Suhr A.C.E User manual

User Guide

2
Table of Contents
Overview � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Powering A�C�E� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Inputs & Outputs � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Controls � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Live Setup 1 � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
Live Setup 2 � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Recording Setup with Speaker Cabinet � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
Silent Recording Setup with Reactive Load � � � � � � � � � � � � � � � � � � � � � � � � 10
Silent Recording Setup with Reactive Load (Alternative) � � � � � � � � � � � � � � 11
Silent Recording Setup with Reactive Load (Filtered & Unfiltered Signals
Simultaneously)� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12
Silent Recording Setup with Reactive Load (Filtered & Unfiltered Signals
Simultaneously) Alternative� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
Sample Settings � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14
Technical Specifications � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
Warranty � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15

3
Overview
The A�C�E� (Analog Cabinet Emulator) is an active analog cabinet emulator
designed to offer guitarists a portable and convenient way to capture the
complex characteristics of a guitar speaker cabinet for a variety of recording
and live performance applications without the use of a microphone�
100% pure analog signal path from start to finish, the A�C�E� employs an ad-
vanced Multi-StageFiltering (MSF) network to generate stunningly realistic
speaker cabinet simulations that capture/bring to life all the warmth, punch
and character of a mic’d speaker cabinet to any performance without the
assistance of DSP (digital signal processing)�
A�C�E�’s on-board filtering is not your run of the mill EQ� Each control (Subs,
Highs and Presence) was carefully voiced to offer a musical range of tone
shaping versatility without becoming unrealistic, synthetic or fatiguing when
fine tuning your desired cabinet response�
Thank you for purchasing the Suhr Analog Cabinet Emulator™ (A.C.E)
Please take the time to read this manual to get the most out of the A.C.E.
The more you familiarize yourself with the features of this pedal, the more
you will enjoy its benets and maximize its potential.

4
Powering A.C.E.
DC Input*: A�C�E� accepts power from power supplies that are regulat-
ed 9 Vdc (center negative) See Technical Specifications on pg 14.
A�C�E� can also be powered internally from a 9V battery as described
below�
Installing/Replacing The Battery:
1�Unscrew the backplate of the pedal to access the battery compartment
with the battery snap located inside�
2�Plug in a 9V battery to the snap and re-screw the backplate�
NOTES:
The battery is connected when a cable is plugged into the FROM AMP
input or the LINE input and when there is no cable plugged into the DC
input.
ACE is a higher power device. A battery will last in the range of 3 hours.
Using the provided power supply is recommended for continued use.
TIP: For longer battery life, an Alkaline battery is recommended.
*WARNING: A.C.E. is NOT a Phantom Powdered device.

5
Inputs & Outputs
INPUTS
LINE: This input is for line level signals only.
NOTE: When using the line input, the INPUT level control is bypassed. Use
a signal cable for connections.
FROM AMP: This input is for Amplier Level signals. The output of an am-
plier can be plugged into this input while the amp is loaded by a suitable
load, such as a speaker cabinet or a Suhr Reactive Load. The load can
be connected to the TO SPEAKER input, which is connected in parallel to
the FROM AMP input. The load can also be connected in parallel with the
A.C.E. if the amplier has multiple available outputs.
TO SPEAKER: This input is a through connection from the FROM AMP
jack to allow the connection of a suitable load or speaker cabinet.
NOTE: When using the FROM AMP / TO SPEAKER jacks, use a speaker
cable for connections.
OUTPUTS
BALANCED: The balanced XLR output is a low impedance line level out-
put.
UNBALANCED: The unbalanced output is a low impedance line level out-
put. Use a mono 1/4” phone jack for this output.
Tip: The BALANCED output is the preferred output when driving long cable
lines. Balanced signals have the benet of rejecting injected noise from the
environment.

6
Controls
INPUT: This control functions only when using the From Amp input. It is
used to set the volume of your amp signal before it goes through the lter.
*This control can be set as desired as long as the Clip light does not turn
on. If it does, turn the Input knob counter clockwise to prevent the lter from
clipping.
SUB: This control reduces or increases the amount of low frequency bass
of the output
HIGHS: This control reduces or increases the amount of middle and high
frequencies of the output
PRESENCE: This control reduces or increases the amount of presence fre-
quencies of the output
LIFT GROUND (XLR): This switch lifts the ground on the XLR output when
ipped to the up position.
BYPASS/ACTIVE: When set to Bypass, the lter is bypassed and the out-
put is an unltered line level signal. When set to Active, the lter is engaged
as in normal operation.
PHASE (XLR): This switch ips the phase of the Balanced output (XLR)
when ipped to the up position.

7
Live Setup 1
SPEAKER CABINET
AMPLIFIER
MIXING CONSOLE
Speaker Input*
Amplifier Output*
Balanced Output
* Use speaker cable for these connections

8
Live Setup 2
SPEAKER CABINET
AMPLIFIER
MIXING CONSOLE
Speaker Input*
Amplifier Output*
Balanced Output
* Use speaker cable for these connections
With ampliers containing multiple output jacks, one output can be connected to A.C.E.’s
FROM AMP jack, while another output can be connected to the speaker cabinet directly

9
Recording Setup with Speaker Cabinet
SPEAKER CABINET
AMPLIFIER
Speaker Input*
Amplifier Output*
Balanced Output
Unbalanced Output
* Use speaker cable for these connections
I/O
HEAD PHONES
DAW
Digital Audio Workstation
SPEAKERS
Dashed line denotes al-
ternative connection. Do
not use unbalanced and
balanced outputs
simultaneously

10
Silent Recording Setup with Reactive Load
AMPLIFIER
SUHR REACTIVE LOAD
Amplifier 8 Ohm Speaker Output*
Reactive Load Unbalanced Line Out
Balanced Output
Unbalanced Output
* Use speaker cable for these connections
I/O
HEAD PHONES
DAW
Digital Audio Workstation
SPEAKERS
Dashed line denotes al-
ternative connection. Do
not use unbalanced and
balanced outputs
simultaneously

11
Silent Recording Setup with Reactive Load (Alternative)
AMPLIFIER
SUHR REACTIVE LOAD
Reactive Load Input*
Amplifier Output 8 Ohm*
Balanced Output
Unbalanced Output
* Use speaker cable for these connections I/O
HEAD PHONES
DAW
Digital Audio Workstation
SPEAKERS
Dashed line denotes al-
ternative connection. Do
not use unbalanced and
balanced outputs
simultaneously

12
Silent Recording Setup with Reactive Load (Filtered & Unltered Signals Simultaneously)
AMPLIFIER
SUHR REACTIVE LOAD
Reactive Load Input*
Amplifier Output 8 Ohm*
Balanced Output
Unbalanced Output
* Use speaker cable for these connections I/O
HEAD PHONES
DAW
Digital Audio Workstation
SPEAKERS
Dashed line denotes al-
ternative connection. Do
not use unbalanced and
balanced outputs
simultaneously

13
Silent Recording Setup with Reactive Load (Filtered & Unltered Signals Simultaneously)
Alternative
AMPLIFIER
SUHR REACTIVE LOAD Reactive Load Input*
Amplifier Output 8 Ohm*
Balanced Output
Unbalanced Output
* Use speaker cable for these connections I/O
HEAD PHONES
DAW
Digital Audio Workstation
SPEAKERS
Dashed line denotes al-
ternative connection. Do
not use unbalanced and
balanced outputs
simultaneously

14
Sample Settings
Rock (4x12 cabinet with 57 mic) Rock (More Mids)
With these sample settings, dial the Input knob to suit your amplifier�
Balanced (Single Coils) High Gain Rock (Full Bottom)

15
Technical Specications Warranty
Input Impedance: 100 KOhm
Output Impedance: 600 Ohm
Power Connector: 9Vdc, center negative, 2.1mm x 5.5mm
Operating voltage: 9Vdc, regulated
Maximum Voltage: 10Vdc
Reverse Battery Protection: Yes
Over Voltage Protection: Yes
Current Consumption: 80mA
Estimated Battery Life: 4.5 hours continuous use
Dimensions: 4.875”(W) x 3.875”(D) x 1.375”(H)
Weight: 1.05 lbs
ROHS Compliant: Yes
JS Technologies, Inc� (JST) warrants for lifetime from date of purchase by the
initial retail purchaser that this product shall be free from defects in workman-
ship� Electronic components such as capacitors, resistors, filters, transformers,
jacks, and pots are covered for 5 years� Any parts determined defective by JST
within the five (5) year term shall be repaired or replaced by JST without charge
for parts and labor provided the unit is returned, transportation costs prepaid, to
JS Technologies, Inc�, 601 Crane Street, Unit A, Lake Elsinore, CA 92530, or to
such facility authorized by JST� JST will pay shipping costs to return the unit to
its owner� Defects in workmanship will be determined by JST for limited lifetime
coverage�
This warranty does not cover damage caused by accident, misuse, abuse, ne-
glect, unauthorized or improperly performed repairs, alterations, and/or wear
and tear occasioned by use of the product, and does not include any expense
for inconvenience or loss of use while the product is being repaired or replaced�
JST expressly disclaims any liability for consequential damages arising from the
sale, use, or inability to use the product� Any warranty implied by law, includ-
ing any warranty of merchantability or fitness, is expressly limited to the one (5)
year warranty term for the parts on our amplifiers and electronic products� The
foregoing statements of warranty are exclusive and in lieu of all other remedies�
Workmanship lifetime warranty is limited strictly to the original retailer purchaser
of the instrument registered with JST within 10 days of purchase from an autho-
rized JST dealer or distributor� JST will pay shipping costs to return the unit to its
owner within the mainland U�S�
The above warranty policy only applies to customers in USA� If you are an in-
ternational customer, please check with your distributor and the dealer in your
country for warranty matters� Warranty issues must be handled through your
dealer or distributor� If you are an international customer who purchased (or
plan to purchase) from a US dealer, we can handle warranty matters direct but
you will be responsible for shipping both ways� We encourage international cus-
tomers to purchase through your local distributor or dealer for this reason� Our
international distributors are set up to handle warranty issues in their respective
countries� If you do not have an authorized Suhr dealer in your country, please
contact us direct for further details�

NOTE: This product has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
manufacturer’s instruction manual, may cause harmful interference with radio communications. Operation of this product in a residential area
is likely to cause harmful interference, in which case you will be required to correct the interference at your own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful
interference. 2) This device must accept any interference received, including interference that may cause undesired operation.
Notice: The FCC regulations provide that changes or modifications not expressly approved by J.S. Technologies Inc. could void your authority
to operate this equipment.
These limits are designed to provide reasonable protection against harmful interference in a non-residential installation. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference with radio or television
reception, which can be determined by turning the equipment off and on, you are encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the antenna of the radio/television receiver.
• Increase the separation between this equipment and the radio/television receiver.
• Plug the equipment into a different outlet so that the equipment and the radio/television receiver are on different power mains branch circuits.
• Consult a representative of J.S. Technologies Inc. or an experienced radio/television technician for additional suggestions.
