Subzero UC-24R Guide

REVISED 1/2021
Undercounter Refrigeration
Design Guide

Features and specifications are subject to change at any
time without notice. Visit subzero.com/specs for the
most up-to-date information.
Throughout this guide, dimensions may vary by ± ⁄" (3).
Dimensions in parentheses are millimeters unless other-
wise specified.
UNDERCOUNTER MODELS
UC-24R UC-24BG UC-24C(I)
UC-24RO
Undercounter Refrigeration
Sub-Zero Undercounter refrigeration is a
helpful addition to a master suite, bar, home
oce, or media room. The design flexibility of
these compact yet roomy units makes them
all the more welcome in any room or outdoor
kitchen. Undercounter wine models feature
cherrywood-faced racks and soft lighting. Model
UW-24FS has a finished stainless steel exterior
for a freestanding application. The outdoor
model comes with a stainless steel door panel
and pro handle—all other models are ready to
be fitted with a custom panel and handle or
can be ordered with a stainless steel panel and
handle.
Undercounter Refrigeration
UNDERCOUNTER WINE MODELS
UW-24 UW-24FS

subzero.com | 3
Undercounter Refrigeration
237/8" (606)
26" (660) 8"
(203)
24" (610)
34"
(864)
253/8"
(645)
4" (102)
Overall Dimensions
UNDERCOUNTER MODELS IMPORTANT NOTE: Overall dimensions are based on the
stainless steel models. Refer to page 9 for door clearance
information.

4 | Sub-Zero Customer Care 800.222.7820
Freestanding model UW-24FS has a finished stainless steel
exterior and handle.
IMPORTANT NOTE: Overall dimensions are based on the
stainless steel models. Refer to page 9 for door clearance
information.
237/8" (606) 24" (610)
34"
(864)
4" (102)
253/8"
(645)
13/4" (44)
Overall Dimensions
WINE MODEL UW-24 WINE MODEL UW-24FS
253/8"
(645)
13/4" (44)
241/4" (616) 245/8" (625)
343/16"
(868)
4" (102)
Undercounter Refrigeration

subzero.com | 5
Undercounter Refrigeration
DUAL INSTALLATION
If two units are installed side by side, a dual installation kit
may be required. Installations without a custom filler strip
require a dual installation kit. If a dual installation kit is not
specified, a 2" (51) filler strip is recommended between the
units. Dual installations without a filler strip can only be
accomplished using two units with opposite hinges. Refer
to the illustrations below.
Dual installation kits are available through an authorized
Sub-Zero dealer. For local dealer information, visit the
find a showroom section of our website, subzero.com.
For questions regarding the installation, call Sub-Zero
Customer Care at 800-222-7820.
Opening Dimensions
UNDERCOUNTER MODELS
OPENING WIDTH W
24" Model 24" (610)
DUAL OPENING WIDTH W
Two 24" Models 48⁄" (1222)
Dual installation kit required.
WITHOUT FILLER STRIP FILLER STRIP
Opposite hinges Same side hinges
W
OPENING WIDTH
341/2"
(876)
OPENING
HEIGHT
TOP VIEW
SIDE
VIEW FRONT VIEW
NOTE:
31/2"(89) finished returns will be visible and should be finished to match cabinetry
.
3/4"(19)
TYPICAL
FRAMED
CABINETRY
W
FILLER
31/2"(89)
FINISHED
RETURN
FRAMELESS
CABINETRY
W
3/4"(19)
TYPICAL
31/2"(89)
FINISHED
RETURN
24" (610)
OPENING
DEPTH

6 | Sub-Zero Customer Care 800.222.7820
Electrical Requirements
Installation must comply with all applicable electrical codes.
Locate the electrical supply within the shaded area shown
in the illustration below. A separate circuit servicing only
this appliance is required.
If the unit will be connected to a home security system,
allow 36" (914) of excess wiring for proper connection.
IMPORTANT NOTE: The electrical outlet must be posi-
tioned with the grounding prong to the right of the thinner
blades.
IMPORTANT NOTE: For outdoor model UC-24RO, a
ground fault circuit interrupter (GFCI) is required to reduce
the risk of electrical shock. A GFCI is not recommended for
use with other Undercounter models and may cause inter-
ruption of operation.
ELECTRICAL REQUIREMENTS
Electrical Supply 115 VAC, 60 Hz
Service 15 amp dedicated circuit
Receptacle 3-prong grounding-type
3" (76)
151/2"
(394)
2"
(51)
LEFT SIDE
OF OPENING
FLOOR
Electrical supply location
Undercounter Refrigeration
3" (76)
151/2"
(394)
2"
(51)
LEFT SIDE
OF OPENING
AREA EXTENDS 1/2"(13)
FORWARD ON FLOOR
Water supply location
Plumbing Requirements
MODEL UC-24CI
Installation must comply with all applicable plumbing
codes.
For Model UC-24CI, locate the water supply line within
the shaded area shown in the illustration below. Connect
the water supply line to the house supply with an easily
accessible shut-o valve between the supply and the
unit. Do not use self-piercing valves. A saddle valve kit is
available through an authorized Sub-Zero dealer. For local
dealer information, visit the find a showroom section of
our website, subzero.com.
IMPORTANT NOTE: A reverse osmosis system can be used
provided there is constant water pressure supplied to the
unit at all times as indicated in the chart below. A copper
line is not recommended for this application.
PLUMBING REQUIREMENTS
Water Supply ⁄" OD copper, braided stainless
steel, or PEX tubing
Pressure 20–100 psi (1.4–6.9 bar)
Excess Line for Connection 36" (914)

subzero.com | 7
Undercounter Refrigeration
Custom Panel
For overlay models, a custom door panel and handle
hardware must be provided. Refer to the charts for panel
requirements and dimensions.
Finish all sides of the custom panel. They may be visible
when the door is open or through the window of glass
door models.
A D-style handle is recommended. Locate the door handle
near the edge of the panel opposite the hinge and cen-
tered top to bottom.
Model UW-24FS has a finished stainless steel exterior that
is designed to be used in a freestanding application.
PANEL REQUIREMENTS
WEIGHT PER PANEL MAX
UC-24R, UC-24C(I) 20 lb (9 kg)
UC-24BG, UW-24 10 lb (5 kg)
PANEL THICKNESS MIN
All Panels ⁄" (16)
GLASS DOOR
For models UC-24BG and UW-24, the custom door panel
will attach directly to the door frame with screws through
a series of pre-drilled holes.
Do not install a solid panel on a glass door unit. A solid
door is available as a sales accessory and must be installed
if a solid panel is specified. Service may be required to
install the door. Contact an authorized Sub-Zero dealer
for more information. Overall dimensions are the same for
glass and solid door panels.
OVERLAY PANEL DIMENSIONS
H
W
H
W
AA
A
A
PANEL DIMENSIONS
MODEL W H
Undercounter Model 23⁄" (603) 30⁄" (764)
STILES / RAILS A
UC-24BG, UW-24 2⁄" (57) min
DOOR CLEARANCE
Undercounter models can be installed flush with surround-
ing cabinetry. Depending on the thickness of the custom
door panel, it may be necessary to install the unit ⁄" (6)
beyond the front surface of adjacent cabinetry to prevent
interference when the door is opened to 145°. Refer to the
full-scale template on page 9.
STANDARD HANDLES
Optional stainless steel tubular and pro handles are avail-
able through an authorized Sub-Zero dealer. For local
dealer information, visit the find a showroom section of
our website, subzero.com. Refer to the chart below for
standard handle lengths.
HANDLE LENGTH TUBULAR PRO
Undercounter Model 24⁄" (616) 22⁄" (572)
Outdoor Model NA 15⁄" (399)
UC-24R, UC-24C(I) UC-24BG, UW-24

8 | Sub-Zero Customer Care 800.222.7820
WOOD FACING WIDTH W
UW-24, UW-24FS 19⁄" (495)
Wine Rack Wood Facing
FULL-SCALE TEMPLATE
The natural cherrywood facing on wine storage racks
can be stained and sealed, or replaced with wood more
complementary to surrounding cabinetry. Refer to the
full-scale templates for the profile dimensions of the wood
facing and the charts for the width.
WOOD FACING WIDTH W
UC-24BG 19⁄" (495)
UC-24C(I) 19⁄" (495)
Wood facing profile—Models UC-24BG and UC-24C(I)
11/2"
(38) 27/32"
(21)
7/64"(3)
23/64"
(9)
23/64"
(9)
1/2"
(13)
27/32"
(21)
1/4"
(6)
5/8"
(16)
9/16"
(14)
5/64"
(2)
5/64"
(2)
9/16"
(14)
7/64"
(3)
424G, UW-24, 424FSG
UW-24FS, WS-30, BW-30
IW
-18, IW-24,
IW
-30, IW-30R
7/32"(6)
Undercounter Refrigeration
Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowflake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf &
Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.
All other trademarks are property of their respective owners in the United States and other countries.
11/2"
(38)
23/64"
(9)
1/2"
(13)
27/32"
(21)
1/4"
(6)
9/16"
(14)
5/64"
(2)
7/64"
(3)
7/32"(6)
Wood facing profile—Models UW-24 and UW-24FS

subzero.com | 9
DOOR CLOSED
UNDERCOUNTER
UNIT
ADJACENT
CABINETRY
3/4"(19) DOOR PANEL
1/2"
(13)
1/8"(3)
1/4"(6)
HINGE AT 145°
OPENING
(DOOR OPENS PAST 145°)
1" (25)0"
SCALE
145° door opening (top view)
Door Clearance
FULL-SCALE TEMPLATE
To allow for a 145° door opening, the unit should
extend a minimum of ⁄" (6) beyond the front surface of
adjacent cabinetry. The unit can be installed flush, how-
ever, there is potential for interference with the panel if
the door is opened past 90°.
Undercounter Refrigeration

10 | Sub-Zero Customer Care 800.222.7820
Sub-Zero Residential Limited Warranty
FOR RESIDENTIAL USE
FULL TWO YEAR WARRANTY*
For two years from the date of original installation, this Sub-Zero product warranty covers all parts and labor to repair or replace,
under normal residential use, any part of the product that proves to be defective in materials or workmanship. All service provided
by Sub-Zero under the above warranty must be performed by Sub-Zero Factory Certified Service, unless otherwise specified by
Sub-Zero, Inc. Service will be provided during normal business hours.
FULL FIVE YEAR SEALED SYSTEM WARRANTY
For five years from the date of original installation, this Sub-Zero product warranty covers all parts and labor to repair or replace,
under normal residential use, these parts that prove to be defective in materials or workmanship: compressor, condenser, evapora-
tor, drier and all connecting tubing. All service provided by Sub-Zero under the above warranty must be performed by Sub-Zero
Factory Certified Service, unless otherwise specified by Sub-Zero, Inc. Service will be provided during normal business hours.
LIMITED TWELVE YEAR SEALED SYSTEM WARRANTY
For twelve years from the date of original installation, Sub-Zero will repair or replace the following parts that prove to be defective in
materials or workmanship: compressor, condenser, evaporator, drier and all connecting tubing. If the owner uses Sub-Zero Factory
Certified Service, the service provider will repair or replace these parts with the owner paying for all other costs, including labor. If
the owner uses non-certified service, the owner must contact Sub-Zero, Inc. (using the information below) to receive repaired or
replacement parts. Sub-Zero will not reimburse the owner for parts purchased from non-certified service or other sources.
TERMS APPLICABLE TO EACH WARRANTY
The warranty applies only to products installed for normal residential use. The warranty applies only to products installed in any one
of the fifty states of the United States, the District of Columbia or the ten provinces of Canada. This warranty does not cover any
parts or labor to correct any defect caused by negligence, accident or improper use, maintenance, installation, service or repair.
THE REMEDIES DESCRIBED ABOVE FOR EACH WARRANTY ARE THE ONLY ONES THAT SUB-ZERO, INC. WILL PROVIDE, EITHER
UNDER THIS WARRANTY OR UNDER ANY WARRANTY ARISING BY OPERATION OF LAW. SUB-ZERO, INC. WILL NOT BE RESPON-
SIBLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING FROM THE BREACH OF THIS WARRANTY OR ANY OTHER
WARRANTY, WHETHER EXPRESS, IMPLIED OR STATUTORY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you. This warranty gives you specific legal rights and you may also have other legal rights that vary from state to state.
To receive parts and/or service and the name of Sub-Zero Factory Certified Service nearest you, contact Sub-Zero, Inc., P.O. Box
44848, Madison, WI 53744; check the Product Support section of our website, subzero.com, email us at customerservice@subzero.
com, or call 800-222-7820.
*Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited 60-day parts and labor warranty
for cosmetic defects.
*Replacement water filters and air purification cartridges are not covered by the product warranty.
Warranty

subzero.com | 11
Sub-Zero Outdoor Limited Warranty*
FOR RESIDENTIAL USE
FULL ONE YEAR WARRANTY**
For one year from the date of original installation, this Sub-Zero product warranty covers all parts and labor to repair or replace,
under normal residential use, any part of the product that proves to be defective in materials or workmanship. All service provided
by Sub-Zero under the above warranty must be performed by Sub-Zero Factory Certified Service, unless otherwise specified by
Sub-Zero, Inc. Service will be provided during normal business hours.
FULL FIVE YEAR SEALED SYSTEM WARRANTY
For five years from the date of original installation, this Sub-Zero product warranty covers all parts and labor to repair or replace,
under normal residential use, these parts that prove to be defective in materials or workmanship: compressor, condenser, evapora-
tor, drier and all connecting tubing. All service provided by Sub-Zero under the above warranty must be performed by Sub-Zero
Factory Certified Service, unless otherwise specified by Sub-Zero, Inc. Service will be provided during normal business hours.
TERMS APPLICABLE TO EACH WARRANTY
The warranty applies only to products installed for normal residential use. The warranty applies only to products installed in any one
of the fifty states of the United States, the District of Columbia or the ten provinces of Canada. This warranty does not cover any
parts or labor to correct any defect caused by negligence, accident or improper use, maintenance, installation, service or repair.
THE REMEDIES DESCRIBED ABOVE FOR EACH WARRANTY ARE THE ONLY ONES THAT SUB-ZERO, INC. WILL PROVIDE, EITHER
UNDER THIS WARRANTY OR UNDER ANY WARRANTY ARISING BY OPERATION OF LAW. SUB-ZERO, INC. WILL NOT BE RESPON-
SIBLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING FROM THE BREACH OF THIS WARRANTY OR ANY OTHER
WARRANTY, WHETHER EXPRESS, IMPLIED OR STATUTORY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you. This warranty gives you specific legal rights and you may also have other legal rights that vary from state to state.
To receive parts and/or service and the name of Sub-Zero Factory Certified Service nearest you, contact Sub-Zero, Inc., P.O. Box
44848, Madison, WI 53744; check the Product Support section of our website, subzero.com, email us at customerservice@subzero.
com, or call 800-222-7820.
*Product must be approved for outdoor use, designated by model and serial number.
**Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited 60-day parts and labor warranty
for cosmetic defects.
**Replacement water filters are not covered by the product warranty.
Warranty

SUBZERO.COM
