Assembly Instructions
revised 0221 - 1.0

It is strongly recommended to have two persons present when
assembling this item. We advise that you unpack the boxes in
the order shown in these instrucons and follow the assembly
instrucons carefully.
Please be careful during construcon as secon of the cupboard
may be unstable unl construcon is complete.

Your hardware pack should contain the following:
CODE DESCRIPTION QTY PICTURE
CB1 Connnectin
g Bolt 32
CL1 Connecting
Lock 32
CB2
Mini
Connecting
Bolt
4
SP3Shelf Peg
(lock) 56
HANDLE2 Bow Handle 2
S30 Handle
Screw 4
H3 Desk Hinge2
AB1Angle
Bracket 4
35-15S Screw 16
Size 3.5 - 15mm long
C2 Castor
Black 4
C3
Castor
Black with
Brake
2
35-17S
Caster &
Angle
Bracket
Screw
40
Size 3.5 - 17mm long
C4 Leg Caster 2
AXI-HINGE-M Axi Hinge
Male Part 4
SPLATE1 Striking
Plate 1
30-15S Screw 2
Size 3 - 15mm long
KEY Desk Key 2

STEP 1
You will need to open box -
screw in to
this point
CB1
Screw CB1 Bolts into all
the holes marked with
a red circle
Insert CL1 Locks into
the holes as indicated
with a blue circle
Screw CB1
Bolts into
all the holes
marked with
a green circle
SA-WOOL-1ST
Attach hinges
AXI-HINGE-M
using pre tted
screws and
35-15S as
shown
Attach angle brackets as shown using
screws 35-17S
SA-WOOL-LHS SA-WOOL-RHS

Insert CL1 Locks into
the holes as indicated
with a blue circle
SA-WOOL-BASE
STEP 2
You will need to open box -
SA-WOOL-DSKBB
Front Edge
Attach castors C2
with screws 35-17S as shown
to holes marked with red circles
Attach castors with brakes C3
with screws 35-17S as shown
to holes marked with green circles
SA-WOOL-MB2

STEP 3
You will need to open box -
SA-WOOL-CD&SH
SA-WOOL-MB1
X 2
Insert CL1 Locks into
the holes as indicated
with a blue circle

STEP 4
Attach the Base to the left hand side by slotting the panel onto the connecting bolts and
tightening the connecting locks in the base. Then secure the base to the sides using the
angle brackets you have already attached to the sides (using screws 35-17S).
Then x the two MB1 backs and the MB2 backs to the left hand side as shown below. You
can choose to have the connecting locks showing on the inside of the unit or the outside by
rotating the panels.
SA-WOOL-MB1
SA-WOOL-MB1
SA-WOOL-MB2
SA-WOOL-LHS
SA-WOOL-BASE

STEP 5
Attach the SA-WOOL-RHS to the section you have already constructed, tighten all of the
connecting locks and secure the base to the right hand side with the angle brackets as in
step 4.

STEP 6
Attach the SA-WOOL-BCD to the base of the section you have already constructed. Screw
CB1 connecting bolts into the two holes in the base and then secure with CL1 connecting
locks in the SA-WOOL-BCD.
It is important to ensure you have the SA-WOOL-BCD panel the correct way up. You will see a
label which states TOP on this panel and this should be at the top when tted.

Attach the SA-WOOL-DSH to the section you have already constructed. Screw CB1 connect-
ing bolts into the two holes in underside of the SA-WOOL-DSH panel (this is the side with
pretted mini connecting locks) and then secure with CL1 connecting locks in the
SA-WOOL-BCD. Also secure the mini connecting locks (which are pretted into the DSH
panel) to the left and right hand sides by turning the mini connecting locks.
STEP 7
You will need to open box -
SA-WOOL-DSH

STEP 8
Attach the SA-WOOL-TCD to the the section you have already constructed as shown below.
Screw CB1 connecting bolts into the two holes in DSH panel and then secure with CL1
connecting locks in the SA-WOOL-TCD.
It is important to ensure you have the SA-WOOL-TCD panel the correct way up. You will see a
label which states TOP on this panel and this should be at the top when tted.

STEP 9
Attach the striking plate to the SA-WOOL-TOP using screws 30-15S.
The striking plate should be tted with as per the image below.
Attach the SA-WOOL-TOP to the the section you have already constructed as shown below.
Screw CB1 connecting bolts into the six holes in TOP panel and then secure with CL1
connecting locks in the SA-WOOL-TCD and the left and right hand sides.
SA-WOOL-TOP
Striking Plate

Below you will see the placement for all for all of the shelves.
To t the shelves insert shelf pegs SP3 into the holes for each shelf. Ensure that the at
surface of the peg is facing up. Once the shelf has been placed onto the pegs tap the centre
of the shelf with your hand to lock the shelf onto the grips on the peg. This will stop the shelf
sliding when taking storage containers out of the unit.
STEP 10
You will need to open box -
SA-WOOL-DOORS
Insert this way up
SHTL2
SHTL1
SHTR
SHBL SHBR
Place all shelves
onto shelf pegs
and tap down
onto centre of
shelves
with your hand
to lock onto
pegs to prevent
shelf sliding

STEP 11
Take your two doors and insert caster C4 into the pretted bracket on the bottom
of each door. Fit the two handles using the screws provided.
Then t your doors by inserting the metal bracket which you have already xed to each side
into the receiving part which is pre tted to the door and then tighten the locking screw.
You may nd it easier to do this if you loosen the locking screw a little before insert the
hinge bracket. At this point ensure the wheel as at the botttom of the door and the handle
at the top.

STEP 12
Position you doors so that they are open no more than 90 degrees so that they will support
you desk panel.
Attach hinges H3 using screws 35-15S to the desk shelf (DSH). Then place
the desk on top of the doors and attach the hinges to the desk panel.
We send the desk with lock in the locked position. Before closing the desk insert the key in
the lock and turn to unlock. To close the desk fold up, press against striking plate and turn
the key to lock -
VERY IMPORTANT - ENSURE THE DESK IS SECURE BEFORE LETTING GO OF IT TO AVOID
THE RISK OF INJURY OR DAMAGE TO YOUR UNIT
Please note you can only remove the key from
the lock when the desk is closed and the lock is engaged

5.5L
BOX
10L
BOX
5.8L
BOX
9L
BOX
The Storeaway Woolacombe unit is designed and manufactured in the UK by:
CRAFTS
storage
www.storage4crafts.co.uk
STEP 13
.Place your storage containers into you unit as shown below.
IMPORTANT SAFETY INFORMATION
When the desk is in use always ensure it is fully supported on the doors - they must
be open no more than 90 degrees.
When the desk is closed always ensure the lock is fully engaged
FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN DAMAGE TO YOUR UNIT
AND /OR INJURY
