Sun Microsystems Sun StorageTek SL24 Manual

Sun StorageTek™ SL24 Tape Autoloader and
SL48 Tape Library
User and service guide
AH945-96001
Part number: AH945–96001
First edition: July 2007

Legal and notice information
©Copyright 2006-2007 Sun Microsystems, Inc. 2550 Garcia Avenue, Mountain View, California 94043–1100 U.S.A
This document was created by Hewlett-Packard Company (“HP”) for Sun Microsystems, Inc. (“Sun”).
Sun makes no warranties of any kind with regard to this material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Sun shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this material.
This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent of Sun.
Sun shall not be liable for technical or editorial errors or omissions contained herein. The information is provided "as is" without
warranty of any kind and is subject to change without notice. The warranties for Sun products are set forth in the express limited
warranty statements for such products. Nothing herein should be construed as constituting an additional warranty.
Sun StorageTek™ SL24 Tape Autoloader and Sun StorageTek™ SL48 Tape Library are trademarks of Sun Microsystems, Inc.
Other trademarks may be mentioned herein which belong to other companies.

Contents
Aboutthisguide.......................... 13
Intendedaudience...................................... 13
Documentconventionsandsymbols.............................. 13
Rackstability........................................ 14
Suntechnicalsupport .................................... 14
Sunwebsites........................................ 14
1 Features and overview ....................... 15
InterfacespecificationsandrequirementsforparallelSCSIdrives................. 16
ParallelSCSIhostbusadapters(HBAs) .......................... 16
MultipleLUNsupport.................................. 16
DefaultSCSIIDs .................................... 17
InterfacespecificationsandrequirementsforFibreChanneldrives................. 17
Frontpaneloverview .................................... 18
Backpaneloverview..................................... 19
TapedriveLED....................................... 20
Powersupplybackpanel(SL48)................................ 20
2 Installing the Autoloader or Library . . . . . . . . . . . . . . . . . 21
Preparingthehost...................................... 21
PlanningtheparallelSCSIconfiguration............................ 21
AboutparallelSCSIbusses................................ 22
Optimizingthroughput ................................. 22
SCSIaddresses..................................... 22
Planning the Fibre Channel configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Directconnection.................................... 23
SAN connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Choosingalocation..................................... 24
UnpackingtheAutoloaderorLibrary ............................. 25
Identifying product components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Removingtheshippinglock ................................. 27
MountingtheAutoloaderorLibraryinarack.......................... 27
InstallingtheTabletopConversionKit............................. 31
Installingadditionaltapedrives................................ 31
Installingaredundantpowersupply ............................. 32
ChangingtheSCSIaddress(parallelSCSIdrivesonly)...................... 33
Connecting the parallel SCSI cable (parallel SCSI devices only) . . . . . . . . . . . . . . . . . . 33
Connecting the Fibre Channel cables (Fibre Channel devices only) . . . . . . . . . . . . . . . . . 34
PoweringontheAutoloaderorLibrary ............................ 35
ConfiguringtheAutoloaderorLibrary............................. 35
Verifying the connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Labelingandloadingthetapecartridges............................ 36
3Tapecartridgesandmagazines................... 37
Tapecartridges....................................... 37
Usingandmaintainingtapecartridges........................... 37
Labelingtapecartridges................................. 38
Write‐protectingtapecartridges.............................. 38
Backwardreadcompatibility............................... 39
User and service guide 3

Magazines......................................... 39
4OperatingtheAutoloaderorLibrary................. 43
Remotemanagementinterface(RMI) ............................. 43
Overview ....................................... 43
Login ......................................... 44
Statuspane....................................... 45
Gettinghelp ...................................... 46
Identity ........................................ 46
Viewingstaticdeviceinformation........................... 46
Viewingstaticdriveinformation ........................... 47
Status......................................... 50
Viewingdynamicdeviceinformation ......................... 50
Viewingdynamicdriveinformation.......................... 51
Viewingthetapecartridgeinventory ......................... 52
Configuration...................................... 54
Changingthesystemconfiguration .......................... 54
Changingthedriveconfiguration........................... 56
Changingthenetworkconfiguration.......................... 58
Changingtheadministratorpassword......................... 58
Settingthedateandtime............................... 59
Settingerrorlogmode................................ 59
Settingeventnotificationparameters ......................... 60
Restoringfactorydefaults .............................. 60
Operations....................................... 62
Movingmedia ................................... 62
Updatingthecurrentmediainventory......................... 62
Releasingandreplacingthemagazines......................... 63
Support ........................................ 63
Performinggeneraldiagnostics............................ 63
Service the Library ‐Servicerestricted......................... 64
Determiningandupdatingfirmware.......................... 64
Rebootingthedevice ................................ 65
Viewinglogs.................................... 65
Cleaningtapedrives................................. 66
SunServicelink..................................... 66
SL24Operatorcontrolpanel(OCP) .............................. 66
LEDindicators..................................... 67
Autoloaderhomescreen................................. 68
Operatorcontrolpanelbuttons.............................. 69
Understandingthemenustructure ............................ 69
Enteringtheadministratorpassword ......................... 70
Unlockingthemailslot.................................. 71
Status/Information ................................... 71
Inventory ..................................... 72
Autoloaderinformation ............................... 73
Driveinformation.................................. 73
Component status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Networkinformation ................................ 74
Configuration...................................... 74
Changingtheadministratorpassword......................... 75
Settingthenumberofreservedslots.......................... 75
Configuringthemailslot............................... 75
Barcodereportformat................................ 76
ChangingtheSCSIaddress(SCSIdrives)........................ 76
Changing the drive configuration (Fibre Channel drives) . . . . . . . . . . . . . . . . . 76
Settingthemasterdrive ............................... 77
Settingbehaviors.................................. 77
Settingthedateandtime............................... 79
Configuringnetworksettings............................. 79
4

Configuringautomaticcleaning............................ 80
Restoringfactorydefaults .............................. 80
Operations....................................... 81
Unlocking,removing,andreplacingmagazines..................... 81
Cleaningthetapedrive ............................... 81
MovingtapesintheAutoloader............................ 82
Updatingtapecartridgeinventory........................... 83
RebootingtheLibrary................................ 83
Enablingpasswordlocks............................... 84
Support ........................................ 84
Poweringadriveonoroff .............................. 84
Runningthedemonstration.............................. 85
Runningtheslottoslottest.............................. 85
Runningthewellnesstest .............................. 85
Upgradingfirmware................................. 86
Viewinglogs.................................... 87
Forcingthedrivetoejectatape............................ 87
SL48operatorcontrolpanel.................................. 88
Overview ....................................... 88
OperationsavailableusingtheOCP.......................... 88
Operatorcontrolpanelnavigationbuttons....................... 89
UsingtheOCP ..................................... 90
Statusmessagebar ................................. 90
Menubar ..................................... 90
Administratorpassword............................... 91
Illustratedmenuoptionandnavigationexamples...................... 92
Openingmailslots(Operations>OpenMailslots).................... 92
MovingMedia(Operations>MoveMedia)....................... 94
Infomenu ....................................... 95
Viewingstatusinformation(Info>Status) ....................... 95
Viewingidentityinformation(Info>Identity)...................... 96
Viewinginventoryinformation(Info>Inventory).................... 96
Viewingnetworkinformation(Info>Network)..................... 96
Configurationmenu................................... 97
Changing the Library configuration (Configuration > Library Configuration) . . . . . . . . 97
Changingthedriveconfiguration(Configuration>DriveConfiguration).......... 98
Changing the network configuration (Configuration > Network Configuration) . . . . . . . 99
Changing the administrator password (Configuration > Administrator Password) . . . . . . 99
Barcode reporting format (Configuration > Barcode Reporting Format) . . . . . . . . . . . 99
Restoredefaults(Configuration>RestoreDefaults) ................... 99
SettingtheLibrarydateandtime(Configuration>SetDate/Time)............ 100
Operationsmenu................................... 101
Openingthemailslot(Operations>OpenMailslot) .................. 101
Unlocking, removing and replacing magazines (Operations > Unlock Left/Right Magazines . 101
MovingMedia(Operations>MoveMedia)...................... 102
PerformingInventory(Operations>Inventory).................... 102
EnablingPasswordLocks(Operations>EnablePasswordLocks) ............ 102
Supportmenu .................................... 102
Poweringdrivesonandoff(Support>Poweron/offDrives) .............. 103
Cleaningthetapedrive(Support>CleanDrive).................... 103
Runningtests(Support>RunTests)......................... 104
Viewinglogs(Support>ViewLogs)......................... 104
UpdatingLibraryanddrivefirmware ........................ 104
Forceejectingadrive(Support>ForceDriveEject) .................. 105
RebootingtheTapeLibrary(Support>Reboot).................... 105
5 Troubleshooting . . . ..................... 107
DetectionproblemsafterinstallingaparallelSCSIdevice.................... 107
Fibre Channel connection problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Operationproblems.................................... 110
User and service guide 5

Performanceproblems................................... 115
Averagefilesize.................................... 116
Filesystemtype.................................... 116
Connection from the host server to the disks . . . . . . . . . . . . . . . . . . . . . . . 117
Operatingsystemconfiguration............................. 119
Windows..................................... 119
Novell...................................... 119
Backupserver .................................... 120
Backuptype ..................................... 120
File‐by‐file with a full‐featuredbackupapplication .................. 120
File‐by‐filewithanativeapplication......................... 121
Diskimage,flash,orsequential........................... 121
Databasebackup ................................. 121
Connection from the host server to the Autoloader or Library . . . . . . . . . . . . . . . . 121
Media........................................ 122
Serviceandrepair..................................... 122
Releasingthemagazinesmanually ........................... 122
Errorcodes........................................ 123
FindingerrorcodeinformationontheSL24OCP ..................... 124
FindingerrorcodeinformationontheSL48OCP ..................... 125
FindingerrorcodeinformationontheRMI........................ 125
Mainerrorcodedescriptions.............................. 126
Error sub‐codedescriptions............................... 130
Robotic error sub‐codes .............................. 130
Device error sub‐codes............................... 133
Driveerrorcodes................................... 133
Warningevents...................................... 134
6UpgradingandservicingtheAutoloaderorLibrary......... 137
Possibletoolsneeded ................................... 137
Installinganewtapedrive................................. 138
Removingandreplacingatapedrive ............................ 139
Removingandreplacingamagazine............................. 141
UsingtheSL24operatorcontrolpanel.......................... 142
UsingtheSL48operatorcontrolpanel.......................... 142
Usingtheremotemanagementinterface......................... 142
Usingthemanualrelease................................ 143
Installingaredundantpowersupply(SL48only) ....................... 144
Replacingthepowersupply(SL48) ............................. 145
Replacingthelibrarycontroller(SL48)............................ 147
Removingandreplacingthebasechassis........................... 149
Recordingconfigurationsettings ............................ 149
Removingthetapecartridgefromthedrive........................ 150
Removingthecables,magazines,andtapedrives..................... 150
Removingthepowersupplyandlibrarycontroller(SL48only) ............... 151
Removingthebasechassisfromtherackorcover..................... 151
Unpackingthenewchassis............................... 152
Replacingthebasechassis ............................... 152
A Technical specifications..................... 155
Physicalspecifications................................... 155
Environmentalspecifications................................ 155
BRegulatorycomplianceandsafety................. 157
Regulatorycompliance................................... 157
Regulatorycomplianceidentificationnumbers ...................... 157
Regulatorycompliancelabellocation ........................ 157
FederalCommunicationsCommissionnotice....................... 157
6

ClassAequipment ................................ 157
ClassBequipment................................. 157
Declaration of conformity for products marked with the FCC logo, United States only . . . 158
Modifications................................... 158
Cables...................................... 158
Laserdevice ..................................... 158
Lasersafetywarning................................ 158
Internationalnoticesandstatements............................. 159
Canadiannotice(avisCanadien) ............................ 159
ClassAequipment ................................ 159
ClassBequipment................................. 159
EuropeanUnionnotice................................. 159
BSMInotice ..................................... 159
Japanesenotice.................................... 160
Koreannotices .................................... 160
Safety.......................................... 160
Taiwanbatteryrecyclingnotice............................. 160
Powercords ..................................... 161
Japanesepowercordnotice............................... 161
Wasteelectricalandelectronicequipmentdirective ...................... 161
Czechoslovakiannotice ................................ 161
Danishnotice..................................... 162
Dutchnotice ..................................... 162
Englishnotice..................................... 162
Estoniannotice.................................... 163
Finnishnotice..................................... 163
Frenchnotice..................................... 163
Germannotice .................................... 164
Greeknotice ..................................... 164
Hungariannotice................................... 165
Italiannotice..................................... 165
Latviannotice .................................... 165
Lihuaniannotice ................................... 166
Polishnotice ..................................... 166
Portuguesenotice................................... 167
Slovakiannotice.................................... 167
Sloveniannotice.................................... 167
Spanishnotice .................................... 168
Swedishnotice .................................... 168
CElectrostaticdischarge...................... 169
Preventingelectrostaticdamage............................... 169
Groundingmethods.................................... 169
Glossary............................. 171
Index.............................. 175
User and service guide 7

Figures
1..SL24defaultSCSIIDs.............................. 17
2..SL48defaultSCSIIDs ............................. 17
3..SL24frontpaneloverview............................ 18
4..SL48frontpaneloverview............................ 18
5..OperatorcontrolpanelLEDs........................... 19
6..SL48backpaneloverviewwithafull-heightparallelSCSItapedrive.......... 19
7..SL24withaFibreChanneldrive......................... 20
8..TapedriveLED ................................ 20
9..PowersupplyLEDs............................... 20
10 ..SL24 parallel SCSI tape drive default SCSI addresses . . . . . . . . . . . . . . . . 23
11 ..SL48 parallel SCSI tape drive default SCSI addresses . . . . . . . . . . . . . . . . 23
12 ..Shippinglocklocation ............................. 27
13 ..Shippinglockstoragelocation.......................... 27
14 ..Rackkit ................................... 28
15 ..Replacingalignmentpins............................ 29
16 ..Attachingtheclipnuttotherail ......................... 29
17 ..Securingtherailstotherack........................... 30
18 ..Clipnutlocation................................ 30
19 ..SecuringtheTapeAutoloaderorLibrarytotherack................. 31
20 ..Installingthetabletopconversioncover ...................... 31
21 ..Installingatapedrive ............................. 32
22 ..Installingthenewpowersupply ......................... 33
23 ..Redundantpowersupplythumbscrews ...................... 33
24 ..AttachingtheparallelSCSIcabletothetapedrive ................. 34
25 ..AttachingtheFibreChannelcable ........................ 34
26 ..Attachingthepowercord............................ 35
27 ..Write-protectingthedatacartridge........................ 39
28 ..SL24slotnumberingwiththesinglemailslotenabled ................ 40
29 ..SL48slotnumberingwithmailslotdisabled .................... 41
30 ..SL48lower-leftmagazineslotnumberingwithmailslotenabled............ 41
31 ..RMIloginpage ................................ 44
32 ..SystemStatuspane............................... 45
33 ..Helpbutton.................................. 46
34 ..Identity:LibraryorAutoloaderpage ....................... 46
35 ..Identity:Drivepage(parallelSCSI)........................ 48
36 ..Identity:Drivepage(FibreChannel) ....................... 49
37 ..Status:LibraryorAutoloaderpage........................ 50
8

38 ..Status:Drivepage(parallelSCSI) ........................ 51
39 ..Status:Drivepage(FibreChannel)........................ 52
40 ..Status:Inventorypage ............................. 53
41 ..Status:Inventory:Mediadetailspane....................... 54
42 ..Configuration:Systempage........................... 55
43 ..Configuration:Drivepage(parallelSCSI)..................... 57
44 ..Configuration:Drivepage(FibreChannel)..................... 57
45 ..Configuration:Networkpage.......................... 58
46 ..Configuration:Passwordpage.......................... 59
47 ..Configuration:Date/Timepage ......................... 59
48 ..Configuration:Logpage ............................ 60
49 ..Configuration: Event notificationpage ...................... 60
50 ..Configuration:Restoredefaultspage....................... 61
51 ..Operations:MoveMediapage ......................... 62
52 ..Operations:Inventorypage........................... 63
53 ..Operations:Magazinespage.......................... 63
54 ..Support:GeneralDiagnosticpage........................ 64
55 ..Support:ServicetheLibrarypage ........................ 64
56 ..Support:Firmwarepage ............................ 65
57 ..Support:Rebootpage ............................. 65
58 ..Support:LibraryLogspage........................... 66
59 ..Support:CleanDrivepage ........................... 66
60 ..Support:SunServiceLinkpage ......................... 66
61 ..LEDs..................................... 68
62 ..Operatorcontrolpanelbuttons.......................... 69
63 ..Autoloadermenutree ............................. 70
64 ..Removingatapefromthemailslot ........................ 71
65 ..OCPmenu,showinginitialsystemstatusinformation ................ 90
66 ..Operatorcontrolpanelmenu .......................... 91
67 ..Mailslot-capablemagazineandslot,eachmarkedwithawhitedot.......... 92
68 ..Operationsmenu ............................... 93
69 ..Removingtheexistingtapefromthemailslot.................... 93
70 ..Operationsmenu ............................... 94
71 ..Infomenu................................... 95
72 ..Configurationmenu .............................. 97
73 ..SL48parallelSCSItapedrivedefaultSCSIaddresses ................ 100
74 ..Operationsmenu ............................... 101
75 ..Mailslot-capablemagazineandslot,eachmarkedwithawhitedot.......... 101
76 ..Supportmenu................................. 103
77 ..SL24 parallel SCSI tape drive default SCSI addresses . . . . . . . . . . . . . . . . 107
78 ..SL48parallelSCSItapedrivedefaultSCSIaddresses ................ 108
User and service guide 9

79 ..RemovableStorageservice ........................... 119
80 ..Accessholesfortherightandleftmagazines ................... 123
81 ..Releasingthemagazine ............................ 123
82 ..InitialOCPerrormessage............................ 124
83 ..ErrorcodeintheOCPErrorLog ......................... 124
84 ..ErrormessageintheOCPErrorLog ....................... 124
85 ..No additional information in the OCP error log . . . . . . . . . . . . . . . . . . 124
86 ..DateandtimeintheOCPerrorlog........................ 125
87 ..Support:LibraryLogspage ........................... 126
88 ..Installinganewtapedrive ........................... 138
89 ..Tightenthebluethumbscrews .......................... 139
90 ..DriveLEDs .................................. 140
91 ..Captivescrewsonthetapedrive......................... 140
92 ..Removingatapedrive ............................. 140
93 ..Installingatapedrive ............................. 141
94 ..RMIloginpage ................................ 143
95 ..Operations:Magazinespage.......................... 143
96 ..Manualmagazinereleaseholes......................... 143
97 ..Removingtheleftmagazine........................... 144
98 ..Installingthenewpowersupply ......................... 145
99 ..SecuringthepowersupplytotheLibrary ..................... 145
100 ..PowersupplyLEDs............................... 145
101 ..Removingtheoldpowersupply ......................... 146
102 ..Installingthenewpowersupply ......................... 146
103 ..PowersupplyLEDs............................... 147
104 ..Removingthelibrarycontroller.......................... 148
105 ..Installingthenewlibrarycontroller........................ 148
106 ..SL48systemstatus............................... 149
107 ..Captivescrewsonthetapedrive......................... 150
108 ..Removingatapedrive ............................. 150
109 ..Removingthepowersupply........................... 151
110 ..Removingthelibrarycontroller.......................... 151
111 ..Removingthebasechassisfromtherack ..................... 152
112 ..Shippinglocklocation ............................. 153
113 ..Shippinglockstoragelocation.......................... 153
114 ..SecuringaTapeLibrarytotherack........................ 154
10

Tables
1..Documentconventions ............................. 13
2..Autoloader and Library capacity . . . . . . . . . . . . . . . . . . . . . . . . . 15
3..LTO-2 HH Autoloader and Library specifications .................. 15
4..LTO-3 FH Autoloader and Library specifications................... 16
5..ParallelSCSImodelandinterfacetype ...................... 16
6..Locationcriteria................................ 25
7..Productcontents................................ 26
8..Backwardreadcompatibility .......................... 39
9..Drivestatus.................................. 68
10 ..Display indication definitions .......................... 72
11 ..OCPbuttons ................................. 89
12 ..Navigationbuttons............................... 89
13 ..Librarystatus ................................. 90
14 ..Powerproblems................................ 110
15 ..Failure/attentionindicationsdisplayedonthefrontpanel .............. 111
16 ..Tapemovementproblems............................ 111
17 ..Mediaproblems................................ 112
18 ..ParallelSCSIdevicenotdetected......................... 113
19 ..AttentionLEDislit ............................... 114
20 ..Inventoryproblems............................... 115
21 ..RMInetworkconnectionissues.......................... 115
22 ..Cleaningproblems............................... 115
23 ..Performance impact of various filesizes...................... 116
24 ..Performance impact of various filesystems..................... 117
25 ..Performanceimpactofvariousdiskconnections .................. 117
26 ..Backupserverrequirements ........................... 120
27 ..PerformanceimpactofvariousAutoloaderorLibraryconnections........... 122
28 ..Mainerrorcodes ............................... 126
29 ..Roboticerrorsub-codes............................. 131
30 ..Deviceerrorsub-codes ............................. 133
31 ..Driveerrorcodes ............................... 134
32 ..Warningeventcodes.............................. 134
33 ..SL24 Tape Autoloader physical specifications:allmodels .............. 155
34 ..SL48 Tape Library physical specifications:allmodels ................ 155
35 ..Environmental specifications........................... 155
User and service guide 11

12

About this guide
This guide provides information about:
•Installing a Sun StorageTek™ SL24 Tape Autoloader or SL48 Tape Library
•Configuring and operating a Sun StorageTek™ SL24 Tape Autoloader or SL48 Tape Library
•Troubleshooting a Sun StorageTek™ SL24 Tape Autoloader or SL48 Tape Library
•Upgrading and servicing a Sun StorageTek™ SL24 Tape Autoloader or SL48 Tape Library
Intended audience
This guide is intended for system administrators and other users who need physical and functional
knowledge of a Sun StorageTek™ SL24 Tape Autoloader or SL48 Tape Library.
Document conventions and symbols
Table 1 Document conventions
Convention Element
Blue text:Table 1 Cross-reference links and e-mail addresses
Blue, underlined text: http://www.sun.com Website addresses
Bold text •Keys that are pressed
•Text entered into a GUI element, such as a box
•GUI elements that are clicked or selected, such as
menu and list items, buttons, tabs, and check boxes
Italic text Text emphasis
Monospacetext •File and directory names
•System output
•Code
•Commands, their arguments, and argument values
Monospace, italic text •Code variables
•Command variables
Monospace, bold text Emphasized monospace text
WARNING!
Indicates that failure to follow directions could result in bodily harm or death.
CAUTION:
Indicates that failure to follow directions could result in damage to equipment or data.
IMPORTANT:
Provides clarifying information or specific instructions.
User and service guide 13

NOTE:
Provides additional information.
TIP:
Provides helpful hints and shortcuts.
Rack stability
Racks must be stable to insure the safety of personnel and avoid equipment damage.
WARNING!
Toreducetheriskofpersonalinjuryordamagetoequipment:
•Extend leveling jacks to the floor.
•Ensure that the full weight of the rack rests on the leveling jacks.
•Install stabilizing feet on the rack.
•In multiple‐rack installations, fasten racks together securely.
•Extend only one rack component at a time. Racks can become unstable if more than one component is
extended.
Sun technical support
Telephone numbers for worldwide technical support are listed on the Sun support website:
http://www.sun.com/service/contacting/solution.html.
Collect the following information before calling:
•SunSpectrum contract number
•Product serial numbers
•Product model names and numbers
•Error messages
•Operating system type and revision level
•Detailed questions
For continuous quality improvement, calls may be recorded or monitored.
Sun websites
For additional information, see the following Sun websites:
•h
ttp://www.sun.com — Sun corporate website
•h
ttp://www.sun.com/storagetek/tape_storage — Sun storage products
•h
ttp://www.sun.com/service/contacting/solution.html — Sun Support website
•h
ttp://www.sun.com/app/docs — documentation about Sun products
14 About this guide

1 Features and overview
The Sun StorageTek™ SL24 Tape Autoloader and SL48 Tape Library provide compact, high‐capacity,
low‐cost solutions for simple, unattended data backup. This unique design houses up to 12 tape
cartridges for each U of height, with easy access to tape cartridges via removable magazines and one
or more mailslots (see Table 2). Each magazine can hold up to 12 tape cartridges.
The Autoloader and Library are compatible with most operating systems. However, the Autoloader
and Library require either direct support from the operating system or a compatible backup
application to take full advantage of their many features.
The Autoloader and Library are customer expandable with exchangeable tape drives. The Autoloader
and Library support the LTO‐2 HH parallel SCSI tape drive, and the LTO‐3FHSCSIandFibre
Channel tape drives.
Table 2 Autoloader and Library capacity
SL24 SL48
Form factor 2U 4U
Maximum cartridge slots 24 48
Mailslots 0, 1 0, 3
Maximum full-height tape drives 12
Maximum half-height tape drives 24
Maximum storage capacity: LTO-2
media
Native: 4.8 TB (24 x 200 GB)
Compressed (2:1): 9.6 TB
Native:9.6TB(48x200GB)
Compressed (2:1): 19.1 TB
Maximum storage capacity: LTO-3
media
Native: 9.6 TB (24 x 400 GB)
Compressed (2:1): 19.1 TB
Native: 19.1 TB (48 x 400 GB)
Compressed (2:1): 38.2 TB
Maximum data transfer rates are shown in Table 3 and Table 4.
Table3LTO‐2 HH Autoloader and Library specifications
Characteristic Specification
Tape drive LTO-2, half-height parallel SCSI
Maximum data transfer rate — one drive Native: 24 MB/s (86 GB/hr.)
Compressed2:1):48MB/s(172GB/hr.)
Maximum data transfer rate — two drives Native: 48 MB/s (172 GB/hr.)
Compressed (2:1): 96 MB/s (344 GB/hr.)
Maximum data transfer rate — three drives Native: 72 MB/s (256 GB/hr.)
C o m p re s s e d ( 2 :1) : 14 4 M B / s ( 516 G B / h r. )
Maximum data transfer rate — four drives Native: 96 MB/s (344 GB/hr.)
Compressed (2:1): 192 MB/s (688 GB/hr.))
User and service guide 15

Table4LTO‐3 FH Autoloader and Library specifications
Characteristic Specification
Tape drive LTO-3, full-height, parallel SCSI and FC
Maximum data transfer rate — one drive Native: 80 MB/s (288 GB/hr.)
Compressed (2:1): 160 MB/s (576 GB/hr.)
Maximum data transfer rate — two drives Native: 160 MB/s (576 GB/hr.)
Compressed (2:1): 320 MB/s (1152 GB/hr.)
Interface specifications and requirements for parallel SCSI
drives
The parallel SCSI Autoloader and Library use the SCSI interface types described in Table 5.The
Autoloader and Library use a separate SCSI ID foreachtapedrive,withdualLUNsonthemaster
driveʹs SCSI ID to control the tape drive (LUN 0) and Library robotic (LUN 1). Sun recommends that
each LTO tape drive be put on its own bus when possible.
Table 5 Parallel SCSI model and interface type
Model SCSI Interface
LTO-2 HH Ultra 160 SCSI LVD/SE
LTO-3 FH Ultra 320 SCSI LVD
The parallel SCSI Autoloader and Library incorporate a wide SCSI‐2orSCSI‐3low‐voltage differential
(LVD) SCSI bus. Make sure your SCSI host adapter or controller supports these standards.
IMPORTANT:
The Autoloader and Library are NOT compatible with a standard differential (Diff) or high‐voltage
differential (HVD) SCSI bus. Do not put the Autoloader or Library on a narrow (50–pin) parallel SCSI bus
because doing so will severely degrade performance.
Parallel SCSI host bus adapters (HBAs)
For optimum performance, place each tape drive on itsownparallelSCSIbuswithahostbusadapter
that can transfer data as fast as the Library can read and write. The HBA must also be supported
by your operating system.
•For LTO‐3 tape drives, use an Ultra 320 HBA.
•For LTO‐2tapedrives,useanUltra3
20 or Ultra 160 HBA.
IMPORTANT:
Do not connect an LTO tape drive to an SE SCSI bus, as it severely degrades Autoloader and Library
performance. A single‐ended SCSI host bus adapter severely degrades Autoloader and Library performance
and limits cable length. Also, if any SE devices are on the SCSI bus, all of the devices on the bus slow
down to SE speed, severely degrading performance.
Multiple LUN support
The Autoloader and Library use a single SCSI ID and two logical unit numbers (LUN). LUN 0 controls
the tape drive and LUN 1 controls the robotic. The Autoloader and Library require an HBA that
supports multiple LUNs. If multiple LUN support is not enabled, the host computer cannot scan
beyond LUN 0 to discover the Autoloader or Library. It just sees the tape drive.
16 Features and overview

RAID controllers, and most on‐board HBAs do not support multiple LUNs.
IMPORTANT:
The Autoloader or Library requires an HBA that supports multiple LUNs, which is also called “LUN
scanning.”
Default SCSI IDs
The default SCSI ID for parallel SCSI tape drivesismanagedbytheAutoloaderorLibrary. The
default SCSI ID for all full‐heighttapedrivesis4.
The default SCSI ID for half‐height tape drives depends on the Library model.
•SL24: The default SCSI ID of the bottom drive bay is 4 and the default SCSI ID of the top
drive bay is 5 as shown in Figure 1.
11434
2
1
Figure1SL24defaultSCSIIDs
1. D e f a u l t S C S I I D 4
2. Default SCSI ID 5
•SL48: The default SCSI ID for the bottom drive of each pair is 4 and for the top drive is 5 as
shown in Figure 2.
11435
1
2
Figure2SL48defaultSCSIIDs
1. D e f a u l t S C S I I D 4
2. Default SCSI ID 5
Interface specifications and requirements for Fibre Channel
drives
The Fibre Channel drive can be connected directly to the server with a host bus adapter (HBA) or
through a storage area network (SAN).
User and service guide 17

If you plan to connect the Autoloader or Library directly to the server, you will need a 2 Gb or 4 Gb
Fibre Channel HBA. A 4 Gb HBA is suitable for all supported drive types. A 1 or 2 Gb HBA might
result in performance degradation when backing up highly compressible data to a 4 Gb tape drive.
In a SAN installation, all switches between the host and the Autoloader or Library must be of the
appropriate type. A 1 or 2 Gb switch in the path may result in performance degradation. Configure
zoning so only the backup servers may access the Library.
Front panel overview
The front panel of the Autoloader or Library provides access to the power button, operator control
panel, left and right magazines, LEDs, and the mailslot as shown in Figure 3 and Figure 4.
11341
17
2 46 6 7
53
Figure3SL2
4 front panel overview
1. Power button 2. Magazine, mailslot location
3. Front panel LEDs 4. Front panel LCD screen
5. Control buttons 6. Air vents
7. M a g a z i n e s
1
77
3
2 6 6 7
4
11346
5
Figure 4 SL48 front panel overview
1. Power button 2. Magazine, mailslot location
3. Front panel LEDs 4. Front panel LCD screen
5. Control buttons 6. Air vents
7. M a g a z i n e s
The operator control panel includes four LEDs that provide a variety of information as shown
in Figure 5.
18 Features and overview

11256
1 32 4
Figure 5 Operator control panel LEDs
1. Green Ready. Illuminated when power is on. Blinking when there is tape drive or robotics
activity.
2. Amber Clean. Illuminated when the tape drive has determined that a cleaning cartridge should
be used. Cleaning is only necessary when the device directs you to do so. Additional
cleaning is not necessary.
3. Amber Attention. Illuminated if the device has detected a condition that requires attention by
the operator.
4. Amber Error. Illuminated if an unrecoverable error occurs. A corresponding error message
displays on the LCD screen (see “Troubleshooting” on page 107 for more information).
Back panel overview
The back panel provides access to the drive interface connectors, the tape drives, the power connector,
the Ethernet, serial and USB ports, and the magazine release holes. The Autoloader and Library
support parallel SCSI and Fibre Channel tape drives. For example, Figure 6 showsanSL48witha
full‐height parallel SCSI tape drives and Figure 7 shows an SL24 with a Fibre Channel tape drive.
11373
12 92 5 643 8 8 7
Figure6SL48backpaneloverviewwithafull‐height parallel SCSI tape drive
1. 68–pin parallel SCSI connector 2. Fan
3. Power connector 4. Tape drive
5. Ethernet port 6. Serial port (Factory use only)
7. U S B p o r t 8. Magazine release hole
9. Pull-out tab containing the serial number and other product information
User and service guide 19

2 2 4 9 5
3 8 8
1
11362
7
6
Figure 7 SL24 with a Fibre Channel drive
1. F i b r e C h a n nel ports 2. Fan
3. Power connector 4. Tape drive
5. Ethernet port 6. Serial port (Factory use only)
7. U S B p o r t 8. Magazine release hole
9. Pull-out tab containing the serial number and other product information
The device requires a 110/220 volt AC power connection.
Tape drive LED
EachtapedrivehasagreenLED,whichindicatesthatthetapedriveispoweredon(seeFigure 8).
11268
To HBA 1
Figure8TapedriveLED
1. Ta p e d r i v e L E D
Power supply back panel (SL48)
11220
2
1
3
Figure 9 Power supply LEDs
1. Blue AC power is connected.
2. Yellow Fan failure. The fan is running too slow or is defective.
3. Green The power supply is producing good power for the Library.
20 Features and overview
