SummitPro
DVD/CD Disc Duplicator
250GB Hard Drive
USERS MANUAL

CONTENT
Introduction
Control Panel
Menu Overview
Operation Guide
1. Copy
2. Test
3. Copy & Verify
4. Copy & Compare
5. Verify
6. Compare Disc
7. Set Burn Speed
8. Select Source
9. Audio Track Edit
10. Utility
10.1 Pre-scan
10.2 Quick Erase
10.3 Full Erase
10.4 Eject All Disc
10.5 Disc Info.
10.6 Drive Info.
10.7 System Info.
10.8 Update BIOS
10.9 Copy Counter
11. Setup
11.1 Auto Start Time
11.2 Display Mode
11.3 Button Beep
11.4 Eject on Start
11.5 Reader Speed
11.6 Language
11.7 Clear Setup
11.8 Advanced Set up
11.8.1 Power on Time
11.8.2 Start-up Menu
11.8.3 Skip Read Error
11.8.4 Change Bad Master Disc
11.8.5 CD Overburn
11.8.6 Copy CD-text
11.8.7 Copy UPC/ISRC
11.8.8 Show HDD Image Name
11.8.9 Boot Password
11.8.10 Set Password
11.8.11 Copy Special Format Disc
12. Image Manager
12.1 Select Image
12.2 Disc to Image
12.3 Reader Speed
12.4 Show Image Info.
12.5 Rename Image
12.6 Delete Image
12.7 Show HDD Info.
12.8 Format HDD
12.9 Load & Copy
13.Trouble Shooting Guide and FAQ’s

INTRODUCTION
The SummitPro stand-alone DVD/CD Disc Duplicator, featuring 24X DVD SATA drives. The system will copy 1
through11 (depending on the number of targets on your duplicator) discs at a time at maximum speeds of 48x on
CD’s and 24x on DVD’s.
An easy to use operating control panel includes a LCD screen and 4 push buttons. All operating messages and
information including function list, instructions, operating status, or error messages will be in real time display on
the screen. Users can easily read and follow the instructions on the LCD to complete their duplication jobs,
usually without referring to the User Manual.
Getting Started
Thank you...
...for choosing the SummitPro Standalone DVD Duplicator. These duplicators are second to none in terms of
speed and accuracy and we hope it will be a valuable addition to your organization for years to come.
Unpacking and Inspection
When unpacking your unit, inspect the carton and packaging material for damage. Damages that may have
occurred during shipping could cause alignment and operation errors. Any damages found upon receipt of your
unit should be immediately reported to Summation Technology.
Important!:Keep your packaging! In the event you need to ship the unit back to the factory for repair, the
product must be shipped in the manner in which it was received. Other containers are not satisfactory and may
void your warranty! If the container is lost or destroyed, another may be purchased from Summation Technology.
Choosing a Location
Placing your unit in an unsuitable location can cause a number of problems. Many problems can be avoided by
following these guidelines.
•The unit must be placed on a flat, level surface. A tilt to the unit’s base can cause errors in calibration
during use. The surface must also be relatively stable and resistant to bumps and jarring.
•The surface the unit is placed on must be able to hold 100+ pounds and be resistant to bowing under
such weight.
•Place the unit in a location with adequate air circulation. Closets or cabinets are not suitable as heat
build-up can cause the unit to malfunction. Likewise, do not place the unit on or near any heat sources
such as heating vents or server racks.
The unit must not be placed in an area with direct sunlight, excessive dust,

Important Safety instructions
Please be aware of the following installation and operation precautions.
1. Read these instructions - All the safety and
operating instructions should be read before use of
this system.
2. Keep these instructions - The safety and operating
instructions should be retained for future reference.
3. Heed all warnings - All warnings on the system and in
the operating instructions should be adhered to.
4. Follow all instructions -All operating and use
instructions should be followed.
5. Do not use this system near water -for example,
near a bathtub, washbowl, kitchen sink, laundry tub, in a
wet basement or near a swimming pool, etc.
6. Clean only with a damp cloth. This system should be
cleaned only as recommended by the manufacturer.
7. Install in accordance with the manufacturers
instructions. Do not block any of the ventilation
openings. For example, the system should not be situated
on a bed, sofa, rug, or similar surface or placed in a built-in
installation, such as a bookcase or cabinet that may
impede the flow of air through the ventilation openings.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other products that
produce heat.
9. Do not defeat the safety purpose of the grounding-
type plug. A grounding type plug has two blades and a third
grounding prong. The third prong is provided for your
safety. When the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles, and
the point where they exit from the system.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with a cart, stand,
bracket, or table specified by the
manufacturer, or sold with the system.
When a cart is used, use caution
when moving the cart/system
combination to avoid injury from tip-
over.
13. Unplug this system during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the system has been damaged
in any way, such as power-supply cord or plug is damaged,
liquid has been spilled on, been exposed to moisture or
extreme heat, does not operate normally, or has been
dropped.

Copyright and Trademark Statement
The information contained in this work is the exclusive property of Summation Technology, LLC, and any
respective copyright owners. This work is protected under United States copyright law and other international
copyright treaties and conventions. No part of this work may be reproduced or transmitted for commercial
purposes, in any form or by any means, electronic or mechanical, including photocopying and recording, or by
any information storage or retrieval system, except as expressly permitted in writing.
Disclaimer--This document has been produced for informational purposes only and as a service to our
customers. The systems intended use is for copying and editing of personal audio and video data. Any
attempted use of this equipment for the duplication of copy-protected materials is a criminal act and the
manufacturer is not responsible for such illegal recordings.
Warranty and Limitation of Liability--THE INFORMATION AND/OR MATERIALS CONTAINED HEREIN ARE
PROVIDED “AS IS,” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
The Company shall not be liable for direct, indirect, special, incidental, or consequential damages related to your
decision document, even if we are advised of the possibility of such damage.
The information in this document is subject to change without notice.
Summation Technology and the Summation Technology logo are the legal properties of Summation Technology,
LLC.

LCD FRONT PANEL
1. Control Buttons
There are 4 control buttons: , , ENT, ESC
: UP; Backward; Use this button to navigate backward in the menu.
: Down; Forward; Use this button to navigate forward in the menu.
ENT : Enter, Execute the function
ESC : Escape, Go back to previous function
2. LCD Screen
The LCD Screen is a 2x16 Mono LCD screen. The system will display function information, messages and
instructions on the LCD.
Note:
There are two display modes to show information on the LCD while copying. You can change the display
mode in “Setup” 11.2. The default setting is “Basic” mode.
← Basic
Advance # 1→
←Advance # 2
Advance # 3→
LCD Front Panel
Copy 4315M
45% 6.2X 1942M
Copy 2:30 4315M
45% 6.2X 1942M
Copy
4315M
■■■□□□□ 45%
Copy 4315M
45% 1942M
Copy finished %
Current copy speed
Copied size
Copy time elapsed
Source size

Below is a quick reference chart of the functions available on the SummitPro DVD Duplicators.
1. COPY Copies the master CD/DVD. All contents of the master disc will be duplicated on
to all target disc(s) simultaneously.
2. TEST
Simulates the copy process, but no data is recorded onto the blank disc(s).
Note: Test mode can only be done with DVD-R and CD-R media only.
3. COPY & VERIFY Copies the master CD/DVD, and then verifies the presence of data on the copied
disc(s) to ensure readability of the copied disc(s).
4. COPY & COMPARE
Copies the master CD/DVD, and then immediately follows the copy process with
a bit-for-bit comparison between the master disc and copied disc(s) to ensure
exact duplication.
Note: The “Compare” function cannot be used with audio CDs.
5. VERIFY Verifies the presence of data on the copied disc(s) to ensure that the copied
disc(s) can be read back.
6. COMPARE
Verifies the presence of data on the copied disc(s) to ensure that the copied
disc(s) can be read back.
7. SET BURN SPEED
Allows the speed settings to be changed for various formats
8. SELECT SOURCE Allows the source drive to be changed to any of the available drives in the
duplicator, including the Hard Disk Drive (HDD).
9. TRACK EDIT
Allows for the selection of individual track(s) from different master audio CDs to
create custom compilation.
9.1 COPY TRACK Allows the selection of individual track(s) from the master CD and copies the
selected track(s) onto all target discs.
9.2 CLOSE DISC
Closes the target discs when all of the track(s) are burned on to all target discs.
Note: The copied disc(s) will NOT play back without this step. Do NOT skip this
step.
9.3 DISC INFO
Displays the information regarding the track(s) on the disc(s) and how much
space is remaining on the target disc(s).
10. UTILITY
10.1 PRE-SCAN Performs a scan on the master disc before the copy process starts and ensures
the master disc can be copied in the duplicator.
10.2 QUICK ERASE
Erases all rewritable media (CD-RW and DVD+/-RW, DVD+/-RW DL).
10.3 FULL ERASE
Erases all rewritable media (CD-RW and DVD+/-RW, DVD+/-RW DL).
10.4 EJECT ALL DISCS
Ejects all disc trays, including source drive.
10.5 DISC INFO
Displays basic information of the discs inserted, such as disc type, amount of
data on disc for master disc(s) (in MB) and media book type. For blank media,
displays the media book type, available space and speed of the media.
10.6 DRIVE INFO
Displays information of all drives in the duplicator including the Reader, HDD (if
present) and Writer drive(s).
10.7 SYSTEM INFO
Displays the duplicator controller information, such as the hardware version,
10.8 UPDATE BIOS Updates the firmware for the controller.
Note: Please make sure that the firmware is approved by the manufacturer and
compatible with the duplicator before performing the update.
10.9 COPY COUNT Counts the number of successful and failed copies of CD and DVD made by the
duplicator.
Menu Overview

11. SETUP
11.1 AUTO START TIME
Allows the duplicator to automatically start one of six following functions once the
master disc and desired number of target disc(s) are inserted and the drive trays
are closed: Copy, Test, Copy & Verify, Copy & Compare, Verify and Compare.
11.2 DISPLAY METHOD
Sets the amount of information displayed on the LCD during the performance of
various functions.
11.3 BUTTON BEEP
Enables or disables the audio feedback when buttons are pressed.
11.4 EJECT ON START
Allows the duplicator to eject disc tray(s) with disc present inside upon boot-up.
11.5 READER SPEED
Sets the speed at which discs are read during various processes.
11.6 LANGUAGE Sets system language interface, there are English, Japanese, Spanish and
Portuguese for selection.
11.7 CLEAR SET-UP
Resets all settings back to original factory settings
11.8 ADVANCED SET-UP
11.8.1 POWER ON TIME
Sets system warm up time from 5 sec to 99 sec. Default is 15 seconds.
11.8.2 START-UP MENU
Assigns a command to be displayed first after the duplicator has been
initialized.
11.8.3 SKIP READ ERROR
Enables the option to halt the duplication process if there is an error on the
master disc. Disables the option to allow the process to continue with the same
errors as the master disc.
11.8.4 CHANGE BAD MASTER DISC Enables or disables changing of a master disc during the copy process when an
error is detected on the master disc.
11.8.5 CD OVER BURN
Enables or disables the duplication of over burned CDs.
11.8.6 COPY CD TEXT
Enables or disables the copying of the CD sub code (CD-TEXT) information for
audio CD’s.
11.8.7 COPY UPC/ISRC
Enables or Disables copying UPC/ISRC.
11.8.8 SHOW HDD IMAGE NAME Allows the image name to be displayed on the LCD screen when selecting the
HDD as the source drive.
11.8.9 BOOT PASSWORD
Sets password protection for machine boot-up.
11.8.10 SET PASSWORD
Sets password for entry to Set-up Menu.
11.8.11 COPY SPECIAL FORMAT DISC
Enable or disable copying special format discs.
12. Image Manager
12.1 Select Image
To select Image file as Sources to be copied to discs.
12.2 Disc==> Image
To copy Source Disc to HDD and save as Image file.
12.3 Reader Speed
ONLY when performing 12.2 Disc -> Image function, you can set the Reading
Speed of reading the master source disc.
12.4 Show Image Info
To check image file information and file size.
12.5 Rename Image
Change the name of an image file stored on the HDD.
12.6 Delete Image
To delete image file in HDD. If the file is selected as source file, you are not able
to delete it unless you go back to 12.1 to re-select
12.7 Show HDD Info
To check the information in HDD, such as how many discs are stored and HDD
available space.
12.8 Format HDD
This feature will allow you to format the HDD. However, you will not be able to
format the HDD if the HDD image was selected as source.
12.9 Load & Copy
Consolidates the imaging and burning process into one step.

QUICK START GUIDE
Product Introduction
That’s all!! Your duplicator will do the rest and eject the copied disc in a few
minutes automatically.
Step 1: Plug in power cord to back of the unit.
Step 2: Turn on power button and wait for LCD
to read “Copy”.
Step 3: Eject reader tray (top drive) and insert source disc.
Close reader tray.
Step 4: Eject writer trays and insert the blank discs. Close
writer trays.

OPERATING GUIDE
1. COPY
This operation will guide you to copy your Master Disc to a Blank CD/DVD disc.
①.Turn on the duplicator.
②.Eject Drive tray of the Top Drive and place the Master disc in the tray and Close the drive tray.
③.Eject Drive tray of the Bottom Drive and place blank disc on the tray and close the tray. Press ENT
to execute CD/DVD copy.
④.When the system starts the copy process, it will: Load the Disc, Analyze the Disc, and then start to
Copy. During the copy process, the LCD will display the Master Disc’s data size and completion
percentage of copy process.
⑤.Once the copy process is completed, the disc trays will eject and the display will read “Copy Result:
Pass X, Fail Y,” with X being the number of successful copies, and Y being the number of failed
copies. To reduce copy failure, please refer to the troubleshooting section of the manual.
Operation Guide
1. Copy 4315M
1 disc detected
Copy 4315M
Loading Disc
Copy 4315M
Analyze Disc…
Copy DVD 4315M
■■■□□□□ 45%

2. TEST
①.This function simulates the copying process.The process is the same as COPY but it won’t write
anything on the recordable discs.
②.Press ，to navigate the function menu to 2. TEST and press ENT to execute it.
③.The system will auto-detect the blank disc and start to simulate the process of COPY, just press
ENT to execute.
When simulation process finished, all disc tray of test-success will eject automatically and LCD will
show the amount of PASS and FAIL.
★☆ Note: TEST is unable to support DVD+R blank discs.
★☆ Note: If you put rewritable disc into writer’s tray for TEST, the rewritable disc data will be erased
completely.
2. Test 4315M
1 disc detected
Test 4315M
Loading Disc
Test 4315M
Analyze Disc...
TEST DVD 4315M
■■■□□□□ 45%

3. COPY & VERIFY
This option will make a copy first and then verify copied discs immediately for ensuring disc readability.
①.Before starting this process, please make sure that the Master Disc and blank disc are placed in
the correct drives. Press ，to navigate the function menu to “3. COPY&VERIFY.”
②.The system will automatically detect and display how many blank discs were detected. When the
system is ready to copy, just press ENT to execute CD/DVD coping.
③.When the system starts the copy process, it will Load the disc, Analyze the disc, and then start the
Copy process. During the copy process, the LCD will display Master Disc’s data size and
completion percentage of copy process.
④.Once the copy process is completed the bottom drive will open briefly, and then automatically
close again to begin the Verify process.
⑤.After a completed Copy & Verify process, a successful disc will eject automatically.
3. Copy & Verify
1 disc detected
Copy & Verify
Loading Disc
Copy & Verify
Analyze Disc…
Copy DVD 4315M
■■■□□□□ 45%
Verify DVD 4315M
■■■□□□□ 45%

4. COPY & COMPARE
This function will perform the copy process, and immediately follows with a comparison between the
master disc and the copied disc(s) to ensure the copies are exact duplicates of the master disc. This
command is especially useful for DVDs, data CDs and video CDs.
①.Before starting this process, please make sure that the Master Disc and blank discs are in the
correct drives.
②.The system will automatically detect and display how many blank discs were detected. Press ，
to navigate the function menu to 4. COPY&COMPARE.
③.Press ENT to execute CD/DVD coping.
④.When the system starts copy process, it will: Load the disc, Analyze the disc, and then start the
Copy process.During the copy process, the LCD will display Master Disc’s data size and
completion percentage of copy process.
⑤.When copying is finished, the system will eject the bottom drive briefly, and then close again,
continuing the Comparison process to ensure the data of copied discs the same as source disc.
⑥.When the Comparison process is finished, a successful disc will eject automatically.
4. Copy & Compare
1 disc detected
Copy & Compare
Loading Disc
Copy DVD 4315M
■■■□□□□ 45%
Compare
DVD 4315M
■■■□□□□ 45%

5. VERIFY
This function will perform the copy process, and immediately follow with the verification
process on all target discs. This command is especially useful for audio CD duplication.
Note: The verification process uses a Disc Readability Check to individually check the presence of data on each
copy. This process does not compare the contents of duplicated discs against that of the master. It only verifies
that the duplicated discs are readable.
①.Put Master disc and blank disc into the duplicator.
②.Press ，to navigate the function menu to 5. Verify. Then, press ENT, the duplicator will Load
the disc, Analyze the disc, and start the Verification process automatically.
③.When the Verification process is finished, a successfully Verified disc will eject automatically.
5. Verify
1 disc detected
Verify DVD 4315M
Loading Disc
Verify DVD 4315M
Analyze Disc…
Verify DVD 4315M
■■■□□□□ 45%

6. COMPARE
This command compares copied disc(s) to the Master disc and ensures that the copies
are exact duplicates of the master disc. This command is especially useful for DVDs, data CDs and
video CDs.
Note: The Compare process is a bit-by-bit comparison between the master disc and the copied discs. This operation ensures
that all of the copies are completely identical to the Master disc. This command is not applicable to audio CDs.
①.Put Master disc and blank disc into the duplicator.
②.Press ，to navigate the function menu to 6. Compare. Then, press ENT, the duplicator will:
Load the disc, Analyze the disc and start the Comparison automatically.
③.When a Comparison was finished, a successfully Compared disc will eject automatically.
★☆ Note: ONLY DATA Discs can utilize Compare Function
6. Compare
1 disc detected
Compare
DVD 4315M
Loading Disc
Compare
DVD 4315M
Analyze Disc…
Compare
DVD 4315M
■■■□□□□ 45%

7. SELECT SPEED
This operation will allows you to adjust and select duplication speed on three different disc types of CD,
Audio CD, and DVD.
①.Press ，to navigate to function 7. Select Speed, and press ENT.
②.You will see three disc types of CD, Audio CD, and DVD. Move ，to select disc type and press
ENT to confirm your selection.
③.Press ，to set burn speed and press ENT to confirm.
[Burn Speed]
CD = 52
7. Set Burn Speed
[Burn Speed]
DVD = 8
[Burn Speed]
Audio CD = 40

8. SELECT SOURCE
This option allows you to set master reading source from any Optical Drive. In this unit it will always be
the top drive.
①.Press ，to navigate to function 8. Select Source and press ENT.
②.Press ，to select HDD or Optical Drive with assigned number as Reading Source and press
ENT to complete your selection.
Source〔D#1〕==>
D#1:DVD-ROM
8. Select Source
Source Drive ==>
D#1: DVD-ROM

9. TRACK EDIT
This process will guide you to select and combine audio tracks from various CDs onto a single
customized audio CD.
9.1 Copy Track:
①.Press ，to navigate to function 9. Track Edit and press ENT. You will see the sub-catalog of
1. Copy Track and press ENT again.
②.The display will read “Waiting Master Disc”. Insert the first Master Disc and press ENT.
③.Once the Master Disc is successfully read, the LCD screen will read “Waiting…Blank Disc”. Insert
blank disc into the bottom drive and press ENT.
④.Once the system has recognized the audio CD and blank disc, the LCD screen will show the song
list as numbers.
⑤.Press ，to navigate to the track number that you want and press ENT to select. Continue your
selections by pressing ENT for every track you wish to select. A letter “a, b, c, d,..” will appear on
top of each selected track.
⑥.After you have finished selecting tracks from this disc, press and move cursor to the end “OK”.
Press ENT to complete and burn it.
⑦.Your submitted selections will be copied to the blank disc, the system LCD screen shows copy
progress as below.
⑧.When duplication was finished, the LCD shows CD-R’s usage and free space for report.
⑨.The display will now read “[Edit Track] 1. Copy Track”. If you would like to add tracks from another
CD press ENT and repeat steps 4-6 for each new Master CD. If your selections of tracks are
complete, proceed to step 9.2.
★☆ Note: Once you finished 9.1 copy Audio Track, you NEED to perform “9.2 Close Disc” on this CD,
otherwise your customized audio CD will NOT be able to play on CD player.
9. Track Edit
[Track Edit]
1. Copy Track
Track Used 59:15
15 Free 20:42
1 2 3 4 5 6 7 8
b a c
1 2 3 4 5 6 7 8
d e
9 10 11 12 OK
Track 01 04:39
Copy…… 00:04

9.2 Close Disc
This process is the last procedure to ensure CD-R/CD-RW disc of copied tracks is a playable Audio CD.
①.Press ，to navigate to function 9. Track Edit and press ENT.
②.Press ，to select 2. Close Disc and press ENT to start close disc process.
③.When the system executes the Close Disc process, you will see the message on the LCD.
④.After the process is complete, the writer drive will eject the tray automatically, and you will see
“Finished!” on the LCD screen.
9.3 Disc Info.
This feature allows you to check your disc status, such as available capacity.
①.Press ，to navigate to function 9. Track Edit and press ENT.
②.Select 3. Disc Info, and press ENT.
[Track Edit]
2. Close Disc
[Track Edit]
3. Disc Info.
[1] 79:59
CD-R Use 27:53
Finalizing Disc
Finished!
9. Track Edit
9. Track Edit

10. UTILITY
This function group includes several Disc related functions. You can press ENT and move ，to
select function you want.
10.1 Pre-scan
This feature Pre-scans the Master disc to make sure it can be duplicated correctly before you try to go
through the copy process.
①.Put the Master disc into the top drive. Press ,to navigate to function 10. Utility and press ENT.
②.Press ，to select 1. Pre-scan, and press ENT. The system starts to execute the Master disc
check.
10.2Quick Erase
This operation can quickly erase data of re-writable disc in the bottom drive. When erasing process is
finished, the drive tray will eject automatically.
The duplicator can erase different types of re-writable discs simultaneously. You can place re-writable
discs you would like to erase in any tray of writers. Under sub-catalog of 10. Utility, press ，to
select 2. Quick Erase, and press ENT for execution.
When done, disc trays will eject automatically.
★
☆ Note: If you see “O” “o” blinking, it means Erasing in process.
If you see “F” “f” blinking, it means new DVD+RW Disc Formatting is processing.
10. Utility
Quick Erase Disc
_ O _ _ _ O _ o
[Utility]
2. Quick Erase
[Utility]
1. Prescan
PreScan DVD4315M
PASS!
Prescan DVD4315M
■■■□□□□ 45%
