Sudvision CB04 User manual

CONTENT
1. Illustration ---------------------------------------- 1
2. Function Controls and Display ------------------- 2
3. General Instruction ------------------------------ 2
4. Safety Instructions ----------------------- 3
5. Power Up ----------------------------------- 4
6. Counting Function ------------------------ 4
7. Counterfeit Detection -------------------- 6
8. Setting the sensitivity level --------------- 7
9. Error message and Solution --------------- 8
10. Error Code and Solution ------------------- 9
11. Hopper Adjustment --------------------- 11
12. Maintenance ----------------------------- 11
13. Features --------------------------------- 11
14. Specifications ---------------------------- 12

1. Illustration
OCRL International SRL 1
www.ocrl.com.ar

2. Function Controls and Display-before operation, please be clear which model you
have bought
3. General Instruction
Being the latest generation of money counter, this model is the vanguard of our
evolution in bill counting technology. Its compact and stylish design is as remarkable a
OCRL International SRL 2
www.ocrl.com.ar

as its integrated electronics and multifunction capabilities. Different from other back-
loading counter, it employs many new function detection methods which other back-
loading counter doesn´t have. Being improved in many aspects of internal structure
which make it quite different from other counting machine, this hi-tech compact
counting machine is easy to operate and repair. It is sturdy and utterly reliable and
suitable for all kind of banking industry and store department.
We recommend the user to verify that the box contains all of the items listed here:
1. Machine body 2. Operation manual
3. Rubber roller 4. Rubber tape
5. Brush 6. Plug
7. External display (option)
4. Safety Instructions
-Read and understand all of the instructions and warnings both on the machine
and in the manual.
-Follow all warnings and instructions marked on the unit.
-This product should be operated only from the type of the power source
indicated in the user´s guide. If you are not sure of the type of power supply
in your location, consult your dealer or local power company.
-Only use the cable provided with the unit. The use of other cable may result in
electric shock, fire or cause serious damage to the unit.
-Never push objects of any kind into the unit through case slots, since they
may touch dangerous voltage points or shortcut parts, resulting in a risk of fire
or electric shock.
-Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled into the unit.
c. If unit has been exposed to rain or water.
d. If the machine has been dropped or the case has been damaged.
OCRL International SRL 3
www.ocrl.com.ar

e. If the product shows a noticeable change in performance.
-To reduce the risk of electric shock, do not disassemble this product. Take it
to qualified service personnel when service or repair work is required. Opening
or removing covers may expose you to dangerous voltages or other risks.
Incorrect reassembly can cause electric shock when the appliance is
subsequently used.
-Do not use the unit if the power cord is damaged or if the plug socket contact
is loose. Not following these instructions may result in electric shock, fire or
other hazards.
-When unplugging the power plug, do not pull it by the cord but rather grip the
plug and pull it out, not following those instruction may result in electric shock,
fire or damage to the unit.
5. Power Up
Connect the power cord to the machine (power outlet), then plug it to power
source and switch the unit on. The unit will conduct a self-checking by
spanning the feeding roller while the UV or MG1/UV functions will be
automatically turned on by default. The counting display will show ‘0’ when the
unit is ready, which means the machine is in its normal working condition.
6. Counting Function
1>Counting Function
Once the bills are correctly placed in the hopper, the machine will start
counting automatically. The number of counted bills will be shown on the
counting display. Moreover, once the bill removed from the stacker and start to
another batch counting, the counting display will start from 1 and the ‘BATCH’
display in turn will be number of last counted bills instead.
OCRL International SRL 4
www.ocrl.com.ar

Bills need to be placed correctly as indicated in the following steps:
Place the bill between the counting guides as shown in the figure 1 and figure
2. Swiftly, push the bills with a finger <see figure 3> to make them rest on the
top of the hopper plate and in the correct counting position.
Figure 1 Figure 2 Figure 3
2>Addition Function
The Addition function can be performed by pressing the ‘BATCH/ADD’ button
twice. When the ADD indicator is on, in this case, removing the counted bills
from the stacker and start another batch counting, the counting display will not
show number from 1 and will be added to previous counted quantity. Press
‘BATCH/ADD’ button again to close this function.
3>BATCH Function
Press ‘BATCH/ADD’ button to open the Batch function which indicator light is
on. The batch number shows 100, press the display ‘RESTART/- or SELECT/+’
to set up the batch number needed.
Note: The Addition function can be performed when the batch function is on. In
this case, the machine will stop automatically when its counting quantity is up
to the batch value. When starting another batch counting, the counting display
will show the total counting sum that’s added form previous counted quantity.
OCRL International SRL 5
www.ocrl.com.ar

7. Counterfeit Detection
·UV (Ultraviolet) detection function <available for the model with UV detection
or the model both with UV and MG detections>
Used to check all kinds of banknotes which contains UV feature.
The UV function is automatically turned on by default when the machine is
powered up. It can also be selected or deselected by pressing the UV button
located in the function console. If the machine detects a counterfeit note
during counting, it will stop and emit beeping sound, while the counting display
will show the message ‘E-2’ and the ‘ ’ indicator will blick (alerting the
presence of a dubious bill). The dubious bill will always be the last one in the
stacker. Remove dubious bill and press ‘BATCH’ button to continue counting.
PLEASE NOTE: there are 10 levels of UV sensitivity for selection, press ‘SET’
button for 3-5 seconds, the counting display window shows ‘OP-A’ and the
batch display window shows one digit of the number ‘OFF-10’.
Press the button ‘BATCH/ADD’ to select ‘UV’ sensitivity as required. If setting
value is higher, the Stronger UV sensitivity, if choosing OFF, the UV detection
is off, After choosing, press RESTART button to confirmed.
·MG (magnetic) detection function (available for the model with both MG and
UV detection).
Used to check all kinds of banknotes which contains MG feature.
The MG1 function is automatically turned on by default when the machine is
powered up. It also can be selected or deselected by pressing the MG button
located in the function console.
PLEASE NOTE: there are two level of MG: MG1 and MG2, MG1 detect the
banknote with low magnetism and MG2 detect the banknote with high
magnetism. They can be selected and deselected by pressing MG button. The
MG1 is automatically activated by default when powered up, pressing MG2 is
activated and MG2 indicator is on. Press MG button one time, then MG2 is
activated and MG2 indicator is on. Press MG buttons one more time to close
OCRL International SRL 6
www.ocrl.com.ar

MG function and COUNT indicator is on.
If the machine detects a counterfeit banknote during counting, it will stop
counting and emit beeping sound, while the counting display will show the
message ‘E-3’ and the ‘ ’ indicator will blink (alerting the presence of a
dubious bill).
The dubious bill will always be the last one in the stacker. Remove the dubious
bill and press ‘RESTART’ button to continue counting.
·Chain notes detection
Serving as a supplementary function, the double-note detection can be
activated when the unit is powered up. If the machine detects a double-note
during counting, it will stop and emit beeping sound. While the BATCH display
will show the message ‘E-9’ (alerting the user the presence of a double-note
bill). Take away the bill and press ‘RESTART’ button to continue counting.
Please note: the suspicious bill will be added to the counted quantity.
·Half-note detection
By default, serving as a supplementary function, the half-note detection can be
activated when the unit is powered up. If the machine detects a half-note
during counting, it will stop and emit beeping sound. While the BATCH display
will show the message ‘E-1’ (alerting the user the presence of a half-note bill).
Take away the dubious bill and press ‘RESTART’ button to continue counting.
Please note: the suspicious bill will be added to the counted quantity.
8. Setting the Sensitivity Level
Press ‘SET’ botton for 3-5 seconds to enter to set u the parameter situation.
Press ‘SELECT/+’ to change the time. Press ‘BATCH/ADD’ to choose the
sensitivity level and off/no. After choosing the level, pls., press ‘RESTART/-’ to
OCRL International SRL 7
www.ocrl.com.ar

confirm and back.
9. Error Message and Solution
The machine automatically enter the program system to self checking when
the machine is powered up, the machine enters into a self-examination system
automatically. The batch display may shows some error message when
counting. Generally speaking, the problem happens by the surface of sensor
with dust or dirt, or the sensor is covered by notes or matter. The way of
OCRL International SRL 8
www.ocrl.com.ar

solution is cleaning the sensor by brush or cloth, or take aways the note, paper
or matter, then power up the machine again.
10. Error Code and Solution
The batch display may shows some error message when counting, which
means there are some problems with the machine. Refer to the following
diagram to find way to solve it.
OCRL International SRL 9
www.ocrl.com.ar

Generally speaking, most of the above-mentioned problems may be
caused by dust or dirt inside of the machine.
Keeping the machine clean is highly recommended.
OCRL International SRL 10
www.ocrl.com.ar

11. Hopper Adjustment
-When improper feeding of bills occur, adjust the bill thickness in the hopper
by turning the bill adjustment screw located in the back of the machine to
ensure proper feeding.
-Turn it right to decrease
the thickness (see figure 4)
-Turn it left to increase the
thickness (see figure 5)
Figure 4 Figure 5
12. Maintenance
- Do not operate the unit in areas with high temperature or high humidity since
it may cause the machine to stop working or preventing it from counting
accurately.
- When not using the unit for a long period of time, remove the power plug
from the wall outlet.
- Never operate the unit under strong light.
- Clean the machine frequently after switching off and unplug the machine.
- Do not use this product in areas where it may be exposed to water or other
liquids.
- Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaner. Use a damp cloth for cleaning.
13. Features
♦Automatic detecting with UV (ultraviolet) and MG (magnetic) while counting.
♦Suitable for most currencies in the world.
♦Automating star, stop and clearing.
OCRL International SRL 11
www.ocrl.com.ar

♦With batching, adding and self-examination functions.
♦Automatic half-note detection.
14. Specifications
♦Dimension: 311mm x 256mm x 213mm
♦Countable Banknote Size: 50 x 100 ~ 90 x 185mm
♦Net Weight: 5.7kgs
♦Counting speed: >900pcs per min
♦Power Supply: □220v 50 Hz □AC110V 60Hz
♦Power Consumption: ≤80W
♦Counting Display: LCD Display
♦Counting Display: 4 Digital LED
OCRL International SRL 12
www.ocrl.com.ar
