Strobel 58 Series User manual

For the professional user
Für den professionellen Anwender
Betriebsanleitung
Class:
Klasse:
Model:
Ausführung:
Dated:
Stand:
58
17
Operang Instrucons
Spezialmaschinen GmbH

Im Zeichen der Qualität
ou nd the Strobel trademark on every Strobel
machine leaving our works. And with good reason.
This symbol is a guarantee of the high quality of
our products. Quality which creates trust – trust
in our technology, our service and, not least of all,
in our good name.
ie nden die Strobel-Schutzmarke auf jeder
Strobel-Maschine, die unser Werk verlässt.
Und das aus gutem Grund. Denn dieses Zeichen
garanert Ihnen die hohe Qualität unserer
Produkte. Qualität, die Vertrauen scha – in unsere
Technik, unseren Service und nicht zuletzt in unseren
guten Namen.
S
Y
The sign of quality

trobel clients know that they can expect a parcularly high
standard of performance from our company and our machines.
Now you have seled for one of our products. For us this is a
source of encouragement and of obligaon to Jusfy your trust.
If you wish to prot from the performance and eciency of your
Strobel machine as long as possible, exact handling and tho-
rough care is necessary. For this reason we kindly request that
you read the operang instrucons closely.
It provides all the informaon you need for trouble free
operaon.
And if you do happen to need a spare part the enclosed spare
parts list gives a complete overview. It is clearly
classied according to components so that you can nd the
required part quickly and easily. In order to avoid errors we
request you to quote machine class, machine number and part
number completely on your spare part order.
We wish you lots of success in your work with your new Strobel
machine.
S
A decision with future
Spezialmaschinen GmbH

Garantiekarte/Warranty Sheet
Boschstraße 16
D-82178 Puchheim
Tel.: [phone]
Fax: [phone]
[email protected]
Maschinenklasse/Machine class:
Serien-Nr./Serial No:
Auftrags-Nr./Order Confirmation No:
Lieferdatum/Delivery Date:
Rechnungs-Nr./Invoice No:
Rechnungsdatum/Invoice Date:
Beanstandung/Complaint:
Datum/Date Unterschrift/Signature:
Bitte nicht vom Kunden ausfüllen/To be filled out by Strobel:
Datum
Bemerkung
EXA:
ETA:
PROD:
EXA:
BH:

1 BA_58_A17_220628_en.doc

2 BA_58_A17_220628_en.doc

3 BA_58_A17_220628_en.doc
Operating instructions
STROBEL Class 58-4D
C o n t e n t s
1General notes on safety ............................................................................................................. 5
2General ....................................................................................................................................... 5
2.1 Operating instructions ...................................................................................................... 7
2.2 Class description, serial number and initial basis for description .................................... 7
2.3 Range of application and intended use ............................................................................ 7
2.4 Technical data ................................................................................................................... 8
3Installation and putting into service ........................................................................................ 10
3.1 Unpacking the machine .................................................................................................. 10
3.2 Installation ...................................................................................................................... 10
3.3 Sense of Rotation............................................................................................................ 12
3.4 Motor drive via V-belts ................................................................................................... 12
3.4.1 Tensioning the V-belt........................................................................................ 12
3.4.2 Positions of the machine .................................................................................. 13
3.5 Motor drive via toothed belt .......................................................................................... 15
3.5.1 Tensioning the toothed belt (Fig. 6) ................................................................. 15
3.5.2 Positions of the machine .................................................................................. 16
4Instructions for use................................................................................................................... 17
4.1 Needles and threads ....................................................................................................... 17
4.2 Inserting the needle........................................................................................................ 17
4.3 Threading and thread course.......................................................................................... 18
4.4 Thread tension ................................................................................................................ 19
4.5 Stitch depth regulator..................................................................................................... 19
4.5.1 General.............................................................................................................. 19
4.5.2 Setting the stitch depth .................................................................................... 19
4.5.3 Digital stitch depth indication .......................................................................... 20
4.5.4 Changing the battery ........................................................................................ 20
4.6 Plunger limit stop............................................................................................................ 21
4.6.1 General (Fig. 12)................................................................................................ 21
4.7 Material feed................................................................................................................... 22
4.7.1 General.............................................................................................................. 22
4.7.2 Setting the stitch length (Fig. 13) ..................................................................... 22
4.7.3 Setting the feed dog ......................................................................................... 22
4.8 Fig. 14 and Fig. 15) .......................................................................................................... 23
4.9 Sewing drive .................................................................................................................... 24

4 BA_58_A17_220628_en.doc
5Operating the machine............................................................................................................. 25
5.1 General............................................................................................................................ 25
5.2 Switching on.................................................................................................................... 25
5.3 Placing and removing the fabric - sewing process ......................................................... 25
5.4 Sewing ............................................................................................................................. 27
5.5 Padding (Fig. 6 and 7)...................................................................................................... 27
5.6 Problems during sewing and possible solutions............................................................. 28
6Machine maintenance.............................................................................................................. 31
6.1 General............................................................................................................................ 31
6.2 Lowering the material support arm to lubricate the machine (Fig. 19 and Fig. 20) ..... 31
6.3 Lubricants........................................................................................................................ 34
7Variable sewing tools ............................................................................................................... 34
8Optional extras ......................................................................................................................... 36
8.1 Thread trimmer............................................................................................................... 36
Subject to change without prior notice

5 BA_58_A17_220628_en.doc
1General notes on safety
Manuals and additional information can be found on the STROBEL website at:
http://www.strobel.biz
Every person in charge of setting up, operating, servicing and repairing the machine
must first read and understand the operating instructions and particularly the safety
instructions before starting up the machine.
Failure to comply with the following safety instructions can lead to physical injuries
or damage to the machine.
1. The machine must only be operated by persons familiar with the relevant
operating instructions and who have been instructed accordingly.
2. Before commissioning also read the notes on safety and the operating
instructions of the sewing drive manufacturer.
3. Only use the machine in the intended manner and never without the provided
guards. Always observe the pertinent safety regulations.
4. Switch off the main switch or pull the power plug for threading, changing the
bobbin, exchanging sewing tools such as needle, hook, stitch plate, transport
devices, trimming knive and cutting block, for cleaning and when leaving the
workplace as well as for maintenance.
5. General maintenance tasks may be carried out only by properly trained persons
in accordance with the operating instructions.
6. Repair work, retrofitting and maintenance may be carried out only by
technicians or specially trained personnel.
7. When servicing or repairing pneumatic equipment, the machine must be
disconnected from the pneumatic supply. Exceptions are only allowed for
adjustment work and tests of functionality performed by specially trained
technicians.
8. Only specially qualified technicians may work on the electrical equipment.
9. It is forbidden to work on electrically live components! Exemptions are covered
by the EN50110 (DIN VDE0105) regulations.
10. Any retrofitting or alterations to the machine may only be performed under
strict compliance with all pertinent safety regulations.
11. Only use our approved spare parts when servicing and/or repairing the machine.
12. It is forbidden to operate the sewing head until it is determined that the entire
sewing unit complies with EU provisions.

6 BA_58_A17_220628_en.doc
13. It is essential that you observe and follow these instructions as well as the
generally valid safety regulations.
14. Warning instructions given in the operating instructions that pertain to
especially dangerous parts of the machine must be indicated at these positions
using a safety symbol.
Warning instructions given in the operating instructions that pertain to special
injury hazards for operating personnel or technicians must be indicated at these
positions using a safety symbol.

7 BA_58_A17_220628_en.doc
2General
2.1 Operating instructions
Any person involved in the installation, operation, maintenance and repair of the
machine must have read and understood the operating instructions and mainly the
safety instructions before starting the machine.
2.2 Class description, serial number and initial basis for description
For side-referenced descriptions, the operating side of the machine is the starting
base.
The class descriptions (type), the serial and model number (after the hyphen) can be
found on the rating plate on the back of the machine.
2.3 Range of application and intended use
The class 58-4D is for the Roll padding of lapels and collars, Flat padding of chest
pieces and interlinings, attaching facings and Blind stitching of breaktape.
The range of applications of the different machines can be extended by exchanging
the variable sewing tools, i.e. that other fabric qualities than the above mentioned
ones can be sewn as well.
Variable sewing tools please see point 7.

8 BA_58_A17_220628_en.doc
2.4 Technical data
Empfohlene Nennstichzahl /
Recommended rated speed
3200 min-1
Stichlänge / stitch length
5,0 - 8,0 mm (abhängig vom Nähmaterial /
depend on fabric)
Auslieferzustand / delivery condition 8,0 mm
Obertransport / top feed
Sägeverzahnung /saw toothing
einstellbarer starrer Drücker für die
verschiedenen Arbeitsgänge /
adjustable fixed plunger for different
applications
Stichplattenöffnung / stitch plate opening
7,0 mm
4,5 mm optional
6,0 mm optional
Stichtiefenanzeige / stitch depth display
digital display
Nadelsystem / needle system
Nadelstärke / needle size
GROZ-BECKERT 4669 EEO
80/12
Fadenabschneider / thread trimmer
optional
Fadenspannung / thread tension
Faden / thread
Auslieferzustand / delivery condition 16 cN bei
Revers / lapels
Polyester, endlos gezwirnt /
polyester continuous filament 120/2
Durchgangsraum / arm space
240 mm
LED Leuchte / LED sewing lamp

9 BA_58_A17_220628_en.doc
Technischer Auslieferzustand / delivery condition:
Riemenscheibendurchmesser Maschine/
machine pulley diameter
dw 80 mm
Motor-Leistung min. / min. motor power
550 W
Keilriemen-Profil / V-belt profile
10 x 6 mm
Zahnriemenscheibe Maschine /
toothed belt pulley/machine
Z = 38
Zahnriemenprofil / toothed belt profile
HTD 5M-9
Stichart / stitch type
Einfaden-Kettenstich-Blindstich Typ 103 /
single thread chain stitch type 103
Anschluss pneumatisch / pneumatic connection
6 bar
Luftverbrauch, Mittelwert /
avarage air consumption
abhängig von der Ausstattung /
depending on the equipement
Stellfläche / Foot print
0,5 m x 1,1 m
Arbeitsgeräusch / operating noise at 3200 min-1
nach DIN 45635-48-1 KL3
LpAm 79,5 dB(A)

10 BA_58_A17_220628_en.doc
3Installation and putting into service
3.1 Unpacking the machine
Strobel machines are supplied either as complete units with head, stand and motor, or
head with motor only, or the head only.
Reel stand, rods and other accessories are packed into the packing.
Make sure that all accessories have been unpacked before throwing away any packing
material.
3.2 Installation
C A U T I O N ! Danger of injury!
Danger of bodily injuries or finger bruises through pulling in of
garments or hairs!
The machine may not be operated without belt guards for head
and motor.
If the machine head is supplied without stand and motor first make the borings into
the table top as shown in the drawing. Mount rods and treadles and electric
connections according to the connecting diagram.
Screw on the motor. The electrical connection must be made according to the circuit
diagram in the online manuals.
Mount the head with the rubber plate (1) to the table top according to Fig. 1 using 3
screws (2), 3 washers (3) and 3 hex nut (4).
Mount the V-belt and tense it according to “3.4.1 Tensioning the V-belt”.
Mount the belt guard.
Mount the lifting and motor operating rods as shown in Fig. 1.
Using a compact motor means to assemble the control box and setpoint device under
the table. Also the connecting rod between setpoint device and pedal has to be
connected.
Make sure that all screws on the stand are tight and retighten them, if necessary.
The position generator must be fitted if available. The correct position to the flange
(handwheel) is marked with a spot of paint. Both clamping screws must be tightened
firmly.
Check positions according to point “3.4.2 Positions of the machine” and adjust if
necessary.

11 BA_58_A17_220628_en.doc
Fig. 1
A T T E N T I O N !
Before putting the machine into service make sure that the
electric connecting data on the motor's name plate, mainly
voltage and frequency, correspond to your electric network.
A T T E N T I O N !
The machine must be oiled before first start. The maintenance
instructions according to the operating instructions must be
followed!

12 BA_58_A17_220628_en.doc
3.3 Sense of Rotation
The correct turning of the hand wheel is clockwise in line of vision on the hand wheel.
3.4 Motor drive via V-belts
3.4.1 Tensioning the V-belt
C A U T I O N ! Danger of injury!
When checking the belt tension, switch off the machine at the
mains. Do not operate the machine without the belt guard.
Otherwise there is a Danger of crushing fingers, of injuries to
the body and of pulling in parts of clothing.
The tensioning of the V-belt is carried out by swivelling the motor underneath the
table plate after releasing the retaining nut with SW 24, (1) in Fig. 2.
The V-belt must not be tensioned too much, especially with the stop motor. You
should be able to compress it with light thumb pressure by about 2 cm.
Too little V-belt tensioning can impair the positioning of the machine and therefore
impair the function sequence.
Fig. 2

13 BA_58_A17_220628_en.doc
3.4.2 Positions of the machine
C A U T I O N ! Danger of injury!
Danger of crushing fingers and needle through stitching as well
as pulling in of parts of clothing.
Keep fingers and hands away from moving parts when setting
the position generator and checking the positions with switched-
on machine.
General:
Stop motors require a position generator, which takes the mechanical setting of the
machine from the main screw and transmits this to the control of the motor. With
this, for instance, the thread cutter can always be electrically approached in exactly
the same needle looper position. (Fig. 3)
The correct position of the position generator to the flange is marked with a spot of
paint.
To adjust or to remove, release the two clamping screws (1), Fig. 3. tighten these
firmly prior to commissioning.
Fig. 3
With positioning with plunger reset, the motor reverses after thread cutting for a
certain value, to facilitate the insertion of the sewing matter. This does not affect the
setting of the position generator.

14 BA_58_A17_220628_en.doc
Machine with or without thread cutter:
The machine requires a needle position and, depending on the sewing drive, possibly
also a reference position.
Reference (Fig. 4):
The reference position must be set in such a way, that the point of the needle in
the direction of the insertion stitch closes with the right (inner) edge of the
needle slide plate.
Fig. 4
Needle position (with stop in and outside the seam (Fig. 5)):
The needle position must be set in such a way, that with the machine stopped,
the hook of the thread knife catches the thread loop lying over the looper
securely without touching the looper.
Afterwards check by manually activating the thread cutter.
Fig. 5
Notes for sewing drives which have two needle positions:
The above mentioned needle position is position 2 at the sewing drive.
It is essential that position 1 is set with consultation of the operating instructions
of the sewing drive.

15 BA_58_A17_220628_en.doc
3.5 Motor drive via toothed belt
3.5.1 Tensioning the toothed belt (Fig. 6)
C A U T I O N ! Danger of injury!
Switch off the machine at the mains when checking the belt
tension. Do not operate the machine without belt guard.
Otherwise Danger of crushing fingers, of injuries to the body or
of pulling in of part of clothing.
The toothed belt should not be tensioned too much. You should be able to compress
it with light thumb pressure by about 5 mm.
Too little or too tight toothed belt tensioning can impair the positioning of the
machine and therefore impair the function sequence.
Tensioning the toothed belt (Fig. 6):
- Release the upper and the bottom retaining screw (1), (2) at the upper part of
the machine.
- Pull out the motor slightly and tighten the bottom retaining screw (2) slightly.
- Tension the toothed belt by swivelling the motor.
- Tighten the upper and the bottom retaining screw (1), (2) again.
Fig. 6

16 BA_58_A17_220628_en.doc
3.5.2 Positions of the machine
C A U T I O N ! Danger of injury!
Danger of pulling in parts of clothing and of hair and danger of
crushing fingers and stitching fingers with needles!
When checking positions with switched-on machine keep fingers
and hands away from moving parts.
Machine with or without thread cutter:
The machine requires a needle position and depending on the sewing drive, possibly
also a reference position.
Reference position (Fig. 4):
The reference position must be set in such a way, that the point of the needle in
direction of the insertion stitch closes with the right (inner) edge of the needle
slide plate.
Needle position (with stop in and outside the seam (Fig. 5)):
The needle position must be set in such a way, that with the machine stopped,
the thread knife catches the thread loop lying over the looper securely without
touching the looper.
Afterwards check by manually activating the thread cutter.
Notes for sewing drives which have two needle positions:
The above mentioned needle position is position 2 at the sewing drive.
It is essential that position 1 is set with consultation of the operating instructions
of the sewing drive
Needle position (when stopped within the stitch):
The needle position must be set so that the tip of the needle closes against the
right edge of the needle slide plate facing towards the outward stitch.
At the same time, the thread loop lies under tension across the looper.
The needle position is position 1 at the sewing drive.
Fig. 7
