sugar-valley Station User manual

A
B
1
9
10
15
16
17
4
5
6
88
C
1
4
5
Electronic box
pH probe
(optional - for models with pH control)
redoX probe
(optional - for models with redoX control)
Conductivity probe
(optional - for models with conductivity control)
6
1DESCRIPTION
Acid dosing pump
(optional - for models with pH control)
Acid injector
(optional - for models with pH control)
Hydrochloric acid container
(optional, for models with pH control,
not supplied with unit)
A
B
C
Filtration pump timer
Silex / glass / diatom filter
Recirculation pump
8
9
10
15
16
17
Other pool equipment
Module RF or RF/WIFI or WIFI
Free chlorine control
2SYSTEM INSTALLATION
Electrical consumption
It’s recommended to use a time delay circuit
breaker of 25 A for domestic devices and a
time delay circuit breaker of 40 A for industrial
devices. In case of sharing the power supply
with other devices please consult a technician
in order to dimension a correct installation.
MAXIMUM CONSUMPTION ST1: 35 W
* Filtration control by external timer
Filtration mode:
“Manual/ON”
110-230 V
* Filtration control by internal timer
110-230 VRelay FILTER PUMP
Filtration mode:
See section 5 -
Filtration of the General
Installation Guide
INSTALLATION GUIDE
parameter controller
PORTABLE
COLOR
DISPLAY
(TFT)
WORLDWIDE
REMOTE
CONTROL
WIFI and
MODBUS
FILTRATION
AND LIGHT
CONTROLS
UP TO
4
PARAMETERS
UPGRADE
POSSIBLE
NEW
MODEL
2016
FAN
LESS
!
Station is a complete pool controller which doses pool-chemicals in order to maintain the pool water in perfect conditions. The base
product controls the temperature, filtration periods, pool lighting and 4 additional relays. The base product is upgraded by adding the
measurement and control of up to 4 water parameters. The management of the additional parameters can also be upgraded post-
sales via “upgrade kits”.
3
4
Fuse for device 4 A
Fuse relays 4 A
5
6
Electronic box
1
2
110-230 V
Main connection 220 V
ON/OFF switch
1
2

3MAINTENANCE
During the first 10-15 days your pool system will require more attention and the following care:
Make sure the pH remains on the ideal level (7,2 - 7,5). If the pH is unusually unstable and uses a lot of acid, check the alkalinity
(recommended levels between 80 y 120 ppm).
The pool must be vacuumed and the skimmers cleaned whenever necessary to ensure perfect water conditions.
1
2
First days of maintenance
DOSING PUMPS: Check regularly to ensure that the container contains liquid to prevent the dosing pump of running dry.
The dosing pump requires maintenance (SEE INSTRUCTIONS ON BOX).
pH PROBES / redoX / CONDUCTIVITY: Probes must be cleaned whenever necessary (check every 5-6 months). To clean the probe insert
in distilled water (clear liquid). After each cleaning the probes must be calibrated. Also: the probes should never dry out and must be
kept wet if stored (when emptying the pool for winterizing, make sure to store the measuring head in water).
1
2
General maintenance
1,0 - 2,0 ppm
7,2 - 7,5
FREE CHLORINE
PH:
Fortnightly checks Monthly checks
4TROUBLESHOOTING
•Check if ON/OFF switch is illuminated.
•Check the connection wire between display and motherboard.
•Check fuse of the device 3.15 A – it could have tripped due to overload.
•Check the power supply 110V/60Hz – 230V/50Hz.
•If problem persists contact TECHNICAL SERVICE
•The maximum dosing time (standard 200 min.) is accomplished and the acid dosing pump stops in order to avoid the
acidification of the water.
•To delete the message and to restart the metering press ESC ( ). Do the following verifications in order to preclude errors on the device:
Verify if the pH probe reading is correct (if not, calibrate the probe or substitute it with a new one); Verify if the acid/base deposit is full and
if the dosing pump is working correctly; Verify the variable speed of the dosing pump.
Blank display
Alarm AL3 and pH dosing pump stopped
White flakes in the water
•The water is excessively hard and it is unbalanced.
•Balance the water and check the cell, proceeding to clean it if necessary.
•Put 1 small bag of flocculant in the skimmer and recirculate 24 hours.
WARNING
Keep chemical levels in pool as instructed in this manual.
EARTHING
All metallic components in the pool such as lamps, ladders, heat exchangers, drains or similar elements within 3 m from the pool
(10 feet) must be connected to an earth below 37 Ohms. If using heat exchangers, we recommend them to be made of titanium.
SECURITY
To avoid accidents, children should not handle this product unless supervised by an adult.
Children should be supervised at all times when in or near a spa, pool or jacuzzi.
80 - 120 ppm
30 - 50 ppm
TOTAL ALKALINITY (TAC) PH:
CYANURIC ACID
