Stone Mountain Elite Series 1, 2 & 3 PTT Speaker Microphone User Manual
Connecting the Speaker Microphone (SM):
1. Charge the unit for a full cycle (at least 6 hrs.) prior to use.
2. Ensure the SM 3.5mm male connector is clean and free of contaminants.
3. Fully insert and seat the 3.5mm male SM connector into the mating
remote audio accessory port on the Smartphone, Tablet, etc. device.
Operating the Speaker Microphone
Transmitting Audio (Tx)
To transmit audio, depress the PTT button and speak into the
microphone opening near the top left side of the SM. Hold the SM about
6 to 8” from your mouth when speaking to avoid distortion. Release the PTT
button when finished transmitting. Note, if you have a black button on the top
of the SM this will act as a PTT button also.
Receiving Audio (Rx)
Incoming audio will automatically be received via the SM speaker.
Note: Some smartphones and tablets (device) automatically decrease volume by 50% for safety reasons when an
accessory is attached. The User can manually adjust the control volume on the Device for desired volume level.
Receive Audio Volume Control
Receive audio volume is adjusted using the button directly below the PTT. Pressing the button toggles between Hi and Lo
volume. Note the button does not change position between Hi and Lo. The change in volume is about ~12 dB between Hi and
Lo.
Optional Emergency/Man Down Alert
If your PTT app & Device supports it, you may declare an emergency/man down condition by depressing the red button on the
top of the SM. Check with your Service Provider, PTT app Provider and/or Device Provider to ensure this feature is supported.
Optional CallCheckTM (CC) Receive Audio Record, Store and Playback System
Communicate with optimum efficiency and confidence using the patented CallCheckTM feature. Note, CallCheckTM configured
units will have a blue colored top button.
Note: When using the CallCheck™feature, it is important that the Smartphone/Tablet be set to ½ volume minimum for
full CallCheck™functionality.
To record:
Quickly double-click the CC button. Note, an Rx transmissions must have occurred prior to recording.
Each new Rx transmission is stored in cache memory. As such, you can record anytime during or after the last Rx
transmission and up to the next Rx transmission (double clicking the CC button will record the last Rx transmission). In
either scenario, the entire Rx transmission will be recorded and stored.
You will hear a high pitched "beep" after a successful record.
You will hear a lower pitched "boop" after an unsuccessful record. An example of an unsuccessful recording attempt
would be if you double-clicked (record) without receiving a new Rx transmission since the last stored transmission.
Record time limit is about 2.5 minutes (2’30”).
The message will be stored until:
oA new message is recorded and stored, which will record over the last message.
oThe SM battery loses power, i.e. needs to be recharged. In this case, the message will be deleted.
To playback:
Single-click the CC button.
You can stop playback with a single-click.
If you single-click again after stopping playback, playback will restart at the beginning of the message.
If you are in playback and a Rx transmission is received, the playback function will terminate and the Rx transmission
will come through the speaker. Playback can be resumed after the Rx transmission ends by a single click to the CC
button.
Volume control
PTT
Red Emergency button, Blue
CallCheck™button or Black
auxiliary PTT button
Note: Some buttons may be absent or
not active depending upon the SM
option configuration ordered.
Audio accessory
interface

Stone Mountain, Ltd.
1597 Eagle Point Road
Huddleston, VA 24104
Customer Support: 540.297.6434 x200
888.244.9306
www.stonemountainltd.com
Effective 07Oct19
Innovation… Quality… Passion
Audio Accessory Interface
3.5mm SureSeal™accessory jack: This interface supports remote receive audio accessories, e.g. surveillance kits, external
speaker, etc. The speaker in the SM is disabled when a receive audio accessory is connected to the audio accessory jack.
Keep the rubber connector cover inserted when an audio accessory is not attached. Note that only Stone Mountain Elite
Series accessories are guaranteed to function correctly with Stone Mountain products. Consult your Stone Mountain Product
Guide for a complete list of available accessories or contact Customer Support at 540.297.6434 with any inquiries.
Charging
1. There is a low battery audible beep that occurs every thirty (30) minutes when the battery gets to 15% capacity. At this
point, the unit should be recharged as soon as possible. Note, depending upon amount of usage, the SM will continue
to function for approximately one full normal business day when the first low battery beep occurs.
2. To recharge the unit, simply disengage the protective rubber plug from the charging port on the SM cable. Next, plug
the 5.5mm connector that is attached to either the wall or vehicular charging unit into the mating connector on the cable.
Full charge takes between 5 to 6 hours assuming a completely discharged battery.
3. Reengage the protective rubber plug after charging is complete.
General Care & Maintenance
Do not use solvents, abrasives or other cleaning solutions to clean your Speaker Microphone (SM).
Clean with mild soap and tap water.
Do not insert objects into the speaker chamber or the microphone port, as this will adversely impact the audio quality
and may result in subsequent water leakage.
Intrinsically Safe Models
Your Stone Mountain, Ltd. Intrinsically Safe speaker mic will have a plastic label affixed by a brass gromet to the cable near the
connector. If there is no label, do not use the speaker mic as an IS rated speaker mic. Your Phoenix Elite speaker mic is
rated Class 1, Division 2, Groups A, B, C, D T4 -30°C ≤ Ta ≤+60°C.
Keep 5.5mm charging and 3.5mm accessory port covers in place while unit is in use in hazardous areas.
4 pole, 3.5 mm interface plug must be a secured connection to the host port. The FasN™strap is an approved option
for a secured connection to the host port
To review the Stone Mountain, Ltd. Conditions of Sale and Warranty Statement, go to:
http://stonemountainltd.com/conditions-sale-warranty-statement/
Innovation... Quality... Passion
Designed, Assembled, Tested and Supported with Pride in the USA, at Stone Mountain we strive to provide our customers with
innovative products of the highest quality, reliability and value. We welcome and appreciate your input - Feel free to contact us.
