Sumitomo Drive Technologies JVOP-182-H User manual

LED Operator
Inverter HF-520 Option
Installation Manual
Type: JVOP-182-H
NOTICE
1. Make sure that this installation manual is dellvered to
the end user of inverter unit.
2. Read this manual before installing or operating the
inverter unit, and store it in a safe place for
reference.
Manual DM2307E-1

2
Copyright © 2014 Sumitomo Heavy Industries, LTD.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted, in any form or by any means, mechanical, electronic, photocopying,
recording, or otherwise, without the prior written permission of Sumitomo. No patent
liability is assumed with respect to the use of the information contained herein. Moreover,
because Sumitomo is constantly striving to improve its high-quality products, the
information contained in this manual is subject to change without notice. Every precaution
has been taken in the preparation of this manual. Sumitomo assumes no responsibility for
errors or omissions. Neither is any liability assumed for damages resulting from the use of
the information contained in this publication.

3
Table of Contents
1 PREFACE AND SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 PRODUCT OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 RECEIVING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 OPTION COMPONENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 INSTALLATION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . .17
6 BASIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7 RELATED PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 OPTION FAULT DIAGNOSTICS. . . . . . . . . . . . . . . . . . . . . . 27
9 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
10 WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4
1 Preface and Safety
1 Preface and Safety
Sumitomo manufactures products used as components in a wide variety of industrial
systems and equipment. The selection and application of Sumitomo products remain the
responsibility of the equipment manufacturer or end user. Sumitomo accepts no
responsibility for the way its products are incorporated into the final system design. Under
no circumstances should any Sumitomo product be incorporated into any product or design
as the exclusive or sole safety control. Without exception, all controls should be designed to
detect faults dynamically and fail safely under all circumstances. All systems or equipment
designed to incorporate a product manufactured by Sumitomo must be supplied to the end
user with appropriate warnings and instructions as to the safe use and operation of that part.
Any warnings provided by Sumitomo must be promptly provided to the end user. Sumitomo
offers an express warranty only as to the quality of its products in conforming to standards
and specifications published in the Sumitomo manual. NO OTHER WARRANTY,
EXPRESS OR IMPLIED, IS OFFERED. Sumitomo assumes no liability for any personal
injury, property damage, losses, or claims arising from misapplication of its products.

1 Preface and Safety
5
◆Applicable Documentation
The following manuals are available for the JVOP-182-H LED Operator Option:
LED Operator
LED Operator
HF-520, SF-520 Series
Installation Manual
Manual No: DM2307E
(this book)
Read this manual first.
The installation manual is packaged with the option
and contains information required to install the
option and set up related unit parameters.
RS-232C Interface Option
SF-520 Option RS-232C
Interface
Technical Manual
Manual No: DM2203E
The Technical Manual is packaged with the RS-
232C Interface Option and contains a basic
overview of wiring, settings, functions, and fault
diagnoses.
Inverter
Operating and Maintenance
Manual HF-520
Manual No: DM2301E
SF-520
Manual No: DM2201E
The unit manuals cover basic installation, wiring,
operation procedures, functions, troubleshooting,
and maintenance information.
The manuals also include important information
about parameter settings and unit tuning. Access
these sites to obtain Sumitomo instruction manuals:
http://cyclo.shi.co.jp
Technical Manual
HF-520
Manual No: DM2302E
SF-520
Manual No: DM2202E
SF-520

1 Preface and Safety
6
◆Terms
◆Registered Trademarks
Company names and product names listed in this manual are the registered trademarks of
those companies.
◆Supplemental Safety Information
Read and understand this manual before installing, operating or servicing this option. The
option must be installed according to this manual and local codes.
The following conventions are used to indicate safety messages in this manual. Failure to
heed these messages could result in serious or fatal injury or damage to the products or to
related equipment and systems.
Note: Indicates a supplement or precaution that does not cause unit damage.
LED: Light emitting diode.
Option: LED Operator
Drive: • HF-520 Series
• SF-520 Series
DANGER
Indicates a hazardous situation, which, if not avoided, will result in death or serious
injury.

1 Preface and Safety
7
■General Safety
WARNING
Indicates a hazardous situation, which, if not avoided, could result in death or
serious injury.
CAUTION
Indicates a hazardous situation, which, if not avoided, could result in minor or
moderate injury.
NOTICE
Indicates an equipment damage message.
General Precautions
• The diagrams in this section may include options and units without covers or safety shields to
illustrate details. Be sure to reinstall covers or shields before operating any devices. The option board
should be used according to the instructions described in this manual.
• Any illustrations, photographs, or examples used in this manual are provided as examples only and
may not apply to all products to which this manual is applicable.
• The products and specifications described in this manual or the content and presentation of the
manual may be changed without notice to improve the product and/or the manual.
DANGER
Heed the safety messages in this manual.
Failure to comply will result in death or serious injury.
The operating company is responsible for any injuries or equipment damage resulting
from failure to heed the warnings in this manual.

1 Preface and Safety
8
NOTICE
Do not expose the unit to halogen group disinfectants.
Failure to comply may cause damage to the electrical components in the option.
Do not pack the unit in wooden materials that have been fumigated or sterilized.
Do not sterilize the entire package after the product is packed.

9
2 Product Overview
2 Product Overview
◆About This Product
The option provides an enhanced unit user interface that can operate the Sumitomo unit from
up to 3 meters away. The option is an LED display that simplifies the task of interfacing with
the unit to perform these tasks:
• Read or modify unit parameters.
• Read and copy unit parameter settings to another Sumitomo unit.
• Operate the unit.
• Monitor unit operation status.
All keys except for the STOP key on the units built-in LED operator will not function when
the option is connected to HF-520 and SF-520. <1>
<1> If desired, to also disable the STOP key on the units built-in LED operator, set parameter o2-02 (STOP Key
Function Selection) to 0 (Disabled).

10
3 Receiving
3 Receiving
Perform the following tasks after receiving the option:
• Inspect the option for damage.
If the option appears damaged upon receipt, contact the shipper immediately.
• Verify receipt of the correct model by checking the model number printed on the Name
plate of the option.
• If you have received the wrong model or the option does not function properly, contact
your supplier.
◆Contents and Packaging
Table 1 Contents of Package
■Parts Sold Separately
Proper installation of the option requires a digital operator cable (sold separately). A
communication cable may be purchased from Sumitomo or recommended LAN cables may
be used.
Description: Option Installation Manual
–
Quantity: 11
MANUAL

3 Receiving
11
Table 2 Item Names and Part Numbers (Sold Separately)
◆Tool Requirements
Screwdriver (M3) is required to install the option on an enclosure panel door.
Item
<1> Digital Operator Cable: Used to connect the digital operator to the drive (sold separately).
<2> To connect the option to SF-520, install the RS-232C Interface Option to the unit.
Yaskawa Part Number Notes Page
RS-232C Interface Option
SI-232/J-H <2> 21
Digital Operator Cable 1 m (3 ft.) <1>
ICS-1
Alternate cables (customer-
supplied), RJ45 8-pin Straight
Connector UTP Cat5e cable
20
Digital Operator Cable 3 m (10 ft.) <1>
ICS-3
Alternate cables (customer-
supplied), RJ45 8-pin Straight
Connector UTP Cat5e cable
20
SF-520

12
4 Option Components
4 Option Components
◆Option
Figure 1
Figure 1 Option Components
A – Data Display Area D – Installation Mounting Holes
B – LED Indicators E – Communication Cable Connector
C–Keys
B
A
C
D
E
D

4 Option Components
13
◆Keys
Refer to Figure 2 and Table 3 for details on key names and functions.
Figure 2
Figure 2 Keys
Table 3 Key Names and Functions
No. Key Name Function
1ESCKey
• Returns to the previous display.
• Moves the cursor one space to the left.
• Pressing and holding this button will return to the following display:
Drive: Frequency Reference
Converter: DC Bus Voltage Reference
Regenerative unit: DC Bus Voltage
2 RESET Key • Moves the cursor to the right.
• Resets the unit to clear a fault situation.
3 RUN Key Starts the unit and motor.
4 Up Arrow Key Scrolls up to display the next item, selects parameter numbers and
increments setting values.
ALM
REV DRV FOUT
LO
RE
ESC
RUN STOP
ENTERRESET
DIGITAL OPERATOR JVOP-182
1
2
345 6
9
14 13 12
10
8
11
7
R
R
U
U
N

4 Option Components
14
5Down Arrow
Key
Scrolls down to display the previous item, selects parameter numbers and
decrements setting values.
6STOPKey
Stops unit operation.
Note: The STOP key can be enabled or disabled when operating from the
external terminal or network communications by setting parameter o2-02.
7ENTERKey
• Enters parameter values and settings.
• Selects a menu item to move between displays.
8LO/RE
Selection Key
Switches unit control between the operator (LOCAL) and an external
source (REMOTE) for the Run command and frequency reference.
Note: The LOCAL/REMOTE key is only effective when the unit is
stopped in Drive Mode. As a safety precaution, it is possible to disable the
LO/RE Selection Key by setting parameter o2-01 (LOCAL/REMOTE
Key Function Selection) to 0 (disabled). <1>
9 RUN Light Illuminated during an operation.
Refer to Option LED Status Indicators on page 15 for details.
10 LO/RE Light Illuminated while the option is selected to run the unit (LOCAL mode).
11 ALM LED
Light
Refer to LED Screen Display on page 16
12 REV LED
Light
13 DRV LED
Light
14 FOUT LED
Light
<1> o2-01 (LOCAL/REMOTE Key Function Selection) is not compatible with SF-520. LO/RE Selection Key is
always effective.
No. Key Name Function
S
T
T
O
O
TO
TO
P
RE
LO

4 Option Components
15
◆Option LED Status Indicators
Table 4 LED Status and Meaning
Figure 3
Figure 3 RUN LED Status
Figure 4
Figure 4 RUN LED and Drive Operation
LED Illuminated Flashing <1>
<1> Refer to Figure 3 for the difference between “flashing” and “flashing quickly”.
Flashing Quickly <1> Off
When the option is
selected for Run
command and
frequency reference
control (LOCAL).
––
When a device other
than the option is
selected for Run
command and
frequency reference
control (REMOTE).
During run.
• During deceleration to
stop.
• When a Run
command is input and
the frequency
reference is 0 Hz.
• During deceleration
when a Fast Stop
command was
entered.
• During stop by
External Fault digital
input.
During stop.
Examples
RE
LO
RUN
Flashing
quickly
Flashing
ONON
ON
ONON
ON
1 s
Drive output frequency
During stop
Frequency setting
OFF ON
Flashing
OFF
OFF
RUN LED
STOP STOP
RUN
0 Hz 6 Hz
RUN
/
RUN STOP

4 Option Components
16
◆LED Screen Display
Display Lit Flashing Off
When the unit detects an alarm
or error
• When an alarm occurs
• oPE detected Normal state (no fault or alarm)
Motor is rotating in reverse – Motor is rotating forward
Drive Mode – Programming Mode
Displays output frequency (Hz) – –
As illustrated
in this manual
AL
M
REV
DRV
FO
UT
D
IGITAL OPERATOR JVOP-182
DRV
AL
M
REV
DRV
FOU
T
D
I
G
ITAL
O
PERAT
O
R
J
V
O
P-1
8
2ALM
AL
M
REV
DRV
FO
UT
D
IGITAL OPERATOR JVOP-182
DRV

17
5 Installation Procedure
5 Installation Procedure
◆Section Safety
NOTICE
Damage to Equipment
Use only Sumitomo connection cables or recommended cables.
Failure to comply may cause the unit or option to function incorrectly.
Properly connect the connectors.
Failure to comply may prevent proper operation and possibly damage equipment.
Do not exceed communication cable bend radius specifications.
Failure to comply may result in broken wires or loose connections.

5 Installation Procedure
18
◆Option Dimensions
Figure 5
Figure 5 Dimensions
<1> Use only Sumitomo cables or cables recommended by Sumitomo. Refer to Item Names and Part Numbers (Sold
Separately) on page 11
90 (3.54)
78 (3.07)
60 (2.36) 7.9
(0.31)
minimum
50 (1.97) Unit: mm (in.)
12.2
(0.48)
1.6 (0. 06) Inst allat ion holes (2-M3 screws, dept h 5 (0. 2))
44 (1.73)
15 (0.59)
<1>

5 Installation Procedure
19
◆Installing the Option
NOTICE: Prevent foreign matter such as metal shavings or wire clippings from falling into the unit during
installation and project construction. Failure to comply could result in damage to the unit. Place a temporary
cover over the top of the unit during installation. Remove the temporary cover before startup, as the cover
will reduce ventilation and cause the unit to overheat.
1. Cut an opening in the enclosure panel for the option according to Figure 6.
2. Position the option so the LED display faces outwards, and mount it to the
enclosure panel as shown in Figure 6.
Figure 6
Figure 6 External/Face-mount Installation
Figure 7
Figure 7 Panel Cut-out Dimensions (External/Face-mount Installation)
Opti o n M3 × 6 (0.24)
Phillips recessed
pan head machine screw × 2
Enclosure panel
Unit: mm (in.)
22 (0.87)
22(0.87)
14
(0.55) Unit : mm (in.)
26
(1.02)
22
(0.87)
78 (3.07)
2 (0.08)

5 Installation Procedure
20
◆Connecting the Option to the Unit
This section contains instructions for connecting the option to units.
■Connecting the Option to HF-520
Plug the customer-supplied communication cable into the communication cable connector of
the option and the drive communications port as shown in Figure 8. Ensure both cable ends
are firmly connected. Refer to Item Names and Part Numbers (Sold Separately) on page 11
for information regarding recommended cables.
Note: Use only Sumitomo recommended cables. Using a cable not specified may cause the option or
drive to malfunction.
Note: The STOP key on the built-in LED operator of the drive is the only functional key on the drive
when the option is connected and parameter b1-02 is set to 0. Set parameter o2-02 (STOP Key
Function Selection) to 0 (Disable) to disable the STOP key.
Figure 8
Figure 8 Communication Cable Connection
STOP
HF-520
(Hz)
(Hz)
(A)
(V)
:
:
:
:
:
:
:
:
:
:
周波数指令
正転逆転選択
出力周波数
出力電流
出力電圧
モニタ
ベリファイ
セットアップ
パラメータ設定
オートチューニング
据え付け、運転の前には必ず取扱説明書を読むこと。
通電中および電源遮断後
5
分以内はフロントカバーを
外さないこと。
400V
級インバータの場合は、電源の中性点が接地
されていることを確認すること。（ 対応）
けが、感電のおそれがあります。
危 険
Read manual before installing.
Wait 5 minutes for capacitor discharge after
disconnecting power supply.
To conform to requirements, make sure
to ground the supply neutral for 400V class.
Risk of electric shock.
WARNING
Option (JVOP-182-H)
Communication Cable Connector
Comm Port
Built-in LED
Operator
Drive
