The SUIFF®PRO equipment consists of the SUIFF®PRO sensor and its training accessories:
The SUIFF®PRO case, the SUIFF®PRO carabiners, the express SUIFF® at sling and the Micro
USB cable.
SUIFF®PRO Kit SUIFF®PRO Case
Express SUIFF® Flat SlingSUIFF®PRO Carabiner

USER’S MANUAL
5
THE SUIFF® PRO SENSOR
The SUIFF®PRO sensor is an innovative and exclusive wireless sensor that can measure traction
forces applied in a wide variety of dynamic and static muscle strength exercises.
The sensor records force measurements and sends them to a mobile device, a smartphone or
tablet. The exclusive SUIFF®PRO mobile App receives and processes the data sent by the SUIFF®
PRO sensor and presents it to the user in real time.
The SUIFF®PRO sensor must be used with SUIFF®training accessories, for example the SUIFF®
PRO carabiners, the express SUIFF® at sling or the SUIFF®resistance band kit.
TECHNICAL SPECIFICATIONS FOR THE SUIFF® PRO SENSOR
Model
Dimensions (width x depth x height)
Weight (g)
Material of tensor piece
Material of body
Maximum load (kg)
Accuracy
Triaxial accelerometer
Sample frequency (Hz)
Maximal Supply Voltage (VAC)
Battery
Full charge cycle
Connectivity
Bluetooth range (m)
Compatibility
Recommended range of temperature
S2
136x78x31 mm
120
Aluminium alloy
PCB+ABS and thermoplastic vulcanizates (TPV)
180
±600 g o ±0.9% of reading (whichever is greater)
± 8 g
100
5 V 3 mA
Built-in rechargeable lithium polymer battery, 450 mAh
1 hour full charge cycle
Bluetooth Low Energy 4.0
15
Android
5°C to 35°C

USER’S MANUAL
6
SUIFF® PRO SENSOR DETAILS
Micro USB connector
To charge the battery with a
USB cable (USB A male Micro
USB B male).
Anchor handles
Aluminium alloy.
To attach the device to a wide
variety of exercise machines in a
fast and easy way.
Body
PCB+ABS and thermoplastic
vulcanizates (TPV).
On/off button
Switch on – click.
Switch off – Hold for 3 sec.

USER’S MANUAL
7
CORRECT USE OF THE SUIFF® PRO SENSOR
MAXIMUM ALLOWED LOAD
WARNING! PLEASE USE THE SUIFF®PRO SENSOR CORRECTLY AS DESCRIBED IN THIS
USER’S MANUAL. PAY SPECIAL ATTENTION TO OUR SAFETY RECOMMENDATIONS AND
KEEP UNATTENDED CHILDREN AWAY FROM THE DEVICE AND ITS ACCESSORIES.
The SUIFF® PRO sensor and its accessories do not require any difcult or complicated operations
but should be used under professional supervision.
The SUIFF®PRO sensor and its accessories can be used in any suitable space for the practice of
sport such as home, a garden, a tness centre or any public area that is appropriate for sport acti-
vities like parks, promenades or sports centres.
Both the SUIFF®PRO sensor and its accessories can be used outdoors at a temperature between
+5°C and +35°C but they should not be used when raining or be immersed in any liquid.
The SUIFF®PRO sensor can be used by children over 8 and by people with no experience or spe-
cialist knowledge if they know how to use the device and its accessories in a safe way and unders-
tand the risks involved.
The maximum traction load allowed by the SUIFF®PRO sensor is 180 kg.
If this maximum load of 180 kg is exceeded, the device’s measuring system or its internal sensor
might be affected leading to incorrect functioning.
WARNING! THE SUIFF®PRO SENSOR PROVIDES A STRUCTURAL SAFETY MARGIN OVER THE
MAXIMUM LIMIT LOAD WITHOUT RISKING THE STRUCTURAL INTEGRITY OF ITS ANCHOR
HANDLES OR THE INTEGRITY OF THE USER.

USER’S MANUAL
8
LED MODES
Upper led
Green light ashing
Sensor on
Upper led
Permanent blue light
Sensor connected to mobile
device
Lower led
Red light ashing
Low battery, recharge battery

USER’S MANUAL
9
CLICK PATTERNS
WARMING UP
To start the SUIFF®PRO sensor, press the power button once. The upper smart led will start blin-
king green, which indicates the device is on.
To switch the SUIFF®PRO sensor off, press the power button for three seconds until the upper
smart led goes off. Your device is off if the two led lights are inactive.
It is advisable to allow the sensor a short warm-up time of at least one minute before you start
training in order to get exact and stable readings. This is the warm-up time required by the
SUIFF®PRO sensor.
WARNING! NOT RESPECTING THE WARM-UP TIME MAY SLIGHTLY AFFECT THE PRECISION
AND ACCURACY OF FORCE MEASURES.
Sensor on
Click
Sensor off
Press for
3 s

USER’S MANUAL
10
CONNECTING THE SENSOR WITH THE APP AND CALIBRATING TO ZERO
Switch on the SUIFF®PRO sensor and open the SUIFF®PRO App on your mobile device.
Keep the SUIFF®PRO sensor on for at least 1 minute (warm-up time) before connecting it to your
mobile device to start training. To pair your SUIFF®PRO sensor with your mobile device:
A. Go to DEVICE LIST (1) and nd your SUIFF®PRO sensor on the DEVICE LIST, select it and
follow the instructions provided to connect and calibrate your SUIFF®PRO sensor.
1

USER’S MANUAL
11
B. Alternatively, you can also pair your SUIFF®PRO sensor with your mobile device going to LIVE
SESSION.
Calibrating to Zero
Right after pairing your SUIFF®PRO sensor with your mobile device, the sensor automatically
carries out a quick and simple calibration process to zero.
Please, to zero calibrate your device, make sure (as indicated in the SUIFF®PRO App) you do not
apply any traction force on the handles of the sensor as this could affect the accuracy of force
measurements.
If you have any doubt or think that you have applied excessive or undue force on the sensor while
carrying out the calibration process, simply disconnect your SUIFF®PRO sensor from your mobile
device and connect it again to start the calibration process anew. Your SUIFF®PRO sensor will
quickly be ready for you to start recording force!

USER’S MANUAL
12
Manual Adjustment to Zero
From the LIVE SESSION screen, you can readjust to zero whenever you like. That means that the
sensor must show a force of 0 Newtons (N).
It is basically the same process of calibrating to zero that is carried out automatically after connec-
ting your device but, in this case, it is done manually.
To manually adjust to 0, click the left button SET TO 0. The adjusting process will take approxima-
tely 5 seconds.
The most common situations in which you may need the SET TO 0 tool are the following:
Removing uctuations due to temperature
Since this kind of devices are sensitive to changes in temperature and/or humidity, big variations
in temperature might slightly alter the 0 value in your device and therefore affect the level of pre-
cision of your measurements.
Use the SET TO 0 tool if, even when no force is applied, you detect a clear alteration of the 0
value in the force records and you want to correct the accumulated error.
The images below show a measurement in which no force is applied to the sensor but gives a
uctuation of ~2.0 N for the 0 value (left) and, when pressing the SET TO 0 button, the error is
corrected (right).

USER’S MANUAL
13
Including the weight of the device in the measurements
The weight of the sensor (~120 g) must be taken into account on many of the occasions when force
is measured.
On these occasions, if you want to get exact measurements, before starting a session, you can ma-
nually adjust to 0 with the sensor lying on a at surface and applying no force to it. In this way, your
sensor will also record its own weight (~120 g).
However, since the SUIFF® PRO sensor is so light, this adjustment will hardly affect the exact levels
of force measurements.
Removing the weight of external accessories from the measurements
If you install your SUIFF®PRO sensor with any accessories attached (handles, bands, etc.) hanging
loose and you do not want the sensor to record their weight, use the SET TO 0 tool before you start
the measurements.
To do this, when the sensor is ready and the accessories are hanging from it with no movement,
click SET TO 0 before starting any force measurement.
AUTOMATIC SWITCH-OFF FEATURE
To switch off the SUIFF®PRO sensor, press the power button for 3 seconds, until the upper smart
led goes off. The SUIFF®PRO sensor is correctly off if both led lights are inactive.
If you forget to switch your sensor off doing this, the SUIFF®PRO sensor has a smart auto shut-off
system to control battery life.
The SUIFF®PRO sensor will automatically shut off in the following situations:
A. When disconnecting the sensor from the mobile device (the upper smart led will ash
green) and not connecting it again in the next 5 minutes.
B. Keeping the sensor completely still for 10 minutes, regardless of whether or not it is
connected with your mobile device.

USER’S MANUAL
14
CHARGING THE BATTERY
The lower smart led will ash red when the battery level is low and it needs to be recharged.
The battery of the SUIFF®PRO sensor can be easily charged using the micro USB cable, included
in your SUIFF®PRO kit.
Connect the micro USB cable to your SUIFF®PRO sensor. Connect the other end of the cable to
a USB device or a USB power outlet. Make sure the charger is compatible with the SUIFF®PRO
hardware.
Recommended operating voltage 5 V 3 mA.
2
1

USER’S MANUAL
15
BLUETOOTH RECOMMENDATIONS
To avoid any connectivity problems between the SUIFF®PRO sensor and the mobile device, place
them close to each other.
Make sure both of them are within maximum Bluetooth range (15 m).
Make sure there are no physical obstacles between the SUIFF®PRO sensor and the mobile device
you want to pair it with (smartphone or tablet), including people, walls, corners or fences.
CHOOSING THE RIGHT PLACE TO USE SUIFF® PRO
It is advisable to do your force measurement sessions with the SUIFF®PRO sensor and its acces-
sories on a non-slippery oor in order to better keep your balance and prevent any accident that
can harm you or damage the equipment.
Make sure you have at least 1 metre of free space around you so you can use the SUIFF®PRO
sensor and its accessories in a comfortable way.

USER’S MANUAL
16
SAFETY INFORMATION
WARNING! SUIFF®PRO EQUIPMENT DOES NOT PREVENT PHYSICAL INJURY. IMPROPER USE
OF SUIFF®PRO EQUIPMENT MAY CAUSE SERIOUS PHYSICAL DAMAGE. IN CASE OF DOUBT,
CONSULT A SPORTS PROFESSIONAL.
• Use only accessories and products recommended by the manufacturer.
• Keep the SUIFF®PRO sensor away from humidity. Prevent water from entering the
sensor.
• Keep the hardware parts away from any conductive elements, such as metal or
liquids.
• Keep the device away from heat and vibration.
• Keep the sensor away from any vibration source.
• Do not store the SUIFF®PRO sensor in extremely hot or cold places.
The recommended range of temperature is between 5°C and 35°C (41°F and 95°F).
• Do not touch the device and its charger cable with wet hands while the battery is
charging.
• Do not use SUIFF®PRO outdoors in rainy or stormy weather.
• Switch the device off in any hazardous or explosive environment.
• Before doing an exercise, make sure the device is properly anchored to the
accessories you are using and there is no risk to your health.
• For a correct functioning, hold the SUIFF®PRO sensor using its anchoring handles.
• When attaching the SUIFF®PRO sensor to any of the SUIFF®resistance bands or
any other accessory, make sure the carabiners are properly placed and the gate
shut.
• Do not apply any torsion force on the handles of the sensor. This could affect its
calibration and consequently the accuracy of force measurements.

USER’S MANUAL
17
• Do not apply any compression forces on the device. Doing this could damage it.
• Avoid any direct impact on the SUIFF®PRO sensor. This could decalibrate the
device and affect its correct functioning and/or some of its components could be
permanently damaged.
• If the device is damaged, broken or if it overheats, stop using it and consult our
technical assistance service.
• Observe road safety rules on mobile devices use while driving.
• Prevent children and pets from putting the device into their mouths.
• Do not hit your eyes, ears or any other part of your body with the device.
• In case of developing a skin eruption or an allergic reaction, stop using the device
and consult your dermatologist.
• Important! Before using the sensor, always check that the SUIFF®PRO carabiners
and the fabric and seams of the EXPRESS SUIFF® at sling are in good condition.
WARNING! ONLY THE MANUFACTURER CAN OPEN THE DEVICE. FOR SAFETY REASONS,
ONLY THE MANUFACTURER CAN DISASSEMBLE, FIX OR MODIFY ANY COMPONENT OF THE
SUIFF®PRO SENSOR OR OF ITS ACCESSORIES. FAILING TO DO THIS COULD DAMAGE THE
PRODUCT AND THE USER.

USER’S MANUAL
18
EXERCISES AND RECOMMENDATIONS
WARNING! BEFORE DOING ANY PROGRAMME OF PHYSICAL EXERCISES, PLEASE CONSULT
YOUR PHYSICIAN.
• Read all the instructions before using the SUIFF®PRO sensor and its accessories.
Incorrect or excessive training may cause health problems. Use SUIFF®PRO
equipment under professional supervision.
• If you feel pain or vertigo while training, stop exercising and cool down. This is
particularly important for those people who have had some health problem.
• The SUIFF®PRO sensor and its accessories have been mainly designed to do static
and dynamic exercises to work the muscles of the upper and lower limbs.
• Please make sure you choose the right exercises for you according to your tness
level.
• SUIFF®will not be liable for any personal injury or damage to any property that may
arise from its use.

USER’S MANUAL
19
HOW TO ANCHOR THE SUIFF® PRO SENSOR
Attach the Suiff® Pro sensor to a xed point
With the EXPRESS SUIFF® at sling and the SUIFF®PRO carabiners you can easily and safely at-
tach the SUIFF® PRO sensor to any xed point.
Choose a resistant and stable anchor point, for example a tree, lamppost, rail or xed bench.
The SUIFF®PRO sensor can be attached in two different ways:
A. Place the EXPRESS SUIFF® at sling (1) on the anchor point so that it hangs equally
on both sides.
B. Then, attach both ends of the EXPRESS SUIFF®
at sling to a SUIFF® PRO carabiner (1). Your EXPRESS SUIFF®
at sling is now correctly secured to a xed point.
C. Finally, attach one of the handles of the SUIFF® PRO sensor (1) to the carabiner.
Your sensor is now correctly attached to the xed point.
1
11
A. B. C.

USER’S MANUAL
20
A. Place the EXPRESS SUIFF® at sling (1) on the anchor point so that it hangs equally
on both sides.
B. Then, pass one of the ends of the EXPRESS SUIFF® at sling (1) through the loop at
the other end (2).
C. Finally, pull the end (1) so that the sling is rmly anchored and hanging. Attach a
SUIFF®PRO carabiner to one of the handles of the sensor (2) and then attach the
carabiner to the hanging end of the at sling (3). Your sensor is now correctly
attached to the xed point.
1
122
3
1
Once the SUIFF® PRO sensor is securely attached to the xed point, use the free handle of the sen-
sor to attach the accessory or part you need to start training (handle, rigid strap, resistance band,
suspension training system, etc.)
WARNING! BEFORE USING THE SENSOR, MAKE SURE THAT THE SUIFF®PRO CARABINER
AND THE FABRIC AND SEAMS OF THE EXPRESS SUIFF®FLAT SLING ARE IN GOOD C O N D I -
TION.
WARNING! WHEN USING ACCESSORIES OR PARTS THAT ARE NOT INCLUDED IN THE SUIFF®
PRO KIT (HANDLES, RIGID STRAPS, SUSPENSION TRAINING SYSTEMS, ETC.) MAKE SURE THAT
THE CARABINERS ARE IN GOOD CONDITION AND CAN SAFELY WITHSTAND THE TRACTION
FORCE TO BE APPLIED.
A. B. C.
