Strider 14x User manual

UNIVERSAL OWNER’S MANUAL
www.StriderBikes.com
1
©2019 Strider Sports Int’l, Inc. All Rights Reserved. 11240 A Owner’s Manual
Proper Use
This bicycle is intended for use by children 3 to 7 years old in safe areas, free of traffic, with surfaces that
are in good condition. These surfaces are smooth paved or smooth unpaved surfaces.
What should be avoided?
Avoid bicycling in wet, slippery, or muddy conditions. The Strider 14x is not intended for stunts, tricks,
downhill or any other extreme sport. The maximum rider weight is 36k (80 lbs). The components of the
bicycle are not designed to support the weight of adult riders.
WARNING: Tires may unintentionally lose ground contact. It is the guardian’s responsibility to ensure
that the child is wearing proper safety gear and riding in safe areas on appropriate surfaces.
Prepare to Ride
For riding safety and success take the time to check that the Strider 14x fits your child properly.
Seat Height
Adjust the seat so that it sits slightly lower than the top of your child’s inseam when they are standing
next to the bike. Open the quick release clamp on the seatpost and slide the seat to the appropriate
position. When your child is seated comfortably on the bike with shoes, there should be a slight bend in
their knee. The dash lines on the seatpost represent the minimum insertion point. For your child’s
safety, insert the post far enough into the frame until the dash lines do not show.
Handlebar Height
The best starting point for handlebar height is to set it with respect to the seat. If the seat is at its lowest
setting, set the handlebar to its lowest setting, etc. The Strider 14x allows for handlebar adjustment
reach as well as height. When your child is sitting comfortably on the bike, their reach should be a
distance where there is only a slight bend to the elbows. The dash lines on the handlebar post represent
the minimum insertion point. For your child’s safety, insert the post far enough into the frame until the
dash lines do not show.
Using the Brakes
Lever Operated Brakes: The front and rear brakes are actuated separately by the left and right brake
levers. The front and rear brakes should be applied at the same time.
Coaster Brakes: Rotate the pedals in reverse until the brake engages.
To become familiar with the brakes, practice using in a safe environment free from vehicle traffic or
other hazards.
The child must be properly instructed in the use of this bicycle, especially the braking system. Please
refer to the assembly guide.
Saddle and Handlebar Height
It is safe to lower the seat on all Strider Bikes as far as it will physically go, around 36.5 cm (14.5”) as
measured from the ground.

UNIVERSAL OWNER’S MANUAL
www.StriderBikes.com
2
©2019 Strider Sports Int’l, Inc. All Rights Reserved. 11240 A Owner’s Manual
Safety Information
Make sure your child is wearing appropriate attire and safety gear when riding. This includes, but is not
limited to, a helmet, close-toed shoes, and knee and elbow pads.
CHECK THE TIRES
• Use a tire pump with a gauge to make sure your tires are inflated within the recommended pressure
range. Do not exceed the pressure limit as stated on the side of the tire or rim; whichever is lowest.
NOTE: It is better to use a hand or foot pump than a service station pump or an electric compressor. The
latter is more likely to over-inflate, which can cause the tire to blow out.
CHECK THE CABLES
• Make sure all cables and housings are properly secured to the frame or fork so that they cannot
interfere with or get caught on moving parts.
CHECK REFLECTORS, LIGHTS, AND ACCESSORIES
• Check that the reflectors are clean and positioned perpendicular with the rim.
CHECK THE PEDALS
• Make sure your pedals and shoes are clean and free of debris that could affect your grip or interfere
with the pedal system.
• Grab your pedals and crank arm and wiggle to see if there is anything loose. Spin the pedals to make
sure they rotate freely.
CHECK THE BRAKES
• While standing still, make sure you can apply full braking force without the brake lever touching the
handlebar. (If the lever touches, your brakes may need adjustment.)
• Check that the front wheel brake is working properly. Ride the bike at a slow speed and apply the front
wheel brake. The bike should come to an immediate stop.
WARNING: Brake force applied to the front wheel suddenly or too forcefully could lift the rear wheel off
the ground. This could decrease your control and cause you to fall. For best results, apply both
brakes at the same time.
• For lever operated brakes, repeat the process with the rear wheel brake.
• For coaster brakes, start with the back pedal crank slightly higher than horizontal. Apply pressure
downwards on the back pedal. When you move the pedal downward, the brake should engage.
CHECK THE CHAIN
• Make sure your chain has the correct tension so that it can’t fall off. If you’re unsure of the correct
tension, see your bike shop.
• Check that the chain has no kinks, rust, broken pins, plates, or rollers.

UNIVERSAL OWNER’S MANUAL
www.StriderBikes.com
3
©2019 Strider Sports Int’l, Inc. All Rights Reserved. 11240 A Owner’s Manual
• Coaster brake: There should be between 10mm total vertical movement in the middle of the chain.
Weight Limits
Maximum weight capacity is 80 lbs / 36 kg for rider and luggage. Maximum weight capacity for the rider,
luggage, and the bike is 100 lbs / 45 kg.
This product is not intended to fit a luggage carrier or child seat.
Safety Advisory
This product is not intended to be ridden on public roads or any places used by automobiles.
Always check and abide by local laws before using this product.
This bike has inherent hazards associated with its use that could lead to injury or death. Never ride this
bike near curbs, stairs, steep slopes, swimming pools, or places used by automobiles. Doing so could
result in an accident resulting in death or serious injury. Ride in a flat, safe area under adult supervision.
Strider Bikes are not designed to be used in conjunction with any type of stabilizer system.
Assembly
When putting the Strider 14x together, refer to assembly guide.
Chain Maintenance

UNIVERSAL OWNER’S MANUAL
www.StriderBikes.com
4
©2019 Strider Sports Int’l, Inc. All Rights Reserved. 11240 A Owner’s Manual
The chain should be lubricated with light oil at least every month, or after use in wet, muddy, or dusty
conditions. Take care to wipe off excess oil, and not to get oil on tires or rim braking surfaces.
When correctly adjusted, the chain should have approximately 10mm of vertical movement when
checked in the center between the chainwheel and rear sprocket. Center the wheel in the frame and re-
tighten the axle nut after adjustment.
Chains require a special tool to fit and remove chain links or to change the length. We recommend that
you go to a local bicycle mechanic to replace or change the length of your chain.
The Strider 14x does not have multiple gears/speeds.
General Maintenance
Keep your bike clean and replace worn parts as needed.
WARNING: servicing your bike may require special tools and skills. If a repair or adjustment is not
specifically listed in the user manual, for your safety, have it repaired at a bike shop.
• Coaster brake: There should be between 10mm total vertical movement in the middle of the chain.
Weight Limits
Maximum weight capacity is 80 lbs / 36 kg for rider and luggage. Maximum weight capacity for the rider,
luggage, and the bike is 100 lbs / 45 kg.
This product is not intended to fit a luggage carrier or child seat.
Safety Advisory
This product is not intended to be ridden on public roads or any places used by automobiles.
Always check and abide by local laws before using this product.
This bike has inherent hazards associated with its use that could lead to injury or death. Never ride this
bike near curbs, stairs, steep slopes, swimming pools, or places used by automobiles. Doing so could
result in an accident resulting in death or serious injury. Ride in a flat, safe area under adult supervision.
Strider Bikes are not designed to be used in conjunction with any type of stabilizer system.
Assembly
When putting the Strider 14x together, refer to assembly guide.
Chain Maintenance

UNIVERSAL OWNER’S MANUAL
www.StriderBikes.com
5
©2019 Strider Sports Int’l, Inc. All Rights Reserved. 11240 A Owner’s Manual
For your safety, only genuine Strider parts are recommended for this bike.
The Strider 14x uses Shrader valves. If, for any reason, you decide to use different kinds of valves during
an inner tube exchange, familiarize yourself with the correct way to handle those.
Rims are friction components that are exposed to large loads. Deformed, cracked, or broken wheels
must be replaced immediately.
The chain should be lubricated with light oil at least every month, or after use in wet, muddy, or dusty
conditions. Take care to wipe off excess oil, and not to get oil on tires or rim braking surfaces.
When correctly adjusted, the chain should have approximately 10mm of vertical movement when
checked in the center between the chainwheel and rear sprocket. Center the wheel in the frame and re-
tighten the axle nut after adjustment.
Chains require a special tool to fit and remove chain links or to change the length. We recommend that
you go to a local bicycle mechanic to replace or change the length of your chain.
The Strider 14x does not have multiple gears/speeds.
General Maintenance
Keep your bike clean and replace worn parts as needed.
WARNING: servicing your bike may require special tools and skills. If a repair or adjustment is not
specifically listed in the user manual, for your safety, have it repaired at a bike shop.
