Summit Microwave link BT Series Instruction manual

Quick Install Manual 1.2 SUMMIT DEVELOPMENT, spol. s r.o.
Microwave link BT series –Quick Start Manual
FOD unit grounding
DC input 20-57V

The connection is not polarity-sensitive
0,5A @ 48V

Connection for DC voltmeter (N-connector)
RSSI measurement
stronger signal lower DC voltage
e.g. -80 dBm ~ 2,45 V, -40 dBm ~ 0,35 V
Pressure compensation valve
Gigabit SFP port
1000BaseT (RJ-45)
Support PoE+ (IEEE 802.3at)
PoE voltage input 40-57V DC
Gigabit SFP port
100/1000BaseT (RJ-45)

Support PoE+ (IEEE 802.3at)
PoE voltage input 40-57V DC
ETH1
SFP2
SFP1
ETH2
2
PWR
1

Quick Install Manual 1.2 SUMMIT DEVELOPMENT, spol. s r.o.
Block diagram

Quick Install Manual 1.2 SUMMIT DEVELOPMENT, spol. s r.o.
Connect the device to a power source. The device can be powered separately by using the power port
(20-57 VDC) or over the Ethernet 802.3at (40-57 VDC). These connections are not polarity sensitive.
Connect the device to a computer by Ethernet cable. Use ETH1 / SFP1 to access to the device.
The default IP address of the device is 192.168.2.9 (TX low freq.) and 192.168.2.10 (TX high freq).
To change IP address open the Summit Management System (sms.exe) and click the „ScanOdus“. Within
few a seconds, the device will appear in the table. Select your device and click „Set IP“ to set new IP
address (Subnet mask and Default gateway are not filled).
The IP address of your computer must be in the same subnet as the device in order to connect to it.
Continue with the configuration process according to the user manual SMS.
How to connect to the device

Quick Install Manual 1.2 SUMMIT DEVELOPMENT, spol. s r.o.
Nut
Sealing Body
Gland
Body
DC Connector
O Ring
SFP module
Cable Gland
Extension
Fiber Optic Connector
RJ-45 Connector
!
!
Caution before removing the cable gland:
To avoid a broken fiber by pulling on the
optic cable you must first loosen the nut on
the gland body and pull the sealing body.
Installing the connectors on FOD unit
Installing tools: Spanner (19, 29 mm)

Quick Install Manual 1.2 SUMMIT DEVELOPMENT, spol. s r.o.
Azimuth alignment
(0 - 360°)
Elevation alignment
(-45° to 45°)
4 x Socket Head Cap Screw (M6)
4 x Rubber Washer
Tube diamater  65 mm - 120 mm
O-ring
Elevation adjustment screw
Fixing the Azimuth
Fixing the Elevation
Installing the FOD unit on the antenna
Installing tools: Spanner (13, 17 mm), Allen (5 mm)

Quick Install Manual 1.2 SUMMIT DEVELOPMENT, spol. s r.o.
Link polarization
BTH 17/24
BTD 10
BT 17
BT 24
BT 80
unit 1
unit 2
Vertical
Vertical





Horizontal
Horizontal





Vertical
Horizontal





Horizontal
Vertical





Microwave link polarization
The polarization is defined by turning FOD unit through 90°
Vertical polarization
Horizontal polarization

Quick Install Manual 1.2 SUMMIT DEVELOPMENT, spol. s r.o.
RSSI calibration graph
The value of received level (RSSI) can be determined by direct reading in the Summit Management System
(SMS) or by calculation using the calibration graph for RSSI. The RSSI voltage can be measured at the N
connector. Connect a voltmeter with the range 2V DC via N connectors to the radio unit and adjust antennas to
the lowest indicated voltage.
-90
-85
-80
-75
-70
-65
-60
-55
-50
-45
-40
-35
-30
0 0,2 0,4 0,6 0,8 1 1,2 1,4 1,6 1,8 2
RSSI [dBm]
U [V]
The RSSI Calibration graph
BTH 17/24
BT10
BT17

Quick Install Manual 1.2 SUMMIT DEVELOPMENT, spol. s r.o.
BT Quick Start Manual ver. 1.2 8
Application options
