finishing work or daily after each refueling stop weekly monthly every 12 months if problem if damaged if required
Complete machine
Visual inspection (condition, leaks) XX
Clean X
Control handle Check operation XX
Air filter (felt)
Clean XX
Replace X
Air filter (paper)
Clean XX
Replace XX
Pickup body in fuel tank
Have checked by dealer1) X
Have replaced by dealer1) XXX
Fuel tank Clean XX
Carburetor
Check idle adjustment XX
Readjust idle X
Spark plug
Readjust electrode gap X
Replace after every 100 operating hours
Cooling inlets
Visual inspection X
Clean X
Spark arresting screen2) in muffler
Check after every 20 hours of operation
Have checked by dealer1) X
Have cleaned or replaced by servicing
dealer1) X
All accessible screws and nuts (not adjust-
ing screws) Retighten X
Antivibration elements
Visual inspection X
Have replaced by dealer1) XX

Hedge Trimmer Safety Manual
English
13
Cutting blades
Clean X
Sharpen X
Visual inspection X
Have replaced by dealer1) X
Adjust blade clearance3) X
Gearbox lubrication Check and replenish after every 25
hours of operation
Safety labels Replace X
1) STIHL recommends a STIHL servicing dealer.
2) not in all versions, market-specific
3) not in all versions, market-specific or available as special accessory
The following intervals apply to normal operating conditions only. If your daily work-
ing time is longer or operating conditions are difficult (very dusty work area, etc.),
shorten the specified intervals accordingly.
before starting work after finishing work or daily after each refueling stop weekly monthly every 12 months if problem if damaged if required

Hedge Trimmer Safety Manual
English
14
Main Parts
5
13
8
9
3
10
7
20
17
2
442BA016 KN
1
4
6
#
11
12 14
16
15
18 19

Hedge Trimmer Safety Manual
English
15
1Starter Grip
2Rear Handle
3Throttle Trigger Lockout
4Throttle Trigger
5Blocking Lever
6Filter Box Cover
7Fuel Pump
8Spark Plug Boot
9Front Handle
10 Carburetor Adjusting Screws
11 Starting Throttle Lock
12 Stop Switch
13 Fuel Filler Cap
14 Fuel Tank
15 Muffler
16 Fan Housing
17 Choke Lever
18 Blade Scabbard
19 Cutting Blade Guard
20 Cutting Blades
#Serial Number
Definitions
1. Starter Grip
The grip of the pull starter, for
starting the engine.
2. Rear Handle
The support handle for the hand,
located at or toward the rear of the
hedge trimmer.
3. Throttle Trigger Lockout
Must be depressed before the
throttle trigger can be activated.
4. Throttle Trigger
Controls the speed of the engine.
5. Blocking Lever
Lever for rotating the rear handle.
6. Filter Box Cover
Covers the air filter.
7. Fuel Pump
Provides additional fuel feed for a
cold start.
8. Spark Plug Boot
Connects the spark plug with the
ignition lead.
9. Front Handle
Handle bar for the hand at front of
hedge trimmer.
10. Carburetor Adjusting Screws
For tuning the carburetor.
11. Starting Throttle Lock
Keeps the throttle partially open
during starting.
12. Stop Switch
Switches the engine’s ignition off
and stops the engine.
13. Fuel Filler Cap
For closing the fuel tank.
14. Fuel Tank
For fuel and oil mixture.
15. Muffler
Reduces engine exhaust noises
and diverts exhaust gases away
from operator.
16. Fan Housing
Polymer housing which encloses
the power unit.
17. Choke Lever
Eases engine starting by enriching
mixture.
18. Blade Scabbard
Covers cutter blades when hedge
trimmer is not in use.
19. Cutting Blade Guard
Helps to reduce the risk of operator
contact by the cutter blade.
20. Cutting Blades
Steel blades for cutting hedges and
shrubs.

Hedge Trimmer Safety Manual
English
16

www.stihl.com *04571893021*
0457-189-3021
0457-189-3021
englisch
G
!WARNING!
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
!WARNING!
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
englisch USA
U
