Storm Surge SS14CW User manual

Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5
Operator’s Manual
Water Pump
SS14CW
P/N: 22541
ECN: 10829
REV 1: 05/01/15
© 2015 Ardisam, Inc.
All Rights Reserved
SN
GAS/OIL
RATIO
50:1
Product Number:
20198

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5
2
INTRODUCTION
Congratulations on your investment in quality. Thank you for purchasing a water pump from Storm Surge™. We have worked to
ensure that your pump meets the highest standards for usability and durability. With proper care, your pump will provide many
years of service.
Please read this entire manual before installation and use. Storm Surge™ reserves the right to change, alter or improve the
product and this document at any time without prior notice.
CONTENTS
Introduction ................................................................................................................................................................................................................................... 2
Pump Specications....................................................................................................................................................................................................................3
Warnings and Safety Precautions....................................................................................................................................................................................... 4-7
Component Identication.........................................................................................................................................................................................................8
Installation ......................................................................................................................................................................................................................................9
Pump Placement ........................................................................................................................................................................................................................10
Operation............................................................................................................................................................................................................................... 11-12
Maintenance and Storage................................................................................................................................................................................................ 13-15
Troubleshooting and Repair............................................................................................................................................................................................ 15-17
Parts Breakdown.................................................................................................................................................................................................................. 18-21
Warranty ........................................................................................................................................................................................................................................22
Maintenance Schedule.............................................................................................................................................................................................................23
Federal Emission Control Warranty Statement......................................................................................................................................................... 24-25
This manual may contain information for several models. Read and keep this manual for future reference. This manual contains important
information on SAFETY, ASSEMBLY, OPERATION, AND MAINTENANCE. The owner must be certain that all the product information is included with
the unit. This information includes the MANUAL, the REPLACEMENT PARTS and the WARRANTIES. This information must be included to make sure
state laws and other laws are followed. This manual should remain with the product even if it is resold.
OWNERSHIP RECORDS
Owner’s Name:
Owner’s Address:
City: State/Province: Zip Code/Postal Code:
Model Number: Serial Number:
Date of Purchase:
Notes:
Record the model number and serial number in the space
provided for easy reference (For serial number location SEE
FIGURE 1). Warranty is valid only if the completed registration
is received by Storm Surge™ within 30 days of purchase.
You can register your warranty online by visiting www.
stormsurgepumps.com. If you do not have a computer, call
our customer service department at [phone] Monday
through Friday from 8 a.m. to 5 p.m. CST.
Federal Emission Information
Viper® warrants to the retail purchaser, that this small, o-
road engine was designed, built and equipped to conform at
the time of initial sale to all applicable regulations of the U.S.
Environmental Protection Agency (EPA) and those of the State
of California (CARB).
FIGURE 1
SERIAL NUMBER
DECAL

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 3
0 500 1,000
Discharge Capacity (gal/hr)
Total Lift/Head (ft)
1,500 2,000
15
30
45
60
75
90
SS14CW
PERFORMANCE DATA
PUMP SPECIFICATIONS
Engine Viper® 40cc 4-cycle
Ignition Type Electronic Ignition
Cooling System Forced Air Cooling
Spark Plug Type / Gap (mm) NGK CMR6A / 0.6
Recommended Fuel Type Minimum 87 octane with NO ethanol content
NOTE: If using an ethanol blended fuel, a fuel stabilizer, mixed
to manufacturer specications, is recommended
Oil Type Viper® 10W-30 4-cycle oil (P/N 13235)
Fuel Capacity (gal) 0.21
Oil Capacity (-oz) 3.72
Inlet/Outlet 1” NPSH
Run Time (hrs) 1.2
Suction Lift (ft) 16
Total Head (ft) 65
Flow Rate (gpm/gph) 26.4/1585
Max Solid Size (in) 0.5
Overall Dimensions (in) 12 x 11 x 13.5
Weight (lb) 17.5
All weights, specications and features are approximate and are subject to change without notice.
SPECIFICATIONS

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5
4
WARNINGS AND SAFETY PRECAUTIONS
Operator’s Responsibility
Accurate assembly and safe and eective use of the machine is
the operator’s responsibility.
• Read and follow all safety instructions.
• Carefully follow all assembly instructions.
• Maintain the machine according to directions and
schedule included in this Storm Surge™ operator’s
manual1.
• Ensure that anyone who uses the machine is familiar
with all controls and safety precautions.
Special Messages
Your manual contains special messages to bring attention to
potential safety concerns, machine damage as well as helpful
operating and servicing information. Please read all the
information carefully to avoid injury and machine damage.
NOTE: General information is given throughout the
manual that may help the operator in the
operation or service of the machine.
This symbol points out important safety
instructions which if not followed could
endanger your personal safety.
Before Operating Engine:
NOTE: Please read this section carefully: Read entire
operating and maintenance instructions for this
product and the engine which accompanies it.
Failure to follow instructions could result in serious
injury or death. Operate the machine according
to the safety instructions outlined here and
inserted throughout the text. Anyone who uses this
machine must read the instructions and be familiar
with the controls.
WARNING
WARNING INDICATES A HAZARD WHICH, IF NOT
AVOIDED, COULD RESULT IN DEATH OR SERIOUS
INJURY AND/OR PROPERTY DAMAGE.
CAUTION
CAUTION INDICATES YOU CAN BE HURT OR
YOUR EQUIPMENT DAMAGED IF THE SAFETY
INSTRUCTIONS THAT FOLLOW THIS SIGNAL
WORD ARE NOT OBEYED.
WARNING
CALIFORNIA PROPOSITION 65 WARNING
ENGINE EXHAUST FROM THIS PRODUCT
CONTAINS CHEMICALS KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS,
OR OTHER REPRODUCTIVE HARM.
IMPORTANT
IMPORTANT INDICATES HELPFUL INFORMATION
FOR PROPER ASSEMBLY, OPERATION, OR
MAINTENANCE OF YOUR EQUIPMENT.
WARNING
YOU MUST READ, UNDERSTAND AND COMPLY
WITHALLSAFETYANDOPERATINGINSTRUCTIONS
IN THIS MANUAL BEFORE ATTEMPTING TO SETUP
AND OPERATE YOUR MACHINE.
FAILURE TO COMPLY WITH ALL SAFETY AND
OPERATING INSTRUCTIONS CAN RESULT IN LOSS
OF MACHINE CONTROL, SERIOUS PERSONAL
INJURY TO YOU AND/OR BYSTANDERS, AND RISK
OF EQUIPMENT AND PROPERTY DAMAGE. THE
TRIANGLE IN THE TEXT SIGNIFIES IMPORTANT
CAUTIONS OR WARNINGS WHICH MUST BE
FOLLOWED.
WARNING
DONOTUSETO PUMP FLAMMABLE OR EXPLOSIVE
FLUIDS SUCH AS GASOLINE,FUEL OIL, KEROSENE,
ETC. DO NOT USE IN FLAMMABLE AND/OR
EXPLOSIVE ATMOSPHERES. PUMP SHOULD ONLY
BE USED TO PUMP WATER. FAILURE TO FOLLOW
THISWARNING CAN RESULT IN PERSONAL INJURY
AND/OR PROPERTY DAMAGE.
1If the maintenance schedule and specications contained in this
document do not match the Federal Emission Control Warranty
Statement, the Federal Emission Control Warranty Statement
supersedes the information in this document.

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 5
GENERAL SAFETY RULES
Read, understand, and follow all instructions on the machine
and in the manual(s). Be thoroughly familiar with the controls
and the proper use of the machine before starting.
Use this equipment for its intended purpose only.
Familiarize yourself with all of the safety and operating
decals on this equipment and on any of its attachments or
accessories.
Only allow responsible individuals who are familiar with the
instructions to operate the machine. Do not allow children
to operate this machine. Do not allow adults to operate the
machine without proper instruction.
Wear appropriate clothing such as a long-sleeved shirt or
jacket. Also wear long trousers or slacks. Do not wear shorts.
Never wear sandals, sneakers, or open shoes, and never
operate the machine with bare feet.
Do not wear loose clothing or jewelry. They can get caught in
moving parts. Always keep hands, feet, hair and loose clothing
away from any moving parts on engine and machine.
Always wear safety goggles or safety glasses with side shields
when operating the machine to protect your eyes from foreign
objects which can be thrown from the unit. Always wear a
protective hearing device.
Always wear work gloves and sturdy footwear. Wear footwear
that will improve footing on slippery surfaces. Leather work
shoes or short boots work well for most people.
Use the correct personal protection at all times. Do not
operate the machine without proper guards or other safety
protective devices in place.
See manufacturer’s instructions for proper operation and
installation of accessories. Only use accessories approved by
the manufacturer.
Operate only in daylight or good articial light.
Do not operate product when fatigued or under the inuence
of alcohol, drugs or other medication which can cause
drowsiness or aect your ability to operate this machine safely.
Watch for trac whenever you are operating near, or when
crossing roads.
If the equipment should start to vibrate abnormally, stop the
engine (motor), disconnect the spark plug wire and prevent
it from touching the spark plug. Check immediately for cause.
Vibration is generally a warning of trouble. If the noise or
vibrations of the machine increase, stop immediately and
perform an inspection.
Regularly inspect the machine. Make sure parts are not bent,
damaged or loose. Keep all screws, nuts and bolts tight.
Temperature of muer and nearby areas may exceed 150°
F (65° C). Allow muer and engine areas to cool before
touching.
Prolonged exposure to noise and vibration from gasoline
engine-powered equipment should be avoided. Take
intermittent breaks and/or wear ear protection from engine
noise as well as heavy work gloves to reduce vibration in the
hands.
Do not pick up, carry, or transport the machine from one place
to another with the engine running.
Check local regulations for age restrictions on use of this
machine.
Product-Specic Safety Rules
Never attempt to operate the pump without priming the
housing.
If an object becomes lodged in the pump, turn engine o.
Allow to cool before attempting to remove the foreign object.
Do not use torches or apply excessive heat, re or ames to
this pump as an explosion can result.
Complete pump and piping system MUST be protected
against freezing temperatures. Failure to do so could cause
serious damage and voids the warranty.
Do not run pump dry. Water is required to lubricate the shaft
seal.
Pumping chemicals or corrosive liquids with this pump is NOT
ALLOWED and can be hazardous to the operator. This pump is
intended for water only.
Always use a intake strainer with this pump to lter large
material.
Pump should be located and should rest on solid foundation.
Do not suspend the pump by means of the discharge pipe.

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5
6
CAUTION
HOT GASES ARE A NORMAL BYPRODUCT OF A
FUNCTIONING INTERNAL COMBUSTION ENGINE.
FOLLOW ALL SAFETY INSTRUCTIONSTO PREVENT
BURNS AND FIRES.
DO NOT ALTER OR MODIFY ENGINE:
NEVER ALTER OR MODIFY THE ENGINE FROM
THE FACTORY. SERIOUS INJURY OR DEATH MAY
OCCUR IF ENGINE IS MODIFIED OR ALTERED.
WHEN WORKING ON OR REPLACING PARTS FOR
THE ENGINE OR PRODUCT, YOU MUST ALWAYS
DISCONNECT SPARK PLUGWIRE FROMTHE SPARK
PLUG AND KEEP IT AWAY FROM THE SPARK PLUG.
USE EXTRA CARE IN HANDLING GASOLINE AND
OTHER FUELS. THEY ARE FLAMMABLE AND
VAPORS ARE EXPLOSIVE.
ENGINE SAFETY PRECAUTIONS
If your product comes with a separate engine manual, be
sure to read and follow all safety and warning precautions
outlined there, in addition to any in this manual.
Preventing Carbon Monoxide Poisoning:
• Always start and run engine outdoors. Do not start
or run engine in an enclosed area, even if doors or
windows are open.
• Never try to ventilate engine exhaust indoors. Carbon
monoxide can reach dangerous levels very quickly.
• Never run engine outdoors where exhaust fumes may
be pulled into a building.
• Never run engine outdoors in a poorly ventilated area
where the exhaust fumes may be trapped and not
easily taken away. (Examples include: in a large hole
or areas where hills surround your working area.)
• Never run engine in an enclosed or partially enclosed
area. (Examples include: buildings that are enclosed
on one or more sides, under tents, car ports or
basements.)
• Always run the engine with the exhaust and muer
pointed in the direction away from the operator.
• Always keep the throttle in the“slow” position when not
in use.
• Never point the exhaust muer towards anyone.
People should always be many feet away from the
operation of the engine and its attachments.
• Do not change the engine governor settings or over-
speed the engine.
WARNING
ENGINES GIVE OFF CARBON MONOXIDE, AN
ODORLESS, COLORLESS, POISONOUS GAS.
CARBON MONOXIDE MAY BE PRESENT EVEN IF
YOUDONOTSMELLORSEEANYENGINEEXHAUST.
BREATHING CARBON MONOXIDE CAN CAUSE
NAUSEA, FAINTING OR DEATH, IN ADDITION TO
DROWSINESS, DIZZINESS AND CONFUSION.
IF YOU EXPERIENCE ANY OF THESE SYMPTOMS,
SEEK FRESH AIR AND MEDICAL ATTENTION
IMMEDIATELY.
Gasoline Fires and Handling Fuel Safely
• When storing extra fuel be sure that it is in an
appropriate container and away from any re hazards.
• Prevent re and explosion caused by static electric
discharge. Use only nonmetal, portable fuel
containers approved by the Underwriter’s Laboratory
(U.L.) or the American Society for Testing & Materials
(ASTM).
• Always ll fuel tank outside in a well ventilated area.
Never ll your fuel tank with fuel indoors. (Examples
include: basement, garage, barn, shed, house, porch,
etc.) Never ll tank near appliances with pilot lights,
heaters, or other ignition sources. If the fuel has to be
drained, this should be done outdoors. The drained
fuel should be stored in a container specically
designed for fuel storage or it should be disposed of
carefully.
• Never remove the fuel cap or add fuel with the engine
running. Stop engine and allow to cool before lling.
• Do not smoke while handling fuel or operating pump.
• Never drain fuel from engine in an enclosed area.
• Always wipe up excess (spilled) fuel from engine
before starting. Clean up spilled fuel immediately.
If fuel is spilled, do not start the engine but move
product and fuel container from area. Clean up spilled
fuel and allow to evaporate and dry after wiping and
before starting.
• Allow fuel fumes/vapors to escape from the area
before starting engine.

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 7
• Test the fuel cap for proper installation before starting
and using engine.
• Always run the engine with fuel cap properly installed
on the engine.
• Never siphon fuel by mouth to drain fuel tank.
• Always have an adult ll the fuel tank and never allow
children to fuel the engine.
• Never allow an adult or anyone under the inuence of
drugs or alcohol to fuel engine.
• When storing gasoline or equipment with fuel in the
tank, store away from furnaces, stoves, water heaters
or other appliances that have a pilot light or other
ignition source because they can ignite gasoline
vapors.
Burns and Fires
• The muer, muer guard, and other parts of the
engine become extremely hot during the operation
of the engine. These parts remain extremely hot after
the engine has stopped.
Prevention of Burns and Fires
• Never remove the muer guard from the engine.
• Never touch the muer guard because it is extremely
hot and will cause severe burns.
• Never touch parts of the engine that become hot after
operation.
• Always keep materials and debris away from muer
guard and other hot parts of the engine to avoid res.
Children and bystanders
Tragic accidents can occur if the operator is not alert to the
presence of children and/or bystanders. Never assume that
others will remain where you last saw them.
• Keep the area of operation clean of all persons,
especially small children and pets. Keep children
under the watchful care of a responsible adult.
• Be alert and if necessary, turn machine o if children
enter the area.
• Never allow children to operate the machine.
Service
• Always stop the engine whenever you leave the
equipment, before cleaning, repairing or inspecting
the unit. Engine should be turned o and cool, spark
plug wire must be removed from spark plug before
any repairs or adjustments are attempted. Never
make adjustments or repairs with the engine (motor)
running. Disconnect the spark plug wire and keep
the wire away from the plug to prevent accidental
starting.
• Use the correct personal protection when you make
adjustments or repairs.
• Keep all nuts and bolts tight and keep equipment in
good condition.
• Never tamper with safety devices. Check their proper
operation regularly.
• When servicing or repairing the machine, do not tip the
machine over or up unless specically instructed to do
so in this manual. Service and repair procedures can be
done with the machine in an upright position. Some
procedures will be easier if the machine is lifted on a
raised platform or working surface.
• To reduce re hazard, keep engine free of grass,
leaves, or other debris build-up. Clean up oil or fuel
spillage. Allow machine to cool before storing.
• Clean and replace safety and instruction decals as
necessary.
• To guard against engine over-heating, always have
engine debris lter mounted and clean.
• Inspect machine before storage. When not in use
store indoors in a dry place locked or otherwise
inaccessible to children.
• Use only original equipment parts from Storm
Surge™, including all nuts and bolts.

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5
8
COMPONENT IDENTIFICATION
Clear Water Pump (SEE FIGURE 2.)
MUFFLER
FRAME
OUTLET
(DISCHARGE)
PORT
PUMP
DRAIN
PLUG
INTAKE
(SUCTION)
PORT
WATER
PRIMING
FILLER
CAP
THROTTLE
LEVER
SPARK PLUG
ACCESS PANEL
RECOIL
STARTER
GRIP
CHOKE
LEVER
FUEL TANK
CAP
PRIMER BULB
LOCATION
ON/OFF
SWITCH AIR
FILTER
OIL FILL
PORT
LOCATION
FIGURE 2

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 9
INSTALLATION
Unpack Pump
1. Set aside the operators manual and parts bag. Carefully
lift the pump out of the box, remove any packing
material and cut any ties holding pieces to the pump
assembly.
Pump Set Up, Connect the Hoses
NOTE: Hose kits may not be included with your pump.
Hose kits can be purchased separately through
www.stormsurgepumps.com.
Assemble Intake Hose to Couplings as follows:
SEE FIGURE 3
1. Place hose coupler (4) on barbed hose end ange (3).
2. Place a hose clamp (5) over the end of the hose (6).
3. Slide open end of hose (6) over the barbed hose end
ange (3).
NOTE: Use dish soap to lubricate the hose end and tting.
This will assist in sliding the hose over the barbed
hose end tting.
4. Slide the hose clamp (3) in place over the barbed hose
end ange (3) and tighten.
5. Install the hose coupler gasket (2) into the female hose
coupler end (1).
6. Thread the intake (suction) hose coupler (4) onto the
pump intake port (1). Turn clockwise until securely
fastened.
7. Install the included intake stainer basket (7) on the
barbed hose end ange (3) with hose clamp (5).
NOTE: Operation of your Storm Surge™ Water Pump
without the included intake strainer basket will
void your warranty. The intake strainer has been
designed to prevent large debris from entering the
pump intake which can cause damage.
Assemble Discharge Hose Coupling as follows:
1. Follow Steps 1-6 from Assemble Intake Hose
CAUTION
DO NOT USE A COLLAPSIBLE INTAKE SUCTION
HOSE. USE ONLY NONCOLLAPSIBLE BRAIDED
REINFORCED INTAKE HOSE. HOSE CAN COLLAPSE
UNDER SUCTION FORCE.
DO NOT USE AN INTAKE HOSE WITH A DIAMETER
SMALLER THAN THE PUMP INTAKE PORT.
DO NOT OVER TIGHTEN HOSE CLAMPS. DAMAGE
TO HOSE OR RESTRICTION OF FLOW CAN OCCUR.
FIGURE 4
Change Direction of Discharge Port
NOTE: The discharge port can be repositioned 180
degrees to allow discharge to the back of the
pump.
1. Make sure engine is turned o and the spark plug wire is
removed.
2. Loosen and remove bolts (1) that attach the discharge
port (2) to the pump housing (4). SEE FIGURE 4.
3. Remove the discharge port and position in the correct
direction. Make sure the O-ring (3) is also positioned
correctly.
4. Install bolts (1) and secure. Do not over tighten bolts.
1
2
3
4
1234
5
6
7
5
FIGURE 3

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5
10
PUMP PLACEMENT
Proper Placement of Pump in Field (SEE FIGURE 5)
NOTE: This pump is designed to be self-priming when
installed and operated as specied below.
• Make sure the pump is positioned on a at, level, and
sturdy surface. The surface must support the weight
of the pump.
• Place the pump as close as possible to the level of the
water to be pumped.
• Use the shortest hoses possible. Hoses that are too
long will decrease the pump ow output and increase
the time to prime the pump.
• When total head increases, the pump output
decreases.
• Discharge head capacity is greater than intake
(suction) head capacity. To achieve the correct
capacities, the pumping height of the intake hose
must be shorter than the pumping height of the
discharge hose.
• The intake hose and strainer must be immersed in
water when the pump is operating.
NOTE: Operation of your Storm Surge™ Water Pump
without an intake strainer basket will void your
warranty. The intake strainer has been designed
to prevent large debris from entering the pump
intake which can cause damage.
• The intake strainer basket should rest on stones or in
a bucket and be secured to prevent movement when
operating.
• Route the discharge hose to a suitable location.
Additional discharge hoses can be used but should be
kept to a minimum to ensure ecient operation.
Water Pump Terminology
Cavitation
• A condition that causes vacuum pockets to form
in the pump. When the air pockets explode under
pressure, pitting to the impeller and volute surfaces
can occur.
Discharge Head
• The total head, including static head and friction
head, on the discharge side of the pump.
Suction Head
• The total head on the suction side of the pump,
including suction lift and friction head.
TOTAL
HEAD
WATER PUMP
DISCHARGE
HEAD
INTAKE
(SUCTION)
HOSE &
STRAINER
SUCTION
LIFT
FIGURE 5
CAUTION
DO NOT START YOUR WATER PUMP UNIT UNTIL
YOU HAVE READ THE ENGINE PREPARATION
INSTRUCTIONS, AND THE “WARNINGS AND
SAFETY PRECAUTIONS” SECTION IN THIS
MANUAL.
NEVER STORE ENGINE WITH FUEL IN THE TANK
INDOORS. FUEL AND FUEL VAPORS ARE HIGHLY
FLAMMABLE.

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 11
CAUTION
NEVER ADD FUEL WHEN ENGINE IS RUNNING OR
HOT FROM OPERATION. NEVER FILL THE TANK
INDOORS. DO NOT SMOKE WHEN FILLING FUEL
TANK.
AN ADULT MUST ALWAYS HANDLE AND FILL THE
ENGINE WITH FUEL.
ALWAYS HANDLE FUEL IN A WELL VENTILATED
AREA, OUTDOORS, AWAY FROM FLAMES OR
SPARKS.
DO NOT START ENGINE IF FUEL IS SPILLED. WIPE
OFF EXCESS FUEL AND ALLOW TO DRY. REMOVE
ENGINE FROM AREA TO AVOID SPARKS.
MAKE SURE THE UNIT IS IN A STABLE POSITION
BEFORE PULLING THE STARTER HANDLE.
IF ENGINE FAILS TO START AFTER TRYING
STARTING PROCEDURES, PLEASE CONTACT OUR
CUSTOMER SERVICE DEPARTMENT AT 800345
6007.
STARTER ROPE CAN CAUSE AN UNANTICIPATED
JERK TOWARDS ENGINE. PLEASE FOLLOW
INSTRUCTIONS TO AVOID INJURY.
NEVER LEAVE ENGINE RUNNING WHILE
UNATTENDED. TURN OFF AFTER EVERY USE.
NEVER CARRY PUMP FROM ONE LOCATION TO
ANOTHER WHILE ENGINE IS RUNNING.
NEVER RUN ENGINE INDOORS OR IN ENCLOSED,
POORLY VENTILATED AREAS. ENGINE EXHAUST
CONTAINS CARBON MONOXIDE, AN ODORLESS
AND DEADLY GAS.
KEEP HANDS, FEET, HAIR AND LOOSE CLOTHING
AWAY FROM ANY MOVING PARTS ON ENGINE AND
EQUIPMENT.
DO NOT OPERATE THE PUMP DRY. IF THE PUMP
IS OPERATED DRY THE PUMP SEALS WILL BE
DAMAGED. IF THE PUMP HAS OPERATED DRY,
STOP THE ENGINE IMMEDIATELY. ALLOW THE
PUMP TO COOL AND INSPECT FOR DAMAGE
BEFORE OPERATING AGAIN.
OPERATION
PREPARING ENGINE FOR STARTING
GAS AND OIL
NOTE: Engine is shipped from factory without oil. You must
add engine oil before starting engine. If engine is started
without oil, engine may be damaged beyond repair and will
not be covered by warranty.
HIGH OIL MARK
LOW OIL MARK
Quality
To operate the engine, we recommend using VIPER® brand
4-cycle oil (13235) or an equivalent 10W-30 engine oil to
ensure that the engine operates correctly throughout the life
of the engine. Use straight unleaded premium gasoline, low/
no ethanol blends recommended.
Filling Fuel Tank
1. Shut-o engine and allow engine to completely cool
before relling the fuel tank.
2. Move to a well ventilated area, outdoors, away from
ames and sparks.
3. Clean debris from area around the fuel cap.
4. Loosen fuel cap slowly. Prevent the cap from coming in
contact with dirt or debris.
5. Carefully add fuel without spilling.
6. Do not ll fuel tank completely full, allow space for fuel to
expand.
7. Immediately replace fuel cap and tighten. Wipe o spilled
fuel and allow to dry before starting engine.
Checking and Adding Oil
Be sure the engine is located on a level surface before
checking or relling oil. Proper position for checking oil level
or relling oil is the standard operation position of the pump.
1. Clean around oil ll area.
2. Unscrew dipstick and wipe clean with cloth.
3. Reinsert dipstick (must be fully threaded for accurate
reading).
4. Unscrew and check dipstick. If no oil shows on the
dipstick, rell so that the oil level appears between the low
and high marks on the dipstick. SEE FIGURE 6
5. Change oil if contaminated.
FIGURE 6

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5
12
PRIMING THE PUMP
1. Add water to the priming port on the pump. SEE FIGURE
8. Continue to add water until the water level is above the
inlet port of the pump.
2. Install the priming plug. The water in the pump will create
the suction that primes the pump.
NOTE: The slightest air leak in the suction hose will not allow
the pump to prime. The pump may take several minutes to
prime. Do not use this pump for suction lifts over 16 feet.
FIGURE 7
STARTING AND STOPPING ENGINE
• Move engine to a well ventilated area, outdoors, to
prevent carbon monoxide poisoning.
• Move to an area away from ames or sparks, to avoid
ignition of vapors if present.
• Remove all debris from air cleaner holes and fuel cap to
ensure proper air ow.
COLD ENGINE START
Starting the engine for rst time or after engine has cooled o
or after running out of fuel.
1. Move choke lever to CHOKE position (SEE FIGURE 7) and
throttle lever to low (Turtle).
NOTE: CHOKE position is dened by moving the choke lever
as far towards the fuel tank as possible.
2. Prime unit until primer hose is lled with fuel.
NOTE: When using the primer bulb, allow the bulb to return
completely to its original position between pushes.
3. Push ON/OFF switch to the ON position.
4. Hold handle bar rmly. Grasp start handle and pull out
slowly until it pulls slightly harder. Without letting starter
handle retract, pull rope with a rapid full arm stroke. Let it
return to its original position slowly. Repeat this step every
time the starter rope is pulled until unit res or runs.
NOTE: If engine fails to start after 5-6 pulls, push primer 1
time and pull starter rope again.
5. After engine starts running, move choke lever to HALF
CHOKE position until unit runs smoothly.
NOTE: Half choke is dened when the choke lever is between
CHOKE and RUN positions. SEE FIGURE 7
6. Move choke lever to RUN position and throttle to desired
speed. SEE FIGURE 7
7. Move throttle lever to high (Rabbit).
NOTE: Full throttle operation ensures that the seal is
lubricated. Do not let unit idle for extended periods of time.
8. To stop engine, push ON/OFF switch to OFF position.
WARM ENGINE START:
1. Move choke lever to CHOKE position. SEE FIGURE 7
2. Continue with Step 3 of Cold Engine Starting.
HOT ENGINE START:
1. Begin with Step 3 of Cold Engine Starting.
2. If engine does not re, refer to Step 1 of Warm Engine
Starting.
DO NOT attempt to start engine in the following ways:
• DO NOT use starting uid.
• DO NOT spray ammable liquids or vapors into air cleaner,
carburetor or spark plug chamber.
• DO NOT remove spark plug and attempt to start engine.
Flammable fuel can spray out and ignite from a spark from
spark plug.
TO STOP ENGINE:
Push the ON/OFF switch to the OFF position.
ON/OFF
SWITCH
PRIMER BULB
THROTTLE
LEVER
R
U
N
C
H
O
K
E

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 13
IMPORTANT
DO NOT OPERATE THE PUMP DRY. IF THE PUMP
IS OPERATED DRY THE PUMP SEALS WILL BE
DAMAGED. IF THE PUMP HAS OPERATED DRY,
STOP THE ENGINE IMMEDIATELY. ALLOW THE
PUMP TO COOL AND INSPECT FOR DAMAGE
BEFORE OPERATING AGAIN.
CAUTION
CHECK PUMP OFTEN FOR LOOSE NUTS AND
BOLTS. KEEP THESE ITEMS TIGHTENED.
MAINTENANCE AND REPAIR ON THE ENGINE AND
PUMP MUST BE DONE BY AN ADULT.
NEVER STORE ENGINE WITH FUEL IN TANK
INDOORS OR IN ENCLOSED, POORLY VENTILATED
AREAS, WHERE FUEL FUMES MAY REACH AN
OPEN FLAME, SPARK OR PILOT LIGHT.
MAINTENANCE AND STORAGE
Steps for Working on Pump
1. Turn engine switch to OFF.
2. Disconnect the spark plug wire from the spark plug.
3. Securely place the disconnected spark plug wire away
from the spark plug and any metal parts. This must
always be done or arcing may occur between spark plug
wire and metal parts.
4. Replace or repair the part on the pump.
5. Check all parts that were repaired, or removed during
repair, that they are secure and t correctly.
Pump Maintenance
Always shut o the engine, allow the engine to cool, and
remove the spark plug before performing any maintenance.
During freezing weather, open the drain port and allow all the
water in the pump to drain. This will prevent damage to the
pump when the water freezes. If the pump will be stored for
a month or more, drain the water from the pump and follow
the engine manufacturer’s recommendations for long-term
storage.
Engine Maintenance
Good maintenance is essential for safe, economical, and
trouble-free operation. It will also help reduce air pollution.
Please read the maintenance schedule and observe these
recommendations to extend the life of your engine.
To help you properly care for your engine, the following
pages include a maintenance schedule, routine inspection
procedures, and simple maintenance procedures using basic
hand tools. Other service tasks that are more dicult, or
require special tools, are best handled by professionals and
are normally performed by a technician or other qualied
mechanic.
Maintenance, replacement or repair of the emissions
control devices and systems may be performed by any
non-road engine repair establishment or individuals.
However, items must be serviced by an authorized dealer
to obtain “no charge” emissions control warranty service.
The maintenance schedule applies to normal operating
conditions. If you operate your engine under unusual
conditions, such as sustained high-load or high-temperature
operation, or use in unusually wet or dusty conditions, consult
your servicing dealer for recommendations applicable to your
individual needs and use.
FIGURE 8
NOTE: All repair parts must come from the factory. Never
replace parts that are not specically designed for
the pump.
6. Reconnect the spark plug wire.
LUBRICATION
Choose 10W-30 engine oil that meets or surpasses the latest
API service classication.
OIL MAINTENANCE
After the rst ve hours of operating a new Viper® engine the
oil should be replaced, and every 50 hours of operating time
thereafter. The oil should be changed every 25 hours if used
under severe conditions, such as in high temperatures or
under heavy loads. Check oil periodically; DO NOT OVERFILL!

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 14
IMPORTANT
PROPER POSITION FOR CHECKING OIL LEVEL OR
REFILLING OIL IS THE STANDARD OPERATION
POSITION. ENSURE THE UNIT IS ON A STURDY,
LEVEL SURFACE. FAILURE TO MAINTAIN THIS
POSITION CAN RESULT IN OVER FILLING THE
ENGINE WITH OIL WHICH WILL IMPAIR THE
ENGINE’S PERFORMANCE.
CARBURETOR
Never tamper with factory setting of the carburetor.
COOLING FINS
Cooling ns, air inlets and linkages must be free from any
debris before each use.
AIR FILTER
Never run engine without air cleaner properly installed. Added
wear and engine failure may occur if air cleaner is not installed
on engine.
Service air cleaner every 3 months or after 20 hours of
operation. Clean lter daily in extremely dusty conditions.
Steps for Replacing and Cleaning Air Filter
1. Before removing the air lter cover, move the chooke lever
to the CHOKE position.
2. To remove air lter cover, unscrew the cover bolt with a
screw driver and gently pop out the front latch tab. The
cover then can be slid o the back latch tabs and away
from the engine. Be careful not to sever or damage the
ON/OFF switch wires while removing the air lter cover.
SEE FIGURE 9
3. Remove the foam lter and ber lter elements. Replace
with a new ber lter and a new oiled foam lter (SEE
FIGURE 10), or clean the original foam and ber lters
CAUTION
TO AVOID INJURY OR DEATH, NEVER SIPHON
FUEL BY MOUTH.
IMPORTANT
NEVER TWIST AIR FILTERS WHEN CLEANING.
ALWAYS PRESS.
with warm water and mild soap. Remember to thoroughly
oil the foam lter with 30 or 40 weight motor oil and
squeeze out any excess oil before reinstalling it. Make sure
to press the foam lter evenly into place over the ber
lter to ensure that the foam is fully seated into its sealed
position.
4. Replace the air lter cover by rst connecting the back
latch tabs then swinging the cover, making sure the foam
lter block stays fully seated and in its proper position,
and connect the front latch tab so that it is secured into
place. Make sure to not pinch the ON/OFF switch wires
while replacing the air lter cover.
5. Screw the cover bolt back into place. Check that the cover
is securely attached by puling slightly on the cover. If the
cover doesn’t move when pulled, it is secure.
Transporting Your Pump
1. After using the pump and before transporting it in a truck
bed, screw the fuel cap on (clockwise) tightly. The fuel
cap will not leak during transporting if fuel cap is tight.
Never transport engine inside an enclosed space within
a vehicle. Fuel or fuel vapors may ignite causing serious
injury or death.
2. If fuel is present in the fuel tank, transport in an open
vehicle in an upright position.
3. If an enclosed vehicle must be used, remove fuel into an
approved red fuel container. DO NOT siphon by mouth.
4. Run engine to use up the fuel in the carburetor and fuel
tank. Always run engine in a well ventilated area. Engine
can run for several minutes due to its ecient design.
5. Wipe away any spilled fuel from engine and pump. Allow
to dry.
6. Fuel cap should be tightly secured before transporting
pump in a vehicle.
Flushing the Pump Housing
1. After use, remove the pump drain plug and allow the
water to drain from the pump housing.
2. Remove the pump primer cap and ush the pump
housing with clean water.
3. After all water has drained from the pump housing,
replace the primer cap and drain plug.
CHANGING OIL
Be sure the engine is not operating and is located on a level
surface before checking or relling oil. Engine should be warm
for easy removal of oil. There are many small oil passages in
the engine so wait ve minutes for the oil to accumulate in the
sump for accurate oil level checking.
STEPS FOR CHANGING OIL
1. Flip the ON/OFF switch to the OFF position/
2. Unscrew oil drain screw and empty oil into suitable oil
container. Dispose of oil properly.
3. Reinsert drain screw and remove oil dipstick.
4. Fill with appropriate oil to FULL or top line of dipstick.
(SEE FIGURE 6 ON PAGE 11)
5. Reinsert dipstick or oil ll cap and tighten.

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 15
AIR FILTER
COVER
FRONT LATCH TAB
ON/OFF
SWITCH
BACK LATCH TABS
COVER
BOLT
AIR FILTER
COVER
FOAM
FILTER
ELEMENT
FIBER
FILTER
ELEMENT
FIGURE 9
FIGURE 10
Long-Term Storage
If your pump will not be used for more than three months,
prepare it for long-term storage.
Steps for Long-Term Storage
1. Mix an appropriate amount of fuel stabilizer to fresh
gasoline, in the ratio recommended on the stabilizer
packaging. Run the engine for ve minutes to distribute
the stabilizer mixture throughout the fuel system. This will
prevent gum, varnish and corrosion build up in your fuel
system during long-term storage for up to 12 months.
2. Store pump in the standard operation position.
3. Remove all debris from pump and engine.
TROUBLESHOOTING AND REPAIR
Service Information
At Storm Surge™ we build quality and durability into the
design of our products; but no amount of careful design by us,
and careful maintenance by you, can guarantee a repair-free
life for your machine. Most repairs will be minor, and easily
xed by following the suggestions in the troubleshooting
guides in this section.
This guide will help you pinpoint the causes of common
problems and identify remedies.
For more complicated repairs, contact Storm Surge™ for an
authorized service center in your area.
We will always be glad to answer any questions you have, or
help you nd suitable assistance. To order parts or inquire
about warranty, call, write or e-mail us using the contact
information found in this section.
Ordering Replacement Parts
For your convenience a parts breakdown is included toward
teh end of the manual.
To order parts visit www.stormsurgepumps.com or call 1-800-
345-6007.
For other general questions, you can e-mail us at info@
ardisam.com.
Please include the following information with your order:
1. Part numbers
2. Part description
3. Quantity
4. Model number and serial number

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 16
Table 1. Engine Troubleshooting Guide
PROBLEM POSSIBLE CAUSE REMEDY/ACTION
Engine will not start 1. Power switch o 1. Flip switch to ON position
2. Spark plug wire disconnected 2. Connect spark plug wire to spark plug
3. Out of fuel 3. Refuel
4. Spark plug wet, faulty, or improperly
gapped
4. Clean, replace , or gap spark plug
5. Fuel line hose not positioned in
bottom of fuel tank
5. Push fuel line down into fuel in fuel tank
Engine runs rough, oods
during operation
1. Dirty air lter 1. Clean or replace air lter
2. Choke partially engaged 2. Turn o choke
3. Carburetor out of adjustment 3. Call factory
Engine is hard to start 1. Stale fuel 1. Drain old fuel and replace with fresh. Use fuel
stabilizer at end of season.
2. Spark plug wire loose 2. Make sure spark wire is securely attached to
spark plug
3. Dirty carburetor 3. Clean carburetor, use fuel stabilizer, new gas can
Engine misses or lacks power 1. Clogged fuel tank 1. Remove and clean fuel tank
2. Clogged air lter 2. Clean or replace air lter
3. Carburetor out of adjustment or bad 3. Call factory
4. Spark plug wet, faulty or improperly
gapped
4. Clean, replace or gap spark plug
Engine runs, but has no power 1. Choke on 1. Turn o choke after engine is running
2. Carburetor out of adjustment or bad 2. Call factory
3. Fuel cap not venting 3. Replace fuel cap
Engine runs, then quits 1. Plugged fuel lter 1. Clean or replace fuel lter
2. Carburetor out of adjustment or bad 2. Call factory
3. Fuel cap not venting 3. Clean or replace fuel cap
Engine revs too high 1. Carburetor out of adjustment 1. Call factory
2. Low fuel in tank 2. Add fuel to tank
Contact Storm Surge™ customer service at 800-345-6007 if additional assistance is needed.
Only use approved Storm Surge™ spare parts.

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 17
PROBLEM: No Pump Output POSSIBLE CAUSE REMEDY/ACTION
Check Pump Housing 1. Pump not primed 1. Prime the pump.
Check Intake (Suction) Hose
1. Hose collapsed, cut or punctured. 1. Replace Hose
2. Strainer not fully under water. 2. Make sure hose end and strainer basket is
completely under water.
3. Air leak at connector. 3. Replace sealing gasket if damaged or missing.
Use Teon pipe thread tape on all threaded
coupling surfaces.
4. Strainer basket clogged 4. Clean debris from strainer basket.
Measure suction and discharge
head SEE FIGURE 5“PUMP
PLACEMENT”
1. Excessive head 1. Relocate pump and hoses to reduce head.
Check Engine Refer to Table 1. (Engine Troubleshooting Guide.)
Contact Storm Surge™ customer service at 800-345-6007 if additional assistance is needed.
Table 2. Pump Troubleshooting Guide: No Pump Output
Table 3. Pump Troubleshooting Guide: Low Pump Output
PROBLEM: Low Pump Output POSSIBLE CAUSE REMEDY/ACTION
Check Intake (Suction) Hose
1. Hose collapsed, cut, or punctured.
Hose too long or too small a
diameter.
1. Replace Hose
2. Strainer not fully under water. 2. Make sure hose end and strainer basket is
completely under water.
3. Air leak at connector. 3. Replace sealing gasket if damaged or missing.
Use Teon pipe thread tape on all threaded
coupling surfaces.
4. Strainer basket clogged 4. Clean debris from strainer basket.
Check Discharge Hose 1. Hose damaged, cut, or punctured.
Hose too long or too small a
diameter.
1. Replace Discharge Hose
Measure suction and discharge
head SEE FIGURE 5“PUMP
PLACEMENT”
1. Excessive head 1. Relocate pump and hoses to reduce head.
Check Engine Refer to Table 1. (Engine Troubleshooting Guide.)
Contact Storm Surge™ customer service at 800-345-6007 if additional assistance is needed.

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5
18
ILLUSTRATED PARTS BREAKDOWN  PUMP & FRAME
16
17
18
12
3
4
5
6
7
8
9
10 11
1
12,
19
13,
19
14,
19
15
12,
19
13,
19
14,
19

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5 19
ITEM # PART # DESCRIPTION Q T Y.
1 67028 BOLT M6 X 1.0 X 16 HEX 19
2 300336 BOLT M6 X 1.0 X 10 HEX 2
3 42127 FOOT RUBBER 4
4 42131 BOLT M6 X 1.0 X 14 PHILIPS 4
5 22507 FRAME PUMP MOUNT 1
6 14109 NUT M6 X 1.0 HEX NYLOC 4
7 22514 THROTTLE CONTROL ASSEMBLY 1
8 42119 SPACER ENGINE MOUNT 2
9**  ENGINE 4CYCLE 40CC 1”PUMP 1
10 42102 ADAPTER PLATE 1”PUMP 1
11 42101 PUMP MOUNT BRACKET 1
12*  WING NUT HOSE ADAPTER 1” 2
13*  BARBED NIPPLE 1”PUMP 2
14*  NIPPLE SEAL 1”PUMP 2
15 15328 PUMP SEMI TRASH 1”NPSH 1
16 42137 STRAINER 1”WATERPUMP 1
17 48166 GARDEN HOSE ADAPTER 1” 2
*Available as kit only.
**Engine not available to purchase. Please replace pump (PN 20198) if engine is irrepairable.
1,
15
1, 15
1, 15
15,
20 15,
21,
34
15,
22,
34 15,
23 15,
24 15,
25,
34
15, 26
15, 27
15, 28, 34
15, 29
15, 29, 30,
15, 31,
34
15,
29,
30
15,
29
15, 32
15, 33
ITEM # PART # DESCRIPTION Q T Y.
18 42135 HOSE CLAMP 1”WATERPUMP 3
19 15521 KIT 1”BARBED HOSE ADAPTER 2
20*  IMPELLER HOUSING COVER 1
21*  MECHANICAL SEAL 1”PUMP 1
22*  CERAMIC SEAL 1”PUMP 1
23 42134 IMPELLER 1“ PUMP 1
24 42122 VOLUTE HOUSING 1”PUMP 1
25*  RUBBER GASKET 1”PUMP 1
26*  HOUSING 1”PUMP 1
27*  OUTLET PORT 1”NPSH 1
28*  ORING SEAL 1.30 X 1/8 INCH 1
29 15195 CAP & ORING FILL/DRAIN PORT 2
30*  ORING SEAL FILL/DRAIN PORTS 2
31*  CHECK VALVE GASKET 1”PUMP 1
32*  HOUSING FRONT COVER 1
33*  BOLT M6 X 1.0 X 50 HEX HEAD 6
34 15520 KIT GASKETS & SEALS 1”PUMP 1

Operator’s Manual
SS14CW Water Pump
Check for parts online at www.stormsurgepumps.com or call 800-345-6007 M-F 8-5
20
ILLUSTRATED PARTS BREAKDOWN  ENGINE
1, 49
2, 49
3, 49
4, 49
5, 49
6, 49
7, 49
8, 48
9, 48
57 2, 46
10, 46 11, 46
12, 55
13, 55
14, 55
14, 55
15, 53,
57
2, 53
16, 53
17, 51
18, 51
17, 51
19, 51
20, 51
17, 51
2
21
2
22
23, 54
24, 52
25, 52
26, 52,
57
27, 54,
57
28
29
39 30, 47,
50
31, 47,
50
32, 47,
50 33, 47,
50
34, 50
36, 50
35, 50
37, 50
38, 50
40, 56
41, 56
42
43
44
45
