Summit Racing SUM-G1083 Quick setup guide

High Top Creeper
Assembly & Use Instructions
Introduction

The Foldable High Top Creeper can adjust between 45 and 66 inches in height. The
heavy-duty steel construction is powder coated for protection. A padded high density
foam deck provides additional comfort. The unit folds to save space.
Specifications
Construction
Powder Coated Steel
Casters
3” Swivel Casters
Dimensions
30.5” x 54” x 66”
Adjustable Height
45” to 66”
Weight Capacity
400 lb.
Padded Deck
18” x 12”
Safety
WARNING! Read and understand all instructions before using this tool. The operator must follow basic
precautions to reduce the risk of personal injury and/or damage to the equipment.
Keep this manual for safety warnings, precautions, operating or inspection and maintenance instructions.
HAZARD DEFINITIONS
Please familiarize yourself with the hazard notices found in this manual. A notice is an alert that there is a possibility of
property damage, injury or death if certain instructions are not followed.
DANGER! This notice indicates an immediate and specific hazard that will result in severe personal injury or death if the
proper precautions are not taken.
WARNING! This notice indicates a specific hazard or unsafe practice that could result in severe personal injury or death if
the proper precautions are not taken.
CAUTION! This notice indicates a potentially hazardous situation that may result in minor or moderate injury if proper
practices are not taken.
NOTICE! This notice indicates that a specific hazard or unsafe practice will result in equipment or property damage, but not
personal injury.
WORK AREA
1. Operate in a safe work environment. Keep your work area clean, well-lit and free of distractions. Place lights so you
are not working in a shadow.
2. Keep anyone not wearing the appropriate safety equipment away from the work area.
3. Store tools properly in a safe and dry location. Keep tools out of the reach of children.
PERSONAL SAFETY
WARNING! Wear personal protective equipment approved by the Canadian Standards Association (CSA) or
American National Standards Institute (ANSI).
PERSONAL PROTECTIVE EQUIPMENT
1. Always wear impact safety goggles that provide front and side protection for the eyes. Eye protection equipment
should comply with CSA Z94.3-07 or ANSI Z87.1 standards based on the type of work performed.
2. Wear gloves that provide protection based on the work materials or to reduce the effects of tool vibration.
3. Wear protective clothing designed for the work environment and tool.

4. Non-skid footwear is recommended to maintain footing and balance in the work environment.
5. Wear steel toe footwear or steel toe caps to prevent a foot injury from falling objects.
PERSONAL PRECAUTIONS
Control the tool, personal movement and the work environment to avoid personal injury or damage to the tool.
1. Do not operate any tool when tired or under the influence of drugs, alcohol or medications.
2. Do not overreach when operating the tool. Proper footing and balance enables better control in unexpected
situations.
SPECIFIC SAFETY PRECAUTIONS
WARNING! DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence
to the tool safety rules. If you use this tool unsafely or incorrectly, you can suffer serious personal injury.
1. Use the correct tool for the job. This tool was designed for a specific function. Do not modify or alter this tool or use it for
an unintended purpose.
2. DO NOT use the tool if any parts are damaged, broken or misplaced. Repair or replace the parts.
3. ALWAYS ensure the height adjustment bar is securely fixed in one of the three position slots prior to using.
4. The maximum capacity listed includes the user (person), tools, equipment and personal items. DO NOT exceed the
maximum capacity.
5. Lean your chest onto the chest pad deck gently. Avoid causing a shock load by jumping or falling onto the chest pad
deck.
6. DO NOT stand or sit on the chest pad deck.
7. DO NOT use the creeper to work over a running engine.
8. DO NOT get the creeper wet or use in damp locations or areas where there is condensation.
9. Use the creeper on a smooth, level surface capable of withstanding the total load.
10. ALWAYS lock the casters before using the creeper.
UNPACKING
WARNING! Do not operate the tool if any part is missing. Replace the missing part before operating. Failure to do
so could result in a malfunction and personal injury.
Remove the parts and accessories from the packaging and inspect for damage. Make sure that all items in the contents
are included.
Contents:
PART
DESCRIPTION
QTY
PART
DESCRIPTION
QTY
1
Leather surface
1
15
Nut M8
12
2
T type head
1
16
Bolt M8X16
6
3
Thin slice
1
17
Bolt M8X40
2
4
Ladder
1
18
Bolt M8X80
2
5
Ladder support
1
19
Brake wheel
2
6
Supporting tube
1
20
Wheel
2
7
Square tube
1
21
Bolt M12X60
4
8
Chassis
1
22
Nut M12
4
9
Grooves
2
23
Pin
2
10
Left foot
1
24
Nut M10
4
11
Right foot
1
25
Spring washer Ø12
4
12
Bolt M6X16
6
26
washer Ø12
4
13
Leather bag
1
27
Nut M6
4
14
Bolt M8X20
2

ASSEMBLY & INSTALLATION
Letter references in Chassis (8) refer to the contents.
1. Assemble the right and left feet (10 & 11) to the Chassis (8). Insert the end of each foot into the
Chassis's openings and align the bolt holes. The height adjustment notches will be on the inside
and the legs must angle outwards.
Secure each leg with a Bolt M12X60 (21) and Nut M12 (22). Insert the two Pins (23) and push the
ends down to secure the feet.
2. Attach the Wheels (20) by inserting the stem of each wheel through the end of each foot and
securing it with a Nut M10 (24). Install the Brake wheels (19) to the Chassis in the same manner.
Lock the rear wheels in place for the remainder of the installation.

3. Install the Ladder support (5) by inserting a Bolt M12X60 (21) through each side of the base
frame and lower ladder assembly. Secure ach bolt with a Nut M12 (22). Swing the ladder's angle
support into the height adjustment notches. Make sure the crossbar is firmly in place.

4. Place the Square tube (7) on both feet (10 & 11), aligning the bolt holes. Insert a Bolt M8X80 (18)
through the each end of the leg cross support and leg. Slide a washer over one bolt and secure with
a Nut M6(27). Repeat with the other cross support bolt.
5. Attach the Grooves (9). Match the angled opening with the adjustment notches. Insert a height
adjustment plate Bolt M6X16 (12) through the bolt hole at each end of the plate. Secure each bolt
with a Nut M6 (27). Repeat on the other side.
6. Attach the T type head (2) to the top of the Ladder
support (5) using three Bolt M8X16 (16) and Nut M8
(15) on each side. Attach the Leather surface(1)
using two Bolt M8X20(14) and Nut M8 (15) from
underneath.

7. Place the Thin slice (3) over the Leather bag (13) and align the screw holes. Insert a Bolt
M8X20(14) and Nut M8 (15) through the screw holes. Line up the protruding screws with the holes
in the deck frame's front. Secure the pouch to the deck frame with screws.
8. Place the foam bumper pads over each of the angle support arms and the ladder assembly's
crosspiece. This will prevent the ladder from scuffing the vehicle.
9. Re-check and tighten all bolts and screws as necessary.
CARE & MAINTENANCE

1. Maintain the tool with care. A tool in good condition is efficient, easier to control and will have
fewer problems.
2. Inspect the tool components periodically. Repair or replace damaged or worn components. Only
use identical
replacement parts when servicing.
3. Maintain the tool's labels and name plates. These carry important information.
WARNING! Only qualified service personnel should repair the tool. An improperly repaired
tool may present a
hazard to the user and/or others.
CLEANING
Wipe clean as needed. Use mild upholstery cleaner (not caustic) to clean the chest deck pad as
needed.
LUBRICATION
DO NOT lubricate casters. This can damage the mechanism.
STORAGE
1. Remove the leg lock pins from each leg. Hold the ladder when removing the second pin as the
base frame will fall to
the floor. Store the pins in the creeper's pouch.
2. Push the ladder's angle support arms back towards the ladder.
3. Lift each leg up until it rests next to the ladder assembly.
4. Store the creeper vertically. Make sure the rear casters are locked once it is in place.
REMOVAL FROM STORAGE
1. Lower each leg.
2. Pull the ladder's angle support arms forward to settle in a height adjustment notch.
3. Remove the leg lock pins from the pouch.
4. Lift the base frame and push the leg down until it the bolt holes align. Push the leg lock pin
through and turn the end
down. Repeat with the other leg.
5. Unlock the rear casters and it is ready for use.
DISPOSAL

Recycle a tool damaged beyond repair at the appropriate facility.
