Summit Industries INNOVET SELECT HF APR Manual

INNOVET SELECT™HF APR
Installation and Service Manual
02104-000
Rev. E Oct2005
SUMMIT INDUSTRIES, INC.
2901 West Lawrence Ave.
Chicago, IL 60625
773-588-2444
www.summitindustries.net

InnoVet Select
™ HF APR Service Manual
2
NOTICE TO INSTALLERS
All freight is shipped FOB from the factory. This means it is the installer's
responsibility to inspect the shipment for damage and proper count. Upon
receipt of the merchandise, any visible damage to the cartons should
immediately be examined while the shipper is present.
If the visible damage to the cartons also includes damage to the
merchandise, the installer is responsible for making all claims with the
shipping company.
If there is hidden damage to the merchandise, it is the installer's
responsibility to discover that damage within a reasonable amount of time
and contact the shipping company to make a claim.
To protect your company in the case of hidden damage it is recommended to
accept freight "subject to inspection". This makes it easier to make a claim
with the freight company in the event of hidden damage.

InnoVet Select
™ HF APR Service Manual
3
WARNING
X-RAY EQUIPMENT IS DANGEROUS TO BOTH
PATIENT AND OPERATOR UNLESS MEASURES
OF PROTECTION ARE STRICTLY OBSERVED
Though this equipment is built to the highest standards of electrical and mechanical safety,
the useful X-ray beam becomes a source of danger in the hands of the unauthorized or
unqualified operator. Excessive exposure to x-radiation causes damage to living tissue.
Adequate precautions must be taken to prevent unauthorized or unqualified persons from
operating this equipment or exposing themselves or others to its radiation. Only qualified
personnel should install, set up, maintain, and operate this equipment. Only qualified
service personnel should remove electrical covers.
Before operation, persons qualified and authorized to operate this equipment should be
familiar with the Recommendations of the International Commission on Radiological
Protection, contained in Annals Number 26 of the ICRP, and with the applicable national
and local standards.
The equipment described in this manual will perform reliably when installed, maintained,
and operated, in accordance with the instructions of this manual by qualified personnel.
This equipment is sold with the understanding that the user assumes sole responsibility for
radiation safety and that the manufacturer does not accept any responsibility for the
following:
•Equipment improperly installed.
•Equipment improperly operated.
•Equipment improperly maintained or repaired.
•Equipment, which has been modified or altered in any way.
•Injury or damage to patient or other personnel for any of the above causes.
We are proud of our products and are confident they will provide many years of useful and
enjoyable service.
Summit Industries

InnoVet Select
™ HF APR Service Manual
4
CAUTION: THIS MANUAL IS FOR USE BY PERSONNEL
QUALIFIED TO INSTALL, CALIBRATE, MAINTAIN AND SERVICE
RADIOGRAPHIC EQUIPMENT. HAZARDOUS VOLTAGES MAY BE
PRESENT, AND PERSONS UNFAMILIAR WITH SAFE OPERATING
PROCEDURES SHOULD NOT ATTEMPT TO PERFORM SERVICE ON
THIS DEVICE.
Installation and Service Manual Revisions History
Revision Pages Affected/Revision Description
Release Date ECR #
A Initial Issue SEPTEMBER 2004 4213
B Revised table 7-1A NOVEMBER 2004 4364
C REVISED SECTION 6.7.5 January 2005 4456
D Revised Section 6.7 June 2005 4630
E Revised Section 7.7.3 October 2005 4723

InnoVet Select
™ HF APR Service Manual
5
1.0 PRE-INSTALLATION........................................................................................... 9
1.1 General......................................................................................................9
1.2 Use of This Manual....................................................................................9
1.3 Equipment Description............................................................................. 10
1.3.1 General.........................................................................................10
1.3.2 Space Requirements..................................................................... 11
1.4 Safety.......................................................................................................12
1.4.1 General.........................................................................................12
1.4.2 Manufacturer's Responsibility .......................................................13
1.4.3 Radiation Protection...................................................................... 13
1.4.4 Monitoring of Personnel................................................................14
1.4.5 Electrical .......................................................................................15
1.4.6 Mechanical....................................................................................15
1.5 Compatibility............................................................................................ 16
1.6 Accuracy Statement................................................................................. 16
1.6.1 Exposure kVp................................................................................ 16
1.6.2 Exposure mAs............................................................................... 16
1.6.3 Duty Cycle..................................................................................... 16
1.7 Maximum Outputs.................................................................................... 17
1.8 Maximum Momentary Line Current.......................................................... 17
1.9 Technique Factors That Constitute Maximum Line Current..................... 17
1.10 Power Line Requirements........................................................................ 18
1.11 Room Inspection......................................................................................18
1.12 Unpacking................................................................................................18
2.0 MECHANICAL ASSEMBLY............................................................................... 19
2.1 Table........................................................................................................ 19
2.2 High Voltage Generator and Transformer Placement..............................19
2.3 Tubestand................................................................................................ 20
2.3.1 Fixed top table .............................................................................. 20
2.3.2 Float top table...............................................................................22
2.4 Tube Arm, Tube, Collimator Installation................................................... 24
2.5 Mounting Operator’s Console and Routing Communication Cables........26
2.6 Foot Treadle Installation .......................................................................... 29
2.7 Film Bin Installation..................................................................................29
2.8 Table Front Cover Installation…………………………………………………29
3.0 FINAL MECHANICAL ADJUSTMENT .............................................................. 30
3.1 Leveling Arm............................................................................................ 30
3.2 40 inch SID Detent Adjustment................................................................ 30
3.3 X-Ray to Light Field ................................................................................. 30
3.4 X-Ray to Grid Cabinet.............................................................................. 31
3.5 Securing Table to Floor............................................................................ 31

InnoVet Select
™ HF APR Service Manual
6
4.0 OPTIONS FOR FIELD INSTALLATION ............................................................ 32
4.1 Table Top Extension................................................................................ 32
4.2 Animal Restraints..................................................................................... 32
4.3 Foot Treadle ............................................................................................33
5.0 GENERATOR PRE-INSTALLATION................................................................. 34
5.1 Introduction.............................................................................................. 34
5.2 Installation Items and Test Equipment .................................................... 34
5.3 Component Access.................................................................................. 35
5.3.1 Access To Operator’s Console PCBA........................................ 35
5.3.2 Power Module Access................................................................ 35
5.3.3 High Voltage Transformer .......................................................... 35
5.4 Circuit Board Identification....................................................................... 36
5.4.1 Operator’s Console..................................................................... 36
5.4.2 Power Module.............................................................................36
6.0 GENERATOR INSTALLATION ......................................................................... 38
6.1 Line Voltage............................................................................................. 38
6.2 Position System Components.................................................................. 38
6.3 Operator’s Console.................................................................................. 38
6.4 Transformer Installation...........................................................................38
6.5 System Interconnection ...........................................................................39
6.6 Connecting Mains Input Power................................................................ 39
6.7 Field Installation of Line Matching Transformer....................................... 40
6.8 High Voltage Cables................................................................................ 43
6.9 Stator Cable............................................................................................. 44
6.10 Table Interface TB - 5 .............................................................................45
6.11 Interlocks .................................................................................................46
7.0 INITIAL POWER UP AND INSPECTION........................................................... 47
7.1 General.................................................................................................... 47
7.2 System Configuration............................................................................... 47
7.3 Power-Up................................................................................................. 49
7.3.1 Start-Up...................................................................................... 49
7.3.2 Status LEDs ...............................................................................49
7.3.3 Power Supply Test and Fuse Designation.................................. 50

InnoVet Select
™ HF APR Service Manual
7
8.0 SYSTEM CONFIGURATION Using The Operator’s Console................. 51
8.1 CAL BOOTUP Screen .............................................................................51
8.2 TUBE ROLL CAL Screen and Calibration................................................ 52
8.3 XRAY CAL Screen................................................................................... 53
8.4 TUBE SETUP Screen..............................................................................54
8.5 PWR MOD SET Screen........................................................................... 54
8.6 PWR MOD CAL, FIL# TBL Screen.......................................................... 55
8.7 MORE Screen.......................................................................................... 55
9.0 GENERATOR CALIBRATION USING THE OPERATOR’S CONSOLE........... 56
9.1 Required Equipment for Calibration
9.1.1 Using the Required Test Equipment .............................................57
9.2 Overview of Calibration............................................................................ 58
9.3 Step-by-Step Calibration.......................................................................... 59
10.0 TROUBLESHOOTING....................................................................................... 64
10.1 Overview..................................................................................................64
10.2 Troubleshooting Guide.............................................................................69
10.3 Testing for High Voltage Breakdown ....................................................... 71
11.0 MEMORY FUNCTIONS ..................................................................................... 72
11.1 Memory Function Screen.........................................................................72
11.2 Inserting the Memory Card ......................................................................73
11.3 The Default Vet Screen............................................................................73
11.4 The POWER MODULE TO CONSOLE Screen....................................... 74
11.5 The CARD TO CONS Screen.................................................................. 75
11.6 The CONS TO CARD Screen.................................................................. 75
12.0 ACCURACY TESTING ...................................................................................... 76
12.1 Overview..................................................................................................76
12.2 Accuracy of kVp and mAs Outputs.......................................................... 77
13.0 REQUIRED MAINTENANCE............................................................................. 78
13.1 Overview..................................................................................................78
13.2 Routine Maintenance Checks.................................................................. 78
14.0 THEORY OF OPERATION ................................................................................ 80
14.1 Power Module.......................................................................................... 80
14.2 Operator’s Console.................................................................................. 80
14.3 High Voltage Transformer…………………………………………………….80
15.0 SCHEMATICS.................................................................................................... 81

InnoVet Select
™ HF APR Service Manual
8
TABLES:
1-1 Maximum Power Rating........................................................................... 17
1-2 Maximum Line Current.............................................................................17
6-1 Line Matching Transformer Connections.................................................41
6-2 Tube Stator Cable Connections............................................................... 44
6-3 Table Interface Cable Connections at TB - 5...........................................45
7-1 DIP1 Functions (System Controller PCBA).............................................. 48
7-2 DIP2 Functions (APR Console PCBA)..................................................... 49
7-3 Fusing for DC Voltages............................................................................ 50
7-4 Fusing for AC Voltages............................................................................ 50
9-1 Typical Filament Values........................................................................... 62
9-2 Recording Filament Values...................................................................... 63
9-3 Recording Master kv and Master Ma Values………………………………..63
10-1 Error Codes……………………………………………………………………...64
12-1 Recording kVp and mAs Outputs……………………………………………..77
13-1 Required Maintenance Log…………………………………………………….79
FIGURES:
1 Space Requirements ............................................................................... 11
2 Back Rail End Stop.................................................................................. 20
3 Tubestand Positioning ............................................................................20
4 Mounting Tubestand to Lower Rail .........................................................21
5/6 Exposing Upper Rail for Mounting Tubestand ......................................... 23
7 Rear view of the operator’s console......................................................... 26
8 Power Module and Transformer in Table Base........................................ 36
9/10 Power Module Interior.............................................................................. 37
11 High Voltage Cable Routing..................................................................... 43

InnoVet Select
™ HF APR Service Manual
9

1.0 PRE-INSTALLATION
1.1 General
This manual contains installation, calibration, and service information for the
InnoVet Select HF APR System. The system includes the generator, table and
tubestand, as well as other equipment (such as collimator and x-ray tube) not
described in this manual. To gain an understanding of the complete system, study
the operator’s and service manuals for all associated equipment.
1.2 Use of This Manual
Throughout the manual there are indented statements, which are preceded by alert
words. These alert words and the following statements may direct the user in the
performance of a task, or inform the user of a potentially hazardous situation. Each
alert word is always used with only one specific type of information. The alert
words and the information they reference are as follows:
NOTE: Information that assists the user of the manual in the performance of a
task. It may provide the user with better methods of conducting the
task, or it may point out conditions that could cause the system to fail
to operate properly.
CAUTION: Information that alerts the user of the manual to situations that could
result in damage to the equipment.
WARNING: Information that alerts the user of the manual to situations that could
be hazardous to the health of the patient, the operator, the
maintenance person, or others.
This manual is generally broken into three main sections, dealing first with the assembly of
mechanical structures, then electrical connections and calibration, then mechanical
alignments and radiographic acceptance testing.

InnoVet Select
™ HF APR Service Manual
10
1.3 Equipment Description
1.3.1 General
The 20 kHz HF APR Generator is a high-frequency constant potential system with
the following features:
•30 kW constant potential output from a single phase line.
•Two-point control (kVp and mAs) in manual mode. Maximum available mA
is automatically selected for minimum exposure time. Operator override is
allowed.
•Protection circuitry to prolong tube life and increase system performance.
•Self-diagnostic displays to inform users and service personnel of system
condition.
•The generator is designed to fit entirely within the table base.
•The InnoVet Select HF APR system is a fully integrated table/tubestand
structure with the generator and transformer installed within the table base
for use in veterinary radiography.

InnoVet Select
™ HF APR Service Manual
11
82-1/2"
HEIGHT
Each Version
2. For tables with Float-Top option
1. For STANDARD Fixed-Top tables
28"
3"
53"
3"
44"
58"
3"
44"
67"
82-1/2"
HEIGHT
(A 12" extension is available for this version only)
AWTDS015
1.3.2 Space Requirements - Figure 1
INNOVET SELECT SYSTEM DRAWING
Model S305

InnoVet Select
™ HF APR Service Manual
12
1.4 Safety
1.4.1 General
It is important that everyone associated with x-ray work is familiar with the
recommendations of the Department of Health, National Bureau of Standards, and
the National Council on Radiation Protection. The control of diagnostic medical x-
ray equipment varies in detail from state to state. However, in general, all of the
states adhere strictly to the established recommendations of the NCRP. Prior to
operation, be sure that all personnel who are authorized to operate the x-ray
system are familiar with the established regulations of the authorities named above.
Also, they should be monitored to assure that they conform to the
recommendations.
Current sources of information include:
•National Council on Radiation Protection Report No. 33 (Medical X-Ray
and Gamma-Ray Protection for Energies up to 10 MEV-Equipment Design
and Use).
•National Bureau of Standards Handbook No. 76 (Medical X-Ray Protection
up to Three Million Volts). Refer to MCRP Report No. 33.
•Current recommendations of the International Committee on Radiation
Protection.
Although x-ray radiation is hazardous, x-ray equipment does not pose any danger
when it is properly used. It is the responsibility of all service and operating
personnel to be properly informed on the hazards of radiation. Also, those
responsible for the system must understand the safety requirements for x-ray
operation. Study this manual and the manuals for each component in the system to
become aware of all the safety and operational requirements.

InnoVet Select
™ HF APR Service Manual
13
1.4.2 Manufacturer’s Responsibility
Although this equipment incorporates protection against x-ray radiation other than
the useful beam, practical design cannot provide complete protection. This
equipment does not prevent the possibility of improper use, which results in
authorized or unauthorized persons from carelessly, unwisely, or unknowingly
exposing themselves or others to direct or secondary radiation. Allow only
authorized, properly trained personnel to operate this equipment.
Be certain that all personnel authorized to use the equipment are aware of the
danger of excessive exposure to x-ray radiation.
This equipment is sold with the understanding that the manufacturer, its agents,
and representatives do not accept any responsibility for over-exposure of patients
or personnel to x-ray radiation. Furthermore, the manufacturer does not accept any
responsibility for over-exposure of patients or personnel to x-ray radiation
generated by this equipment which is a result of poor operating techniques or
procedures.
Also, no responsibility will be assumed for any machine that has not been serviced
and maintained in accordance with the system technical manual, or which has been
modified or tampered with in any way.
1.4.3 Radiation Protection
WARNING
X-Rays are dangerous to both operator and others in the vicinity unless
established safe exposure procedures are strictly observed.
The useful and scattered beams can produce serious, genetic or potentially
fatal bodily injuries to any persons in the surrounding area if used by an
unskilled operator. Adequate precautions must always be taken to avoid
exposure to the useful beam, as well as to leakage radiation from within the
source housing or to scattered radiation resulting from the passage of
radiation through matter.

InnoVet Select
™ HF APR Service Manual
14
Those authorized to operate, test, participate in or supervise the operation of
the equipment must be thoroughly familiar and comply completely with the
currently established safe exposure factors and procedures described in
publications such as Sub-Chapter J of Title 21 of the Code of Federal
Regulations, "Diagnostic x-ray Systems and their Major Components," and
the National Council on Radiation Protection (NCRP) No. 33, "Medical x-ray
and Gamma-Ray protection for energies up to 10 MeV-Equipment Design
and Use," as revised or replaced in the future.
Failure to observe these warnings may cause serious, genetic or potentially
fatal bodily injuries to the operator or those in the area.
Those working in the immediate area must protect themselves with lead shielding.
These items would include but not necessarily be limited to goggles, thyroid shield,
apron and gloves with a lead equivalency of not less than 0.5 mm.
The best safety rule for x-ray operators is:
“Avoid exposure to the primary beam at all times.”
1.4.4 Monitoring of Personnel
Monitoring of personnel to determine the amount of radiation to which they have
been exposed provides a valuable cross-check to determine whether or not safety
measures are adequate. The most effective method of determining whether or not
the existing protective measures are adequate is the use of instruments to measure
the exposure in Rads. This measurement should be taken at all locations where
the operator or any portion of his body may be during exposure.
A common method of determining whether personnel have been exposed to
excessive radiation is the use of film badges. These are x-ray sensitive film
enclosed in a badge which incorporates metal filters of varying degrees of
transparency to x-ray radiation. Even though this device only measures the
radiation, which reaches the area of the body on which it is worn, it does furnish an
indication of the amount of radiation received.

InnoVet Select
™ HF APR Service Manual
15
1.4.5 Electrical
WARNING
Failure to comply with the following may result in serious or potentially fatal
bodily injuries to the operator or those in the area.
Only properly trained and qualified personnel should be permitted access to
any internal parts of the x-ray system. Live electrical terminals may be
deadly; be sure line disconnect switches are opened and other appropriate
precautions are taken before opening access doors, removing enclosure
panels, or attaching accessories.
Do not remove the flexible high voltage cables from the x-ray tube housing or
high voltage transformer or the access covers from the generator until the
main and auxiliary power supplies have been disconnected.
When disconnecting high voltage cables, they must be grounded
immediately in order to dissipate any electrical charge that may remain on
the cables or the tube.
1.4.6 Mechanical
WARNING
Particular care should be taken when servicing the inside of the tubestand. There
is an extreme threat of mechanical pinching between the vertical slide and
counterweight due to their close proximity and opposite directions of motion.
All of the movable assemblies and parts of x-ray equipment should be operated
with care. Only properly trained and qualified personnel should be permitted
access to any internal parts of the x-ray system.

InnoVet Select
™ HF APR Service Manual
16

1.5 Compatibility Statement
This x-ray system is compatible with the following equipment:
X-RAY TUBES:
Toshiba E7239 (1.0/2.0 mm focal spots), Toshiba E7242 (0.6/1.5 mm focal spots),
Varian RAD 13 (1.0/2.0 mm focal spots), Varian RAD 14 (0.6/1.2 mm focal spots).
Contact the factory for tube compatibility not listed.
COLLIMATOR:
Summit G800 and D800, Progeny MC150 and Linear II or Linear IV
1.6 Accuracy Statement
All measurements are made in compliance with the directions of the 20 kHz HF
APR Generator Service Manual in the Installation, Accuracy testing, and Calibration
procedures sections.
NOTE: Specified accuracy for kVp and mA does not include test
equipment tolerance.
1.6.1 Exposure kVp
Output kVp within ± 5% of indicated kVp, ± 1 kVp
1.6.2 Exposure mAs
Output mAs within ± 10% of indicated mAs, ± 1 mAs
1.6.3 Duty Cycle
The duty cycle is continuous for radiographic use. However, operation should be
limited to the capacity of the x-ray tube.

InnoVet Select
™ HF APR Service Manual
17
1.7 Maximum Outputs
The maximum rating for the output is listed in Table 1-1. The maximum line current
is listed in Table 1-2.
FACTOR MAX VALUE
kVp 125 kVp
mA 300 mA
Power 30 kW
Table 1-1: Maximum Power Rating
1.8 Maximum Momentary Line Current
Complete power requirements are shown in Section 1.8 below.
LINE VOLTAGE
(60 Hertz)
LINE CURRENT
(Single Phase)
208 VAC 230 Amps
220 VAC 220 Amps
240 VAC 200 Amps
Table 1-2: Maximum Line Current
1.9 Technique Factors That Constitute Maximum Line Current
Maximum line current will occur during exposures of 100 kVp, 300 mA.

InnoVet Select
™ HF APR Service Manual
18
1.10 Power Line Requirements
The line currents given in Table 1-2 (for the 208 to 240 volt line) are the momentary
line currents during an exposure. This is not the recommended circuit breaker
rating. The recommended supply power requirements are:
100AMP circuit breaker
37.5 kVA distribution transformer
#2 AWG wire for 50 feet run
#00 AWG wire for 100 feet run
250 mcm wire for 200 feet run
Maximum load voltage drop under full load to be not more than 5%
These wire sizes are for copper conductors between the distribution transformer
and the 100 Amp service disconnect. The 100 Amp breaker listed for 240 VAC
operation must be upgraded to 125 Amp for operation below 240 VAC as indicated
by the line currents listed in Table 1-2 above.
1.11 Preliminary Room Inspection
Prior to beginning installation, inspect the x-ray room to verify compliance with
specifications for the following:
•Incoming Line
•Service Disconnect
•Lead Shielding per local code
•Conduit
•Space Requirements
1.12 Unpacking
Upon receipt of the x-ray generator and associated equipment, inspect all shipping
containers for signs of damage. If damage is found, notify the carrier or his agent
immediately. When the equipment is unpacked, inspect all pieces for visible
damage. If any damaged parts are detected, repair or order replacements to
prevent unnecessary delay in installation.
Before beginning the installation, verify the following:
•All internal connections and fasteners are secure
•All internal wiring is secure

InnoVet Select
™ HF APR Service Manual
19
2.0 MECHANICAL ASSEMBLY
2.1 Radiographic Table
1. During shipment, the tabletop is banded to the table base. Cut loose the
banding and set the table top aside for assembly later. Loosen the hold-
down screws underneath the front rail of the table to release the grid cabinet.
Remove packing material from rear of grid cabinet.
2. Install the five leveling feet by threading them into the holes at the two front
corners of the table and at the ends and middle of the back rail. The two feet
with a 4" long body should be installed at the front corners of the table. The
three feet with a 1" long body should be installed at the back rail. (In the
accessory bag there are six blue and six red “U” shaped plastic spacers.
When leveling the table fully tighten the foot until the shoulder of the foot is
firmly against either these spacers or the bottom of the table/back rail). Use
of the spacers makes the table base/leveling feet union a solid “one piece”
structure, minimizing any wobble or table base motion.
Position the table close to its final location, using the leveling feet and
spacers to bring the table close to level at this time. Final leveling can be
done at end of assembly.
2.2 High Voltage Generator and Transformer placement
1. Verify that the oil level in the HV transformer is approximately 1/2" to 3/4"
below the underside of the cover. Refill with "Shell Diala oil AX" or remove
oil as necessary.
2. Using a piece of cardboard to protect the floor, push the transformer onto the
shelf in the table by tilting the transformer and sliding it up onto the right side
of the shelf. Once the transformer is in place, loosen the screw on the vent
plug to allow for oil expansion. Cover the vent plug and flange with one of
the loose fitting plastic covers provided with the HV transformer to prevent
contaminants from entering the oil.
3. Place the Power Module close to the front left side of the table but not inside,
leaving access on all sides. This allows the installer to establish the proper
wiring, routing and lengths for all cables.

InnoVet Select
™ HF APR Service Manual
20
2.3 Tubestand Installation
The sequence of assembly is different between Fixed-Top and Float-Top tables.
For Fixed-Top (standard) tables, proceed directly to section 2.3.1 below.
For Float-Top (optional) tables the table, top frame must first be removed before the
tubestand can be mounted. Skip to section 2.3.2. for instructions on this type of
table.
2.3.1 For Standard Fixed-Top Table
1. Remove tubestand stop from the left end of the table’s lower rear rail. See
figure 2.
2. Position the tubestand so that it is a few inches from the end of the back rail
of the table with the lower tubestand bearings in line with the back rail. See
figure 3.
Figure 2 - Back Rail and End Stop Figure 3 - Tubestand Positioning
AWK286-01 AWK286-02
(The tubestand shown in the pictures above is for a Float-Top table, but mounting the
tubestand to the rail is done the same for either configuration.)
