Strawbees QUIRKBOT User manual

Make a new companion to react and
express when meeting new friends.
Use circuit touch as meaningful
interaction to express different
feelings for the Friendbot.
QUIRKBOT
FRIENDBOT
x 2
x 10 x 16
x 4
x 1 x 1x 2x 1 x 1
x 12
x 2
x 17
Bend 8 of the 3-leg
connectors
1
Take a 2-leg servo
arm and fit 2
yellow straws
3Fit 2 of the 2-leg
connectors on
yellow straws
4
x 8 x 2
Build 2 squares
with 8 orange
straws
2
FRIENDBOT HEAD
© Strawbees AB. All rights reserved.
For activities, lesson plans and
support material please go to:
LEARNING
PLATFORM learning.strawbees.com

x 2
Connect to the base
5Take 4 orange
straws, attach to the
3-leg connectors
6
Attach second
square to orange
straws to close
the head
7Take 4 of the 1-leg connectors
and 2 yellow straws, build 2
beams
8
Slide the beams
on orange straws
and click
9
Bend 8 of the 3-leg
connectors
10
Take 1 yellow
straw, 1 orange
straw and 2 pink
straws. Build the
base
11 Take 4 pink straws,
fit on the 3-leg
connectors
12
x 8
FRIENDBOT BODY

Attach the top
part to pink
straws
complete the
body
14
Take 2 of the 1-leg connectors and
1 orange straw, build an orange
beam
15 Slide the beam
on yellow straws
of top of body
and click
16
Build the top part of body with 3
yellow straws and 1 orange
straw
13
18
Snap the servo
backpack on
the Quirkbot
Fit the yellow beams and click
on front bottom of body
19 Fit the mounts on the servo motor 20
Take 2 of the 1-leg connectors and 2
yellow straws, build two yellow
beams
17
x 2

x 2
Take 2 of the 5-leg connectors, 2 of
the 1-leg connectors and 2 yellow
straws, build two beams for arms
26
Connect the
alligator clips
on the 5-leg
connectors
26
Connect the
servo arm of the
head to the
servo on the
body
25
Slide arms on
pink straws in
front of body
and click
27
Connect alligator clips on the Quirkbot
22
Click the servo between orange
straws on top of the body
23 Attach Quirkbot to the body 24
Connect the servo
motor to the Quirkbot
backpack
21
Horn
Right Eye

Find & try the coding cards with these icons:
code.strawbees.com
