Anmytek H0037 Installation guide

Contact Us: [email protected]
C
1 HOUR 2 PEOPLE
2 x 1 m
H0037
3 Drawers Storage
Dresser Chest

CARE AND CLEANING
SAFETY PRECAUTIONS
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND USING THE PRODUCT.
2
1.
2.
3.
4.
5.
6.
7.
8.
9.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Please periodically check all fings and re-ghten as necessary.
• To clean your item, please use a damp cloth and wipe clean.
• Never allow any kind of liquid to remain on your furniture. If liquid spills onto the
product, please wipe clean as soon as possible.
WA RNING : ENSURE THE WA LL STRA P IS AT TACHED TO
AVOID SERIOUS INJURY .
To avoid any serious or fatal injury, this product has been fied with a wall strap to
prevent toppling. We strongly recommend that this product is permanently fixed to the
wall or other suitable surface. Fixing devices are not included since different surface
materials require different aachments. Please seek professional advice
if you are in doubt of what fixing device to use.
Do not stand on the product. Do not climb on the product. Do not swing on the product.
Item No. : XXXX
Item No. : H0037
Contact Us : [email protected]
Contact Us : [email protected]
Please check that all parts are present beforeyou start the assembly of your furniture. A Philips
head screwdriver (not included) is required for the assembled of this product.
For ease and speed of assembly, we recommend that before you commence each step
of the assembly, that you idenfy all the parts required for that step.
For larger items, please ensure that you have sufficient space and people to assemble your
product safely.
We recommend that, where possible, all items are assembled near to the area in which they
will be placed in use, to avoid moving the product unnecessarily once assembled.
For the protecon of your furniture, we recommend that the product is placed on a
protected surface during assembly to prevent any damage.
During assembly, Do not tighten bolts / screws completely until all bolts / screws are lined up and
inserted into holes, Do not over tighten screws and bolts to avoid stripping, Do not use power tools
Always place the product on a flat, steady and stable surface.
Do not stand on the product. Do not use the product as a stepladder.
This product is intended for indoor, household use only as it is a non industrial product.

3
PARTS LIST
Item No. : XXXX
Item No. : H0037
Contact Us : [email protected]
Contact Us : [email protected]
Ax25 Bx27 Cx27
Dx32 Ex6 Fx3
Gx3 Hx4 Ix3
Jx3 Kx12 Lx4
Mx1 Nx8 Ox8
Px2 Qx2 Rx2
Sx2 Tx12
3.5x30mm
3.5x45mm
3.5x10mm
3x12mm
3x10mm
3.5x35mm
3.5x10mm
6x35mm

Item No. : H0037
Contact Us : [email protected]
ASSEMBLY DIAGRAM
AFTER SALES SUPPORT
If you have any general enquiries or require spare parts for this product, please feel free to
contact us via the following email:
Email: [email protected]
You can contact us for support at any time. We'll answer you in 24hrs.
Contact Us : [email protected]
4
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑨ ⑩
⑪
⑫
⑫
⑬
⑭
⑭
⑮
⑮

TIPS Before ASSEMBLY
IMPORTANT:
1. Do not tighten bolts / screws completely until all bolts / screws are
lined up and inserted into holes.
2. Do not over tighten screws and bolts to avoid stripping.
What you need
• Some of your favourite fruits or your
preferred snacks.
• Use the packaging carton as a working
surface to prevent possible product damage
during assembly .
Safety First,
Fun Later
We want your Furniture Unit to last as long as possible, so we
recommend that you tighten the screws 2 weeks after assembly,and
for added safety, check the tightness of all screws every 2 months.
We do our best to ensure your F urniture arrives without any problems,
but occasionally mistakes happen - as humans we are imperfect
beings. In the event that a part is damaged or missing, we will be more
than happy to provide you with replacement part(s) for free.
For more help, you can send a message to our customer support
email servic e @anmytek.com in any time.
Ready? Ok, let’s get rolling!
This should be very easy, just follow our simple instructions
step by step and you will put it together in no time .

ASSEMBLY STEPS
STEP 1.
STEP 2.
Item No. : XXXX
Item No. : H0037
Contact Us : [email protected]
Contact Us : [email protected]
①
②③
④
⑤
B
C
⑥
A
5
Attach part (2), (3), (4) to part (1) using 5 x cam bolts (C) and 5 x cam locks (B).
Tighten with a screwdriver.
Slide panel (5) into position as shown.
Attach part (6) to assembled unit using 5 x screws (A). Tighten with a screwdriver.
A
x3

ASSEMBLY STEPS
STEP 3.
STEP 4.
Item No. : XXXX
Item No. : H0037
Contact Us : [email protected]
Contact Us : [email protected]
D
①
TE
6
Attach 2 x handles (E) to the drawer using 4 x screws (T). Tighten with a screwdriver.
F
G
Attach rail (F) to the left side of drawer as shown and secure with 2 x screws (D).
Attach rail (G) to the right side of drawer as shown and secure with 2 x screws (D).
Tighten with a screwdriver.
D
x3
x3

ASSEMBLY STEPS
STEP 5.
STEP 6.
Item No. : XXXX
Item No. : H0037
Contact Us : [email protected]
Contact Us : [email protected]
⑦⑧
DD
⑦
⑨⑨
⑩
B
B
CC
K
7
J
Attach 2 x panels (9) to the left side panel (7) using 2 x wooden dowels (K), 2 x cam bolts (C) and
2 x cam locks (B). Attach panel (10) to panel (7) using 2 x cam bolts (C) and 2 x cam locks(B).
I
Find out the correct runners (I) and (J). Fix (I) on panel (7), (J) on panel (8) using 12 x screws (D).
Don't mix (I) and (J).
For the 6 x runners (I & J), the protruding edge at the
silver button screw
end
is upward.
The end of the runners (I) and (J) are close to the seam.

ASSEMBLY STEPS
STEP 7.
STEP 8.
Item No. : XXXX
Item No. : H0037
Contact Us : [email protected]
Contact Us : [email protected]
⑧
B
B
C
C
K
⑪
⑫
B
C
8
Attach the right side panel (8) to the assembled unit using 2 x wooden dowels (K), 4 x cam bolts (C)
and 4 x cam locks (B) as shown. Tighten with a screwdriver.
Slide back panel (12) into position.
Attach the top panel (11) to assembled unit using 4 x wooden dowels (K), 4 x cam bolts (C)
and 4 x cam locks (B). Tighten with a screwdriver.

ASSEMBLY STEPS
STEP 9.
STEP 10.
Item No. : XXXX
Item No. : H0037
Contact Us : [email protected]
Contact Us : [email protected]
H
⑮
⑮
A
LM
9
Turn the furniture upside down. Attach the bottom panel (13) to assembled unit using 4 x wooden
dowels (K) and 4 x screws (H). Tighten with a screwdriver.
Attach 2 x parts (14) to 2 x parts (15) using 4 x bolts (L). Tighten with a hex key (M).
Attach the metal frame to the bottom panel using 10 x screws (A).
⑫
⑬
⑭
⑭

ASSEMBLY STEPS
Item No. : H0037
Contact Us : [email protected]
STEP 11.
STEP 12.
N
Q
R
S
Contact Us : [email protected]
10
Attach 8 x plastic wedges (N) to the back panels using 8 x screws (O).
Tighten with a screwdriver.
Attach 2 x safety straps (Q) to the back panel of furniture using 2 x screws (S) as shown.
Fasten assembled furniture to the wall using 2 x wall anchors (P), 2 x screws (R).
Ensure unit is balanced and steady before use.

WALL FIXING GUIDE
NOTE: Supplied wall plugs are only suitable for use in masonry walls.
If you have any doubts about using the correct plug for your wall, please seek professional advice. Failure of
the product due to using incorrect fixings is the responsibility of the installer.
IMPORTANT:
When drilling into walls, always check for hidden wires or pipes, etc.
Tips & Tricks
Make sure that the hardware used is suitable for supporng your unit.
Please consult a qualified trades person if unsure.
 If you are unsure, please select a larger screw and wall plug.
 Ensure that you use the recommended drill bit to match the wall plug and hole size.
 Take extra care when drilling high walls, ceiling and ceramic les. Ensure wall plugs are
inserted beyond the thickness of the ceramic les to avoid spling or cracking.
 Ensure that wall plugs are well fitted and are a ght fit in the drilled hole.
Types of Walls
Use one of the following types of wall plug (not included) if your walls are made of brick, breeze block, concrete,
stone or wood. Screws may be able to be fixed directly to solid wood walls as they will provide a secure anchor point.
1. General Purpose Wall Plug
Generally, aerated blocks should not be used to
case. For light loads, general purpose wall plugs
can be used.
2. Plasterboard Wall Plug
For use when aaching light loads onto
plasterboard parons.
3. Cavity Fixing Wall Plug
For use with plasterboard parons or hollow
wooden doors.
4. Cavity Fixing Heavy Duty Wall Plug
such as shelving and wall cabinets.
5. Hammer Fixing Wall Plug
For use with concrete block or brick walls, or walls
6. Shield Anchor Wall Plug Heavy Loads
For use with concrete or brick walls, or for use
with heavier loads such as TV & HiFi speakers
and satellite dishes, etc.
Item No. : XXXX
Item No. : H0037
Contact Us : [email protected]
Contact Us : [email protected]
11
