Summit Appliance SWCDAR24 User manual

WINE CELLAR DRAWER COMBO
Models:
SWCDAR24
SWCDAF24
SWCDRF24
SWCDAR24PNR
SWCDAF24PNR
SWCDRF24PNR
User Manual
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.

2
TABLE OF CONTENTS
Appliance Safety 3
Important Safeguards 3-4
Installation Instructions 5-9
Before Using your Appliance 5
Installation of your Appliance 5
Electrical Connection 5-6
Extension Cord 6
Anti-Tip Bracket Installation 6
Reversing the door Swing for the ALWC532 7
Panel Installation Instructions for the ALWC352PNR 8
Panel Installation Instructions for the Drawer Fronts 9
Operating your Appliance 10-16
Control Panel for the ALWC532 10-11
Control Panel for the SCFF532D 11-13
Control Panel for the FF642D 13-14
Control Panel for the SPRF34D 14-15
Cleaning and Care 17
Cleaning your Appliance 17
Power Failure 17
Vacations 17
Moving your Appliance 17
Energy-Saving Tips 17
Troubleshooting 18-19
Limited Warranty 20

3
APPLIANCE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. The symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words "DANGER" or "WARNING".
DANGER means that failure to heed this safety
statement may result in severe personal injury or
death.
WARNING means that failure to heed this safety
statement may result in extensive product
damage, serious personal injury, or death.
All safety messages will alert you about the potential hazard, tell you how to reduce the chance of injury,
and let you know what can happen if the instructions are not followed.
IMPORTANT SAFEGUARDS
Before the appliance is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance, follow basic precautions,
including the following:
•Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do
not use an extension cord.
•Replace all panels before operating.
•It is recommended that a separate circuit serving only your appliance be provided. Use receptacles
that cannot be turned off by a switch or pull chain.
•Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
•Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is
disconnected. Failure to do so can result in electrical shock or death.
•Do not connect or disconnect the electric plug when your hands are wet.
•Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this manual. All other servicing should be referred to a qualified technician.
•This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which is
environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the
greenhouse effect. Care must be taken during transportation and setting up of the appliance that no
parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes.
•In the event of any damage:
oAvoid open flames and anything that creates a spark,
oDisconnect from the electrical power line,
oAir the room in which the appliance is located for several minutes, and
oContact the Service Department for advice.

4
•The more coolant there is in an appliance, the larger the room it should be installed in. In the event of
a leakage, if the appliance is in a small room, there is the danger of combustible gases building up.
For every ounce of coolant at least 325 cubic feet of room space is required. The amount of coolant in
the appliance is stated on the data plate on the back of the appliance. It is hazardous for anyone
other than an Authorized Service Person to carry out servicing or repairs to this appliance.
•Take serious care when handling, moving, and using the appliance to avoid either damaging the
refrigerant tubing or increasing the risk of a leak.
FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
•This unit is intended FOR INDOOR USE ONLY.
•Use two or more people to move and install appliance. Failure to do so can result in back or other
injury.
•Choose a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C) (The
optimal operating range is between 72º and 78ºF, or 23º to 26ºC.) This unit must be installed in an
area protected from the elements, such as wind, rain, water spray or drips.
•The appliance should not be located next to ovens, grills or other sources of high heat.
•Never place heavy objects or items containing water on top of the unit. Spilled water could deteriorate
the insulation of electrical components and result in electrical leakage.
•The appliance must be installed with all electrical, water and drain connections in accordance with
state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances, is required.
•Do not throw items onto the shelves and do not place items totaling more than 65 lbs on each shelf.
The shelf could fall, possibly causing injury.
•Do not kink or pinch the power supply cord of the appliance.
•The size of the fuse (or circuit breaker) should be 15 amperes.
•It is important that the appliance be leveled in order to work properly. You may need to make several
adjustments to level it.
•All installations must be in accordance with local plumbing code requirements.
•Make certain that the pipes are not pinched, kinked or damaged during installation.
•Check for leaks after connection.
•Never allow children to operate, play with or crawl inside the appliance.
•Do not allow anyone to hang from the door or climb onto the unit. The unit could tip over and fall,
causing material damage and injury.
•Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may damage
or discolor the interior.
•This appliance is intended for storage and display of beverages for sale. Use this appliance only for
its intended purpose.
•Keep fingers out of the “pinch point” areas. Clearances between the doors and between the doors
and cabinet are necessarily small. Be careful closing doors when children are in the area.
Risk of child entrapment!
Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are still
dangerous, even if they will “just sit in the garage a few days”.
Before discarding your old refrigerator:
•Take off the doors
•Leave the shelves in place so that children may not easily climb inside.
- SAVE THESE INSTRUCTIONS -

5
INSTALLATION INSTRUCTIONS
Before Using your Appliance
•Remove the exterior and interior packing.
•Before connecting the appliance to the power source, let it stand upright for approximately 2
hours. This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
•Install the door handles, if they are not already attached.
Installation of your Appliance
•The appliance is designed for free-standing or built-in (fully recessed) installation.
•If free standing, the unit should have at least 4” of clearance at both sides, at the top and at the
back to allow for adequate ventilation. If it is built-in, leave 3/16” at both sides, 1/16” at the top
and 2” at the rear. Be sure that airflow under the appliance is not blocked.
•Take care that the air vent at the front of the appliance is never covered or blocked in any way.
•Place your appliance on a floor that is strong enough to support it when it is fully loaded. To level
your appliance, adjust the front leveling legs at the bottom.
•Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extremely cold ambient temperatures may also cause the unit not to perform
properly. Avoid locating the unit in moist areas.
•Plug the appliance into an exclusive, properly installed and grounded wall outlet. Do not under
any circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified and authorized
products service center
•The handles are stored inside the unit. Install using the screws (supplied).
Electrical Connection
This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug which mates with standard three-prong wall outlets to minimize the
possibility of electrical shock.
Do not under any circumstances cut or remove the third (ground) prong from the power cord
supplied. For personal safety, this appliance must be properly grounded.
This appliance requires a standard 115/120 Volt AC ~ 60Hz three-prong grounded electrical outlet.
Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly
grounded. When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation
to have it replaced with a properly grounded 3-prong wall outlet.
To prevent accidental injury, the cord should be secured behind the appliance and not left exposed
or dangling.

6
The appliance should always be plugged into its own individual electrical outlet which has a voltage
rating that matches the rating label on the appliance. This provides the best performance and also
prevents overloading house wiring circuits that could cause a fire hazard from overheating. Never
unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight out
from the receptacle. Repair or replace immediately all power cords that have become frayed or
otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length or at
either end. When moving the appliance, be careful not to damage the power cord.
Extension Cord
Because of potential safety hazards under certain conditions, it is strongly recommended that you do
not use an extension cord with this appliance. However, if you must use an extension cord, it is
absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord
having a grounding type plug and outlet and that the electrical rating of the cord be 115 volts and at
least 10 amperes.
Anti-tip Bracket Installation
When properly installed, the anti-tip brackets will keep your appliance from tipping forward, even
when an unexpected weight is placed on the front of the unit. Follow these instructions to ensure
proper installation.
The brackets must be firmly screwed into the floor or wall behind the unit, depending on the height of
the unit off the floor. The anchoring screws should be appropriate to the type of surface your until will
be anchored to.
•Mark the locations of the screw holes of the anti-tip brackets so that the brackets align with the
rear grillwork cutouts.
•Use an appropriate masonry drill bit, depending on what type of surface your unit will be
anchored to. Drill into a suitable foundation, either wood studs or joists.
NOTE: The brackets must not be screwed into sheetrock.
•Secure brackets to the floor or wall, using screws.
•Once the brackets are secured, slide the appliance into place, being sure that the horizontal
prongs of the bracket are positioned in the grillwork at the back of the unit. Test the bracket by
exerting a downward force on the front of the unit; if it seems stable, the unit is secure.
NOTE: If the unit is relocated, the brackets must be removed and installed in the new location

7
Reversing the Door Swing (for the ALWC532)
This appliance has the capability of the door opening from either the left or right side. The unit is
delivered to you with the door opening from the left side. Should you desire to reverse the opening
direction, please follow the instructions below. To make the reversal, you will find two hardware
pieces in a plastic bag inside the appliance: the top left hinge and the bottom left hinge. The bottom
support bracket is used for both sides.
1. Carefully lay the appliance on its back. Use cushioning to protect the floor and appliance.
2. Using a Phillips screwdriver, remove the two screws and bottom right hinge beneath the door.
Keep the hinge in a safe place in case you need to reverse the door again in the future.
3. Carefully slide the door off and place it on a padded surface.
4. Interchange the plastic shaft sleeves at the top of the door.
5. Remove the bottom support bracket from the right side.
6. Remove the top right hinge and keep in a safe place in case you want to reverse the door in the
future.
7. Remove the screws from the top left and transfer to the right.
8. Install the top left hinge.
9. Install the bottom left hinge to the door. Do not over-tighten the screw.
10. Place the door back on the appliance, lining up the top hinge.
11. Install the bottom support bracket.
12. Adjust door alignment. When set, tighten screw on hinge.
13. Remove handle. Transfer the screw hole covers to the left and install the handle on the right.

8
Panel Installation Instructions for the ALWC352PNR
NOTE: Not all units will be panel ready. Visit www.summitappliance.com for more information about
your specific model.
Parts included in PNR kit:
(8) Screws to attach the custom panel
(1) Replacement top hinge
(1)Replacement bottom hinge
(2)Plastic bushing for panel
(2)Washers
Remove the door from the unit
1. Remove the door from its chassis by unscrewing the top and bottom hinges
from the cabinet and door. Save all of the screws for Step 10.
Attach the handle & panel
2. Attach your door handle to the panel using countersunk screws (not included).
You can use the handle that ships with this appliance or substitute your own.
3. Pull out the rubber gasket located around the inner door frame to access the
eight screw holes from the inside of the door.
4. Place your custom panel over the door pane.
5. Using the provided screws, attach the panel by holding it in place from the front
and screwing it onto the door pane from the inside of the door.
6. Reinstall the gasket to its original position.
Reattach the door
7. You will have to drill a hole into the top and bottom of the custom panel in order to
connect it to the new provided hinges. To do this, line the door up in its final
position, using the new hinges as a guide to mark where you will be drilling the
holes. Drill a hole through the top and bottom of the custom panel using a 23/64”
drillbit.
8. Insert the provided bushing into the top and bottom holes of thepanel.
9. For models with a lock, drill a 5⁄8” minimum keyhole in the door frame as illustratedabove.
10. You can now reinstall the door using the replacement hinges.
Panel/Frame Dimensions:
Exterior: 27 5⁄8” H x 23” W
Overlay panel thickness: 3⁄4” thick
Lock diameter (select models): 5⁄8”

9
Panel Installation Instructions for the Drawer Fronts
NOTE: Some units are designed to be panel ready
(PNR). Please check
www.summitappliance.com if you are unsure if
you have a PNR unit.
These models are designed for field-installed overlay
panels. The overlay panels cover the stainless steel to
give a built-in appearance. The overlay panel and
appropriate hardware are not included with the unit and
the end user needs to prepare them himself. Please
follow the instructions below for installation:
1. Remove any items stored inside the drawers. Press
the left slide release lever down and at the same
time lift the corresponding right slide lever up, and
pull the drawer out until it is free of tracks and the
cabinet. (Fig. 1)
2. Peel off the gasket and remove the handle by
removing the two screws that attach the handle to
the door.
3. Drill the 2 holes shown by using a 3/16” drill bit on
the bottom of drawer door front. (Fig. 2)
4. Cut the overlay panels with thickness 3/4” to the
following dimensions: 23.43”x 15”.
5. If reusing the handles that came with the unit, drill
two holes with diameter 3/16”in the overlay panel.
Attach the handle and overlay panel together to the
drawer face using 2 M4x65 screws and through the
upper 2 existing holes inside the door groove. Then
attach the overlay panel to the drawer face using 2
wood screws #10x2 (ST4x50) Type AB Phillips and
through the lower 2 existing holes inside the door
groove. (Fig. 3)
6. If user-supplied handles will be used, attach the
handles to the overlay panels by using the flat head
screws and drive the screws flush with the panels.
Then attach the overlay panel to the drawer face
using the 4 wood screws #10x2 (ST4x50) and
through the 4 existing holes inside the door groove.
7. Peel back the gaskets, then align the left and right
slide channels with the tracks in the cabinet.
Ensuring an even track engagement on both sides,
gently push the drawer into the cabinet until it
stops.

10
OPERATING YOUR APPLIANCE
It is recommended you install the appliance in a place where the ambient temperature is between
44º and 95ºF (7º to 35ºC). If the ambient temperature is above or below the recommended
temperatures, the performance of the unit may be affected. For example, placing your unit in
extremely cold or hot conditions may cause interior temperatures to fluctuate. The expected
operating temperature range may not be reached.
Control Panel for the ALWC532 (Top Unit)
ON/OFF Power
To turn the appliance on or off, press the ON/OFF button for 3 seconds.
Lock
If you press and hold the button for 3 seconds, the control panel will lock and cannot be
operated again until the button is pressed again. After that, it will operate normally.
Light
You can turn the interior light ON or OFF by pushing the button marked LIGHT. The light will turn off
automatically if it remains ON for 10 minutes. Pushing the LIGHT button again will turn the light back
on. For optimum storage of wine, keep the light off except when viewing.
Setting the temperature control
Upper zone adjustable temperature: 5°C to 10°C (41°F to 50°F)
Lower zone adjustable temperature: 10°C to 18°C (50°F to 64°F)
Set the desired temperature by pressing the corresponding buttons, Left or Right to
decrease. Each press is in 1-degree increment. Once released, set temperature will flash for
approximately 5 seconds then revert back to display the internal temperature.
To view your set temperature, press either button once and LED display will flash set
temperature for 5 seconds.
Temperature Conversion
The appliance has the capacity to display temperature in either Celsius or Fahrenheit. To change the
temperature scale, press and hold both the and LIGHT buttons simultaneously for approx. 3
seconds.
Run
Indicator light illuminates to signify the cooling mode is currently in operation.
Lock
If illuminated, indicates the control panel is locked.

11
NOTES:
•If the unit is unplugged or turned off, or if there has been a power failure, you must wait 3 to 5
minutes before restarting the unit. If you attempt to restart before this time delay, the appliance
will not start.
•When you use the appliance for the first time, or restart it after it has been shut off for a long
time, there could be a few degrees variance between the temperature you select and the one
indicated on the display. This is normal and due to the length of inactivation time. Once the
appliance has been running for a few hours, everything will be back to normal.
•You may notice condensation on the outer surface of the glass door. This occurs when water
vapor from the air contacts the cold surface of the door and the vapor condenses on the glass,
causing a fogging effect. In extreme situations, water can even drip off the door, indicating
excessive humidity in the environment.
•If the appliance has been off for less than 5 minutes, the compressor will not restart at once
when is pressed. This behavior is built into the control system to protect the compressor.
Recommended Temperatures for Chilling Wine
Red Wines: 15 - 18°C (59 - 64.4°F)
Dry / White Wines: 9 - 14 °C (48.2 - 57.2°F)
Sparkling Wines: 5 - 8 °C (41 - 46.4°F)
The cabinet temperature may vary slightly depending on whether or not the interior light is ON or
OFF, and whether the bottles are located in the upper/middle or lower section of the cabinet.
Bottle Storage and Capacity
Wine bottles can vary in size and shape, and the stated capacity may not apply to every varietal. For
a detailed view showing how your shelves can best accommodate different types of bottles, visit
your product on our website and open the “Shelving Guide” included in the Downloads section.
Control Panel for the SCFF532D (Bottom Unit as a Freezer)
ON/OFF Power
To turn the appliance ON or OFF, press and hold the POWER key for 5 seconds.
NOTE: Pressing the POWER key once can switch off the audible alarm when the alarm is on.
SuperFreeze
SuperFreeze is used to freeze fresh food quickly. The function overrides the thermostat control and
will make the compressor operate continuously. It is not necessary to adjust the thermostat setting
when using this function. When the function is selected, the SuperFreeze indicator (the dot at the
bottom right of the display) will be ON. The function can be turned off by pressing the key again and
the indicator will turn OFF. SuperFreeze will turn off automatically after 8 hours.

12
UP
Used to increase (warm) the set temperature by 1°C/1ºF.
DOWN
Used to decrease (cool) the set temperature by 1°C/1ºF.
ºF/ºC Selector
Select the temperature display setting in Fahrenheit or Celsius degree. To change the temperature
from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the SUPERFREEZE key
for 5 seconds.
Setting the Temperature Control
•You can set the temperature by pressing the UP and DOWN keys. When you press either of the
two keys for the first time, the LED readout will show the original temperature set previously.
(The temperature preset at the factory is 0°F or -18°C.)
•The temperature you are setting will increase by one degree each time you press the UP key,
and will decrease by one degree each time you press the DOWN key.
•The range of set temperatures is from -11°F to 11°F.
•To view the set temperature at any time, press the UP or DOWN key. The set temperature will
flash in the display window for 5 seconds. After 5 seconds, the temperature inside the unit will
reappear in the display window.
Interior Light
The unit is equipped with an interior LED light which will be turned ON when a drawer is open.
NOTES:
If the unit is unplugged or power is lost or turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the unit will not start.
When you use the unit for the first time or restart the unit after it has been shut off for a long time,
there could be a few degrees variance between the temperature you select and the one
indicated on the LED readout. This is normal and is due to the length of the activation time.
There should not be a problem once the unit has been running for a few hours.
Sabbath Mode
Sabbath mode is available for the observance of certain religious holidays. This mode turns off the
displays, interior light and audible alarms and prevents them from turning on again. Normal cooling
operations will still take place.
To initiate Sabbath mode, press the POWER and SUPERFREEZE keys at the same time for at least
5 seconds. The indicator light (the dot at the bottom right of the display) will flash four times and
confirm the Sabbath mode is ON. Sabbath mode can be canceled by repeating the above process.
Sabbath Mode will automatically turn off after 96 hours.
Temperature Memory Function
In the event of a power interruption (power surge, breaker switch, etc.), the unit can remember the
previous temperature settings, and when power is recovered, the cabinet temperature will return to
the same set temperature as before the power went off.

13
Defrosting
•Under normal operating conditions, the unit requires no manual defrosting.
•The evaporator behind the rear wall of the unit defrosts automatically. The condensate collects in
the drainage channel behind the rear wall of the unit and flows through the drainage hole into the
drip tray by the compressor where it evaporates.
•However, frost may accumulate on the evaporator if the unit is repeatedly opened in high heat or
high humidity locations.
Using the Freezer
•This unit is designed for the long-term storage of frozen food. Storage time is up to three months.
•The storage life of frozen foods varies and the recommended storage time should not be
exceeded.
•Pre-packed commercially frozen food should be stored in accordance with the frozen foods
manufacturer’s instructions for a three-star frozen food storage compartment or home freezer.
•Place frozen food into the freezer as quickly as possible after purchase. If there are instructions
on the packet, carefully follow these instructions regarding storage times.
Temperature Alarm/Door Alarm
•An audible alarm sounds if the storage temperature is not cold enough. The temperature display
flashes at the same time.
•The cause of the temperature being too high may be:
oWarm fresh food was placed inside
oToo much warm ambient air flowed in when rearranging or removing food
oPower failure for some time
oThe appliance is faulty.
•The audible alarm is automatically silenced and the temperature display stops flashing when the
temperature is sufficiently cold again.
•If a drawer has been left open for more than 60 seconds, the alarm will sound. Pressing the
POWER key once switches off the audible alarm.
Control Panel for the FF642D (Bottom Unit as a Refrigerator)
ON/OFF Power
To turn the appliance ON or OFF, press the symbol and hold for 5 seconds.
NOTE: Pressing the POWER key once can switch off the audible alarm when the alarm is on.
UP
Used to increase (warm) the set temperature by 1°C/1ºF.
DOWN
Used to decrease (cool) the set temperature by 1°C/1ºF.

14
ºF/ºC Selector
Select the temperature display in Fahrenheit or Celsius degrees. To change the temperature from
Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the LIGHT key for 5 seconds.
Setting the Temperature Control
•You can set the temperature by pressing the UP and DOWN symbols. When you press either of
the two buttons for the first time, the LED readout will show the original temperature set
previously. (The temperature preset at the factory is 38°F or 3°C.)
•The temperature you are setting will increase by one degree each time you press the UP
symbol, and will decrease by one degree each time you press the DOWN symbol.
•The range of set temperatures is from 36°F to 43°F.
•To view the set temperature at any time, press the UP or DOWN symbol. The set temperature
will flash in the display window for 5 seconds. After 5 seconds, the temperature inside the unit
will reappear in the display window.
Interior Light
The interior light makes it easy to view your items. Pressing the LIGHT symbol toggles between 2
modes of operation for the internal lights: functional (default) mode and showcase mode. If 10 you
are in functional (default) mode, the lights will turn on only when a drawer is open. If you are in
showcase mode, the lights will be on whether or not the drawer is open.
Control Panel for the SPRF34D (Bottom Unit as a Refrigerator/Freezer)
ON/OFF Power
To turn the appliance off, touch and hold the key for 5 seconds until the temperature display
goes off.
To turn the appliance on, touch and hold the key for 1 second until the temperature display
lights up.
NOTE: Touching the POWER key once can switch off the audible alarm when the alarm is on.
Setting the Temperature Control
The unit has two separate temperature compartments. You can set the temperature of the bottom
compartment (freezer) by touching the left UP and DOWN symbols and set the temperature of the
top compartment (refrigerator) by touching the right UP and DOWN symbols. When you touch
either key for the first time, the LED readout will show the original temperature set previously.
(The temperature preset at the factory is 0°F/-18°C for freezer compartment and 39°F/4°C for
refrigerator compartment.)
The temperature you are setting will increase by one degree each time you touch the UP symbol,
and will decrease by one degree each time you touch the DOWN symbol.
The range of the temperature control is from -11°F/-24°C to 11°F/-12°C for freezer compartment
and from 36°F/2°C to 43°F/6°C for refrigerator compartment.
To view the set temperature at any time, touch the UP or DOWN symbol. The set temperature will
temporarily flash in the display window for 5 seconds. Then the display shows the current inner
temperature again.

15
UP +
Used to increase (warm) the set temperature by 1°C/1ºF.
DOWN -
Used to decrease (cool) the set temperature by 1°C/1ºF.
ºF/ºC Selector
Select the temperature display setting in Fahrenheit or Celsius degree.
Indicator Light
The indicator light is the dot located at the bottom right corner of the display. The indicator light will
be on when a multi-key function is selected. To perform a multi-key function, touch and hold the first
key, then touch the second key for at least 5 seconds and then release both keys.
Child Lock
If in 2 minutes or longer without touching any key, the child lock will be activated automatically. To
cancel the lock, touch the UP and DOWN keys at the same time for at least 5 seconds and the
indicator light will flash three times to confirm the action.
Interior Light
The unit is equipped with the interior LED lights which will be turned ON when a door is opened. The
LED type lights are designed for extremely long life. They are not user serviceable. To change them
please contact the service department.
NOTE: Please use only the original LED light fittings provided by the manufacturer.
Sabbath Mode
Sabbath mode is available for the observance of certain religious holidays. This mode turns off
the displays, interior light and audible alarms and prevents them from turning on again. Normal
cooling operations will still take place.
To initiate Sabbath mode, touch the POWER and ºC/F keys at the same time and hold for at
least 5 seconds. The indicator light (the dot at the bottom right of the display) will flash four times
and confirm the Sabbath mode is ON.
Sabbath mode can be canceled by repeating the above process. The Sabbath Mode will
automatically turn off after 48 hours.
NOTE:
If the unit is unplugged or power is lost or turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the unit will not start.
When you use the unit for the first time or restart the unit after it has been shut off for a long
time, there could be a few degrees variance between the temperature you select and the one
indicated on the LED readout. This is normal and is due to the length of the activation time.
There should not be a problem once the unit has been running for a few hours.

16
Temperature Memory Function
In the event of a power interruption (power surge, breaker switch, etc.), the unit can remember the
previous temperature settings, and when power is recovered, the cabinet temperature will return to
the same set temperature as before the power went off.
Defrosting
Under normal operating conditions, the unit requires no manual defrosting.
The evaporator behind the rear wall of the unit defrosts automatically. The condensate collects in
the
drainage channel behind the rear wall of the unit and flows through the drainage hole into the
drip tray by the compressor where it evaporates.
However, frost may accumulate on the evaporator if the unit is repeatedly opened in high heat or
high humidity locations. If this frost pattern does not clear within 24 hours, your unit will require
manual defrosting.
Temperature Alarm / Door Alarm
An audible alarm sounds if the storage temperature is not cold enough. The temperature display
flashes at the same time.
The cause of the temperature being too high may be:
oWarm fresh food was placed inside
oToo much warm ambient air flowed in when rearranging and removing food
oPower failure for some time
oThe appliance is faulty.
The audible alarm is automatically silenced and the temperature display stops flashing when the
temperature is sufficiently cold again.
If a drawer has been left open for more than 60 seconds, the alarm will sound. Pressing the
POWER key once switches off the audible alarm.

17
CLEANINIG AND CARE
Cleaning your Appliance
•Turn off the power, unplug the appliance, and remove all items, including racks and dividers.
•Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of
baking soda to a quart of water).
•Wash the racks and dividers with a mild detergent solution.
•Wring excess water out of the sponge or cloth when cleaning the area where the controls are
located, or any electrical parts.
•Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry
with a clean soft cloth.
•Use an approved stainless steel cleaner to clean the doors and handles. Do not use steel wool
or a steel brush on the stainless steel.
CAUTION: Failure to unplug the appliance before cleaning could result in electrical shock or other
personal injury.
Power Failure
Most power failures are corrected within a few hours and should not affect the temperature of your
appliance if you minimize the number of times the door is opened. If your power is going to be off for
a longer period of time, you need to take the proper steps to protect your contents.
Vacations
•Short vacations: Leave the appliance operating during vacations of less than three weeks.
•Long vacations: If the appliance will not be used for several months, remove all items and turn
off the appliance. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave
the drawers open slightly, blocking them open if necessary.
Transporting Your Appliance
CAUTION: This appliance is very heavy. It should NOT be moved by only one person.
If you need to move your appliance once the box has been discarded:
1. Securely tape down all loose items (shelves) inside your appliance.
2. Turn the adjustable legs up to the base to avoid damage.
3. Tape the door shut.
4. Be sure the appliance stays secure in the upright position during transportation. Also protect the
outside of the appliance with a blanket or similar item.
Energy-Saving Tips
•The appliance should be located in the coolest area of the room, away from heat-producing
appliances and out of direct sunlight.
•Ensure that the unit is adequately ventilated. Never cover air vents.
•Do not keep the door or drawers open any longer than necessary.
•Let hot or warm items cool to room temperature before placing in the unit. Overloading the unit
forces the compressor to run longer.

18
TROUBLESHOOTING
You can solve many common problems easily, saving you the cost of a possible service call. Try the
suggestions below to see if you can solve the problem before calling the servicer.
PROBLEM
POSSIBLE CAUSE
REMEDY
Appliance
does not
operate.
Appliance is not connected to a power
supply.
The appliance is turned off.
Tripped circuit breaker or blown fuse
Connect the appliance.
Switch on the appliance.
Switch on circuit breaker or replace
fuse.
Appliance is
not cold
enough.
The temperature is not set correctly.
The ambient temperature could require
a lower temperature setting.
Appliance is opened too often.
A drawer was not closed completely.
Door or drawer is not hermetically
sealed.
The condenser is too dirty.
The ventilation opening is blocked or too
dusty.
Check the set temperature.
Set a lower temperature.
Do not open door or drawers more
often than necessary.
Close door or drawers properly.
Check the seal and clean or replace.
Clean the condenser when
necessary.
Clear the obstructions and wipe off
the dust.
Appliance
turns itself on
and off
frequently.
The room temperature is higher than
average.
A large amount of food has been added
to the unit.
The appliance is opened too often.
A drawer or door is not closed
completely.
A gasket does not seal properly.
Put the appliance in a cooler place.
Leave the appliance to work for a
while until the set temperature has
been reached.
Do not open the appliance more often
than necessary.
Close the door or drawer properly.
Check the all gasket seals and clean
or replace it.
The light does
not work.
Appliance is not connected to a power
supply.
Tripped circuit breaker or a blown fuse.
The light was switched off on the
control panel.
Connect the appliance.
Switch on circuit breaker or replace
fuse.
Switch on the light.
Vibrations
The appliance is not properly leveled.
Level the appliance with the
adjustable feet.
The appliance
seems to
make too
much noise.
The rattling noise may come from the flow of the refrigerant, which is normal. As each
cycle ends, you may hear gurgling sounds caused by the flow of refrigerant in your
appliance.
If temperature fluctuations occur, the contraction and expansion of the inner walls
may cause popping and crackling noises.
The appliance is not properly leveled.
Level the appliance with the
adjustable feet.
Drawers
will not close
properly.
The appliance is not properly leveled.
The gaskets are dirty.
The racks or bins are out of position.
Level the appliance with the
adjustable feet.
Clean the drawer gaskets.
Check the racks and bins and refit
correctly.
Display “E0”,
“E1”. “E2”,
“E0”indicates a communication error
for 3 zone models.
Call for service.

19
“E3”, “E4”,
“E5”or “E7”.
“E1”or “E2”indicates that the air
temperature sensor has failed.
“E3”or “E4”indicates that the defrost
sensor in the evaporator has failed.
“E5”indicates defrost heater failure.
“E7”indicates door switch failure.
The alarm
sounds and
the
temperature
display
flashes.
Has a drawer been open for longer than
60 seconds? If not, then the temperature
has risen higher or fallen lower than the
temperature that has been set. This could
be due to:
The appliance drawers being opened
too often.
The ventilation opening being covered
or too dusty.
A lengthy interruption in the power
supply.
A large amount of food has been added
to the unit.
If yes, close the drawer.
Do not open drawers more often than
necessary.
Clear the obstructions and wipe off
the dust.
Leave the appliance to work for a
while until the set temperature has
been reached.
The icon “--” is
lit and flashing
in the
temperature
display.
The display temperature is out of
range.
Only temperatures within the range
0~99°F/-9~37°C for FF642D and the
range -49~99°F/-45~37°C for
SCFF532D can be displayed. If the
temperature is not within this range,
the icon “--” will be displayed instead.
This is normal.
LIMITED WARRANTY

20
ONE-YEAR LIMITED WARRANTY
Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated
and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-
specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a
designated service company. Outside the 48 states, all parts are warranted for one year from manufacturing
defects. Plastic parts, shelves and cabinets are warranted to be manufactured to commercially acceptable
standards, and are not covered for damage during handling or breakage.
5-YEAR COMPRESSOR WARRANTY
1. The compressor is covered for 5 years.
2. Replacement does not include labor.
ITEMS WARRANTOR WILL NOT PAY FOR:
1. Service calls to correct the installation of your appliance, to instruct you how to use your appliance, to
replace or repair fuses or to correct wiring or plumbing.
2. Service calls to repair or replace appliance light bulbs or broken shelves. Consumable parts (such as filters)
are excluded from warranty coverage.
3. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation,
installation not in accordance with electrical or plumbing codes, or use of products not approved by
warrantor.
4. Replacement parts or repair labor costs for units operated outside the United States.
5. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
6. The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not installed
in accordance with published installation instructions.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR AS PROVIDED HEREIN. IMPLIED WARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR.
WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR
LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS, SO
THESE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
