Sumitomo CYCLO User manual

No. CM2001E-12 Maintenance Manual
■These Products should be handled, installed and maintained by trained technicians.
 Carefully read the maintenance manual before use.
■A copy of this maintenance manual should be sent to the actual user.
■This maintenance manual should be kept by the user for future reference.
CYCLO® Drive
Gearmotor
Reducer
CYCLO Drive for Servo Motors
Application Product CYCLO Drive with Torque Limiter
 CYCLO Drive with Special Vertical Base Mount
《CAUTION》

1
Introduction: Safety Precautions
- Carefully read this maintenance manual and all accompanying documents before use (installation, operation, maintenance,
inspection, etc.). Thoroughly understand the machine, information about safety, and all precautions for correct operation.
After reading, retain this manual for future reference.
- Pay close attention to the "DANGER" and "CAUTION" warnings regarding safety and proper use.
DANGER Improper handling may result in physical damage, serious personal injury and / or death.
CAUTION Improper handling may result in physical damage and/ or personal injury.
Matters described in CAUTION may lead to serious danger depending on the situation.
Be sure to observe important matters described herein.
DANGER
- Transport, installation, plumbing, wiring, operation, maintenance, and inspections should be performed by trained
technicians; otherwise, electric shock, injury, re, or damage to the equipment may result.
- In the case of maintenance with disassembly, please contact the nearest authorized service station.
- When using the equipment in conjunction with explosion proof motor , a technician with electrical expertise should
supervise the transport, installation, plumbing, wiring, operation, maintenance and inspection of the equipment, so as to
avoid a potentially hazardous situation that may result in electrical shock, re, explosion, personal injury and/or damage
to the equipment.
- When the unit is to be used in a system for human transport, a protecting device for human safety should be installed
to prevent accidents resulting in personal injury, death, or damage to the equipment due to running out of control or
falling.
- When the unit is to be used for an elevator or lifter, install a safety protecting device on the elevator side to prevent
falling; otherwise, personal injury, death, or damage to the equipment may result.

22
Introduction: How to Refer to the Maintenance Manual, Table of Contents
This maintenance manual is common for “gearmotors”, “reducers”, “CYCLO Drive for servo motor” and “the application products CYCLO
Drive with Torque Limiter and CYCLO Drive with Vertical Base”.
The symbols shown below appear in the upper right or left corner of each page to indicate the classication. Please read the
applicable pages.
On Common pages, symbols identify distinctions between specic specications.
Specications All specications are
common
Gearmotor Reducer
(Include with Drive for
servo motor)
Application product
Without brake With brake
Mark
Contents
Common
Introduction: Safety Precautions……………………………………………………………………………………… 1
Introduction: How to Refer to the Maintenance Manual, Table of Contents ……………………………………… 2
1. Inspection Upon Delivery…………………………………………………………………………………………… 3
2. Storage ……………………………………………………………………………………………………………… 8
3. Transport …………………………………………………………………………………………………………… 9
4. Installation …………………………………………………………………………………………………………… 10
5. Coupling with Other Machines …………………………………………………………………………………… 13
6. Wiring ………………………………………………………………………………………………………………… 15
7. Operation …………………………………………………………………………………………………………… 34
8. Daily Inspection and Maintenance ………………………………………………………………………………… 36
9. Troubleshooting …………………………………………………………………………………………………… 72
10. Construction Drawings …………………………………………………………………………………………… 74
Application Product CYCLO Drive with Torque Limiter
11. Wiring ……………………………………………………………………………………………………………… 82
12. Adjusting Preset Torque …………………………………………………………………………………………… 84
13. Daily Inspection and Maintenance ……………………………………………………………………………… 85
14. Torque Indicator …………………………………………………………………………………………………… 86
15. Construction Drawings …………………………………………………………………………………………… 87
Application Product CYCLO Drive with Vertical Special Base Mount
16. Coupling with Other Machines …………………………………………………………………………………… 92
17. Daily Inspection, Maintenance …………………………………………………………………………………… 94
18. Construction Drawings …………………………………………………………………………………………… 95
Common
19. Warranty …………………………………………………………………………………………………………… 96
Common Application
Product

32
1. Inspection upon Delivery Common
2
Introduction: How to Refer to the Maintenance Manual, Table of Contents
CAUTION
- Unpack the unit after verifying that it is positioned right side up; otherwise, injury may result.
- Verify that the unit received is in fact the one you ordered. Installing the wrong unit may result in personal injury or
equipment damage.
- Do not remove the nameplate.
Verify the items listed below upon receiving the product. If a nonconformity or problem is found, contact our nearest agent,
distributor, or sales oce.
[1] Does the information on the nameplate conform to what you ordered?
[2] Was any part broken during transport?
[3] Are all bolts and nuts tightened rmly?
1-1 Reading the Nameplates
There are two main types of nameplates: type 1 and type 2. Representative examples are shown below. Please observe them by type.
When contacting the company, please provide [1]. Gearmotor or reducer nomenclature, [2]. Reduction ratio, and [3]. Serial number.
(1) For gearmotor
■Nameplate type 1: Gear unit and motor unit are combined.
MODEL
SF
JAPAN
OUTPUT RATING
RATIO
RATIO
INPUT kW r/min
J A P A N
SERIAL NO.
OUTPUT TORQUE
SERVICE FACTOR
MODEL
VOLTS
kW P φTYPE
FRAME
TIME RATING
M/B INS.CLASS
JISC4004
B.TORQUE
N•m
N•m
N
•
m
Hz
M.AMP
r/min
B.AMP
SERIAL NO.
INPUT kW
N•m
SERIAL NO.
SF
r/min
OUTPUT RATING
MODEL
RATIO
R
R
JAPAN
R
[1] Gearmotor nomenclature
(See P5)
[2] Reduction ratio
- Motor capacity
- Motor characteristics
- For motor with brake
Brake current value
[3] Serial number
- Motor nomenclature (see P7)
- For motor with brake
Brake type (see P7)
- Motor frame size
Figure 1-1 Gearmotor nameplate (type 1)
- For motor with brake
Brake torque
- Service factor
■Nameplate type 2: Separate nameplates for gear unit and motor unit.
[1] Gearmotor nomenclature
(See P5)
[2] Reduction ratio
- Service factor
- Input capacity, speed
- Allowable output torque
[3] Serial number
- Motor nomenclature (see P7)
- For motor with brake
Brake type (See P7)
- Motor frame size
- For motor with brake
Brake torque
[3] Serial number
MODEL
SF
JAPAN
OUTPUT RATING
RATIO
RATIO
INPUT kW r/min
J A P A N
SERIAL NO.
OUTPUT TORQUE
SERVICE FACTOR
MODEL
VOLTS
kW P φTYPE
FRAME
TIME RATING
M/B INS.CLASS
JISC4004
B.TORQUE
N•m
N•m
N
•
m
Hz
M.AMP
r/min
B.AMP
SERIAL NO.
INPUT kW
N•m
SERIAL NO.
SF
r/min
OUTPUT RATING
MODEL
RATIO
R
R
JAPAN
R
- Brake current value For motor with brake
- Motor capacity
- Motor characteristics
Figure 1-2 Gearmotor nameplate (type 2)
(Gear unit nameplate) (Motor unit nameplate)

4
1. Inspection upon Delivery
Common
(2) For reducer
■Nameplate type 1
[1] Reducer nomenclature
(See P5)
[2] Reduction ratio
- Input capacity, speed
- Allowable output torque [3] Serial number
- Service factor
MODEL
SF
JAPAN
OUTPUT RATING
RATIO
RATIO
INPUT kW r/min
J A P A N
SERIAL NO.
OUTPUT TORQUE
SERVICE FACTOR
MODEL
VOLTS
kW P φTYPE
FRAME
TIME RATING
M/B INS.CLASS
JISC4004
B.TORQUE
N•m
N•m
N
•
m
Hz
M.AMP
r/min
B.AMP
SERIAL NO.
INPUT kW
N•m
SERIAL NO.
SF
r/min
OUTPUT RATING
MODEL
RATIO
R
R
JAPAN
R
Figure 1-3 Reducer nameplate (type 1)
■Nameplate type 2
[1] Reducer nomenclature
(See P5)
[2] Reduction ratio
- Service factor
- Input capacity, speed
- Allowable output torque
[3] Serial number
MODEL
SF
JAPAN
OUTPUT RATING
RATIO
RATIO
INPUT kW r/min
J A P A N
SERIAL NO.
OUTPUT TORQUE
SERVICE FACTOR
MODEL
VOLTS
kW P φTYPE
FRAME
TIME RATING
M/B INS.CLASS
JISC4004
B.TORQUE
N•m
N•m
N
•
m
Hz
M.AMP
r/min
B.AMP
SERIAL NO.
INPUT kW
N•m
SERIAL NO.
SF
r/min
OUTPUT RATING
MODEL
RATIO
R
R
JAPAN
R
Figure 1-4 Reducer nameplate (type 2)
(3) For torque limiter equipped
Application
Product
(motor unit nameplate is the same as in gure 1-2.)
■Gear unit nameplate
Conrm that the preset torque value marked in the gear unit nameplate and the preset torque value marked on the adjustment
indicator plate (see P84) are the same as the required specication.
[1] Gearmotor nomenclature
(See P5)
[2] Reduction ratio
- Input capacity, speed
- Allowable output torque
- Torque setpoint
[3] Serial number
- Service factor
Figure 1-5 Torque limiter nameplate (gear unit nameplate)
（
RATIO ）
INPUT kW N
•
mr/min
（
SERIAL NO. ）
OUTPUT TORQUE
SERVICE FACTOR
（
MODEL ）
N
•
m
PRE-SET TORQUE N
•
m
R
JAPAN
with TORQUE LIMITER
■Alarm torque nameplate
With 2-point signal conguration (double safety specication), an alarm torque nameplate is attached near the nameplate in gure 1-5.
Alarm torque
Figure 1-6 Torque Limiter Nameplate (Alarm torque nameplate)
ALARM TORQUE
N•m
1-2 Checking Lubrication Method
Refer to“8-2 Conrmation of Lubrication Method” (P37) to conrm the lubrication method.
Oil lubricated machines are shipped with oil removed. Before operating, make certain to oil with the recommended lubricating oil.
(See P38–40)

54
1. Inspection upon Delivery Common
1-3 Gearmotor, Reducer Nomenclature
Symbol meanings are shown below. Please conrm that the nomenclature matches the order.
C H H M 3 6130 EP 43
Input capacity symbol (gearmotor)
4
P
Capacity
symbol 01 02 03 05 08 1 1H 2 3 4 5 8 10 15 20 25 30 40 50 60 75 100
kW
(HP)
0.1
(1/8)
0.2
(1/4)
0.25
(1/3)
0.4
(1/2)
0.55
(3/4)
0.75
(1)
1.1
(1.5)
1.5
(2)
2.2
(3)
3.0
(4)
3.7
(5)
5.5
(8)
7.5
(10)
11
(15)
15
(20)
18.5
(25)
22
(30)
30
(40)
37
(50)
45
(60)
55
(75)
75
(100)
6
P
Capacity
symbol 056 16 26 36 56 86 106 156 206 256 306 406 506 606 756 1006 1256 1506 1756
kW
(HP)
0.4
(1/2)
0.75
(1)
1.5
(2)
2.2
(3)
3.7
(5)
5.5
(8)
7.5
(10)
11
(15)
15
(20)
18.5
(25)
22
(30)
30
(40)
37
(50)
45
(60)
55
(75)
75
(100)
90
(125)
110
(150)
132
(175)
Slow Speed Shaft Direction
H Horizontal, Slow speed shaft level
V Vertical. Slow speed shaft down
W Inverse Vertical, Slow speed shaft up
N Universal mounting
Vertical special base mount
14 15 17 18 24 25 27 28 3
Shaft type
Blank Metric (standard)
Y Inch
YA AGMA I
YB AGMA II
YC AGMA III
G Metric (DIN)
Mounting style
H Foot
F Flange
V V-Flange
Model symbol
CCYCLO Drive
CYCLO Drive SK series
PCYCLO Drive low reduction ratio
series
Special
specication
Blank
Standard
specica-
tion
S
Special
specica-
tion
With or without
brake
Blank Without
brake
B With brake
Frame size
See P6, Table 1-1
through 1-5
Type of input
Gearmotor Reducer
M Gearmotor (motor directly connected)
Blank Reducer (free shaft)
XM X With motor ange (high speed shaft,
hollow connector)
JM J With motor ange
(With adapter, connected by coupling)
BM B Beier® Variator, direct coupling
PM Pulley connection
CM With clutch brake
RM With uid coupling
Reduction ratio
Actual reduction
ratio CYCLO Drive
Nominal ratio CYCLO Drive SK series
CYCLO Drive low reduction ratio series
Sux
BlankNote With 3-phase motor TL With torque
limiter
EP
With premium-
eciency, 3-phase
motor
R1 Simple heavy
radial
AV With AF motor for
inverter R2 Heavy radial
AP
With premium-
eciency, 3-phase
motor for inverter
BP With baseplate
ES With high-eciency,
3-phase motor H1 Foot mount and
ceiling mount
VV With vector control
motor H2 With foot mount
and left wall mount
LB Low backlash H3 Foot mount and
right wall mount
Various
code Motor ange code
Note: Only for gearmotor

66
1. Inspection upon Delivery
Common
Table 1-1 SK Series Frame Sizes
Frame size
6070SK 6080SK 6090SK 6100SK 6110SK
6075SK 6085SK 6095SK 6105SK 6115SK
Table 1-2 Low Reduction Ratio Series Frame Sizes
Frame size
6130 6140 6160 6170
6135 6145 6165 6175
Table 1-3 Single Reduction Frame Sizes
Frame size
6060
6065
6090
6095
6110
6115
6130
6135 6160
6165
616H
6180
6185 6205 6235 6265
6070
6075 6100
6105
610H
6120
6125
612H
6140
6145
614H
6190
6195 6215 6245 6275
6080
6085
6170
6175 6225 6255
Table 1-4 Double Reduction Frame Sizes
Frame size
Second stage
(Output
stage)
First stage
(Input stage) Frame size
Second stage
(Output
stage)
First stage
(Input stage) Frame size
Second stage
(Output
stage)
First stage
(Input stage) Frame size
Second stage
(Output
stage)
First stage
(Input stage)
6060DA 6060 [phone]DA 6130 [phone]DA 6165 [phone]DA 6205 ＋6125
6065DA 6065 [phone]DB 6130 [phone]DB 6165 [phone]DB 6205 ＋6135
6070DA 6070 [phone]DC 6130 [phone]DC 6165 [phone]DA 6215 ＋6135
6075DA 6075 [phone]DA 6135 [phone]DA 6170 [phone]DB 6215 ＋6165
6090DA 6090 [phone]DB 6135 [phone]DB 6170 [phone]DA 6225 ＋6135
6095DA 6095 [phone]DC 6135 [phone]DC 6170 [phone]DB 6225 ＋6175
6100DA 6100 [phone]DA 6140 [phone]DA 6175 [phone]DA 6235 ＋6165
6105DA 6105 [phone]DB 6140 [phone]DB 6175 [phone]DB 6235 ＋6185
6120DA 6120 [phone]DC 6140 [phone]DC 6175 [phone]DA 6245 ＋6165
6120DB 6120 [phone]DA 6145 [phone]DA 6180 [phone]DB 6245 ＋6185
6125DA 6125 [phone]DB 6145 [phone]DB 6180 [phone]DA 6255 ＋6175
6125DB 6125 [phone]DC 6145 [phone]DA 6185 [phone]DB 6255 ＋6195
6160DA 6160 [phone]DB 6185 [phone]DA 6265 ＋6195
6160DB 6160 [phone]DA 6190 [phone]DA 6275 ＋6195
6160DC 6160 [phone]DB 6190 ＋6135
6195DA 6195 ＋6125
6195DB 6195 ＋6135
Table 1-5 Triple Reduction Frame Sizes
Frame size
Third stage
(Output
stage)
Second stage
(Intermediate
stage)
First stage
(Input stage) Frame size
Third stage
(Output
stage)
Second stage
(Intermediate
stage)
First stage
(Input stage) Frame size
Third stage
(Output
stage)
Second stage
(Intermediate
stage)
First stage
(Input stage)
6060TA 6060 + 6060 + 6060 6170TA 6170 + 6095 + 6075 6205TA 6205 + 6125 + 6075
6065TA 6065 + 6065 + 6065 6170TB 6170 + 6105 + 6075 6205TB 6205 + 6125 + 6095
6070TA 6070 + 6065 + 6065 6170TC 6170 + 6125 + 6075 6205TC 6205 + 6135 + 6075
6075TA 6075 + 6065 + 6065 6170TD 6170 + 6125 + 6095 6205TD 6205 + 6135 + 6095
6090TA 6090 + 6075 + 6065 6175TA 6175 + 6095 + 6075 6205TE 6205 + 6135 + 6105
6095TA 6095 + 6075 + 6065 6175TB 6175 + 6105 + 6075 6215TA 6215 + 6135 + 6075
6100TA 6100 + 6075 + 6065 6175TC 6175 + 6125 + 6075 6215TB 6215 + 6135 + 6095
6105TA 6105 + 6075 + 6065 6175TD 6175 + 6125 + 6095 6215TC 6215 + 6135 + 6105
6120TA 6120 + 6075 + 6065 6180TA 6180 + 6105 + 6075 6215TD 6215 + 6165 + 6095
6120TB 6120 + 6095 + 6075 6180TB 6180 + 6135 + 6075 6215TE 6215 + 6165 + 6105
6125TA 6125 + 6075 + 6065 6180TC 6180 + 6135 + 6095 6215TF 6215 + 6165 + 6125
6125TB 6125 + 6095 + 6075 6180TD 6180 + 6135 + 6105 6225TA 6225 + 6135 + 6075
6130TA 6130 + 6075 + 6065 6185TA 6185 + 6105 + 6075 6225TB 6225 + 6135 + 6095
6130TB 6130 + 6095 + 6075 6185TB 6185 + 6135 + 6075 6225TC 6225 + 6135 + 6105
6130TC 6130 + 6105 + 6075 6185TC 6185 + 6135 + 6095 6225TD 6225 + 6175 + 6095
6135TA 6135 + 6075 + 6065 6185TD 6185 + 6135 + 6105 6225TE 6225 + 6175 + 6105
6135TB 6135 + 6095 + 6075 6190TA 6190 + 6125 + 6075 6225TF 6225 + 6175 + 6125
6135TC 6135 + 6105 + 6075 6190TB 6190 + 6125 + 6095 6235TA 6235 + 6165 + 6095
6140TA 6140 + 6075 + 6065 6190TC 6190 + 6135 + 6075 6235TB 6235 + 6165 + 6105
6140TB 6140 + 6095 + 6075 6190TD 6190 + 6135 + 6095 6235TC 6235 + 6165 + 6125
6140TC 6140 + 6105 + 6075 6190TE 6190 + 6135 + 6105 6235TD 6235 + 6185 + 6105
6145TA 6145 + 6075 + 6065 6195TA 6195 + 6125 + 6075 6235TE 6235 + 6185 + 6135
6145TB 6145 + 6095 + 6075 6195TB 6195 + 6125 + 6095 6245TA 6245 + 6165 + 6095
6145TC 6145 + 6105 + 6075 6195TC 6195 + 6135 + 6075 6245TB 6245 + 6165 + 6105
6160TA 6160 + 6095 + 6075 6195TD 6195 + 6135 + 6095 6245TC 6245 + 6165 + 6125
6160TB 6160 + 6105 + 6075 6195TE 6195 + 6135 + 6105 6245TD 6245 + 6185 + 6105
6160TC 6160 + 6125 + 6075 6245TE 6245 + 6185 + 6135
6160TD 6160 + 6125 + 6095 6255TA 6255 + 6175 + 6095
6165TA 6165 + 6095 + 6075 6255TB 6255 + 6175 + 6105
6165TB 6165 + 6105 + 6075 6255TC 6255 + 6175 + 6125
6165TC 6165 + 6125 + 6075 6255TD 6255 + 6195 + 6125
6165TD 6165 + 6125 + 6095 6255TE 6255 + 6195 + 6135
6265TA 6265 + 6195 + 6125
6265TB 6265 + 6195 + 6135
6275TA 6275 + 6195 + 6125
6275TB 6275 + 6195 + 6135

76
1. Inspection upon Delivery
6
1-4 Motor Nomenclature
Symbol meanings are shown below. Please conrm that the nomenclature matches the order.
When used with a vector motor, or other manufacturer’s motor (There are some models made by other manufacture.), see the
relevant operation manual.
H T C E X
Support for standards and
regulations
P Premium-eciency motor
EHigh-eciency motor
(IEC standard)
Blank Motor other than above
Cooling type
FWith self-ventilating fan
(external fan)
B With ventilated fan
E Fanless (natural air cooling)
Mounting style
H Foot
Blank Flange
Type of sheath
TTotally
enclosed
Rotor symbol
C Normal box
K Special box
Drive power source
V Inverter drive (motor for inverter)
Blank Commercial power source drive
Explosion Proof, Protection Type
AIncreased safety explosion proof,
indoor type
BIncreased safety explosion proof, out-
door type
C Indoor ameproof
CX Outdoor ameproof
X Outdoor (honexplosion proof)
Blank Indoor (honexplosion proof)
1-5 Brake type
Table 1-6 shows the relationship between standard brake type and motor type and capacity range.
Table 1-6 Brake type
Brake type
Motor capacity (kW)
3-phase motor Premium-eciency,
3-phase motor AF motor for inverter
Premium-eciency,
3-phase motor for
inverter
High-eciency,
3-phase motor

4P 4P 6P 4P 6P 4P 4P
FB-01A1 0.1 - - - - - -
FB-02A1 0.2 0.25 - - 0.1 - - -
FB-05A1 0.4 - - 0.2 - - 0.2
FB-1D 0.55 - - 0.4 - - 0.4
FB-1E - 0.75 - - - 0.75 -
FB-1HE - 1.1 - - - - -
FB-2E - 1.5 - - - 1.5 -
FB-3E - 2.2 - - - 2.2 -
FB-4E - 3.0 - - - - -
FB-5E - 3.7 - - - 3.7 -
FB-8E - 5.5 - - - 5.5 -
FB-10E - 7.5 - - - 7.5 -
FB-15E - 11 - - - 11 -
FB-20 - 15 - - - 15 -
FB-30 - 18.5 22 30 15 18.5 22 - - 18.5 22 30 -
ESB-250
(Horizontal Type)
ESB-250-2
(Vertical Type)
- 37 45 30 37 30 37 18.5 22 30 37 45 -
Note : Depending on the specication, brake type may dier from the types shown in Table 1-6. Check the nameplate.

88
2. Storage
Common
If this product is not for immediate use, note the following points when storing it.
2-1 Storage Location
Store the product indoors in a clean, dry location.
Do not store outdoors. Store in a location that is free of moisture, dust, extreme temperature changes, corrosive gases, etc.
2-2 Storage Time
- The storage time should be within the rust prevention time shown below.
- Standard rust prevention specications
External rust prevention Rust prevention oil is applied when shipping from the factory. Check the rust conditions to see
if any rust is forming on the machined surface every six months after shipment. Reapply the rust
prevention oil or any other rust prevention process, if necessary.
Internal rust prevention
Lubrication Grease lubricated machines Oil lubricated machines
Rust prevention time One year Six months
Storage conditions Store in an ordinary factory or warehouse in an environment free of
moisture, dust, extreme temperature changes, corrosive gases, etc.
- If for export, or if the storage time is longer than one year, adherence to special rust prevention specications is required.Please
consult with us.
- If the storage time is longer than one year, run for a few minutes under no load once every two to three months. Measure (see P16)
and check the insulation resistance of the motor at that time.
2-3 Using after Storage
- Oil seals are aected by temperature, ultraviolet light and other ambient conditions and can easily degrade. After long storage
periods, inspect before operation, and replace any degraded seals with new seals.
- If the storage time is longer than two years, replace the oil seal and the grease before starting operation.
- At startup, check that there are no unusual noises, vibrations, temperature rises, or other symptoms. For models with brakes, check
that brakes work properly.
If any abnormalities are found, immediately contact the nearest authorized service station.

98
3. Transport Common
8
DANGER
- Do not stand directly under a unit suspended by a crane or other lifting mechanism; otherwise, injury, or death may
result.
CAUTION
- Exercise ample care so as not to drop the unit.
When a hanging bolt or hole is provided, be sure to use it. After mounting a unit to a machine, do not hoist the entire
machine using the hanging bolt or hole; otherwise, personal injury or damage to the equipment and/ or lifting device
may result.
- Before hoisting, refer to the rating plate, crate, outline drawing, catalog, etc. for the weight of the unit. Never hoist a unit
that exceeds the rating of the crane or other mechanism being used to lift it; otherwise, personal injury or damage to the
equipment and/ or lifting device may result.
- When the products are lifted, use suitable lifting parts, and conrm which eye-bolts and nuts are not loose.
- Always drain oil lubricated models before mounting, moving, and transporting.
Moving with lubricating oil in the machine may cause oil to escape from the air vent, etc.

10
4. Installation
Common
DANGER
- Do not use a standard unit in an explosive atmosphere (which is likely to be lled with explosive gas or steam). Under
such conditions, an explosion proof motor should be used; otherwise, electric shock, personal injury, explosion re, or
damage to the equipment may result.
- In the case of a Explosion proof motor , use a motor that has specications that are appropriate for a dangerous location
(a location where gas or volatile vapor is present); otherwise explosion, ignition, electric shock, injury, re, or equipment
damage may result.
- Since the inverter itself is not explosion proof, when a ameproof motor is driven by an inverter install an inverter in a place
free from explosive gas; otherwise, electric shock, personal injury, explosion re, or damage to the equipment may result.
CAUTION
- Do not use the products for purposes other than those shown on the nameplate or in the manufacturing specications;
otherwise, electric shock, personal injury, or damage to the equipment may result.
- Do not place ammable objects around the gearmotor; otherwise, re may result.
- Do not place any object around the gearmotor or reducer that will hinder ventilation. Insucient ventilation can cause
excessive heat build-up that may result in burns or re.
- Do not step on or hang from the gearmotor or reducer; otherwise injury may result.
- Do not touch the shaft end of the gearmotor or reducer, inside keyways, or the edge of the motor cooling fan with
bare hands; otherwise, injury may result.
- When the unit is used in food processing applications, machines for cleanroom and so on, vulnerable to oil
contamination, install an oil pan or other such device to cope with oil leakage due to breakdown or failure; otherwise, oil
leakage may damage products.
- Always drain oil lubricated models before mounting, moving, and transporting. Moving with lubricating oil in the
machine may cause oil to escape from the air vent, etc.
4-1 Installation Location
Ambient temperature: −10 to +40℃
Ambient humidity: Maximum 85％
Altitude: Maximum 1,000 m
Atmosphere: No corrosive or volatile gases, no steam
  Dust-free, well-ventilated area.
Installation location: Indoor type: Indoors (area with minimal dust, no contact with water)

Outdoor type: Indoors or outdoors (place where are got wet with common rainwater not but direct heavy
wind and rain)
  Vibration: Maximum 1G
- Mounting in conditions other than the above requires adherence to optional specications. Please consult with us.
- Drives built to specications, such as explosion proong, can be used in the specied mounting environments. However, concerning
the connector to the machine used, implement measures based on the mounting environment.
- Mount in a location that enables easy operation, such as inspection and maintenance.
- Mount on a suciently rigid base.
4-2 Mounting Angle
Table 4-1 Mounting Angle
Grease lubricated
machines
Long-life grease models
(Except SK series) Free
Machine types other than
the above
Slow speed shaft is horizontal or vertical (depends on nomenclature. See P5.
Please consult with us for inclined mounting).
Oil lubricated machines Slow speed shaft is horizontal or vertical (depends on nomenclature. See P5.
Please consult with us for inclined mounting).
For machines built to a specied mounting angle, only use the specied mounting angle.
Do not remove the motor’s eye-bolt. In the rare case that it is removed, insert a bolt or other appropriate material into the screw
hole to prevent water or other substances from entering the motor through the screw hole.

1110
4. Installation Common
For the horizontal slow speed shaft level type (see P5), attach it as shown in the gure below.
Figure 4-1 Mounting Angle (Example: Foot mount type)
4-3 When Load Condition Is Critical
In cases of extreme vibration or frequent startup, it is recommended to knock the foot unit, and use a mounting bolt of at least class 8.8
(JIS B 1051) strength.
4-4 Flange Type Assembly Issues (Models: CNFM, CHFM, CNF, CHF, etc.)
[1] Remove the fan cover if there is one installed (reducer frame size of 6160 or more).
[2]
Remove the nut and bolt for ring gear housing. Take care when loosening the nut, as the bolt for ring gear housing may rotate together.
[3] A nut of a dierent size to the nut for ring gear housing may be assembled between the nut for ring gear housing and casing when
the device is shipped. Remove this nut, as it is a spacer replacement nut for preventing damage to the faces of the nut for ring gear
housing and casing, as well as for preventing the nut coming free of the threaded section of bolt for ring gear housing.
[4]
Assemble the device to the driven machine, and tighten the nut and bolt for ring gear housing with the tightening torque shown in Table 4.2.
- Disassembly prevention nuts are installed at 2 locations of the bolt for ring gear housing (opposing angles) to prevent disassembly
of the reducer in case the bolt for ring gear housing is removed. Do not remove the disassembly prevention nuts. Removing them
may result in the casing, ring gear housing, internal cover, motor and other parts disassembling and falling o, and may cause injury.
- Using only the disassembly prevention nuts with the nut for ring gear housing removed does not generate a sucient level of
torque. Do not use only the disassembly prevention nuts for ring gear housing for long periods of time, move them excessively or
subject them to shock. Lubricant or grease may leak if there gaps develop between any of the mating faces.
- Tightening the nut for ring gear housing changes the axial force of the disassembly prevention nuts, and may result in them coming
loose. To remove the CYCLO Drive after temporarily assembling the device to the driven machine, check that the disassembly
prevention nuts have not become loose.
Bolts for ring
gear housing
Nuts for ring
gear housing
Casing
Ring gear housing
Fan cover
Internal cover
Spacer replacement nuts
Internal cove
r
Casing Ring gear housing
Disassembly
prevention nuts
Disassembly prevention nuts
(2 locations at opposing angles)
Figure 4-2 Construction Drawings
Table 4-2 Tightening torque for nuts and bolts for ring gear housing
Frame size Size
Tightening Torque
(N·m)
Frame size Size
Tightening Torque
(N·m)
Single reduction Double reduction Single reduction Double reduction
606□606□DA M6 11 617□617□DA, 617□DB, 617□DC
M12 96607□607□DA 618□618□DA, 618□DB
608□-
M8 25
619□619□DA, 619□DB
609□609□DA 6205 6205DA, 6205DB M16 219
610□610□DA 6215 6215DA, 6215DB M18 298
611□- 6225 6225DA, 6225DB M20 475
612□612□DA, 612□DB
M10 55
6235 6235DA, 6235DB
613□613□DA, 613□DB, 613□DC 6245 6245DA, 6245DB M24 794
614□614□DA, 614□DB, 614□DC 6255 6255DA, 6255DB
616□616□DA, 616□DB, 616□DC M12 96 6265 6265DA M30 1590
Note : 1. The symbol □in frame size can be "0" or "5."
2. If a nut and bolt are prepared by the customer, a tightening torque that suits the nut and bolt should be used.
3. The position of the disassembly prevention nuts and the shape of each part depend on the frame size.
1° or mor
e
1° or more

1212
4. Installation
Common
4-5 Keyless Shaft Motor Assembly Issues (Hollow Connection High Speed Shaft for Servo Motors)
[1] Remove oil, dirt, and other contaminants from the motor shaft and inside of the CYCLO Drive high speed shaft. (The inner surface of
the high speed shaft is treated with rust prevention oil before shipping.)
[2] Position the reducer on a platform so that the slow speed shaft is on the bottom.
[3] Align the high speed shaft with the notch on the clamp ring.
[4] Remove the adapter plate cap and insert a hexagonal wrench through the setting hole into the hexagon socket head bolt in the
clamp ring. Next, insert the motor shaft into the high speed shaft.
[5] When assembling the motor and CYCLO Drive, make sure that the centers of both shafts are aligned. Do not force the assembly if the
shafts are slanted or misaligned.
[6] Fasten the motor and adapter plate using the motor mounting bolt. Tighten after conrming that the motor tting is securely
inserted into the adapter plate tting. Important: If the bolt is tightened when the tting is not inserted, uneven tightening will
result, causing damage to the internal bearing and other components.
[7] Tighten the clamp ring hexagon socket head bolt to the torque shown in Table 4-3.
[8] After operating at low speed, increase the tightening torque as shown in Table 4-3.
[9] Attach the adapter plate cap that had been removed.
Table 4-3 Tightening torque for the clamp ring hexagon socket head bolt
Bolt size M4 M5 M6 M8 M10 M12
Tightening Torque (N·m) 4.3 5.5 9.6 23 46 79
Motor
Clamp ring
Cap
High speed shaft
Figure 4-2 Assembly Diagram
4-6 Keyed Shaft Motor Assembly Issues (Hollow Connection High Speed Shaft for Servo Motor or
General Flange Motors)
[1] Remove oil, dirt, and other contaminants from the motor shaft and inside of the CYCLO Drive high speed shaft. (The inner surface of
the high speed shaft is treated with rust prevention oil before shipping.)
[2] Align the motor shaft key with the high speed hollow shaft keyway. (Keyway dimensions conform to JIS B 1301-1996 (ISO)“Keys and
Their Corresponding Keyways: Parallel keys (Normal Type)”).
[3] Coat the motor shaft with molybdenum disulde grease to prevent fretting.
[4] Depending on the motor combination, a spacer for preventing the key from falling out may be in a separate shipment. Before
assembly, insert the spacer deep into the hole in the high speed shaft. Operation with uninserted spacer could result in the key
falling out and damaging the shaft.
[5] When assembling the motor and CYCLO Drive, make sure that the centers of both shafts are aligned. Do not force the assembly if the
shafts are slanted or misaligned or if the key is only partially engaged.
[6] Fasten the motor and adapter plate (internal cover) using the motor mounting bolt. Tighten after conrming that the motor tting
is securely inserted into the adapter plate (internal cover) tting. Important: If the bolt is tightened when the tting is not inserted,
uneven tightening will result, causing damage to the internal bearing and other components.

1312
5. Coupling with Other Machines Common
12
CAUTION
- Conrm the rotation direction before coupling the unit with the driven machine. Incorrect rotation direction may
cause personal injury or damage to the equipment.
- When operating the product alone (uncoupled), remove the key that is temporarily attached to the slow speed shaft;
otherwise the key could y o, and injury may result.
- Cover rotating parts; otherwise, injury may result.
- When coupling the product with a load, check that the centering, the belt tension and parallelism of
the pulleys are within the specied limits. When the unit is directly coupled with another machine, check that the
direct coupling accuracy is within the specied limits. When a belt is used for coupling the unit with another machine,
check the belt tension. Correctly tighten bolts on the pulley and coupling before operation; otherwise there is a risk of
injury due to scattering the broken pieces or of damage to the products.
5-1 Checking Rotational Direction
(1) For gearmotor
Table 5-1 shows the direction of slow speed shaft rotation when wiring is performed as on P18–31.
Table 5-1 Slow Speed Shaft Rotation Direction (Gearmotor)
When wiring is performed as shown on P18–31, the motor shaft rotates to the right as seen from
the anti-load side.
In the following diagrams, arrows show the direction of slow speed shaft rotation in this case.
Gear unit construction Single Reduction – Triple Reduction
Double Reduction
SK Series
Low reduction ratio series
Slow speed shaft
rotation direction
(Seen from load side)
Note : To cause reverse rotation, reverse R and T on P18 and P20–27.
(2) For reducer
Table 5-2 Slow Speed Shaft Rotation Direction (Reducer)
Gear unit construction Single Reduction – Triple Reduction Double Reduction
SK Series
Slow speed shaft
rotation direction
Rotates in opposite direction as the
high speed shaft.
Rotates in same direction as the high
speed shaft.
Note : For the SK series,“SK” is appended to frame sizes.
For the low reduction ratio series, “P” is prepended to nomenclature.

1414
5. Coupling with Other Machines
Common
5-2 Mounting Connected Equipment
- When mounting connected equipment, do not apply impact or excessive axial load to the shaft. The bearing could be damaged, or
the collar could come o.
- Shrinkage t is recommend.
(1) When using a coupling
The alignment accuracy (A, B, X) in gure 5-1 should be no greater than that shown in Table 5-3.
(2) When using chains, sprockets, or gears
- When using a chain, attach so that the chain tension angle is perpendicular to the shaft.
- Refer to the chain catalog or other reference for chain tension.
- The pitch circle of the sprocket and gear shall be more than three times of the shaft diameter.
- The working load point of the sprocket or gear should go from the center of the shaft to this product. (See gure 5-2)
(3) When using a V belt
- Over-tightening the V belt will damage the shaft and bearing. Refer to the V belt catalog or other reference for V belt tension.
- The parallelism, eccentricity β of the two pulleys should be within 20´. (See gure 5-3)
- When using multiple V belts, use a matched set having the same circumferential length.
Table 5-3 Alignment Precision for Flexible Coupling
Allowable tolerance A
0.1 mm or
manufacturer-specied
value
Allowable tolerance B
0.1 mm or
manufacturer-specied
value
Xmanufacturer-specied
value
X
A
X
B
Figure 5-1
Figure 5-2 Figure 5-3
ConnectorProduct
Shaf
t
β
β

1514
6. Wiring
14
When using a vector motor, or other manufacturer’s motor (There are some models made by other manufacture.), follow the opera-
tion manual for that motor.
This manual shows wiring for motors with Japanese standard specications. Please consult with us for motors with overseas
specications.
DANGER
- Do not handle the unit when cables are live. Be sure to turn o the power; otherwise, electric shock may result.
- Connect a power cable to the unit according to the diagram shown inside the terminal box or in the maintenance
manual; otherwise, electric shock or re may result.
- Do not forcibly bend, pull, or clamp the power cable and lead wires; otherwise, electric shock or re may result.
- Correctly ground the grounding bolt; otherwise, electric shock may result.
- The lead-in condition of an explosion proof motor shall conform to the facility's electrical codes, extension regulations
and explosion proong guide, as well as the maintenance manual; otherwise, electric shock, personal injury, explosion,
re or damage to the equipment may result.
CAUTION
- When wiring, follow the facility's electrical codes and extension regulations; otherwise, burning, electric shock,
injury, or re may result.
- The motor is not equipped with a protection device. However, it is compulsory to install an overload protector according
to facility electrical codes. It is recommended to install other protective devices (earth leakage breaker,
etc.), in addition to an overload protector, in order to prevent burning, electric shock, injury, and re.
- Never touch the terminals when measuring insulation resistance; otherwise, electric shock may result.
- When using a When using a star-delta starter select one with an electromagnetic switch on the primary side (3-contact
point type); otherwise, re may result.
- Voltage PWM inverters that use IGBT generate high-voltage surges at the motor terminals, which may degrade the
insulation on the motor windings. Especially such as when the cable is long in the 400V class, a surge voltage over 1300V
occurs. Therefore, in this case, install an LCR lter, AC reactor, etc. between the inverter and motor to inhibit the surge
voltage.
- When using a motor with brake , do not turn on connection power to the brake coil when the motor is stopped.
Otherwise coil burnout re, may result. Also, mistaken wiring could damage the rectier.
- When a explosion proof motor is driven by an inverter , use one inverter for one motor. Use the approved inverter for the
motor.
- When measuring the insulation resistance of a explosion proof motor , conrm that there is no gas or explosive vapor in
the vicinity, in order to prevent possible explosion or ignition.
- If ambient temperature exceeds 60℃, place the rectier in a location where the temperature is 60℃or less. In this case,
always protect the entire rectier with a cover. However, standard ambient temperature conditions for units with and
without brakes is −10 to 40℃. (Manufacture to special specication is required for operation in an environment where
ambient temperature exceeds 40℃.)
- Long cables cause large voltage drops. Select cables with appropriate diameter so that the voltage drop will no greater
than 2%.
- After wiring outdoor types and explosion proof types , check that terminal box mounting bolts are not loose, and
correctly attach the terminal box cover.

16
6. Wiring
6-1 Removing and Attaching the Resin Terminal Box Cover
3-phase motor 4P: 0.1–0.4kW, high-eciency, 3-phase motor 4P: 0.2kW, AF motor for inverter: 0.1–0.2kW
(1) Removal
As shown in gure 6-1, to remove the cover, grab the sides of the terminal box, and pull it toward you.
(2) Attachment
Push the terminal box cover from above the terminal box case until a click is heard.
Figure 6-1
6-2 Measuring Insulation Resistance
When measuring insulation resistance, always disconnect the control board and measure the motor alone.
Measure insulation resistance before wiring. Insulation resistance (R) is changed by a number of factors, including motor output,
voltage, type of insulation, winding temperature, moisture, degree of fouling, time used, and amount of time test voltage is applied.
However, normally, it must be above the values in Table 6-1.
Table 6-1 Values for Insulation Resistance
Motor voltage Megaohmmeter voltage Insulation resistance (R)
Low-voltage electric motors of
no more than 600V 500V Minimum 1 M
Reference: JEC -2100 contains the following equation.
Rated Voltage (V) + (RPM/3)
R ≧+ 0.5 (M)
Rated output power (kW) + 2,000
Rated Voltage (V)
R ≧(M)
Rated output power (kW) + 1,000
Low insulation resistance is a sign that there is an insulation failure. Do not apply power. Consult an accredited service station.
6-3 Coordination of System Protection
- Use a wiring breaker for short circuit proong.
- Use an overload protection device designed to handle currents that exceed the rated current on the nameplate.
- For Increased safety, explosion proof motor , use an overload protection device capable of protecting the locked rotor current on the
nameplate within the allowable locking time.
6-4 Connecting the Power Cable
Connect the power cable and motor lead wire by clasping in a pressure connection
terminal as shown in gure 6-2.
Figure 6-2
Power source cable
Motor lead wire
Insulating tape
Fig. 11


1716
6. Wiring
6-5 Motor Wiring
Shows the pages for motor wiring diagrams.
Table 6-2 Without Brake
Motor type Number of
poles Capacity (kW) Number of lead
wires
Page
Direct
input from
commercial
power source
Inverter drive
3-phase motor
Standard 4P 0.1–0.55 3 P18 P19
4/8P All 6 P18 -
Increased
safety,
explosion proof
4P 0.1–7.5
11–55 3 6P18 -
6P 7.5
11–55 3 6P18 -
Flameproof
4P 0.1–22
30–37 3 6P18 -
4P 0.75-3.7
5.5-55 3 6P18 -
Premium-
eciency,
3-phase motor
Standard 4P 0.75–3.7
5.5–55 3 6P18 P19
6P 15-55 6 P18 P19
Increased
safety,
explosion proof 4P 0.75-3.7
5.5-11 3 6P18 -
AF motor for
inverter
Standard 4P 0.1–0.4
30–45 3 11 - P19
6P 18.5–45 11 - P19
Flameproof 4P 0.2–15 22
30-55
3
6
11 - P19
Premium-eciency, 3-phase
motor for inverter 4P 0.75–3.7
5.5–55 3 6- P19
High-eciency, 3-phase motor 4P 0.2–0.4 3 P18 P19
Table 6-3 With Brake
Motor type Number of
poles Capacity (kW) Brakes Number of lead
wires
Page
One-direction
rotation Plugging rotation
Inverter drive
3-phase motor 4P
0.1 FB-01A1
5 P20 P24 P28
0.2 0.25 FB-02A1
0.4 FB-05A1
0.55 FB-1D
Premium-eciency,
3-phase motor
4P
0.75 FB-1E
5 P20 P24 P28
1.1 FB-1HE
1.5 FB-2E
2.2 FB-3E
3.0 FB-4E
3.7 FB-5E
5.5 FB-8E
8
P21 P25
P29
7.5 FB-10E
11 FB-15E
15 FB-20 P22 P26
18.5 22 30 FB-30
37 45 ESB-250
ESB-250-2 P23 P27 P30
6P
15 18.5 22 FB-30
8P22
P23 P26 P27 P29 P30
30 37 ESB-250
ESB-250-2
AF motor for inverter

4P
0.1 FB-02A1
5
- -
P280.2 FB-05A1
0.4 FB-1D
30 37 ESB-250
ESB-250-2 13 P31
6P 18.5 22 30 ESB-250
ESB-250-2 13 P31
Premium-eciency,
3-phase motor for inverter
4P
0.75 FB-1E
5
- -
P28
1.5 FB-2E
2.2 FB-3E
3.7 FB-5E
5.5 FB-8E
8
P29
7.5 FB-10E
11 FB-15E
15 FB-20
18.5 22 30 FB-30
37 45 ESB-250
ESB-250-2 P30
High-eciency,
3-phase motor 4P 0.2 FB-05A1 5 P20 P24 P28
0.4 FB-1D
Note : 1. Brake type may dier depending on specication. Check the nameplate.
2. For motors with standard Japanese domestic specications. Please consult with us for motors with overseas specications.

18
6. Wiring
Shows motor wiring and standard specication for terminals and lead wires that are indicated by symbols.
■Without brake. 3-phase power source
3-phase motor
Premium-eciency, 3-phase motor
High-eciency, 3-phase motor
3 lead wires 6 lead wires (direct on-line starting)
Control Panel Control Panel
Motor Motor
6 lead wires (
‒Δ
starting) 4/8P two speed, single wound rotor (constant torque)
At start
Wiring
MCMON
MCOFF
MC ON
When
acceleration
is completed
 wiring
MCMON
MCON
MC OFF
When at low
speed
(8P)
MCLON
MCH1 OFF
MCH2 OFF
When at
high speed
(4P)
MCLOFF
MCH1 ON
MCH2 ON
Control Panel Control Panel
Motor Motor
MC: Electromagnetic contactor
OLR: Overload protection device or electronic thermal relay Customer to prepare.
- This diagram shows cases for motors with standard Japanese domestic specications. Please consult with us for motors with
overseas specications.
U1 V1 W1
V2 W2 U2
RST
MC
OLR
Motor
U1 V1 W1 V2 W2 U2
MC
MC
M
OLR
MCΔ
MC
Motor
SRT
1U 1V 1W 2U 2V 2W
MCL
OLRL
RST
MCH1
MCH2
OLRH
Motor
U V W
RST
MC
OLR
Motor
