Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[e-mail], 888-680-7460, 877-831-0319
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Tool(s) required for assembly: LevelPhillips screwdriver,
D.
Side Panel
2 Pcs.
L.
Side Panel
1 Pc.
E.
Side Panel
1 Pc.
M.
Side Panel
1 Pc.
N.
Side Panel
1 Pc.
F.
Back Panel
1 Pc.
O.
Back Panel
1 Pc.
I.
Door
1 Pc.
P.
Door
1 Pc.
J.
Door
1 Pc.
Q.
Door
1 Pc.
C.
Side Panel
1 Pc.
K.
Side Panel
1 Pc.
Carton 20 05525 0681 is also needed for assembly.
20 05525 0682
Corner Cabinet

Assembly Instructions 2/7
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
STEP 1
Insert Cam Lock Screws into pre-drilled holes in Top (A),
Side Panels (C), (E), (K), (M), Fixed Shelf (B) and Base (G), then tighten.
(See Figure 1)
Attach Magnets to Top (A) and Fixed Shelf (B) with Wood Screws into pre-drilled holes.
(See Figure 2)
Cam Lock Screw
Wood Screw
Magnet
Figure 1 Figure 2
G
A
C
E
K
M

Cam Lock
Assembly Instructions 3/7
STEP 3
Attach Side Unit (C, D) and
Side Unit (E, D) from Step 2
to Base (G) with Cam Locks.
Attach Back Panel (F) to unit
with Cam Locks.
EC
F
DD
G
Cam Lock
STEP 2
Attach Side Panel (C) to Side Panel (D)
with Cam Locks. (See Figure 3)
Attach Side Panel (E) to Side Panel (D)
with Cam Locks.
Figure 3
D
D
C
E

Assembly Instructions 4/7
STEP 5
Insert Cam Locks and Cam Lock Screws
into pre-drilled holes in unit, then tighten.
Cam Lock
Cam Lock
Cam Lock Screw
STEP 4
Insert Adjustable Pins into side panels
at desired level. (See Figure 4)
Place Shelves (H) into position.
Attach Doors (I) and (J) to unit
by sliding door hinges
into side panel hinges.
(See Figure 5)
Attach Knobs to Doors (I)
and (J) with Machine Screws.
(See Figure 6)
Attach Fixed Shelf (B) to unit
with Cam Locks.
Machine Screw
Knob
Adjustable Pin
Figure 5Figure 4 Figure 6
B
IJ
H
H

Assembly Instructions 5/7
STEP 6
Attach Side Panel (K) to Side Panel (L)
with Cam Locks.
Attach Side Panel (M) to Side Panel (N)
with Cam Locks.
Cam Lock
Cam Lock
STEP 7
Attach Side Unit (K, L) and Side Unit (M, N)
from Step 6 to unit from Step 5 with Cam Locks.
Attach Back Panel (O) to unit
with Cam Locks.
MK
NL
O
L
N
M
K

Cam Lock
Cam Lock
Machine Screw
Assembly Instructions 6/7
Knob
Adjustable Pin
Figure 7
STEP 8
Insert Adjustable Pins into side panels
at desired level.
Place Shelves (H) into position.
Attach Doors (P) and (Q) to
unit by sliding door hinges
into side panel hinges.
Attach Knobs to Doors (P) and (Q)
with Machine Screws.
Attach Top (A) to unit
with Cam Locks.
STEP 9
Insert Cam Locks into pre-drilled holes
of unit, then tighten.
Level unit by adjusting the adjustable
levelers on bottom of unit.
(See Figure 7)
Note: Unit must be level to work properly.
A
H
PQ
H

Assembly Instructions 7/7
STEP 10
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
the pre-drilled hole at top of unit.
Move unit.
Insert Anchor into the wall holes
and attach Brackets with Wall Screws.
Attach Brackets at pre-drilled holes
at top of unit with Wood Screws.
Move unit back into place.
Slide Tipover Restraints through
Brackets on wall and Brackets on unit.
(See Figure 8)
Put tie end of Tipover Restraints into lock
end of Tipover Restraints and pull until tight.
Anchor
2 pcs. (+1 extra)
Bracket
4 pcs. (+1 extra)
Tipover Restraint
2 pcs. (+1 extra)
M3.5x40
Wall Screw
2 pcs. (+1 extra)
M3.5x16
Wood Screw
2 pcs. (+1 extra)
Drill 3/8” hole in wall
Top of unit
IMPORTANT
To help reduce the risk of the unit tipping over, the Tipover Restraint must be installed following these instructions exactly.
Bracket
on wall
Anchor in wall
3/8” wall hole
Tie end
Lock end
Bracket at
top of unit
Tipover
Restraint
Figure 8
Wood Screw
Wall Screw Pre-drilled hole
at top of unit
Hardware List

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
