Stompa Uno S Highsleeper T1082-02 User manual

White - 4ft6 Bed with Slats
Dimensions
Width - 148cm
Depth - 204cm
Height -109cm
Issue 1 - 22/10/10
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0844 8008475
Assembly Instructions - Please keep for future reference 6564942
- Uno S Highsleeper desk
T1082-02
100 cm
94 cm
T1082-02 VL36-V6/V8 Issue 1 - 08/12/14
Desk can be fitted
right or left side
1 of 8
Batch nr:

· Warning! Children can become trapped
between the bed and the wall.
To avoid risk of serious injury the
distance between the top safety barrel
and the wall shall not exceed 75 mm or
shall be more than 230mm.
2 of 8
Glue safety - Take care when using glue, please follow the advice below
Skin contact: Remove
contamination by washing with
soap and water. This procedure
should also be followed prior to
eating and drinking.
Eye contact: Rinse immediately
with clean water for 15 minutes
and seek medical advice.
If swallowed: Seek medical
advice immediately.
Care and maintenance
• Do not use the bed if any structural
part is broken or missing.
• Periodically tighten all screws and
load-bearing connecting parts to ensure
permanent stability.
• Mattress: This bed is designed to use
a mattress size 200cm long and 90 cm
wide.
•Warning: Do not place this child`s bed
near heat sources, windows and other
furniture.
Warning: This product is suitable for
children above the age of 4 years old
Before Starting Assembly
• Only clean using a damp cloth
and mind detergent, do not use
bleach or abrasive cleaners.
• Regularly check that there are
no loose screws on this unit and
retighten when necessary.
Parts of your product are produced
from solid pine which is a natural
product containing a beautiful
wooden structure.
Direct sunlight can speed up the
natural process of the resin
contained in the pine knots to
change colour around knots.
This is a normal process happening
to natural wood and cannot be seen
as a manufacturers fault. All wood
has been dryed to Industry
standards for furniture timber and all
procedures for obtaining the best
lacquring finish have been followed.
Our furniture will endure most
temperatures in the home but it is best
to avoid placing furniture next to heat
sources as radiators or fire. Be
particularly careful with solid wood as
the lack of humidity caused by central
heating can cause damage such as
warping.

Components - Fittings
Please check you have all the fittings listed below
Note:The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
A
Tools reqiured
1cm 2 345678910 11 12 13 14 15 16
1 inch 23456
Rulers - Use this ruler to help correctly identify the screws
Philips screwdriver (medium)
Flathead screwdriver (medium)
Allen key (incl)
Small hammer
Dowel Ø8x40 x34 Conformat screw Ø7x 60mm x20 Screw 3.5 x 35mm x60
Barrel nut Ø10 x 14mm x24 Allen key 4mm x1 Cover cap Ø15/Ø18 x12
Cover cap Ø8/Ø13 x16
E F
H K L
N P
Spacer 20x72x3mm x2
3
Rubber hammer
Q
Connecting bolt M6 x 50mm x5
Connecting bolt M6 x 75mm x19
R
Metal dowel x16
S
Locking nut x32
T
Cover cap Ø4/Ø17 x12
U
Cover cap Ø10/Ø13 x6
V
Cover cap Ø12/Ø3 x20
Y
Rubber hammer
Rubber hammer
DD15x18 Cover Cap x 1
B
6,3x70 Screw x 1
C5x38 (Zn) Screw x 4
8x40 Wooden dowel x 2
A
3 of 8

&RPSRQHQWV/@MDKR
3OHDVH FKHFN \RX KDYH DOO WKH SDQHOV OLVWHG EHORZ

 



 


  

  
   

Components
2 Desk support x 1 (39,7x11,5x1,5 cm)
1 Desk top x 1 (100x94x1,6 cm)
4 of 8

1
8x40 Wooden dowel x 2
2
A
A
A2
DD15x18 Cover Cap x 1 J
B6,3x70 Screw x 1
2BD
5 of 8

3
C
CC
C
1
C5x38 (Zn) Screw x 4
6 of 8

Customer Notice
Dear Customer,
Congratulations on the recent purchase of your furniture!
Customer Service:
For missing or spare parts requests please contact us Monday to Friday – 10am to 3pm in
one of the following ways:
Phone: [phone]
Email: [email protected]
Please inform: product, colour, where did you buy it, part no, quantity and
reason for request. We need your full name, address and telephone number.
Fax: Please complete the enclosed Service Form and fax to 0560 1132071
By post: Please complete the enclosed Service From and post to:
Nordika Design Ltd.
High Rigg
Panorama Drive
Ilkley, LS29 9RA
We will do our utmost to supply spare parts within 7-10 working days of receipt of
request.
Our quality control team has ensured a high quality product that we are sure you will be
pleased with. All our furniture is produced from solid wood which contains knots and
may have surface defects which are a feature of a natural product.
Page 8 of 9
[email protected]
t/a Stompa
7 of 8

Page 9 of 9 8 of 8
