Style selections SRPH33C-546S User manual

If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
An LP-cylinder not connected for
use shall not be stored in the vicinity
of this or any other appliance.
DANGER
WARNING
WARNING
For Outdoor Use Only.
CAUTION:
Installer: Leave the manual instructions
to the user for future use.
Consumer: Please keep this manual
for future reference.
Read the instructions before use.
This appliance must be installed in
accordance with such regulations as
are in force.
ITEM #3159473
#11875032
MODEL #SRPH33C-546S
OUTDOOR PATIO HEATER
STYLE SELECTIONS and logo design are trademarks
or registered trademarks of LF, LLC. All rights reserved.
Français p. XXFrançais p. 26
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at
1-877-888-8225, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could
also contact us at [email protected] or visit www.lowespartsplus.com.
Serial Number
ATTACH YOUR RECEIPT HERE
Purchase Date
JS21012

TABLE OF CONTENTS
Package Contents .................................................................................................................................3
Hardware Contents ...............................................................................................................................4
Safety Information ..............................................................................................................................5-8
Preparation ............................................................................................................................................8
Assembly Instructions ......................................................................................................................9-13
Operating Instructions ....................................................................................................................15-20
Care and Maintenance ...................................................................................................................21-22
Troubleshooting ..................................................................................................................................23
Warranty ..............................................................................................................................................24
Replacement Parts List .......................................................................................................................24
2
Igniter Battery Installation ....................................................................................................................14

PACKAGE CONTENTS
Center Reflector Cap
Reflector Shields
Burner Head
Upper Pole
Lower Pole
Decorative Cap
Base
Cylinder Locking Bar
Wheel Assembly
1
4
1
1
1
1
1
1
1
PART DESCRIPTION QUANTITY
E
G
F
H
I
D
C
B
A
3
A
B
E
D
C
I
H
G
F

HARDWARE CONTENTS (shown actual size)
M6 x 10
Screw
Qty. 12
6mm
Washer
Qty. 18
M6 Nut
Qty. 15
M6 x 70
Double Pointed Bolt
Qty. 3
M6 x 14
Bolt
Qty. 8
M5 x 12
Countersunk
screw
Qty. 6
M6 x 20
Bolt-Washer
Combo
Qty. 2
AA BB CC DD EE
FF GG
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product.
4

This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance inan enclosed space such
as a camper, tent or home.
Improper installation, adjustment, alteration, service or maintenance
can cause property damage, injury or death. Read the installation, operating and
maintenance instructions thoroughly beforeinstalling or servicing this equipment.
DANGER CARBON MONOXIDE HAZARD
WARNING:
SPECIFICATION
Certification CSA
Height
90.55" (230cm)
Diameter of reflector 32.28" (82cm)
Rated heat input 48,000 BTU/hr
Fuel LP
Gas Supply 20 lb (9 kg) LP gas cylinder
Manifold pressure 11" W.C.
Diameter of injector 0.0846" (2.15mm)
Safety features Flame failure device, anti-tilt switch
Gas supply pressure Max. 250 PSI, Min. 25PSI
SAFETY INFORMATION
5

The installation must conform with local codes
or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1/NFPA 54,
NFPA58 Natural Gas and Propane Installation
Code, CSA B149.1, or Propane Storage and
Handling Code, B149.2
The heater, when installed, must be electrically
grounded in accordance with local codes or, in
the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70, or the Canadian
Electrical Code, CSA C22.1.
Children and adults should be alerted to
the hazards of high surface temperatures
and should stay away to avoid burns or
clothing ignition.
Young children should be carefully
supervised when they are in the area of
the heater.
Clothing or other flammable materials
should not be hung from the heater, or
placed on or near the heater.
Prior to use, check for damaged parts such as
hoses, regulators, pilot or burner.
All leak tests should be done with a soapy solu-
tion. NEVER USE AN OPEN FLAME TO
CHECK FOR LEAKAGE.
The propane hose with regulator assembly shall
be located out of pathways where people may
trip over it or in areas where the hose will not be
subject to accidental damage.
Any guard or other protective device
removed for servicing the heater must be
replaced prior to operating the heater.
Installation and repair should be done by
a qualified service person. The heater
should be inspected before use and at
least annually by a qualified service
person.
More frequent cleaning may be required
as necessary. It is imperative that control
compartment, burners and circulating air
passageways of the heater be kept clean.
Keeping the appliance area clear and free from
combustible materials, gasoline and other flam-
mable vapors and liquids.
Not obstructing the flow of combustion and venti-
lation air.
Keeping the ventilation opening(s) of the cylin-
der enclosure free and clear from debris.
This appliance shall be used only in a well-
ventilated space and shall not be used in a build-
ing, garage or any other enclosed area.
An appliance may be installed with shelter no
more inclusive than:
With walls on all sides, but with no overhead
cover.
Within a partial enclosure which includes an
overhead cover and no more than two side
walls. These side walls may be parallel, as in a
breezeway, or at right angles to each other.
NOTE:PLEASE READ THE FOLLOWING SAFETY RULES.
WARNING:
SAFETY INFORMATION
6

W
The pressure regulator and hose assembly sup-
plied with the appliance must be used, replace-
ment pressure regulators and hose assemblies
must be those specified by the appliance manu-
facturer.
Do not store a spare LP-gas cylinder under or
near this appliance.
Never fill the cylinder beyond 80 percent full.
Do not clean the heater with cleaners that are
combustible or corrosive.
NOTE:PLEASE READ THE FOLLOWING SAFETY RULES.
Place the dust cap on the cylinder valve outlet
whenever the cylinder is not in use. Only install
the type of dust cap on the cylinder valve that is
provided with the cylinder valve. Other types of
caps or plugs may result in leakage of propane.
Within a partial enclosure which includes an
overhead cover and three side walls, as long as
30 percent or more of the horizontal periphery of
the enclosure is permanently open.
This appliance requires 9kg(20lb) LP-gas supply
cylinder.
The LP-gas supply cylinder to be used must be:
Constructed and marked in accordance with the
specifications for LP-gas cylinders of the U.S.
Department of Transportation (DOT); or the
Standard for Cylinders, Spheres and Tubes for
Transportation of Dangerous Goods and Com-
mission, CAN/CSA-B339, as applicable;
Provided with a listed overfilling prevention
device; and provided with a cylinder connection
device compatible with the connection for the
appliance.
The cylinder be disconnected when the appli-
ance is not in use.
Storage of an appliance indoors is permissible
only if the cylinder is disconnected and removed
from the appliance.
A cylinder must be stored outdoors in a well-
ventilated area out of the reach of children. A
disconnected cylinder must have dust caps
tightly installed and must not be stored in a build-
ing, garage or any other enclosed area.
WARNING:
Certain materials or items, when stored under
the heater, will be subjected to radiant heat and
could be seriously damaged.
Inspect the visible portion of the hose before
each use of the appliance and inspect the entire
hose assembly at lease annually.
The cylinder used must include a collar to protect
the cylinder valve.
SAFETY INFORMATION
7

SAFETY INFORMATION
PRECAUTIONSPRECAUTIONS
This heater is designed to operate with a standard 20 Ib propane cylinder with Approved Cylinder
Connection.
NOTE: PLEASE READ THE FOLLOWING SAFETY RULES.
Estimated Assembly Time : 30 minutes.
Tools required for assembly (not included) :
Adjustable open end wrench.
Philips screwdriver.
Before assembling product, make sure all parts are present. Compare parts with package contents
list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the
product.
Perform a leak test with a soapy solution:
1. To check gas connections.
2. After connecting a new cylinder.
3. Upon re-assembly after disassembly.
PREPARATION
8

GG
EE
GG M6 x 20 Bolt-Washer Combo x 2
Step 1
Attach the Wheel Assembly (I) to the Base (G)
by using 2pcs M6 x 20 Bolt-Washer Combo (GG).
Hardware Used
Step 2
Attach the Lower Pole (E) to the Base (G) by using
4pcs M6 x 14 Bolt (EE), then put the Decorative
Cap (F) to the Lower Pole (E).
Hardware Used
ASSEMBLY INSTRUCTIONS
1
2
G
I
E
F
G
EE M6 x 14 Bolt x 4
9

EE M6 x 14 Bolt x 4 EE
FF
C
D
Step 3
Put the Gas Hose and Regulator (Preassembled)
of the Burner Head (C) into the Upper Pole (D),
then fix the Burner Head (C) to Upper Pole (D)
by using 4pcs M6 x 14 Bolt (EE).
Hardware Used
Step 4
Put the Gas Hose and Regulator (Preassembled)
into the Lower Pole (E), then fix the Burner Head
(C) and Upper Pole (D) to the Lower Pole (E)
by using 6pcs M5 x 12 Countersunk screw (FF).
Hardware Used
ASSEMBLY INSTRUCTIONS
3
4
E
D
C
FF M5 x 12 Countersunk screw x 6
10

DD
BB
BB 6mm Washer x 3
CC M6 Nut x 12
C
Step 5
Attach 3pcs of M6 x 70 Double Pointed Bolt (DD)
to the Burner Head (C), then put 3pcs 6mm Washer
(BB) on the M6 x 70 Double Pointed Bolt (DD).
Hardware Used
Step 6
Reflector Shields (B) using 12pcs M6 x 10 Screw
(AA), 12pcs 6mm Washer (BB) and 12pcs M6 Nut
(CC) as illustrated.
NOTE: Remove protective cover before
assembly.
ASSEMBLY INSTRUCTIONS
5
6
AA M6 x 10 Screw x 12
A
B
CC
BB
AA
BB 6mm Washer x 12
DD M6 x 70 Double Pointed Bolt x 3
11

BB
DD
CC
BB 6mm Washer x 3
A
Step 7
Attach the assembled Center Reflector Cap (A) and
Reflector Shields (B) to 3pcs M6 x 70 Double
Pointed Bolt (DD) on step 5, then fix with 3pcs 6mm
Washer (BB) and 3pcs M6 Nut (CC) as illustrated.
Hardware Used
Step 8
Open the door, fill the dry sand into the hole on the
bottom till full.
ASSEMBLY INSTRUCTIONS
7
8
CC M6 Nut x 3
B
Fill the sand into
the hole till full.
12

G
H
H
Step 9
Attach the Cylinder Locking Bar (H) tothe correct
holes on the base as illustrated, then put Gas
Cylinder into the Base (G), fix the Gas Cylinder by
pulling the Cylinder Locking Bar (H), connect the
Gas hose and Regulator tothe Gas Cylinder.
ASSEMBLY INSTRUCTIONS
9
Tighten
13

IGNITER BATTERY INSTALLATION
ignition button ignition button
AAA battery
(not included)
14

Check for leaks
All connection on the patio heater have been
checked for leakage at the factory. Follow these
steps to check the gas hose/regulator/cylinder
connections:
1) Make leakage solution by mixing 1 part liquid
dish soap and 3 parts water.
2) Spoon or brush several drops (or use squirt
bottle) of the solution onto hose connection,
regulator & cylinder connection.
3) Turn on gas cylinder valve. Inspect the
connections and look for bubbles.
4) If no bubbles appear, the connection is safe.
5) If bubbles appear, there is leakage. Loosen
and re-tighten this connection. If connection
still leaks, please call customer service:
1-877-888-8225
Note:
1) The cylinder supply system must be arranged
for vapor withdrawal;
2) The cylinder used must include a collar to
protect the cylinder valve.
WARNING : ONLY AN AUTHORIZED GAS TECHNICIAN SHOULD INSTALL THIS PRODUCT.
OPERATING INSTRUCTIONS
hose
connection
brush
regulator & cylinder
connection
15

i. Hose checking step:
(1) Unscrew M6 X 14 screw from the pole.
(2) Pull out the head assembly, hose &
regulator from the pole.
(3) Check if there are cracks or owrn
sections on the hose. If yes, replace the
hose & regulator immediately.
(4) Check for leaks according to the above
step by step after replacing the
hose & regulator.
WARNING: ONLY AN AUTHORIZED GAS TECHNICIAN SHOULD INSTALL THIS PRODUCT.
e. If no bubbles appear, the connection is safe.
f. If bubbles appear, there is a leak. Shut off
the LP gas cylinder valve, loosen and then
re-tighten this connection.
line 1-877-888-8225. Do not attempt
to use the heater.
OPERATING INSTRUCTIONS
16

Push in gas control knob and turn counter-clockwise to
"PILOT" position, at the same time push in the ignition
button and keep the button depressing until light the
pilot.
Once the pilot is lit, continue to keep the control knob
depressed for at least 30 seconds, then release control
knob.
OPERATING INSTRUCTIONS
17
IGNITE
ALLUMER
P
U
S
H
T
O
T
U
R
N
P
O
U
R
T
O
U
R
N
E
R
/
O
F
F
É
T
E
I
N
D
R
E
H
I
G
H
H
A
U
T
E
L
O
W
F
A
I
B
L
E
P
I
L
O
T
/
P
I
L
O
T
E
P
R
E
S
S
E
R
IGNITE
ALLUMER
P
U
S
H
T
O
T
U
R
N
P
O
U
R
T
O
U
R
N
E
R
/
O
F
F
É
T
E
I
N
D
R
E
H
I
G
H
H
A
U
T
E
L
O
W
F
A
I
B
L
E
P
I
L
O
T
/
P
I
L
O
T
E
P
R
E
S
S
E
R

If pilot does not stay lit, repeat steps 3 and 4 after 5 minutes.
If pilot still does not stay lit, then:
a) Push in gas control knob and turn counter clockwise to the
"PILOT" position.
b) keep depressing the control knob, put long stem lighter into
the ignition hole on the emitter screen to light the pilot.
c) Repeat step 4.
Push in and turn control knob counter clockwise to "HIGH"
position, If you want a lower temperature, push in the
control knob and turn clockwise to the "LOW" position.
OPERATING INSTRUCTIONS
18

pilot.
OPERATING INSTRUCTIONS
19
IGNITE
ALLUMER
P
U
S
H
T
O
T
U
R
N
P
O
U
R
T
O
U
R
N
E
R
/
O
F
F
É
T
E
I
N
D
R
E
H
I
G
H
H
A
U
T
E
L
O
W
F
A
I
B
L
E
P
I
L
O
T
/
P
I
L
O
T
E
P
R
E
S
S
E
R
IGNITE
ALLUMER
P
U
S
H
T
O
T
U
R
N
P
O
U
R
T
O
U
R
N
E
R
/
O
F
F
É
T
E
I
N
D
R
E
H
I
G
H
H
A
U
T
E
L
O
W
F
A
I
B
L
E
P
I
L
O
T
/
P
I
L
O
T
E
P
R
E
S
S
E
R

LOCA
CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT, ABOVE, BESIDE OR UNDER
THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE
SERIOUSLY DAMAGED.
This heater is primarily used for the heating of
outdoor patios, decks, spas, pools and open
working areas.
Always make sure that adequate fresh air
ventilation is provided. Follow the spacing
tolerances shown in the following figure right at
all times.
This heater must be placed on level, firm
ground.
Never operate in an explosive atmosphere.
Keep away from areas where gasoline or other
flammable liquids or vapors are stored or used.
OPERATING INSTRUCTIONS
20
