Commercial
Countertop Beverage Center
Model SCR114L
INSTRUCTION MANUAL
To ensure safe operation, please read this instruction manual
thoroughly before use.
FELIX STORCH, INC.
Summit Appliance Division
ISO 9001:2015 registered
770 Garrison Avenue
Bronx, New York 10474
www.summitappliance.com
Write Serial No. here:
________________________

1
TABLE OF CONTENTS
Important Safeguards .............................................................................2 –3
Moving and Installing the Appliance ..............................................................4
Reversing the Door Swing ......................................................................4 –5
Preparation....................................................................................................5
Safety Precautions ........................................................................................6
Storage of Articles .........................................................................................6
Temperature Adjustment ...............................................................................6
Defrosting .....................................................................................................6
Cleaning Your Beverage Center ...................................................................6
Maintenance .................................................................................................7
Caution .........................................................................................................7
Normal Phenomena ......................................................................................7
Warnings .......................................................................................................7
Disposal of an Old Appliance ........................................................................7
Disposal of Packaging ..................................................................................8
Troubleshooting Guide ..................................................................................9
Limited Warranty .........................................................................................11

2
IMPORTANT SAFEGUARDS
WARNINGTo reduce the risk of fire, electrical shock or injury when using
your appliance, follow these basic precautions:
•Read all instructions before using the Beverage Center.
•Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter,
and do not use an extension cord.
•It is recommended that a separate circuit, serving only your Beverage Center, be provided.
Use receptacles that cannot be turned off by a switch or pull chain.
•Never clean Beverage Center parts with flammable fluids. Fumes can create a fire hazard or
explosion.
•Before proceeding with cleaning and maintenance operations, make sure the power line of
the unit is disconnected.
•Do not connect or disconnect the electric plug when your hands are wet.
•Unplug the Beverage Center or disconnect the power before cleaning or servicing. Failure to
do so can result in electrical shock or death.
•Do not attempt to repair or replace any part of your appliance unless it is specifically
recommended in this manual.All other servicing should be referred to a qualified technician.
•Do not store or use gasoline or any flammable vapors and liquids in the vicinity of this or any
other appliance. The fumes can create a fire hazard or explosion.
•Use two or more people to move and install the Beverage Center. Failure to do so can result
in back or other injury.
•To ensure proper ventilation for your appliance, the front of the unit must be completely
unobstructed. Choose a well-ventilated area with temperatures above 61°F (16°C) and below
95°F (35°C). [The unit performs best when the ambient temperature is in the range 66 –75°F
(19º –24ºC).] This unit must be installed in an area protected from the elements, such as
wind, rain, water spray or drips.
•The Beverage Center should not be located next to ovens, grills or other sources of high
heat.
•For optimum energy conservation, locate the Beverage Center in the coolest area of the
room, away from heat- producing appliances and out of direct sunlight.
•The Beverage Center must be installed with all electrical connections in accordance with
state and local codes. A standard electrical supply (115V AC only, 60 Hz), properly grounded
in accordance with the National Electrical Code and local codes and ordinances, is required.
•Do not kink or pinch the power supply cord.
•The fuse (or circuit breaker) size should be 15 amps.
•It is important for the Beverage Center to be leveled in order to work properly. You may need
to make several adjustments to level it.
•Although the unit has been tested at the factory, due to transit and storage, you should clean
the appliance before use.
•Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may
damage or discolor the interior.
•Do not use this apparatus for other than residential purposes.
•This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a)

3
which is environmentally friendly, but flammable. It does not damage the ozone layer, nor
does it increase the greenhouse effect. Care must be taken during transportation and setting
up of the appliance that no parts of the cooling system are damaged. Leaking coolant can
ignite and may damage the eyes.
•In the event of any damage:
- Avoid open flames and sparks,
- Disconnect from the electrical power line,
- Air the room in which the appliance is located for several minutes, and
- Contact the Service Department for advice.
•The more coolant there is in an appliance, the larger the room it should be installed in. In the
event of a leakage, if the appliance is in a small room, there is the danger of combustible
gases building up. For every ounce of coolant at least 325 cubic feet of room space is
required. The amount of coolant in the appliance is stated on the data plate on the back of
the appliance. It is hazardous for anyone other than an Authorized Service Person to carry
out servicing or repairs.
•Take serious care when handling, moving, and using the appliance to avoid either damaging
the refrigerant tubing or increasing the risk of a leak.
•Replacing component parts and servicing shall be done by factory-authorized service
personnel so as to minimize the risk of possible ignition due to incorrect parts or improper
service.
•This appliance is designed to be used in household and similar non-retail applications. Do
not use this appliance for any but its intended purpose.
DANGER! Risk of child entrapment!
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances can still be dangerous.
•Before you throw away your old Beverage Center or any appliance: Remove the
door. Leave the shelves in place so that children may not easily climb inside.
•Never allow children to operate, play with, or crawl inside the appliance.
–SAVE THESE INSTRUCTIONS –

4
Moving and Installing the Appliance
a. When carrying the cooler, keep it vertical. The angle of inclination between the sides of the
cooler and the vertical should be less than 40ᵒ, otherwise the compressor will be affected
and disrupt normal operation.
b. After unpacking the cooler, remove the packing materials and place the cooler on a level
and sturdy floor near a power socket.
c. Be sure to leave at least 4” of clearance at the back and sides of the cooler for ventilation
and leave a space with an open angle of 160ᵒfor the door.
d. Keep the cooler away from heat sources and avoid direct sunlight.
e. Never place the cooler in a location where water can reach it or with unusually high
humidity.
f. This appliance is intended for use indoors, such as in shopping centers, restaurants, etc.
Reversing the Door Swing
This appliance has the capability of the door opening from either the left or right side. The unit
is delivered to you with the door opening from the left side. Should you desire to reverse the
opening direction, please follow these illustrations and instructions:
You will need to tilt the fridge backward to access the lower hinge which holds the screws. Do
not tilt more than 45 degrees and do not lay the fridge flat on its side.
Reversing the door：
1. Remove the top plastic hinge cover and set aside
2. Unscrew the 3 screws from the metal bracket and set aside. Carefully remove the door and
place it on a cushioned surface.
