Sumitomo Beier Variator Series User manual

BM2001E-3

1
DANGER
Transport, installation, plumbing, wiring, operation, maintenance, and inspections should be performed by trained
technicians; otherwise, electric shock, injury, fire, or damage to the equipment may result.
When using the equipment in conjunction with an explosion proof motor , a technician with electrical expertise
should supervise the transport, installation, plumbing, wiring, operation, maintenance and inspection of the
equipment so as to avoid a potentially hazandous, situation that may result in electrical shock, fire, explosion,
personal injury and/or damage to the equipment.
When the unit is to be used in a system for human transport, a secondary safety device should be installed to
minimize chances of accidents resulting in personal injury, death, or damage to the equipment.
When the unit is to be used for an elevator, install a safety device on the elevator side to prevent it from falling;
otherwise, personal injury, death, or damage to the equipment may result.
Safety and Other Precautions
Carefully read this maintenance manual and all accompanying documents before use (installation, operation,
maintenance, inspection, etc.). Thoroughly understand the machine, information about safety, and all precautions for
correct operation. Retain this manual for future reference.
Pay close attention to the "DANGER" and "CAUTION" warnings regarding safety and proper use.
: Improper handling may result in physical damage, serious personal injury and/or
death.
: Improper handling may result in physical damage and/or personal injury.
Matters described in may lead to serious danger depending on the situation. Be sure to observe important
matters described herein.
DANGER
CAUTION
CAUTION

Specifications
Common
specifications
Basic type
Beier variator
Symbol
with
motor
without
motor
COMMON
Beier variator
with built in gear
Beier Cyclo
variator
CONTENTS
1. Inspection Upon Delivery............................................................................................................. 3
2. Storage ....................................................................................................................................... 7
3. Transport .................................................................................................................................... 7
4. Installation .................................................................................................................................. 8
5. Coupling with Other Machines ................................................................................................... 9
6. Wiring ................................................................................................................... 11
7. Operation ................................................................................................................................. 15
8. Daily Inspection and Maintenance ........................................................................................... 16
9. Lubricating Oil Cooling Device .................................................................................................. 28
10. Troubleshooting ..................................................................................................................... 30
11. Remote Control Equipment ................................................................................... 31
12. Construction Drawing................................................................................................................ 35
13. Oil seal list ............................................................................................................................... 39
14. Bearing list .............................................................................................................................. 40
15. Disk, spline list.......................................................................................................................... 42
16. Warranty ................................................................................................................................. 42
2
OP
How to Refer to the Maintenance Manual
This maintenance manual is common for both Cyclo gearmotor and reducer. The symbols shown below appear in the upper
right corner of each page to indicate the classification. Read the applicable pages. On COMMON pages, these symbols
identify distinctions between gearmotors and reducers.
• Refer to the brake maintenance manual (Cat. No.MM0202E) for the handling of beier variator .

3
Beier Variator Basic type , With Built-in gear type
(1) Beier
(2) Motor
1Model name
(Refer to page 5)
2Speed Rang
· Motor capacity speed
3Serial No.
Fig.1 Rating Plates of Beier Variator Basic type, or with Built-in gear type
· Motor capacity
· Motor characteristics
· Brake characteristics
(optional)
3Serial No.
4Motor Type (Refer to page 6.)
5Brake Type (optional)
(Refer to the brake maintenance
· Motor frame size
· Motor shaft bearing No.
Fig.2 Motor Rating Plate
ER243WW
VOLTS
TYPEkW P
Hz
M.AMP
B.AMP
B.TORQUE
BRG.
SERIAL NO.
r/min
M/B INS.CLASS
RATING
FRAME
N·m
JISC4004
JAPAN
INDUCTION MOTOR
COMMON
1. Inspection Upon Delivery
CAUTION
Unpack the unit after verifying that it is positioned right side up; otherwise, injury may result.
Verify that the unit received is in fact the one you ordered. Installing the wrong unit may result in personal injury or
equipment damage.
Do not remove the rating plate.
Verify the items listed below upon receiving the Beier Variator. If a nonconformity or problem is found, contact our nearest
agent, distributor, or sales office.
(1) Does the information on the rating plate conform to what you ordered?
(2) Was there any part broken during transport?
(3) Are all bolts and nuts tightened firmly?
1-1) How to Refer to the Rating Plate
• When making an inquiry, advice us of the model name, Serial no.
COMMON

4
MODEL
RATIO
INPUT
OUTPUT TORQUE
SERIAL NO.
BEIER SPEED RANGE
R
AN9077G
JAPAN
kW r/min
N-m AT MAX. SPEED
N-m AT MIN. SPEED
1Model name
(Refer to page 5)
3Speed Rang
· Motor capacity speed
· Allowable output
torque
4Serial No.
Fig.3 Rating Plates of Beier-Cyclo Variator
2Cyclo Reducer Ratio
Same as page 3.
Beier Cyclo Variator
(1) Beier Cyclo
(2) Motor
COMMON
1-2) Lubrication Method
Refer to "8-2. Confirmation of Lubrication Method" on page 17 to confirm the lubrication method.
•Oil-lubricated models are shipped without oil. Units must be filled with the proper amount of recommended oil prior
to start-up.
COMMON
COMMON

GBMN5A G30
5
1-3) Type of Variator
Respective codes and motor nomenclature are shown below. Please verify that the type you received conforms to
whatyou ordered.
Nomenclature
BASIC
TYPE FRAME SIZE SUFFIX
REDUCTION
RATIO
B H H M N05D
Shaft Direction
HHorizontal
VVertical
Method of
Mounting
HFoot
Mount
FFlange
Mount
Method of Input
Free Input
Shaft
M
K
P
With
Motors
With
Coupling
With
V-Pulley
BEIER
Frame Size
Suffix
With 3-phase Motor
EP With 3-phase Premium
Efficiency Motor
BP With Baseplate
GEAR
Frame Size
BEIER-CYCLO®VARIATOR
REDUCTION
RATIO
CHH
VBase
Mount
CYCLO
®
Frame Size
B M 30B 6245 BP
REDUCTION
RATIO
BEIER
CYCLO®
Built in
Gear Type
BEIER
BEIER
Shaft Direction
HHorizontal
VVertical
Method of
Mounting
HFoot
Mount
FFlange
Mount
Method of Input
Free Input
Shaft
M
K
P
With
Motors
With
Coupling
With
V-Pulley
BEIER
Frame Size
BEIER
Frame Size
Shaft Direction
HHorizontal
VVertical
Method of Input
Free Input
Shaft
M
K
P
With
Motors
With
Coupling
With
V-Pulley
Method of
Mounting
HFoot
Mount
FFlange
Mount
BEIER VARIATOR (Built in Gear Type)
BEIER VARIATOR
COMMON
VF
Suffix
With 3-phase Motor
EP
With 3-phase Premium
Efficiency Motor
BP With Baseplate
Suffix
With 3-phase Motor
EP With 3-phase Premium
Efficiency Motor
BP With Baseplate

6
H With Foot
Blank Flange type
1-4) Type of Motor
Respective codes and motor nomenclature are shown below. Please verify that the type you received conforms to what
you ordered.
TC EX
Mounting method
T Totally enclosed
Type of casing
C Ordinary cage type
K Special cage type
Rotor V
Blank
Inverter driven (AF Motor)
Commercial power driven
Driving power
A Increased safety explosion-proof(Indoor)
Protection method
B Increased safety explosion-proof(Outdoor)
C Explosion-proof (Indoor)
CX Explosion-proof (Outdoor)
X Nonexplosion-proof (Outdoor)
Blank Indoor
E Without fan (Self-cooling)
Cooling method
F With Self-ventilating fan(External fan)
B With Separate ventilation fan
COMMON
P
E
Premium Efficiency Standards
IEC Efficiency Standards
Blank Other types of motors
Standards •Regulations

7
COMMON
When storing Beier variators for any extended period of time, consider the following important points:
2-1) Storage Location
Store the unit in a clean, dry place indoors.
• Avoid storage outdoors or in places with humidity, dust, sudden temperature changes or corrosive gas.
2-2) Storage Period
(1) Storage period should be less than the "Rust-Proofing period" listed below.
(2) When the storage period exceeds the standard "rust-proofing period", special rust-proofing is necessary. Contact the
factory for details.
(3) Export models need export rust prevention. Contact the factory for details.
(4) Standard rust-proofing specification:
1Outside rust-proofing
Before shipment, rust-proofing treatment is administered. Check the effect of rust-proofing, whenever necessary it
should be administered.
2Inside rust-proofing
Lubrication Grease lubricated models Oil lubricated models
Rust-proofing period 1 Year 6 Months
Storage condition
Generally to be stored inside the shop or warehouse, relatively free
of humidity, dust, extreme temperature fluctuation, corrosive gas
and similar atmosphere.
2-3) Use After Storage
(1) Oil seals will deteriorate when exposed to high temperatures and UV rays. Inspect the oil seals before operation.
Replace the oil seals after long-term storage if there is any sign of deterioration.
(2) After starting the Beier, verify that there is no abnormal sound, vibration, or heat rise. If supplied as a brakemotor,
check that the brake operates properly. If any anomaly is observed, contact our nearest agent, distributor, or sales
office.
2. Storage
3.Transport
DANGER
Do not stand directly under a unit suspended by a crane or other lifting mechanism; otherwise, injury or death may
result.
CAUTION
Exercise ample care so as not to drop the gearmotor or reducer. When a hanging bolt or hole is provided, be sure
to use it. After mounting a Beier unit to the equipment, do not hoist the entire machine using the hanging bolt or
hole; otherwise, personal injury or damage to the equipment and/or lifting device may result.
Before hoisting, refer to the rating plate, crate, outline drawing, catalog, etc. for the weight of the Beier gearmotor
or reducer. Never hoist a unit that exceeds the rating of the crane or other mechanism being used to lift it;
otherwise, personal injury or damage to the equipment and/or lifting device may result.
Table 1

8
COMMON
4. Installation
DANGER
Do not use a standard unit in an explosive atmosphere (which is likely to be filled with explosive gas or steam).
Under such conditions, an explosion-proof motor should be used; otherwise, electric shock, personal injury,
explosion fire, or damage to the equipment may result.
Since the inverter itself is not explosion-proof, install an inverter-driven, explosion-proof type motor in a place
free from explosive gas; otherwise, electric shock, personal injury, explosion fire, or damage to the equipment may
result.
CAUTION
Do not use the Beier variator for purposes other than those shown on the rating plate or in the manu-facturing
specifications; otherwise, electric shock, personal injury, or damage to the equipment may result.
Do not place flammable objects around the Beier variator; otherwise, fire may result.
Do not place any object around the Beier variator that will hinder ventilation. Insufficient ventilation can cause
excessive heat build-up that may result in burns or fire.
Do not step on or hang from the Beier variator; otherwise injury may result.
Do not touch the shaft end of the Beier variator, inside keyways, or the edge of the motor cooling fan with bare
hands; otherwise, injury may result.
When the unit is used in food processing applications vulnerable to oil contamination, install an oil pan or other
such device to cope with oil leakage due to breakdown or faillure; otherwise, oil leakage may damage products.
Filling lublication oil after installation.
4-1) Installation Location
Ambient temperature : -10°C to +40°C
Ambient humidity : 85% max.
Altitude : 1000m max.
Ambient atmosphere : There should be no corrosive gas, explosive gas, or steam.
The location should be well ventilated without dust.
Installation location : Indoors, with minimum dust and no water splashing.
• Units made to special specifications are necessary for installation under conditions other than the above.
• Units made according to the outdoor, explosion-proof or other specifications can be used under the specified conditions
without any problem.
• Install units where inspection, maintenance, and other such operations can be easily carried out.
• Install units on a sufficiently rigid base.
4-2) Installation Angle
Grease lubricated model Free
Oil lubricated model Low speed shaft Horizontal or Vertical (Refer to page 5. Contact us inclined installation.)
Table 2 Installation Angle
When the unit is made according to your specification for inclined installation, do not install it at any angle other than the
specified angle. (The shaft orientation of the standard outdoor variator is horizontal. Contact us for other shaft
orientations.)
• Do not remove the eyebolt on the motor. Should the eyebolt be removed, put a bolt into the threaded hole or take other
water-proofing measures to prevent water from entering the motor through the threaded hole.

9
Without motor
When the motor wiring conforms to Fig. 9 the motor shaft turns clockwise viewed from the opposite side of the load side. At that time, the
rotation direction of slow speed shaft is in the direction of the arrow shown below.
Type
Rotation
direction of slow
speed shaft
Viewed from
load side
Basic, Beier-Cylo (2 stages)
Rotation
direction of slow
speed shaft
Viewed from
load side
with Built-in Gear Beier Cyclo (1 stage)
· For reverse rotation, change the positions of R and T of the motor wiring.
Type Basic, Beier-Cylo (2 stages)
Rotation
direction of slow
speed shaft
A·B
Type
As compared with high speed shaft,
opposite direction.
As compared with high speed shaft,
opposite direction.
As compared with high speed shaft,
same direction.
Rotation
direction of slow
speed shaft
D
Type
As compared with high speed shaft,
same direction.
As compared with high speed shaft,
opposite direction.
with Built-in Gear Beier Cyclo (1 stage)
Table 3 Rotation Direction of slow speed shaft.(without motor)
Fig.4 Rotation Direction of slow speed shaft.(with motor)
A·B TypeD Type
COMMON
5. Coupling with Other Machines
CAUTION
Confirm the rotation direction before coupling the unit with the driven machine. Incorrect rotation direction may
cause personal injury or damage to the equipment.
When operating the variator alone (uncoupled), remove the key that is temporarily attached to the output shaft;
otherwise, injury may result.
Cover the rotating parts; otherwise, injury may result.
When coupling the variator with a load, check that the centering, the belt tension and parallelism of the pulleys are
within the specified limits. When the unit is directly coupled with another machine, check that the direct coupling
accuracy is within the specified limits. When a belt is used for coupling the unit with another machine, check the
belt tension. Correctly tighten bolts on the pulley and coupling before operation; otherwise, injury may result
because of misalignment.
With motor
5-1) Confirming Rotation Direction
Figure 4 shows the rotation direction of the output shaft when wires are connected as shown in Fig.9 on page 13.
⎞
⎠
⎞
⎠
⎞
⎠
⎞
⎠

10
COMMON
5-2) Coupling Installation
• When installing a coupling, do not impact or apply excessive thrust load to the shaft ; otherwise, the bearing may be
damaged or collar may be left.
• Thermal shrinking is the recommended installation method.
• when a sprocket, gear or pulley is coupled with the variator, use within the range of the allowable radial and axial load
defined on our catalog.
(1) When Using a Coupling
The accuracy of the dimensions (A, B, and X) shown in Fig.5 should be within the tolerance shown in Table 4.
(2) When Using a Chain Sprocket and Gear
• The chain tension angle should be perpendicular to the shaft.
• Refer to the chain catalog for the chain tension.
• Select sprockets and gears whose pitch diameter are three times the shaft diameter or greater.
• Install sprocket and gears so that their point of load application will be closer to the variator side with respect to the
length of the shaft. (Fig.6)
(3) When Using a V-belt
• Excessive V-belt tension will damage the shaft and bearing. Refer to the V-belt catalog for proper tension.
• The parallelism and eccentricity (ß) between two pulleys should be within 20'. (Fig.7)
• Use a matched set with the same circumferential length when more than one belt is to be installed.
• Install V-pulley so that their point of load application will be closer to the variator side with respect to the length of the
shaft.
Dimension A Tolerance 0.1mm or manufacturer’s
specification
Dimension B Tolerance 0.1mm or manufacturer’s
specification
X dimension Manufacturer’s specification
Table 4 Centering Accuracy of Flexible Coupling
Fig. 5
X
A
X
B
Fig. 6 Fig. 7
Gear Beier variator
Shaft
ß
ß

11
6.Wiring
DANGER
Do not handle the unit when cables are live. Be sure to turn off the power; otherwise, electric shock may result.
Connect a power cable to the unit according to the diagram shown inside the terminal box or in the maintenance
manual; otherwise, electric shock or fire may result.
Do not forcibly curve, pull, or clamp the power cable and lead wires; otherwise, electric shock or fire may result.
Correctly ground the grounding bolt; otherwise, electric shock may result.
The lead-in condition of an explosion-proof type motor shall conform to the facility's electrical codes, extension
regulations and explosion-proofing guide, as well as the maintenance manual; otherwise, electric shock, personal
injury, explosion, fire or damage to the equipment may result.
CAUTION
When wiring, follow the facility's electrical codes and extension regulations; otherwise, burning, electric shock,
injury, or fire may result.
The motor is not equipped with a protective device. However, it is compulsory to install an overload protector
according to facility electrical codes. It is recommended to install other protective devices (earth leakage breaker,
etc.), in addition to an overload protector, in order to prevent burning, electric shock, injury, and fire.
Never touch the terminals when measuring insulation resistance; otherwise, electric shock may result.
When using a star-delta starter , select one with an electromagnetic switch on the primary side
(3-contact type); otherwise, fire may result.
When a using 400V-class inverter to drive the motor, mount a suppresser filter or reactor on the inverter side,
or provide reinforced insulation on the motor side; otherwise, dielectric breakdown may cause fire or damage to
the equipment.
When driving an explosion-proof type motor with an inverter , use one inverter for one motor. Use the
approved inverter for the motor.
When measuring the insulation resistance of an explosion-proof type motor , confirm that there is no gas,
steam, or other explosive suhstance in the vicinity, in order to prevent possible explosion or ignition.
• Wiring for SUMITOMO standard 3-phase motor is shown below.
Refer to the respective instruction manual for brakemotors and motors made by other companies when they are used.
• Long cables cause voltage to drop. Select cables with appropriate diameter so that the voltage drop will be less than 2%.
• After wiring outdoor and explosion-proof type motors , check that terminal box mounting bolts are not loose, and
correctly attach the terminal box cover.
6-1) Attaching and Detaching the Terminal Cover ( 0.1~04kW 3-phase motor )
(1) Detaching
As shown in Fig.8, hold both sides of the terminal box and pull it towards you. The cover will detach.
(2) Attaching
Press the terminal box cover onto the terminal box case until it snaps into place.
Fig. 8

Low-voltage motor of 600V or less 500V 1M (Ω) or more
12
6-3) Measuring Insulation Resistance
• When measuring the insulation resistance, disconnect the motor from the control panel. Check the motor separately.
Measure the insulation resistance before wiring. The insulation resistance (R) varies according to the motor output,
voltage, type of insulation, coil temperature, humidity, dirt, period of operation, test electrification time, etc. Usually, the
insulation resistance exceeds the values shown in Table 10.
Motor voltage Megohmmeter voltage Insulation resistance (R)
Table 10 Insulation Resistance
Referance : The following equations are shown in JEC-2100.
R≥
Rated Voltage (V)
Rated Output (kW)+1000 (M Ω)
R≥
Rated Voltage(V)+Speed(rpm)/3
Rated Output(kW)+2000 +0.5(M Ω)
A drop in insulation resistance may be attributed to poor insulation. In that case, do not turn on the power. Contact our
nearest agent, distributor, or sales office.
6-4) Protection Coordination
(1) Use a molded case circuit breaker for protection against short circuit.
(2) Use an overload protection device that protects the unit against a surge of electric current exceeding that shown on the
rating plate.
(3) For an explosion-proof type motor , use an overload protector that can protect the unit within the allowable binding
hour by means of the locked rotor current shown on the rating plate.
6-2) Connection with Power Source Cable
Connecting method is shown below.
Power Source Cable
Motor Lead wire Insulating Tape

13
4/8-Pole, 2-step speed single coil (Constant torque)
Star-delta connection
Direct starting of star-delta connection
Three outlet cables
6-5) Motor Connection
Fig.9 shows the motor connection and the standard specifications for terminal codes.
Star
connection
for starting
MCMON
MCΔOFF
MC ON
Delta
connection
after start
MCMON
MCΔON
MC OFF
For slow
speed (8P)
MCLON
MCH1 OFF
MCH2 OFF
For high
speed (4P)
MCLOFF
MCH1 ON
MCH2 ON
MC
OLR
R
U
S
V
Motor
T
W
RST
MC
MCM
MC
OLR
Motor
Y
U1 V1 W1 V2 W2 U2
MC
OLR
RS
Motor
T
U1V1W1
V2W2U2
RST
MCH1
MCL
MCH2
OLROLR
Motor
1U 1V 1W 2V 2W
2U
MC : Electromagnetic contactor
OLR : Overload protection device These should be furnished by the customer.
Fig. 9 Motor Connection and Terminal Code

14
Beier frame size Horizontal type
A type B type
N10A N8B
15A 10B
20A 15B
30A
40A
20B
30B
Trochoid pump Pump motor
Vertical type
Trochoid pump Pump motor
– – TOP-13AK 0.2kW 4P
– – TOP-208HB 0.4kW 4P
– – TOP-212HB 0.4kW 4P
– – TOP-216HB 0.75kW 4P
50A
75A
100A
150A
200A
50B
75B
100B
150B
TOP-212HB
TOP-N350HVB-7
With relief valve
0.75kW 4P TOP-N330H
TOP-N350HVB-7
With relief valve
2.2kW 6P
2.2kW 6P
Table 6 Trochoid Pump Specification for Beier portion
a
b
c
d
Pressure gauge
Trochoid pump
Motor (For Trochoid pump)
Oil level gauge
Fig. 10 Trochoid Pump Construction
Fig. 11 Torochoid Pump Wiring Diagram
MC1 : Electromagnetic switch (For Main motor)
MC2 : Electromagnetic switch (For Trochoid pump motor
PB1 : Push button switch (For Starting)
PB2 : Push button switch (For Stopping)
T : Timer (Approx, 30 sec. or more)
R1
PB2
S1
PB1 MC2
T
TMC1MC2
Main motor
Trochoid
pump
motor
OLROLR
MC2MC1
RS
Power source
T
Cyclo frame
size
6275
Vertical type
Trochoid pump
TOP-216HBVB-3
With relief valve
Pump motor
0.75kW 4P
6275DA TOP-204HBVB-3
With relief valve 0.4kW 4P
Table 7 Trochoid Pump Specification for
Cyclo portion
Lubrication oil cooling device will be
set separately for over 50A and 50B.
Refer to "9. Lubricating Oil Cooling
Device (page 28)."
COMMON
CAUTION
Conduct priming shown in the maintenance manual, before the start up of the main motor, in case of forced oil
lubrication by the trochoid pump; otherwise damage to the equipment may result.
For forced oil lubrication by trochoid pump, prime the pump, as shown in the maintenance manual, before starting
the main motor; otherwise, the equipment may be damaged.
(1) Because forced lubrication by the trochoid pump is necessary for the models with trochoid pump system as in "8-2
Confirmation of Lubrication Method (page 17)", a separate power source should be prepared for the pump. (Refer to
Table 6, 7 and Fig.10)
(2) Refer to Fig.11 for the trochoid pump wiring. At this point, connect so that the pump motor will rotate the designated
direction.
(3) Establish an electrical interlocking device between the trochoid pump motor and main motor that satisfies the following
two functions; (Refer to Fig.11)
1 Start-up time-The main motor stops when the trochoid pump stops.
2 During operation-The main motor stops when the trochoid pump stops for some unknown reason.
(4) To assure optimal lubrication conditions, the trochoid pump should be started-up at least 30 seconds before the start-up
of the main motor. (priming)
6-6) Trochoid Pump Connection

15
COMMON
7. Operation
DANGER
Do not approach or touch rotating parts (output shaft, etc.) during operation; loose clothing may became caught in
these rotating parts and cause serious injury or death.
When the power supply is interrupted, be sure to turn off the power switch. Unexpected resumption of power may
cause electric shock, personal injury, or damage to the equipment.
Do not operate the unit with the terminal box cover removed. Return the terminal box cover to the original position
after maintenance, in order to prevent electric shock.
Do not open the terminal box cover when power is supplied to an explosion-proof type motor ; otherwise,
explosion, ignition, electric shock, personal injury, fire, or damage to the equipment may result.
CAUTION
Do not put fingers or foreign objects into the opening of the variator; otherwise electric shock, personal injury, fire,
or damage to the equipment may result.
The variator becomes very hot during operation. Touching the unit may result in burns.
Do not loosen the oil filler plug during operation; otherwise, hot, splashing lubricant may cause burns.
If any abnormality occurs during operation, stop operation immediately; otherwise, electric shock, personal injury,
or fire may result.
Do not operate the unit in excess of the rating; otherwise, personal injury or damage to the equipment may result.
• Oil-lubricated models are shipped without oil. Units must be filled with the proper amount of recommended oil prior to
start-up.
• Never turn speed control handwheel when Beier Variator is not in operation.
If handwheel is turned when the unit is not in operation, this will exert undue force on internal parts which in turn may
break disc and other parts.
• When starting under full load condition, it is easier to start on low speed range.
This is because Beier Variator can give a larger torque in low speed range.
• Cushion start is required when the moment of inertia of driven machine is big. Please consult us.
After the unit is installed, filled with oil and properly wired, check the following before operating:
(1) Is the wiring correct ?
(2) Is the unit properly coupled with the driven machine ?
(3) Are foundation bolts tightened firmly ?
(4) Is the direction of rotation as required.
(5) Does the oil level in the oil-lubricated model reach the top line of the oil gauge when the unit is at rest ?
After confirming these items without a load, gradually apply a load.
Check the items shown in Table 8.
Is abnormal sound or
vibration generated ?
(1) Is the housing deformed because the installation surface is not flat ?
(2) Is insufficient rigidity of the installation base generating excessive noise ?
(3) Is the shaft center aligned with the driven machine ?
(4) Is the vibration of the driven machine transmitted to the gearmotor or reducer ?
Is the surface temper-
ature of the variator
abnormally high ?
(1) Is the voltage rise or drop substantial ?
(2) Is the ambient temperature too high ?
(3) Does the current exceed the rated current shown on the rating plate ?
Table 8 Items to Check During Initial Start-up and Break-in Period
If any abnormality is found, stop operation and contact our nearest agent, distributor, or sales office.

16
COMMON
8. Daily Inspection and Maintenance
DANGER
Do not handle the unit when cables are live. Be sure to turn off the power; otherwise, electric shock may result.
Do not approach or touch any rotating parts (output shaft, etc.) during maintenance or inspection of the unit; loose
clothing may become caught in these rotating parts and cause serious injury or death.
Customers shall not disassemble or modify explosion-proof type motors ; otherwise, explosion, ignition, electric
shock, or damage to the equipment may result.
The lead-in condition of an explosion-proof type motor shall conform to the facilities electrical codes, extension
regulations, and explosion-proofing guide, as well as the maintenance manual ; otherwise, explosion, ignition,
electric shock, or damage to the equipment may result.
CAUTION
Do not put fingers or foreign objects into the opening of the gearmotor or reducer; otherwise, electric shock, injury,
fire, or damage to the equipment may result.
The gearmotor or reducer becomes very hot during operation. Touching the unit with bare hands; may result in
serious burns.
Do not touch the terminal when measuring insulation resistance; otherwise, electric shock may result.
Do not operate the unit without a safety cover in place to shield rotating parts; otherwise loose clothing may
become caught in the unit and cause serious injury.
Promptly identify and correct, according to instructions in this maintenance manual, any abnormalities observed
during operation. Do not operate until abnormality is corrected
.
Change lubricant according to the maintenance manual instructions. Be sure to use factory recommended lubricant.
Do not change lubricant during operation or immediateus after stopping operation; otherwise, burns may result.
Supply/discharge grease to/from the motor bearing according to the maintenance manual instructions. Avoid
contact with rotating parts; otherwise, injury may result.
Do not operate damaged gearmotors or reducers; otherwise, injury, fire, or damage to the equipment may result.

We cannot assume any responsibility for damage or injury resulting from an unauthorized modification by a customer.
Dispose of the gearmotor or reducer lubricant as general industrial waste.
When measuring the insulation resistance of an explosion-proof type motor , confirm that there is no gas,
steam, or other explosive substance around the unit in order to prevent explosion or ignition.
8-1) Daily Inspection
To ensure proper and continued optimum operation, use Table 9 to perform daily inspections.
Inspection item Details of inspection
Electric
current Is the current below the rated current shown on the rating plate ?
Noise Is there abnormal sound ? Is there sudden change in sound ?
Vibration Is there excessive vibration ? Does vibration change suddenly ?
Oil or grease leakage Does oil or grease leak from the gear section ?
Foundation bolt Are foundation bolts loose ?
Chain and V-belt Are chain and V-belt loose ?
Oil level
(Oil-lubricated
model )
At rest Does the oil level reach the top line of the oil gauge ?
In operation When compared to the oil level at rest, is this level different ?
When using the
trochoid pump
Is the function of oil signal or flow gauge normal ?
When the function is abnormal, stop the unit and inspect it ; otherwise inadequate oil will cause poor
lubrication of reduction portion, broken pump and fill-up the oil pipe.
Surface temperature
Is the surface temperature abnormally high ?
Does the surface temperature rise suddenly ?
The temperature rise during operation differs according to the models. When the difference
between the temperature of the casing surface and the ambient temperature is approx. 50°C,
there will be no problem if there is no fluctuation.
Table 9 Daily Inspection
When any abnormality is found during the daily inspection, take corrective measures listed in section 10, Troubleshooting
(page30.) If the abnormality cannot be corrected, contact our nearest agent, distributor or sales office.
⎫
⎪
⎪
⎭
⎫
⎪
⎪
⎭
• It is recommended to overhaul the gearmotor or reducer after 20,000 hours or 3 to 5 years of operation to ensure a
longer service life, although it depends on the operating conditions.
• Overhauls should be done by appropriately skilld our foctory technician. Please contact our nearest agent, distributor or
sales office.

17
Table 10 Standard Lubrication System, BEIER part
Long-life grease series
A Type
BEIER
VARIATOR
BEIER size N02A N05A N1A N2A N3A N5A N8A N10A 15A 20A 30A 40A 50A
Forced lubrication type
Forced lubrication typeForced lubrication type
75A 100A 150A 200A
Horizontal Oil bath
Oil bath
N02B N05B N1B N2B N3B N5B N8B 10B 15B 20B 30B 50B 75B
Forced lubrication type
Forced lubrication typeForced lubrication type
100B 150B
Oil bath
Oil bath
N05D N1D N2D N3D N5D N8D N10D
Oil bath
Oil bath
Vertical
BEIER size
Horizontal
Vertical
BEIER size
Horizontal
Vertical
B Type
BEIER
VARIATOR
D Type
BEIER
VARIATOR
Lubricating oil cooling device is attached.
Refer to page 28.
Table 11 Standard Lubrication System, A Type and B Type BEIER-CYCLO Variator, CYCLO Part
Frame size
Horizontal Grease Oil bath
Grease Oil bath Plunger pump (Self-lubrication)Vertical
6075 6095 6105 6125 6135 6145 6165 6175 6185 6195 6205 6215 6225 6235 6245 6255 6265 6275
Forced
lubrication
type
Single reduction
Frame size 6125DB
Grease
6130DB
6135DB
Grease Oil bath
–187
Plunger pump (Self-lubrication)
–210 –289 –522 –522
210–
Grease
231– 319– 595– 649–
Grease
6130DC
6135DC
6160DA
6165DA
6160DC
6165DC
6170DC
6175DC
6180DB
6185DB
6190DA
6195DA
6205DA
6205DB
6215DA
6215DB
6225DA
6225DB
6235DA
6235DB
6245DA
6245DB
6255DA
6255DB 6265DA 6275DA
Forced lubirica-
tion type
Horizontal
Reduction
ratio
Reduction
ratio
Vertical
Double reduction
Long-life grease series
Table 12 Standard Lubrication System, D Type (ND Series) BEIER-CYCLO Variator, CYCLO Part (at standard input speed
by Table 13)
Frame size
Horizontal Grease Oil bath
Grease Oil bath Plunger pump (Self-lubrication)Vertical
6095 6105 6125 6135 6145 6165 6175 6185 6195
Single reduction
Frame size 6125DB
Grease
6130DC
6135DC
Grease Oil bath
104
Plunger pump (Self-lubrication)
– –165 –319 –377 –559
649–121–
Grease
104– 195– 377– 473–
Grease
6160DB
6165DB
6170DB
6175DB
6180DA
6185DA
6180DB
6185DB
6190DA
6195DA
6190DB
6195DB
6205DA
6205DB
6215DA
6215DB
6225DA
6225DB
6235DA
6235DB
6245DA
6245DB 6255DA 6265DA 6275DA
Forced lubirica-
tion type
Horizontal
Reduction
ratio
Reduction
ratio
Vertical
Double reduction
COMMON
8-2) Confirmation of Lubrication Method
• Refer to the applicable items regarding maintenance. Improper maintenance may decrcase unit life.
(1) Refer to Table 10–12 to confirm the gear lubrication method for your unit.
(2) Table 14 lists maintenance manual pages that can be referenced regarding lublication maintenance.
1. For models with trochoid pump, before start of Beier Variator or Beier-Cyclo Variator, start
pump motor and make sure there is mo abnormality in lubrication. Then start main motor. For
this requirement, interlock power supply for main motor with pump motor and give pump
motor a lead time of 30 to 60 seconds. Wire pump motor so that it will run in the specified
direction.
2. Oil filter (Fig. 12) is equiped on piping of forced lubrication type. Turn a handle on the oil filter
and take out clogging. At the beginning of operation, clean the filter once a day.
3. Discharge the sludge from drain plug at the bottom edge when the machine stops.
Fig. 12
Handle
Drain plug

18
Table 14 Maintenance Manual Pages that can be Referenced Regarding Lubrication Maintenance
In the case where the ambient temperature is high, there is intense change in temperature, or the air contains corrosive gas
consult the oil producter. These situations may accelerate the deterioration of the oil.
Lubrication method
Supply of oil/grease
before initial operation
after purchase
Pages where maintenance method is shown
Oil/grease change
period
Recommended
oil/grease Qty of oil/grease Disposal of
oil/grease
Necessary
Self-lubricationOil bath
Oil
Beier
Forced lubrication
Trochoid pump
lubrication
8–3) (1)
P18
8–3) (2)
P19
8–3) (3)
P19
8–3) (4) (5)
P20
UnnecessarySelf-lubrication
Self-lubrication
Long-life
―――
GreaseGrease
Variator Bearing
Except for
Long-life
8–5) (1)
P23
8–5) (1)
P23
8–5) (3)
P23
8–5) (4)
P24
Unnecessary
Self-lubrication
―――
Grease
Motor Bearing
Unnecessary
8–6) (1)
P25
8–6) (2)
P25
8–6) (3)
P25
8–7) (1)
P26
8–7) (2)
P27
8–7) (1)
P26
8–6) (4)
P25
8–7) (3)
P27
Necessary
Self-lubrication
Oil bath
Oil
Cyclo
Plunger pump
lubrication
Forced lubrication
Trochoid pump
lubrication
8–4) (1)
P21
8–4) (2)
P21
8–4) (3)
P21
8–3) (4) (5)
P21
8-3) Oil Supply and Change for Beier
(1) Standard for lubricating oil change frequency
Task
Supply of oil
Oil change
Conditions of use
common
common
Indoor temperature is 0–35C°
Location where temperature cannot be kept
at 0–35C°
Conditions interval
At purchase
500 hrs operation or 6 months, whichever comes first.
5000 hrs operation or 1 year, whichever comes first.
2500 hrs operation or 6 months, whichever comes first.
First change
Second change and
thereafter
Table 15 A Type and B Type BEIER Part
Oil
supply
Time for lubricating oil
change Remarks
——————At the time of purchase
Every 20,000 hours or
every 3 to 5 years
Increased frequency of
supply for use under
severe operating
conditions
Oil
change
Table 16 D Type (ND Series) BEIER Part
Table 13 Standard input speed
A Type BType D Type (ND Series)
Beier size
N02A–15A 1450/1750
980/1165
720/870
20A–40A
50A–200A
N02B–10B 1450/1750
980/1165
720/870
15B–30B
50B–150B
N05D–N10D 1450/1750
Standard input speed
(r/min) Beier size Standard input speed
(r/min) Beier size Standard input speed
(r/min)
COMMON

19
(2) Recommended Lubricants
Be sure to use a lubricant recommended by our company.
Ambient
Tempperature
-10°C – 5°C
0°C– 35°C
30°C – 50°C
Shell Oil
Shell Tellus
S2 M 46, 68
Shell Tellus
S2 M 100
Shell Morlina
S2 B 150
Shell Morlina
S2 B 220
Nuto H 68
Teresso 100, 150
Teresso 220, 320
Exxson Mobil
Mobil DTE 25, 26
(ISO VG46, 68)
Mobil DTE
Oil Heavy
(ISO VG100)
Mobil Vacuoline 528
(ISO VG150)
Mobil Vacuoline
533,537
(ISO VG220, 320)
Table 17 Recommended Lubricating Oil for A Type and B type
Ambient
tempperature
-10°C – 40°C
Idemitsu
Kosan
Daphne Alpha
Drive P150
JX Nippon Oil &
Energy
TD Oil 150
Table 18 Traction oil designated for D Type (ND Series)
1For operation in winter or at a relativery low ambient temperature, use lubricating oils with lower viscosity.
In the case of forced lubrication models , a plunger pump or trochoid pump may cause cavitation and necessary
amount of oil may not be supplied. In such a case, a burned main body may result.
2For N02A and M02B with small input capacity in particular, use of lower viscosity oils is recommended.
3Table 19 shows selection standard for viscosity of lubricating oil.
Min allowable viscosity
Max allowable
viscosity
Above 20mm2/s at oil temp, during operation Viscosity to obtain the oil film needed for transmission of the load
Viscosity that allows Variators to start
Viscosity that allows plunger pumps and trochoid pumps to start
Oil bath lubrication
models less than 4300mm2/s
Forced oil lubrication
models less than 2200mm2/s
Table 19 Selection Standard for Oil Viscosity for A Type and B Type
4To ensure smooth start, use lubricating oil whose pour point is at least 5-10°C lower than ambient temperature.
5If ambient temperature varies over a wide range, use lubricating oil whose viscosity remains stable, or lubricating oil
that will satisfy requirments in Notes 3and 4in high viscosity index.
6When units are always used at an ambient temperature other than 0 to 40°C, consult with the factory because
depending on models it may need to change some parts or preheat or cool lubricating oil.
(3) Oil Quantity
Table 20, 21 shows approx. quantity of oil. Be sure to check the oil level through the oil gauge.
Note: Regarding 50A—200A and 50B—150B, amounts in pipe and oil cooling device. Amounts of oil in the oil cooling device : 3.2L for 50A. 75A, 100A,
50B, and 75B, 6.7L for 150A amd 100B, 13.5L for 200A and 150B.
Table 20 Amount of Lubricating Oil (L) for A Type and B Type BEIER Part
BEIER size
Horizontal
Basic model
With a gear reducer
Built-in gear type
Verticlal
Basic model
With a gear reducer
Built-in gear type
N02A
N05A
N1A
0.7
1.1 2.3 5.2 7.5 13 20 38 98 – –
2.6 7.4 15 10 20 24 38 108 – –
1.8 3.7 4.3 11 10 20 56 85 95
1.5 4.1 7.6 6.5 12 13 23 56 85 95
N02B
N05B
N2A
N3A
N1B
N2B
N5A
N8A N10A
N3B
N5B N8B 15A 10B 20A 15B 30A
40A
20B
30B
50A
75A
100A
50B
75B 150A 100B 200A 150B
Table 21 Amount of Lubricating Oil (L) for D Type (ND Series) BEIER Part
BEIER size N05D
Horizontal 1.2
Vertical 2.6
N1D N2D
2.4
5.5
N3D N5D
4.8
13.5
N8D N10D
8.7
19.5
COMMON
Always use correct lubrication oil for D Type (ND Series) BEIER-CYCLO Variator , which requires different lubrication
oil for BEIER part and CYCLO part.
