Sumitomo TYPE-72M12 User manual

Splice program Heater program Wireless LAN SD Power Time
Heater panel
Control panel
Using Keypad
Home Screen icons
Start and cancel
heating cycle Power ON/OFF
Reset
Set
TYPE-72M12
Quick Reference Guide
Display the Settings panel
Power source type
Change image view
Display/Non-display icons
Start the splicing process
Start the arc test
Start the heating process on heater 1 and 2
View splice data after splicing
Adjust the zoom of a fiber image
Adjust display brightness
Capture a fiber image
Heater 1
Heater 2
Heater 1
Heater 2
Display the menu screen.
Set up Splice Program.
Set up Heater Program.
Play a help video to learn
fiber preparation etc.
Settings panel icons
To display the Settings panel, tap the
Settings panel icon ( ) on Home screen.
■Settings panel
■Home screen
Heater 1
Heater 2
Log in to Administrator
mode by entering passcode.
Adjust the volume.

2 Perform an arc test
1. Tap Arc Test icon ( ). 2. After “Arc Test Ready
”
appears, tap Set icon .An
arc test is started.
3. When the splicer shows
“Good arc state”, prepare fiber
again to proceed to the
splicing process. *Fibers are
not spliced in the arc test.
3 Start splicing process / Start heating cycle
1. Tap Set icon or press
Set key to start the
splicing process.
2. Fusion splicing is completed. 3. Open the wind hood. A proof
test is automatically carried
out.
4. Remove the fiber from the
splicer. Center the protection
sleeve over the splice and
load the fiber in the heat
shrink oven.
5. Press Heater key to
start the heating process.
Sumitomo Electric Industries, Ltd. reserves the right to change the specification or design
without notice and may therefore not coincide with the contents of this quick reference guide.
E&OE
For further detailed operating instructions and functions, please see Operation manual.
The Operation manual can be downloaded via https://global-sei.com/sumitomo-electric-
splicers/support/
OME1824075/Ver.1.02
Heater
p
ro
g
ress bar
* Repeat fiber preparation and arc tests
until “Good arc state.” is displayed.
Heating in progress
Pre-heating
Cooling
Standby
Operating Procedures
1 Splice program setting
1. Tap the Splice program label
on the Settings panel. 2. Select fiber category. 3. Tap the splice program you
would like to use.
* Setup and change the Heater program in the same procedures as described above.
*”Quick” heater program only
*AS24F848*
