1. Product characteristics
1.1. Overview
A5-H0404 is a cost-effective and function-extensive equipment specially designed for mobile
surveillance and intelligent scheduling. It uses high-speed processor and embedded operating system,
combined with H. 264 video compression/decompression technology, 3G/4G, WIFI, network technology
and GPS locating technology. It can realize AHD 1080P and 720P high definition, IP 1080P and 720P
high definition, WD1, WHD1, WCIF, D1, HD1, CIF video recording and vehicle driving information
recording, as well as wireless data upload. With center software it also achieves alarm linkage central
monitoring, remote management and playback analysis. A5-H0404 is easy to use with modular design,
multi-functions, superior anti-vibration, flexible installation and high reliability, etc.
1.2. Product advantage
1.2.1. Structural advantages
1) Modular design for easy maintenance. User replaces main module when changing 3G module
to 4G one.
2) Dual SIM cards design for different applications.
3) Adopts explosion-proof and seal design, water proof dust proof is up to IP54.
4) The design of machine is with anti-pressure design, which bears a machine of 4000 kg weight
without any deformation
5) Good heat dissipation, for the device shell and the main modules adopt aluminum material.
6) Independent fan module.
1.2.2. Hardware advantage
1) Power adopts buck / boost structure. When power input is below 8V, it will rise to 12V, when
power input is above 36V, it will reduce to 12V to maintain power stability.
2) Power supply is with dynamic response design.
3) Power supply can bear a variety of power shock, such as anti-reverse, transient high voltage
protection. It applies with ISO7636-2 standard.
4) With power loss protection, the equipment can work about 8-10 seconds after sudden power off
to ensure the integrity of the video. Besides, it can resist various high and low pulse. In the test,
unplug the power and plug immediately, the device keeps working without restarting.
5) Built-in three-axis sensor, can perceive the acceleration in different directions.
6) Built-in 4G memory (dedicated MLC), for station report file storage which is reliable and stable.
Generally, the 4G memory can store all the line files.
7) Boards are connected with high quality connectors to reduce data transmission error.
8) Connectors match device structure precisely to prevent displacement or damage of the

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
5
connector in the case of vibration.
9) All the materials are tested scientifically:
Step 1: test whether the electrical characteristics meet the requirements
Step 2: test whether the environmental characteristics meet the requirements in the car
Step 3: the device goes through four stages before launching market, sample/ trial production /
market test / batch import
1.2.3. Software advantage
1) Streamax owns patented invention of the excellent and strong file management systems to
ensure the integrity of audio and video data and reliability.
2) File list, index and other important data backup will not lead to a large number of data can not
be accessed in a slight hard disk physical damage.
1.2.4. Function advantage
1) Supports minimum temperature -40℃, intelligent control of negative feedback heating curve. It
supports regular start-up preheating and intelligent insulation. In addition, it meets the global
climate requirements of different climatic conditions and equipment can work in a variety of
harsh conditions.
2) Supports pre-recording for about 1 hour.
3) Support 8 channels 720P AHD and 1 channel 720P HD simultaneously.
4) Alarm recording can be locked for a certain time before the deletion, which cannot be covered
randomly.
5) Alarm recording can be exported by flash drive to facilitate the extraction of video.
6) Delayed shutdown function. After the vehicle ignition switches off, it keeps working during the
specified time (5 minutes to 6 hours). It turns off at specified time. The advantage of the delay
shutdown function is that it can extend the recording time and avoid damage to the hard disk
caused by sudden power off.
7) It can report station automatically in complicated road conditions without the driver intervention.
8) There is a special PC software to prevent the driver to know the password and to operate the
device.
1.3. Features
1) All the modules are connected with exquisite connectors, supporting quick disconnection,
which is safe and easy to maintain.
2) Each module (including waterproof fan modules) when a failure occurs, the system
automatically detects and alarms.
3) Adopts explosion-proof and seal design for the outer shell.
4) Combines together three vibration-resistant technologies: mechanical anti-vibration, electronic
anti-vibration and software anti-vibration.
5) Supports DC8~36V wide voltage input, suitable for 12V and 24V vehicles.

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
6
6) Monitor video streams coherence.
7) Watermark technology: prevents data tempering and guarantees the video authenticity and
legal efficiency.
1.4. Functions
1) Local recording and video playback: 720P/WD1/WHD1/WCIF/D1/HD1/CIF resolution optional.
2) Driving recording: provides statistics on speed, turning, brake, reverse, opening door, etc.
3) Network function: supports break point uploading continually, which can realize the remote
video surveillance, video download, remote alarming and network timing of the equipment, network
setting and remote upgrade, etc.
4) High-speed backup: support high-speed backup through USB2.0, as well as backup through
SD card.
5) User log: on-off status of the device, video loss, recording start time / end time, user log in / log
out, modification of the device parameters, checking the time, GPS status.
6) Import and export of the configuration file: thumb drive import/export device parameters.
7) Device upgrade: supports local upgrade and remote upgrade.
8) Alarm linkage: supports linkage switch value output, image display, etc.
9) Storage formatting: formatting SD cards and external USB devices.
1.5. Specifications
Items
Technical Index
Product Series
A5-H0404
Function Overview
Preview, Recording, Network, Playback,
Location tracking, Dispatching
System
OS
Linux 3.0.8
Control Mode
IR remote control, control panel, network
Video
Input
4 channels AHD(720P)+4 channels IPC(720P)
Output
1 channel
Total Resource
PAL:
4*1080P@25FPS (AHD) +4*1080P@30FPS (IPC)
NTSC:
4*1080P@30FPS (AHD)+4*1080P@30FPS (IPC)
Video Signal Standard
Electrical level: 1Vpp; Impedance: 75Ω
NTSC/PAL Optional
Audio
Input
8 channels
Output
1 channel
Audio Signal Standard
Electrical level: 2Vpp; Input impedance: 4.7Ω
Display
Display Split
1/4/9
OSD
GPS information, alarm, temperature, acceleration,
voltage, device information, software version, MCU
version, network information

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
7
Operation Interface
Semi-transparent GUI
Recording
Video/Audio
Compression
H.264/ADPCM
Image Resolution
PAL:
1080P(1920X1080)
720P(1280X720)
WD1（960X576）,D1(704X576)
WHD1(960X288),HD1(704x288)
WCIF(480X288),CIF(352x288)
NTSC:
1080P(1920X1080)
720P(1280X720)
WD1（960X480）,D1(704x480)
WHD1(960X240),HD1(704x240)
WCIF(480X240),CIF(352x240)
Digital: 1080P(1920X1080),720P(1280X720)
Image Quality
8 Levels adjustable
Recording Mode
Schedule/Alarm (sensor trigger, speed, acceleration, video
loss, temperature)
Pre-recording
0-60minutes
Post-recording
0-30minutes
Mirror recording
Yes
Playback
Playback Channel
1 channel by local playback, 1 channel by software
playback, 4/8 channels playback
Search Mode
Date/time, channel, event
Network
3G/4G
EVDO/WCDMA/TDD/FDD
WIFI
802.11b/g/n/
Ethernet
100Mbps
Locating
GPS
Location tracking, speed detection and time sync
Storage
Hard Disk
2.5” SATA HDD
Interface
USB
USB2.0 × 2
SD
SD × 1
Sensor
8 inputs, 2 outputs
Serial Port
RS232*2, RS485*2
CAN
Supports CAN port*2
Speed
1 channel pulse speed detection
Intercommunication
Intercommunication inside/outside vehicle
Panel
Control panel CP4 (Optional accessory)
Power
Input
DC8-36V
Output
1A@12V,1A@5V
Consumption
Impact current: input 13.5V@7.8A
Working current: input 13.5V@1.6A

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
8
input [email protected]A
Standby current: 0A
Physical
Characteristic
Dimension
(L x W x H)
313x176x119mm
Weight
3.7Kg
Operating
Environment
Temperature
-25℃- +60℃
Relative Humidity
8%-90%
Certificates
CE, FCC, MIL-STD-810F
1.6. System diagram

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
9
1.7. External interface
1.7.1. Dimension
1.7.2. Front panel
Serial No.
Print
Description

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
10
1
WiFi antenna interface
2
GPS antenna interface
3
3G antenna interface
4
USB
USB interface
5
Debug test interface
6
SD/SMI1/SIM2 Slot
Mirror image SD card/SMI1/SIM2 Slot
1.7.3. Rear panel
Serial No.
Print
Description
1
USB
USB interface
2
CAN
External CANBUS
3
Panel
Control panel(CP4)
4
Amplifier
Amplifier port
5
DC8-36V
Power input
6
IPC-1/2/3/4
4 channels IPC interfaces
7
A/V IN1/2/3/4
4 channels analog interfaces
8
RS485-1/2,RS232
R232/R485 interface
9
Speed
Pulse speed interface

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
11
1.8. Hard disk installation instruction
1.9. Sim card installation instructions
10
Sensor
Sensor interface

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
12
2. FAQ
1) The system can’t start?
Usually this problem results from the incorrect power connection. Please follow below steps to
check the power connection:
1. Check the input power, whether the power wire is connected correctly, whether the ground wire is
connected back to the battery, and whether the fuse on the power wire is in good condition.
2. Check whether the ACC signal wire input to the power is with voltage higher than 7 V.
3. Check whether the device key is closed.
2) The MNVR restarts uninterruptedly?
Please follow below steps to check it:
1. Check whether the voltage of MNVR is insufficient. If the voltage is less than the start-up voltage of
the device, the device would always restart.
2. The problem in hard disk/SD card may cause the failure to start. Take off the storage part and check
whether it is broken down.
3) The device can’t record?
Usually this problem results from the storage disk or camera. Please follow below steps to check it:
1. Check whether the storage disk is installed, whether it is in good contact, and whether the disk can
be read normally in computer.
2. Check whether the storage disk is formatted. The storage disk should be formatted before normally
storing record files.

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
13
3. Check whether there is video signal input into the device from camera, and whether there is
video/image on the screen.
4) There is no voice in record file?
Please follow below steps to check it:
1. Check whether there is an external pickup, or whether the camera features with the function of
audio collection.
2. Access to Video Channel Settings, check if Audio is set on.
3. There must be video input into the channel for recording and it must record normally.
5) The GPS works abnormally?
Please follow below steps to check it:
1. Check whether the GPS antenna is installed correctly. There is a silk print logo on the GPS antenna
holder behind the host device.
2. Check whether the antenna receiver is sheltered. It should not be covered by any stuff, which may
cause it not to receive signals.
3. Environmental influence such as tree shades, being inside tunnel, driving near tall building or
elevated roads, thunderstorms or other weather influence, etc. can also cause signal loss or
receiving wrong signals.
6) The device can’t shutdown in ignition switch mode?
Please follow below steps to check it:
1. Check if the ACC line connection mode is correct; and check whether there is voltage on ACC
yellow line when the key is turned off.
2. If the device has been set with schedule recording, it can’t shutdown if it is still during recording time
of the task table.
7) How to install the WIFI antenna?
The antenna must be installed on unobstructed place of the roof, and be fixed with glue.
8) The device cannot be shut down when in ignition ON/OFF mode.
Check if the ACC signal wiring is correct and if there is voltage for ACC signal line after the key is
turned off .
If you have set timing recording, and at the current time it is still in task recording, the device may be
impossible to be shut down.
9) GPS anomaly.
Check if the GPS antenna is properly installed. There is silkscreen GPS identification on the GPS
antenna pedestal on the back of the MNVR device. Check if the antenna connector is blocked and
make sure the antenna connector not be covered by other things.
Trees block, being inside the tunnel, driving near tall buildings or viaduct, thunderstorms and other
environmental effects may also cause to receive no GPS signal or error signal.
10) No voice in video files.
See if there is an external microphone, or if the camera cannot capture audio;
Enter into the video channel settings, then check if the audio is open;
Ensure video input and normal recording, on which the audio recording channels must be based.
11) The device doesn’t record.
Make sure the storage part is installed and of fine contact, the data can be read on PC, and the
storage device is not formatted.
Check if there are video signal input to the main device, and whether there are video images in the

User Manual for A5-H0404
For more information, please visit our website www.en.streamax.com
14
channel pictures.
12) Why has the MNVR device always been in a state of restart?
Check whether the MNVR device voltage is insufficient. If the device voltage does not reach the
start voltage, the device will restart.
Hard disk or SD card may cause the MNVR device unable to start. You need to remove the storage
device and then boot up to verify whether it is caused by the storage device.
13) Why the MNVR device cannot start?
Check the device input power to see if the power wiring is correct, if there is ground wire connected
back to the battery, and if the fuse of the power wire is n good condition;
Check whether there is voltage(more than 7V) on power input ACC signal wire;
Check whether the hard disk key is turned off.
14) What is the log in user name and password for new device?
The default user name and password are both “admin”. The device password can be set as empty.
