Suburban OXYGEN THERAPY DOOR 12155-00-DRDRAA User manual

Owner’s Manual
Oxygen Therapy Door
 Converts standard Regal cage into an
oxygen therapy chamber
 Models to fit most single-door Regal cages
 Door-mounted thermometer/hygrometer
 Outside compartment for nebulizer and ice
New Model Numbers:
12155-00-DRDRAA, 12155-00-DREPAA, 12155-00-EPDRAA,
12155-00-EPEPAA, 12155-00-EPFNAA, 12155-00-EPHJAA,
12155-00-FNFNAA, 12155-00-FNHJAA
Former Model Numbers:
102563-1, 102566-1, 102564-1, 102567-1, 102568-1, 102570-1,
102573-1, 102575-1
Form No. 702703 Rev. E 08/06
SSCI
Wheeling, IL [phone]

© Copyright 2006 by Suburban Surgical Co., Inc. All rights reserved.
No part of this document may be reproduced or utilized in any form or by any means, electronic or mechanical,
including photocopying, recording, or by any information storage and retrieval system without written permission.
Inquiries should be addressed to Suburban Surgical Co., Inc.
Wheeling, Illinois 60090, USA
Warning: Oxygen is a highly combustible gas. Avoid the use of open
flames, smoking materials, or equipment capable of producing sparks
in any area in which oxygen is being used.

Form No. 702703 Rev. E August, 2006 i
Owner’s Manual - Oxygen Therapy Door
Table of Contents
Chapter 1 - General Information ................................................................. 1
Introduction ................................................................................................................................1
About this Manual ...................................................................................................................... 1
Information and Safety Notices ................................................................................................... 2
Notes ............................................................................................................................. 2
WARNINGS ................................................................................................................. 2
Models ....................................................................................................................................... 2
Care and Cleaning of Stainless Steel ............................................................................................ 3
Introduction .................................................................................................................... 3
Cleaning and Cleansers ................................................................................................... 3
DeodorizingAgents, Disinfectants and Sanitizers .............................................................. 4
Effect on Warranty .......................................................................................................... 4
Safety ......................................................................................................................................... 4
Cleaning Requirements ................................................................................................................ 4
SSCI Contact Information .......................................................................................................... 5
Warranty .................................................................................................................................... 5
Chapter 2 - Installation and Setup............................................................... 7
Unpacking and Inspection ........................................................................................................... 7
Parts Included ............................................................................................................................ 7
Installation and Setup .................................................................................................................. 7
Tools Required ............................................................................................................... 7
Procedure ...................................................................................................................... 8
Disposition of the Shipping Carton .............................................................................................. 9
Chapter 3 - Operating and Cleaning ......................................................... 11
Door and Latch ........................................................................................................................ 11
Door Seals ................................................................................................................... 11
Opening and Closing ..................................................................................................... 11
LatchAdjustment .......................................................................................................... 11
Ice Tray .................................................................................................................................... 12
Gauges ..................................................................................................................................... 12
General ........................................................................................................................ 12
Cautions ....................................................................................................................... 12
Maximum/Minimum Temperature and Humidity Recording ............................................. 13
Changing Between °C and °F Displays .......................................................................... 13
Replacing the Gauge Battery ......................................................................................... 13
Using the Nebulizer ................................................................................................................... 14
Oxygen Concentration Control .................................................................................................. 15

ii SSCI - Suburban Surgical Company, Inc.
Table of Contents
Cleaning Instructions ................................................................................................................. 16
Introduction .................................................................................................................. 16
Stainless Steel Cleaning Procedures .............................................................................. 16
Clear Polycarbonate Cleaning Procedures ..................................................................... 16
Ice Tray Cleaning Procedures ....................................................................................... 16
Nebulizer Cleaning Procedures ..................................................................................... 16
Chapter 4 - Repairs and Replacements ....................................................17
Replacement Parts .................................................................................................................... 17
General Information .................................................................................................................. 18
Parts Ordering Procedure ......................................................................................................... 18
Procedures ............................................................................................................................... 19
Nebulizer Assembly, Complete ...................................................................................... 19
Tool Required ............................................................................................. 19
Procedure .................................................................................................. 19
NebulizerAssembly, Partial ........................................................................................... 20
Nebulizer Oxygen Supply Hose .................................................................................... 20
Nebulizer Hose Barb Fitting .......................................................................................... 21
Tools Required ........................................................................................... 21
Procedure .................................................................................................. 21
Nebulizer Extension ...................................................................................................... 22
Nebulizer Cotter Pin ..................................................................................................... 22
GaugeAssembly ........................................................................................................... 22
Overview ................................................................................................... 22
Tools Required ........................................................................................... 22
Removal - Old-style Gauge ......................................................................... 22
Removal - New-style Gauge ....................................................................... 23
Installation of New-style Gauge ................................................................... 23
Ice Tray ........................................................................................................................ 25
Ice Tray Valve .............................................................................................................. 25
Tools Required ........................................................................................... 25
Procedure .................................................................................................. 25
Seal Strip Retainer and Seal Strip .................................................................................. 26
Parts Identification ...................................................................................... 26
Tools Required ........................................................................................... 26
Procedure .................................................................................................. 26
Chapter 5 - Troubleshooting .....................................................................29
General .................................................................................................................................... 29
Returning the Oxygen Therapy Door for Repairs ....................................................................... 30
RMA Numbers ............................................................................................................. 30
Packing and Shipment ................................................................................................... 30
There is no oxygen flow into the cage. ....................................................................................... 31
There is excessive oxygen leakage from the cage. ...................................................................... 32
The door does not close or latch correctly. ................................................................................ 33
One or both of the gauges does not read correctly. .................................................................... 34

Form No. 702703 Rev. E August, 2006 1
Owner’s Manual - Oxygen Therapy Door
Introduction The SSCI Oxygen Therapy Door transforms your standard Regal
cage into an oxygen therapy chamber. The clear door features a
continuous-flow nebulizer with .25 in (.635 cm) inner diameter x
.062 in (.16 cm) thick tubing to deliver a regulated flow of
medicated, moist oxygen.
A thermometer/hygrometer mounted on the door monitors cage
temperature and humidity for optimal treatment. The clear
polycarbonate door allows you to view the animal at all times.
A detachable compartment on the outside holds the oxygen
nebulizer and ice to cool the oxygen if needed. The door mounts
onto the front of the cage in place of the regular door, and uses
standard hinges and latches to close securely. Rubber door seals on
all four sides of the door are open at the corners to uniformly
distribute oxygen and exhaust carbon dioxide.
Every attempt has been made to insure that the information in this
manual is correct and complete. SSCI, however, always welcomes
our customer’s suggestions for improvements to our products and
associated publications.
About this Manual
Chapter 1 - General Information
