Company Quickguide
SE5000 Digital Tachograph
Insert the card (always possible in standard menu and ignion ON)
1. Press and hold the driver or co-driver buon unl tray opens.
2. Insert the card with the chip facing upward.
3. Close the tray by pushing it gently forward.
Withdraw the card (not possible in all menus)
1. Press and hold the driver or co-driver buon unl tray opens.
2. Press the card up slightly from underneath through the opening in the tray
or push the edge of the tray down unl the card pops out.
Driver
buon
Co-driver
card tray
Paper
cassee
Driver
card tray
Co-driver
buon
ECancel, move back to previous display
TR Select, highlight, change values
yConrm, move forward in displays
Default Acvity key on/o
This seng gives the opportunity to preset an automac acvity change for
both driver and co-driver when switching the ignion key on or o (consult
relevant authority for naonal regulaons).
1. Press the conrm buon.
Select and conrm Sengs.
2. Select and conrm Parameters.
3. Select and conrm Default acv.key on or
Default acv.key o.
4. Select and conrm the preferred acvity; No
change, Rest, Available or Work.
5. The following is displayed.
6. Press the cancel buon three mes to re-
turn to the standard display.
Daylight Saving Time
An automac local me adjustment for summer and winter is automacally
prompted on the last Sunday in March and last Sunday in October, respecvely.
1. Select YES to acknowledge or NO to cancel
the me change. 03:01
Default activ.
key on
Default activ.
key off
Changes
saved
New time?
Parameters
SETTINGS
YES
SE5000 Rev.7.5, 102024P/01R04 EN For full details on the SE5000 funconality we refer to the
Driver & Company Manual or visit www.stoneridgeelectronics.com
Stoneridge - every angle covered
Note! Card handling and browse in menu is only possible when vehicle is not moving.

123
Vehicle Unit Download
1. Remove the printer cassee.
2. Aach the download equipment to the
tachograph through the 6-pin download
connector.
3. Download the data according to the instruc-
on on the downloading equipment. Ensure
that the ignion is ON when starng the
download.
4. The following message will be displayed
indicang that the tachograph downloading
is acve.
5. When the downloading is completed, the
following message will be displayed.
6. If the downloading process fails, the follow-
ing message will be displayed. Check the
connecons and downloading equipment.
For further informaon, see the Driver &
Company Manual (Company Mode).
Company lock-in
In order to prevent unauthorized persons from accessing the tachograph data, a
lock-in should be performed before start using the tachograph.
1. Insert a company card in either of the
tachograph trays. The tachograph asks if a
Company Lock shall be acvated if there is
none for this company.
2. Press the conrm buon to enter the tacho-
graph menu.
Select and conrm COMP LOCKS.
3. Conrm with YES to perform the lock-in.
4. Aer conrmaon the following message
will be displayed.
YES
Company
lock-in
Lock-in
complete
Downloading
busy
Download
complete
Download
failed
Company lock-out
A lock-out (unlock) must be performed before transferring the tachograph to
another company/owner. Otherwise, there is a risk geng the next users data
recorded on current company. If the lock-out is forgoen the data will not be
locked-out unl the next company performs a lock-in. To secure your data, you
should download your data before performing a lock-out.
1. Insert a company card in either of the tacho-
graph trays. The tachograph automacally
enters the company mode of operaon.
2. Press the conrm buon to enter the tacho-
graph menu.
Select and conrm COMP LOCKS.
3. Conrm with YES to perform the lock-out.
4. Aer conrmaon the following message
will be displayed.
YES
COMP LOCKS
Company
lock-out
Lock-out
complete
