Sumitomo HF-430NEO Series User manual

UserʼsGuideDM3412E-1
AnalogInput/Outputoption
Model:P1-AG
UserʼsGuide
HF-430NEOSeries
1. Makesurethatthisuserʼsguideisdeliveredtotheenduser
 ofinverterunit.
2. Readtheinstructionmanualanduserʼsguidebeforeinstallingor
 operatingtheinverterunit,andstoreitinasafeplaceforreference.
NOTICE
Power Transmission & Controls Group
Headquarter ThinkPark Tower, 1-1 Osaki 2-chome, Shinagawa-ku, Tokyo 141-6025, Japan
Specications, dimensions, and other items are subject to change without prior notice.
No.DM3412E-1.0
EA10 Printed 2020.03
Worldwide Locations
U.S.A
Sumitomo Machinery Corporation of America
(SMA)
4200 Holland Blvd. Chesapeake, VA 23323, U.S.A.
TEL [phone] FAX [phone]
Canada
SM Cyclo of Canada, Ltd. (SMC)
1453 Cornwall Road, Oakville, Canada ON L6J 7T5
TEL [phone] FAX [phone]
Mexico
SM Cyclo de Mexico, S.A. de C.V. (SMME)
Av. Desarrollo 541, Col. Finsa, Guadalupe,
Nuevo León, México, CP67132
TEL [phone] FAX [phone]
Brazil
Sumitomo Industrias Pesadas do Brasil Ltda.
(SHIB)
Rodovia do Acucar (SP-075) Km 26
Itu, Sao Paulo, Brasil
TEL [phone] FAX [phone]
Chile
SM-Cyclo de Chile Ltda. (SMCH)
Camino Lo Echevers 550, Bodegas 5 y 6,
Quilicura, Región Metropolitana, Chile
TEL [phone] FAX [phone]
Argentina
SM-Cyclo de Argentina S.A. (SMAR)
Ing Delpini 2230, B1615KGB Grand Bourg,
Malvinas Argentinas, Buenos Aires, Argentina
TEL [phone] FAX [phone]
Guatemala
SM Cyclo de Guatemala Ensambladora, Ltda.
(SMGT)
Parque Industrial Unisur, 0 Calle B 19-50 Zona 3,
Bodega D-1 Delta Bárcenas en Villa Nueva, Guatemala
TEL [phone] FAX [phone]
Colombia
SM Cyclo Colombia, S.A.S. (SMCO)
Parque Industrial Celta, Km 7.0 Autopista Medellín,
Costado Occidental, Funza, Cundinamarca, Colombia
TEL [phone]
Peru
SM Cyclo de Perú, S.A.C (SMPE)
Jr. Monte Rosa 255, Ocina 702, Lima,
Santiago de Surco, Perú
TEL [phone] FAX [phone]
Germany
Sumitomo (SHI) Cyclo Drive Germany GmbH
(SCG)
Cyclostraße 92, 85229 Markt Indersdorf, Germany
TEL [phone] FAX [phone]
Austria
Sumitomo (SHI) Cyclo Drive Germany GmbH
(SCG)
SCG Branch Austria Oce
Gruentalerstraße 30A, 4020 Linz, Austria
TEL [phone] FAX [phone]
Belgium
Hansen Industrial Transmissions NV (HIT)
Leonardo da Vincilaan 1, Edegem, Belgium
TEL [phone] FAX [phone]
France
SM-Cyclo France SAS (SMFR)
8 Avenue Christian Doppler, 77700 Serris, France
TEL [phone] FAX [phone]
Italy
SM-Cyclo Italy Srl (SMIT)
Via dell' Artigianato 23, 20010 Cornaredo (MI), Italy
TEL [phone] FAX [phone]
Spain
SM-Cyclo Iberia, S.L.U. (SMIB)
C/Gran Vía Nº 63 Bis, Planta 1, Departamento 1B
48011 Bilbao–Vizcaya, Spain
TEL [phone] FAX [phone]
United Kingdom
SM-Cyclo UK Ltd. (SMUK)
Unit 29, Bergen Way, Sutton Fields Industrial Estate,
Kingston upon Hull, HU7 0YQ, East Yorkshire,
United Kingdom
TEL [phone] FAX [phone]
Turkey
SM Cyclo Turkey Güç Aktarım Sis. Tic. Ltd. Sti.
(SMTR)
Barbaros Mh. Çiğdem Sk. Ağaoğlu, Ofce Mrk. No:1 Kat:4 D.18
Ataşehir, İstanbul, Turkey
TEL [phone] FAX [phone]
India
Sumi-Cyclo Drive India Private Limited (SDI)
Gat No. 186, Raisoni Industrial Park, Alandi Markal Road,
Fulgaon-Pune, Maharashtra, India
TEL [phone]
China
Sumitomo (SHI) Cyclo Drive China, Ltd. (SCT)
11F, SMEG Plaza, No. 1386 Hongqiao Road,
Changning District, Shanghai, China （P.C. 200336）
TEL [phone] FAX [phone]
Hong Kong
SM-Cyclo of Hong Kong Co., Ltd. (SMHK)
Rm 1301, CEO Tower, 77 Wing Hong Street,
Cheung Sha Wan, Kowloon, Hong Kong
TEL [phone] FAX [phone]
Korea
Sumitomo (SHI) Cyclo Drive Korea, Ltd. (SCK)
Royal Bldg. 19 Rm. 913, 5 Saemunan-ro 5-Gil Jongro-Gu
Seoul, Korea 03173
TEL [phone] FAX [phone]
Taiwan
Tatung SM-Cyclo Co., Ltd. (TSC)
22 Chungshan N. Road 3rd., Sec. Taipei, Taiwan 104,
R.O.C.
TEL [phone] FAX [phone]
Singapore
Sumitomo (SHI) Cyclo Drive Asia Pacic Pte.
Ltd. (SCA)
15 Kwong Min Road, Singapore 628718
TEL [phone] FAX [phone]
Philippines
Sumitomo (SHI) Cyclo Drive Asia Pacic Pte. Ltd.
Philippines Branch Oce (SMPH)
C4 & C5 Buildings Granville Industrial Complex, Carmona,
Cavite 4116, Philippines
TEL [phone] FAX [phone]
Vietnam
SM-Cyclo (Vietnam) Co., Ltd. (SMVN)
Factory 2B, Lot K1-2-5, Road No. 2-3-5A,
Le Minh Xuan Industrial Park, Binh Chanh Dist.,
HCMC, Vietnam
TEL [phone] FAX [phone]
Malaysia
SM-Cyclo (Malaysia) Sdn. Bhd. (SMMA)
No.7C, Jalan Anggerik Mokara 31/56, Kota Kemuning,
Seksyen 31, 40460 Shah Alam, Selangor Darul Ehsan,
Malaysia
TEL [phone] FAX [phone]
Indonesia
PT. SM-Cyclo Indonesia (SMID)
Jalan Sungkai Blok F 25 No. 09 K, Delta Silicon III,
Lippo Cikarang, Bekasi 17530, Indonesia
TEL [phone] FAX [phone]
Thailand
SM-Cyclo (Thailand) Co., Ltd. (SMTH)
195 Empire Tower, Unit 2103-4, 21st Floor, South
Sathorn Road, Yannawa, Sathorn, Bangkok 10120,
Thailand
TEL [phone] FAX [phone]
Australia
Sumitomo (SHI) Hansen Australia Pty. Ltd.
(SHAU)
181 Power St, Glendenning, NSW 2761, Australia
TEL [phone] FAX [phone]
Japan
Sumitomo Heavy Industries, Ltd. (SHI)
ThinkPark Tower, 1-1 Osaki 2-chome, Shinagawa-ku,
Tokyo 141-6025, Japan
TEL [phone] FAX [phone]

Copyright © 2020 Sumitomo Heavy Industries,Ltd. All rights reserved.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, mechanical, electronic, photocopying, recording, or otherwise,
without the prior written permission of Sumitomo. No patent liability is assumed with respect to the use of
the information contained herein. Moreover, because Sumitomo is constantly striving to improve its
high-quality products, the information contained in this manual is subject to change without notice. Every
precaution has been taken in the preparation of this manual. Sumitomo assumes no responsibility for
errors or omissions. Neither is any liability assumed for damages resulting from the use of the information
contained in this publication.

S-1
Introduction
Introduction
Thank you for purchasing the P1-AG: Analog Input/Output option for HF-430NEO series inverter.
This instruction manual describes how to handle and maintain the P1-AG. Please read this manual carefully
before using the P1-AG, and keep it handy for those who operate, maintain and inspect it.
■User's Guide(this document)
The User's Guide provides detailed information necessary for handling the product.
Please make sure to read User's Guide for proper use.
Always use the P1-AG strictly within the range described in the User's Guide and perform proper inspection
and maintenance to prevent failures or accidents.
The latest version of the User's guide can be obtained through our website.
■Handling the inverter HF-430NEO
For handling the HF-430NEO, please make sure to read its Instruction manual and User's Guide.
■For a proper use
Before using the inverter, please read carefully the HF-430NEO Instruction manual and User's Guide, the
P1-AG User's Guide.
In Addition any personnel handling or performing maintenance of the product must read carefully the HF-
430NEO Instruction manual and User's Guide, the P1-AG User's Guide.
Before any attempt to install, operate, maintain or inspect this equipment, a complete understanding of the
equipment specifications, safety instructions, precautions, handling and operation instructions is required.
Please follow all the specifications and instructions for a proper use. Additionally, periodically review the
HF-430NEO Instruction manual and User's Guide, the P1-AG User's Guide.
■Precautions
It is prohibited to reproduce or reform this document partially or totally in any form without the publisher's
permission.
The contents of the document are subject to change without prior notice.
Any handling, maintenance or operation method NOT described on the HF-430NEO Instruction manual
and User's Guide, the P1-AG User's Guide is not covered by the product warranty.
Please DO NOT perform any procedure NOT described on the HF-430NEO or the P1-AG manuals since it
can be the cause of unexpected failures or accidents.
We are not responsible for any impact from operations regardless of unexpected failure or accident due to
operation or handling of the product in a manner not specified on the HF-430NEO Instruction manual and
User's Guide, the P1-AG User's Guide. We appreciate your understanding.
Note that, in case the HF-430NEO Instruction manual and User's Guide, the P1-AG User's Guide are
enclosed, they should be delivered to the end user of the inverter. Also make sure to download and keep
accessible any other related guides or instruction manuals for the end user.
■Trademark
・CRIMPFOX® is a registered trademark of Phoenix Contact GmbH & Co. KG.
・Any other brand names and product names mentioned in this guide are trademarks or registered
trademarks of their respective owners.

S-2
Table of Contents
Table of Contents
●Introduction.................................................... S-1
●Table of Contents .......................................... S-2
1.1 About this chapter ......................................1-1
1.2 Types of warnings........................................... 1-1
2.1 About this chapter.......................................... 2-1
2.2 Applicable devices ......................................... 2-1
2.3 Before reading this guide..............................2-1
3.1 About this chapter.......................................... 3-1
3.2 P1-AG appearance and nomenclature........ 3-1
4.1 About this chapter.......................................... 4-1
4.2 About the enclosed items ............................. 4-1
5.1 About this chapter.......................................... 5-1
5.2 Installation....................................................... 5-1
6.1 About this chapter.......................................... 6-1
6.2 Terminal connection...................................... 6-1
7.1 About this chapter.......................................... 7-1
7.2 Self-diagnosis.................................................. 7-1
8.1 About this chapter.......................................... 8-1
●
Warranty ............................................... App.1-1
1.3 Symbol explanation ....................................... 1-2
1.4 Precautions ..................................................... 1-2
2.4 Guide objectives............................................. 2-1
2.5 Guide outline .................................................. 2-2
3.3 Name plate...................................................... 3-1
3.4 Dimensions after installed ............................ 3-2
4.3 Verification after the purchase..................... 4-1
5.3 Terminal block and wiring ............................ 5-4
6.3 List of parameters related to the P1-AG ..... 6-2
7.3 Inverter troubleshooting ............................... 7-1
7.4 Any other trouble ........................................... 7-3
8.2 Device Specifications .................................... 8-1
Chapter 1 Safety Precautions
Chapter 2 Overview
Chapter 3 Preparing for operation
Cha
p
ter 4 Enclosed Items
Chapter 5 Installation and wiring
Chapter 7 Troubleshooting
Chapter 8 Specifications
Chapter 6 Function of Analog Input/Output

1-1
Chapter 1 Safety Precautions
1.1 About this chapter
This chapter contains the information about Safety precautions during the installation, wiring, operation
and inspection.
Before installation, wiring, operation, inspection, or usage please read completely and fully understand
this guide.
1.2 Types of warnings
In this guide, the safety precautions as well as residual risks are categorized by degree of risk as
“Danger”, “Warning” and“Caution”.
The definition of each category is described below.
Danger
This category warns the user that in case of an incorrect or improper handling, it leads to a dangerous
situation that have a high risk of causing death, serious injuries and/or major property damage.
Warning
This category warns the user that in case of an incorrect or improper handling, it leads to a dangerous
situation that may cause death, serious injuries and/or major property damage.
Caution
This category warns the user that in case of an incorrect or improper handling, it leads to a dangerous
situation that may cause physical injuries and/or property damage.
However, any content labeled with “ Caution” and depending on the case, might have a possibility of
leading to a highly dangerous situation.
It is extremely important that you follow the instructions and warnings.
Furthermore, content labeled with “ ”must be followed and paid special attention.
1
Chapter 1 Safety Precautions

1-2
Chapter 1 Safety Precautions
1.3 Symbol explanation
In this guide, there are some explanatory notes using different symbols. Please pay attention to this
content and keep in mind itsinformation.
Symbol definition
When handling this product, this symbol indicates danger, warning or caution about
ignition, electric shock, high temperature or other dangers.
Inside or near the symbol, the specific content will be shown.
This symbol indicates “General hazard not specified, be cautious”.
This symbol indicates “Electric shock hazard”.
This symbol indicates prohibited actions“Actions that should not be done” when handling
this device.
This symbol indicates actions that must be done based on the instructions.
1.4 Precautions
1.4.1 Please be careful!
・If handled incorrectly or improperly, it might cause death, serious physical injuries, or damage to
the inverter, motor or even the entire system.
・Before installation, wiring, operation, inspection, or usage please read and fully understand this
guide and other references.
・There will be additional warnings about hazards and failure causes in other chapters.
・Before installation, wiring, operation, inspection, or usage please read and fully understand this
guide.
・In order to explain this device details the illustrations in this guide might show this device without
covers.
・Before operating this device please return all the covers to the original position, and follow all the
necessary regulations and instructions written in this guide.
Caution
Do
Danger
Caution
Do
Caution
Do

1-3
Chapter 1 Safety Precautions
1.4.2 Precautions during the installation！
●Risk of Fire!
・DO NOT place inflammable objects nearby
・DO NOT let scraps of wire, welding sputtering, irons scraps or other objects get inside the device.
・Avoid installing this device in places with high temperature, high humidity, Condensation-prone
conditions, dusty conditions, corrosive gas, explosive gas, flammable gas, grinding fluid mist,
hydrogen sulfide or salt damage prone conditions. Additionally, it is recommended to install this
device in ventilated room not exposed to direct sunlight.
●Risk of Injury!
・DO NOT install or operate products with damage or missing parts.
●Risk of an Inverter failure!
・This device is a precision equipment, DO NOT drop it, or give it a strong shock.
・DO NOT get on (step on) or place heavy objects on this device.
・When handling the object, avoid places prone to static electricity(like carpets).
・Since the human body can get charged with static electricity, as a safety measure please touch
a safe metallic surface before handling this device.
1.4.3 Precautions during the wiring!
●Risk of an electric shock and/or fire!
・Be sure to ground the inverter.
・Entrust the wiring work only to a qualified electrician.
・Before the wiring work make sure to turn off the power supply and wait for more than 10 or 15
minutes depending on the inverter model.＊
Confirm that the charge lamp is OFF and the DC voltage between terminals P and N is 45 V or
less.
＊For HF4322-5A5 to HF4322-022, HF4324-5A5 to HF4324-022 models the wait time is 10 minutes.
For HF4322-030 to HF4322-055, HF4324-030 to HF4324-055 models the wait time is 15 minutes.
●Risk of inverter failure!
・DO NOT pull any wire after wiring.
Do
Electric
shock
and Fire
hazard
Danger
Failure
Prohibited
Danger
Do
Fire
Hazard
Injury
Prohibited
Prohibited
Failure
Do

1-4
Chapter 1 Safety Precautions
●Risk of an electric shock and/or injury!
・Perform the wiring only after installing the inverter.
●Risk of an electric shock and/or injury!
・DO NOT operate/switch any of the switches from the 4 pole DIP switch on this device.＊
When this device is shipped all switches are turned off.
・If any of the switches from the 4 pole DIP switch is operated/switched, this device will not work
as intended and it might be the cause of failure.
・Please handle the cables properly and DO NOT let them get damaged. Using damaged cables will
not only interfere with the correct operation of this device but also might be the cause of a system
failure.
＊4 pole DIP switch is implemented on the board exposed from the case of this product.
●Risk of Fire!
・Please tighten the screws and bolts with the specified torque.
(Please refer to the inverter user's guide)
・Verify that none of the screws and bolts are loose.
・Make sure that the inverter and this device are fixed together with the securing screw.
・Make sure that the connectors are properly fixed.
1.4.4 Precautions during operation and trial operation!
●Risk of an electric shock or fire!
・DO NOT touch the inside of this device, check the signal, do any wiring or plug/unplug the
connectors while it energized.
・DO NOT insert any sick or rod like objects inside this device while it is energized.
●Risk of an injury and/or fire!
・DO NOT touch the inside of this device or the inverter while they are energized.
Do
Fire
hazard
Do
Electric
shock
and
injury
Warning
Prohibited
Prohibited
Injury
and Fire
hazard
Danger
Do
Electric
shock
and
injury
Electric
shock
and Fire
hazard

1-5
Chapter 1 Safety Precautions
●Risk of an electric shock!
・Make sure to fasten all the screws of this device before turning it on. DO NOT detach this device
while it is energized or the inverter capacitors are still charged.
・Additionally DO NOT touch the inside of the inverter while the inverter capacitors are still charged.
・DO NOT touch this device with wet hands.
●Risk of an injury and/or device damage!
・By using this device it becomes easier to change the settings and the output frequency of the
inverter. When changing the settings or the output frequency of the inverter please make sure
that it is within the supported range by the gear motor and/or the equipment.
・In case this device is being used to make the inverter produce high frequency outputs for a motor
or other equipment, make sure with the respective manufacturer that the motor or the equipment
can tolerate the high frequency output given by the inverter.
・During operation verify the motor rotation direction, and that there are no irregular sounds or
vibrations.
1.4.5 Precautions during Maintenance/ Inspection!
●Risk of an electric shock!
・Before the wiring work make sure to turn off the power supply and wait for more than 10 or 15
minutes depending on the inverter model.＊
(Confirm that the charge lamp is OFF and the DC voltage between terminals P and N is 45 V
or less.)
・Entrust the maintenance, inspection and/or part replacement only to a specialized personnel.
(Be sure to remove wristwatches and metal accessories, e.g., bracelets, before maintenance and
inspection work and use insulated tools for the work).
＊For HF4322-5A5 to HF4322-022, HF4324-5A5 to HF4324-022 models the wait time is 10 minutes.
For HF4322-030 to HF4322-055, HF4324-030 to HF4324-055 models the wait time is 15 minutes.
Injury or
device
Damage
Warning
Do
Do
Electric
shock
Danger
Electric
shock
Prohibited
Prohibited

1-6
Chapter 1 Safety Precautions
1.4.6 Precautions for disposal!
●Risk of an injury and/or an explosion!
・Outsource to a qualified industrial waste disposal contractor when discarding this device.
Disposing of this device on your own may result in the production of poisonous gas
・Contact your sales agent if you need to get this device fixed.
・A qualified waste disposer includes industrial waste collector/transporter and industrial waste
disposal operator. Follow all laws and decrees related to procedures of waste management and
public cleansing when disposing of this device.
1.4.7 Other Precautions
●Risk of an injury, an electric shock and/or fire!
・DO NOT modify this device.
＊In addition to the precautions described above, there are other precautions described in the chapter 8
of the inverter user's guide. Please read and follow those precautions as well.
Do
Injury and
explosion
hazard
Danger
Prohibited
Electric
shock
injury
and Fire
hazard
Danger

2-1
Chapter 2 Overview
2.1 About this chapter
This chapter specifies the devices that this guide will describe. Additionally, it contains information
necessary to clearly understand this guide, the objectives of this guide.
2.2 Applicable devices
The contents of this guide will apply to the P1-AG device. For information about the inverter please refer
to the HF-430NEO user's guide or the instruction manual.
2.3 Before reading this guide
This guide is aimed for people who purchase, handle, install or connect control equipment, design
systems or manage factories.
This guide units are based on the SI system.
2.4 Guide objectives
The objectives of this guide are:
・explain how to wire and connect the device.
・explain how to set the necessary parameters.
2
Chapter 2 Overview

2-2
Chapter 2 Overview
2.5 Guide outline
This guide has the following structure.
● The chapter 1: Safety Precautions
"Safety Precautions" contains the safety instructions for installing, wiring, operating, maintaining and
inspecting this device.
● The chapter 2: Overview
"Overview" contains information necessary to clearly understand this guide.
● The chapter 3: P1-AG
"About the P1-AG" contains the explanation about this device appearance and general features.
● The chapter 4: Enclosed Items
"Enclosed Items" contains information about the items included with this device.
● The chapter 5: Installation and Wiring
"Installation and Wiring" contains information for installing and wiring this device on the inverter.
● The chapter 6: Function of Analog Input/Output
"Function of Analog Input/Output" contains the explanation of the inverter parameters that relate with
this device.
● Chapter 7: Troubleshooting
"Troubleshooting" contains the explanation of inverter error (trip) status and its trouble shooting while
in use this device.
● Chapter 8: Specifications
"Specifications" contains the specifications of this device.

3-1
Chapter 3 P1-AG
3.1 About this chapter
This chapter contains the explanation about this device external features and information on the name
plate.
3.2 P1-AG appearance and nomenclature
An external view of this device is shown below.
For installing this device, connectors and other parts refer to the chapter 5 "Installation and Wiring".
3.3 Name plate
The P1-AG name plate gives the following information.
3
Chapter 3 P1-AG
P1-AG
○○○○ Ver.▽▽▽
＊＊＊＊＊＊＊△□□□□
Device model
Manufacture number (MFG No.)
Factory control number Version
FG Terminal
Name Plate (Bottom)
Input/Output terminal

3-2
Chapter 3 P1-AG
3.4 Dimensions after installed
The dimensions of this device after it is installed on the HF-430NEO are shown in the image below.
As shown on the image a part of this device will stand out from the HF-430NEO.
Please be cautious when installing the P1-AG.
HF-430NEO
Inverter
HF-430NEO
Front surface
View from the right side of HF-430NEO
96.5mm
47 mm

4-1
Chapter 4 Enclosed Items
4.1 About this chapter
This chapter contains information about the items enclosed with the P1-AG.
Additionally, it is explained how to inspect and verify this product after its purchase.
4.2 About the enclosed items
・Enclosed items
Contact your sales agent immediately in case there are defects or imperfections.
4.3 Verification after the purchase
4.3.1 Verification when unpacking
・Please verify the items written on the right when unpacking.
・In case there is any doubt or trouble with the product please contact your sales agent as soon as
possible.
4
Chapter 4 Enclosed Items
P1-AG x1 User's guide x1
Check that the items were not smashed or damaged during the delivery.
Check that
there is a P1-AG,
there is a connector,
there is a User's Guides,
there is a name label,
when unpacking.
Please check again that your order match with the name plate of the device.
Connector x1
Name label x1

5-1
Chapter 5 Installation and Wiring
5.1 About this chapter
This chapter contains information for installing and wiring this device on the HF-430NEO.
For information about the HF-430NEO installation, please refer to the HF-430NEO user's guide.
Additionally, when doing any work or operation, always follow the safety instructions and cautions given
in the chapter 1.
5.2 Installation
5.2.1 Installation
The P1-AG can be attached to any of the 3 option slots of HF-430NEO inverter.
Keypad
RJ45
USB(micro-B)
SLOT1 SLOT3
SLOT2
5
It can be attached to either SLOT1, 2 or 3.
Chapter 5 Installation and Wiring
Option cassette connection slots

5-2
Chapter 5 Installation and Wiring
5.2.2 How to install
For explanation purposes, it will be assumed that the P1-AG is going to be installed in the SLOT1.
(1) Remove the cover of the option cassette connection slot. Despite the removed cover will no longer
be needed, it is recommended to keep it in a safe place. However the screw that secured the cover
will be used to secure the P1-AG.
(2) Attach the P1-AG. The slots 2 and 3 have one more connection in the lower side.
However, the P1-AG will not need that connection.
Option cassette connection slots
Keypad
RJ45
USB(micro-B)
SLOT1 SLOT2 SLOT3
Option cassette connection slots
Keypad
RJ45
USB(micro-B)
SLOT1 SLOT2 SLOT3
Remove the screw and then
remove the cover.
The screw will be used later.
Attach the P1-AG to this
connection.

5-3
Chapter 5 Installation and Wiring
(3) Secure the P1-AG with the screw removed in procedure (1).
(4) Connect the FG terminal to functional ground.
Option cassette connection slots
Keypad
RJ45
USB(micro-B)
SLOT1 SLOT2 SLOT3
Fasten the screw.
Option cassette connection slots
Keypad
RJ45
USB(micro-B)
SLOT1 SLOT2 SLOT3
Connect to functional ground.

5-4
Chapter 5 Installation and Wiring
5.3 Terminal block and wiring
Terminal arrangement, symbols and specifications of P1-AG are shown the followings.
■Terminal arrangement
■Terminal specifications
It cannot work the following terminal combinations simultaneously.
・Combination of Vi4 and Ii4 terminal ：Combination of Vi5 and Ii5 terminal
Besides, redundant terminals need to be opened, do not wire or connect them.
・Combination of Vo3 and Io3 terminal：Combination of Vo4 and Io4 terminal
Terminal Name Symbol Description Electrical Characteristic
Analog Input
Analog Input
Terminal 4
Vi4 Voltage input 4:
0 to 10V
Input impedance: 10kΩ(approximately)
Allowable range of input: -0.3 to 12V
Ii4 Current input 4:
0 to 20mA
Input impedance: 100Ω(approximately)
Allowable range of input: 0 to 24mA
Analog Input 4
Switch Si4 Select input 4:
voltage or current
Shorted Si4 to L: Vi4 enabled(initial condition)
Opened Si4: Ii4 enabled
Analog Input
Terminal 5
Vi5 Voltage input 5:
0 to 10V
Input impedance: 10kΩ(approximately)
Allowable range of input: -0.3 to 12V
Ii5 Current input 5:
0 to 20mA
Input impedance: 100Ω(approximately)
Allowable range of input: 0 to 24mA
Analog Input 5
Switch Si5 Select input 5: voltage or current
Shorted Si5 to L: Vi5 enabled(initial condition)
Opened Si5: Ii5 enabled
Analog Input
Terminal 6 Vi6 Voltage 6:
-10 to 10V
Input impedance: 10kΩ(approximately),
allowable range of input: -12 to 12V
Analog Output
Analog Output
Terminal 3
Vo3 Voltage output 3:
0 to 10V
Maximum output current: 2mA
Allowable range: 0 to 10V(±10% accuracy)
Io3 Current output 3:
0 to 20mA
Allowable load impedance: 250Ωor less
Allowable range : 0 to 20mA(±20% accuracy)
Analog Output 3
Switch So3 Select output 3:
voltage or current
Shorted So3 to L: Vo3 enabled(initial condition)
Opened So3: Io3 enabled
Analog Output
Terminal 4
Vo4 Voltage: 0 to 10V Maximum output current: 2mA
Allowable range: 0 to 10V(±10% accuracy)
Io4 Current: 0 to 20mA Allowable load impedance: 250Ωor less
Allowable range : 0 to 20mA(±20% accuracy)
Analog Output 4
Switch So4 Select output 4: voltage or current
Shorted So4 to L: Vo4 enabled(initial condition)
Opened So4: Io4 enabled
Analog Output
Terminal 5 Vo5 Voltage output 5: -10 to 10V
Maximum output current: ±2mA
Allowable range: -10 to 10V(±10% accuracy)
Input/Output Common L Reference potential(signal ground)
Functional Ground FG Connect to the functional ground (the screw size: M3)
14 Vo3
15 Io3
16 L
17 So3
18 L
19 Vo4
20 Io4
21 L
22 So4
23 L
24 Vo5
25 L
26 L
1 Vi4
2 Ii4
3 L
4 Si4
5 L
6 Vi5
7 Ii5
8 L
9 Si5
10 L
11 Vi6
12 L
13 L
FG

5-5
Chapter 5 Installation and Wiring
■Recommendation terminals
In order to make convenience to wiring and improve the connection, it's recommended to use the ferrule
terminals with the following specifications for signal wire.
*1) Manufacturer:
PHOENIXCONTACTGmbH&Co.KG Crimpingtool:CRIMPFOX®6
Note that these specifications are different from the recommended ferrule terminals for the inverter.
■Wiring
Inserting the wire:
①Inserting the ferrule terminal into the P1-AG connector. It will be easy to insert without any tools if use
the recommendation ferrule terminals. *2)
*2) In case not using the recommendation ferrule terminal,
please insert it with a flat head screwdriver in the reverse
order of removal method.
Pulling out the wire:
①Pressing the grey part *3) on P1-AG connector with flat screwdriver（width 2.5mm or less）to open
the wire port.
②Pulling out the wire or the ferrule terminal while pressing the flat screwdriver.
③Pulling out the flat screwdriver.
*3) It is orange of the actual color that grey part
on the connector.
■Detaching the connector
Pulling down the latch lever in the arrow direction as shown below, then pulling out the connector.
Wire diameter
[mm2] (AWG)
Ferrule terminal
model *1) L1[mm] L2[mm] φd[mm] φD[mm]
0.25 (24) AI 0,25-10 YE 10.0 14.5 0.8 2.0
0.34 (22) AI 0,34-10 TQ 10.0 14.5 0.8 2.0
0.5 (20) AI 0,5-10 WH 10.0 16.0 1.1 2.5
0.75 (18) AI 0,75-10 GY 10.0 16.0 1.3 3.4
Inserting wire
Pressing the grey part *3)
with flat screwdriver
Pulling out
the wire or
the ferrule terminal
Pulling out the flat
screwdriver
Pulling down the latch lever
Pulling out the connector
