CHAPTER 1
Upgrade Overview
This document provides procedures for preparing Sun Fire™ E4900 and Sun Fire
6800/4800 systems to accept the UltraSPARC®IV/IV+ CPU/Memory board
configurations.
The system needs to be powered off for the EMI gasket kit installation portion of this
upgrade. Arrange with the system administrator for a scheduled system shutdown.
This upgrade procedure involves installing:
■An EMI gasket kit (if one is not already installed)
An EMI gasket kit must be installed to ensure Class A EMI compliance
worldwide. This kit must be installed while the system is powered off, prior to
the insertion of UltraSPARC IV/IV+ CPU/Memory boards.
■Power supplies of higher current ratings
■Fan trays of higher cooling capacity (Sun Fire E4900 and Sun Fire 4800 systems
only)
Note – Install the UltraSPARC IV/IV+ CPU/Memory boards only after you have
installed the other upgrade hardware.
Portions of this upgrade procedure (power supplies and/or fan trays) can be
installed in a powered-on system. However, the EMI Gasket kit must have been
previously installed.

1-2 Sun Fire E4900 and Sun Fire 6800/4800 Systems Power Supply and Fan Tray Upgrade Guide • June 2006
1.1 Sun Fire 6800 System Upgrade Roadmap
Upgrade domains to a minimum supported version of firmware and Solaris
Operating System. Refer to the applicable Sun Fire High-End and Midrange Systems
CPU/Memory Board Upgrade Requirements document at
http://sun.com/documentation.
Select one of the following upgrade options:
■For a powered-off Sun Fire 6800 system, go to Chapter 2, page 2-1.
■For a powered-on Sun Fire 6800 system, go to Chapter 2, page 2-4.
1.2 Sun Fire E4900 and Sun Fire 4800 System
Upgrade Roadmap
Upgrade domains to a minimum supported version of firmware and Solaris
Operating System. Refer to the applicable Sun Fire High-End and Midrange Systems
CPU/Memory Board Upgrade Requirements document at
http://sun.com/documentation.
Select one of the following upgrade options:
■For a powered-off Sun Fire E4900/4800 system, go to Chapter 3, page 3-1.
■For a powered-on Sun Fire E4900/4800 system, go to Chapter 3, page 3-6.
1.3 Tools Required
For the procedures in this document, you will need these tools:
■Screwdriver, Phillips No. 2 with six-inch shank
■Needlenose pliers
■ESD mat
■ESD grounding wrist strap or foot strap

2-1
CHAPTER 2
Upgrading a Sun Fire 6800 System
This kit contains the following:
■Sun Fire 6800 Power Supplies (6)
■Sun Fire 6800 EMI Gasket kit
This chapter contains information on the following topics:
■“Upgrading in a Powered-Off System” on page 2-1
■“Upgrading in a Powered-On System” on page 2-4
Note – Sun Fire E6900 and upgraded Sun Fire 6800 systems upgrading to
UltraSPARC IV+ CPU/Memory boards do not require the Sun Fire 6800 UltraSPARC
IV/IV+ Upgrade Kit.
2.1 Upgrading in a Powered-Off System
Upgrading the system requires:
1. Installing the EMI Gasket kit.
2. Upgrading the power supplies.

2-2 Sun Fire E4900 and Sun Fire 6800/4800 Systems Power Supply and Fan Tray Upgrade Guide • June 2006
2.1.1 Configuration Requirements
■An EMI Gasket kit must be installed. For systems with gaskets already installed,
a second gasket should not be installed.
■For hardware, firmware, and OS minimum upgrade requirements, refer to the
applicable Sun Fire High-End and Midrange Systems CPU/Memory Board
Upgrade Requirements document at http://sun.com/documentation.
■Upgrade power supplies before upgrading the UltraSPARC IV/IV+
CPU/Memory boards.
2.1.2 Powering Off
Note – Instructions for the removal and replacement of the power supplies can also
be found in your Sun Fire 6800/4810/4800/3800 Systems Service Manual.
1. Shut down the domains and power off the system.
Refer to the system administration manual for your product for complete step-by-
step software commands.
2. Press the switches that are located on the AC input boxes to the Off position.
AC input box
switches

Chapter 2 Upgrading a Sun Fire 6800 System 2-3
2.1.3 Installing the EMI Gasket Kit
This kit contains the following:
■Four 7.75-inch/200mm gaskets, plus a spare
■One 5-inch/130mm gasket, plus a spare
■Six ESD CPU/Memory board bags
Note – For systems with gaskets already installed, a second gasket should not be
installed.
You will need a pair of needle-nosed pliers to guide the gaskets into the upper and
lower U-channels.
1. Remove all the CPU/Memory boards.
Refer to the Sun Fire 6800/4810/4800/3800 Systems Service Manual for the remove and
install instructions.
Note – Place each CPU/Memory board on one enclosed ESD CPU/Memory board
bag.
Caution – To avoid breakage, do not stack the CPU/Memory boards.
Lower U-channel
Upper U-channel

2-4 Sun Fire E4900 and Sun Fire 6800/4800 Systems Power Supply and Fan Tray Upgrade Guide • June 2006
2. Remove the FT1 fan tray to access the area for the 5-inch gasket, located on the
underside of the chassis guide rail SB5.
Refer to the Sun Fire 6800/4810/4800/3800 Systems Service Manual for the remove and
install instructions.
2.1.3.1 Installing the 5-inch/130mm Foam Gasket
Note – Do not apply the gasket to the chassis side wall.
A 5-inch foam gasket is required on the underside of the chassis guide rail SB5.
1. Peel the entire tape off of the gasket.
2. Rotate the gasket so that the adhesive faces to the right.
3. Apply the gasket to the side of the guide rail frame, immediately below guide rail
SB5 (see figure below).
When properly installed, there will be no gaps above or in front of the gasket.
Gasket must touch this edge

Chapter 2 Upgrading a Sun Fire 6800 System 2-5
2.1.3.2 Installing the Four 7.75-inch/200mm Foam Gaskets
Two 7.75-inch foam gaskets must be installed in each U-channel.
Note – Do not remove the gasket adhesive strip prior to inserting the gasket into the
channel.
1. Insert a 7.75-inch gasket (adhesive side down) into the center of the lower U-
channel.
The gasket will be snug in the channel.
2. Using needle-nose pliers, carefully pull the gasket through the channel until it
reaches the end.
Caution – Be careful that the gasket does not snag in the channel. Excess force
could tear the gasket.
3. Repeat this procedure for the other half of the U-channel.
Note – There should be no visible gap between gaskets.
4. Once the gaskets are in place, lift the ends of each gasket and peel off 1/2 inch of
the tape and then firmly adhere the gasket into the channel.

2-6 Sun Fire E4900 and Sun Fire 6800/4800 Systems Power Supply and Fan Tray Upgrade Guide • June 2006
5. Repeat steps 1-4 for the upper U-channel.
6. Reinstall the FT1 fan tray.
Refer to the Sun Fire 6800/4810/4800/3800 Systems Service Manual for the remove and
install instructions.
7. Reinstall all the CPU/Memory boards back into the system.
2.1.4 Replacing Power Supplies
1. Attach a wrist or foot strap and connect the ESD strap to the system.
2. Loosen the two captive screws.
3. Unlock the ejector by pulling the ejector lever down.
4. Remove the power supply and set it aside.
5. Remove the protective cover from the new power supply connector, if applicable.
Note – Check the connector for any bent pins or damage. Also check the connector
on the system chassis backplane.
6. Pull the ejector lever down on the new power supply.
7. Insert the power supply into the slot and firmly seat it.
8. Push the ejector lever up to lock it into place.
Captive screw
Ejector

Chapter 2 Upgrading a Sun Fire 6800 System 2-7
9. Tighten the two captive screws of the power supply.
10. Repeat Steps 2-9 for the remaining power supplies.
Caution – Do not mix old and new power supplies.
2.1.5 Powering On the System
1. Press the switches that are located on the AC input boxes to the On position.
2. Power on the system.
Refer to the system administration manual for your product for complete step-by-
step software commands.
2.2 Upgrading in a Powered-On System
Caution – A Sun Fire 6800 system EMI Gasket kit must be installed prior to
upgrading the UltraSPARC IV/IV+ CPU/Memory boards. The gasket kit cannot be
installed while the system is powered on. If the EMI gasket kit is not installed, see
section 2.1 Upgrading in a Powered-Off System.
2.2.1 Configuration Requirements
■An EMI gasket kit must be installed. For systems with gaskets already installed, a
second gasket should not be installed.
■For hardware, firmware, and OS minimum upgrade requirements, refer to the
applicable Sun Fire High-End and Midrange Systems CPU/Memory Board
Upgrade Requirements document at http://sun.com/documentation.
■Upgrade power supplies before upgrading the UltraSPARC IV/IV+
CPU/Memory boards.

2-8 Sun Fire E4900 and Sun Fire 6800/4800 Systems Power Supply and Fan Tray Upgrade Guide • June 2006
2.2.2 Replacing the Power Supplies
There are six power supplies in a Sun Fire 6800 System. Upgrade all power supplies
individually before installing the new UltraSPARC IV/IV+ CPU/Memory boards.
Note – Instructions for the removal and replacement of the power supplies can also
be found in your Sun Fire 6800/4810/4800/3800 Systems Service Manual.
1. Attach a wrist or foot strap and connect the ESD strap to the system.
2. Power off the appropriate power supply.
Refer to the platform administration manual for your system for complete
procedures to power off a power supply.
Note – When the green Activated LED on the power supply is off (not lit) and the
amber or blue OK to remove LED is on (lit), it is safe to continue. You DO NOT have
to power off the power grids, AC input box, or RTS module(s).
3. Loosen the two captive screws.
4. Unlock the ejector lever by pulling the ejector down.
5. Remove the power supply and set it aside.
6. Remove the protective cover from the new power supply connector, if applicable.
Captive screws
Ejector lever

Chapter 2 Upgrading a Sun Fire 6800 System 2-9
Note – Check the connector for any bent pins or damage. Also check the connector
on the system chassis backplane.
7. Pull the ejector down on the new power supply.
8. Insert the power supply into the slot and firmly seat it.
9. Push the ejector up to lock it into place.
10. Tighten the two captive screws of the power supply.
11. Wait for the power supply to automatically power-on within 10 seconds.
Note – Make sure the green Activated LED is on (lit). If the green Activated LED is
not on, check to see if the power supply is seated properly.
12. Repeat Steps 2-11 for each of the remaining power supplies.
13. Reboot the system controller after all the new power supplies are installed.
Refer to the system administration manual for your product for complete step-by-
step software commands.

2-10 Sun Fire E4900 and Sun Fire 6800/4800 Systems Power Supply and Fan Tray Upgrade Guide • June 2006

3-1
CHAPTER 3
Upgrading a Sun Fire E4900 or Sun
Fire 4800 System
This kit contains the following:
■Sun Fire E4900 Power supplies (3)
■Sun Fire E4900 Fan trays (3)
■Sun Fire 4800 EMI Gasket Kit
This chapter contains information on the following topics:
■Section 3.1, “Upgrading in a Powered-Off System” on page 3-1
■Section 3.2, “Upgrading in a Powered-On System” on page 3-9
3.1 Upgrading in a Powered-Off System
Upgrading the system requires:
1. Installing the EMI Gasket kit.
2. Upgrading the power supplies.
3. Upgrading the fan trays.

3-2 Sun Fire E4900 and Sun Fire 6800/4800 Systems Power Supply and Fan Tray Upgrade Guide • June 2006
3.1.1 Configuration Requirements
■An EMI gasket kit must be installed. For systems with gaskets already installed, a
second gasket should not be installed.
■Upgrade domains to a minimum supported version of firmware and Solaris
Operating System.
Refer to the applicable Sun Fire High-End and Midrange Systems CPU/Memory
Board Upgrade Requirements document at http://sun.com/documentation.
■Upgrade power supplies and fan trays before upgrading the UltraSPARC IV/IV+
CPU/Memory boards.
3.1.2 Powering Off
1. Shut down the domains and power off the system.
Refer to the system administration manual for your product for complete step-by-
step software commands.
2. Press the three switches that are located on the AC input box to the Off position.
AC input box

Chapter 3 Upgrading a Sun Fire E4900 or Sun Fire 4800 System 3-3
3.1.3 Installing the EMI Gasket Kit
The gasket kit contains:
■Two large (7.7 in./195 mm) EMI gaskets, plus a spare
■Two small (2.6 in./66mm) EMI gaskets, plus a spare
■Three ESD-safe CPU/Memory board bags
Note – For systems with gaskets already installed, a second gasket should not be
installed.
3.1.3.1 Installing the Large EMI Gaskets
Install the large (7.7 in./195 mm) gaskets in the upper and lower U-channels of the
cardcage.
1. Place a padded ESD-safe mat close to the system.
2. Wear an ESD strap and connect it to the system.
3. Remove all CPU/Memory boards and/or CPU/Memory filler panels.
Refer to the Sun Fire 6800/4810/4800/3800 Systems Service Manual or the Sun Fire
E6900/E4900 Systems Service Manual for the removal and installation instructions.
Note – Place each CPU/Memory board on one enclosed ESD-safe CPU/Memory
board bag.
Caution – To avoid breakage, do not stack the CPU/Memory boards.
4. Install one of the large gaskets in the lower U-channel.
a. Remove the protective tape from the gasket.
b. Insert the gasket (adhesive side down) into the lower U-channel.

3-4 Sun Fire E4900 and Sun Fire 6800/4800 Systems Power Supply and Fan Tray Upgrade Guide • June 2006
5. Install the other large gasket in the upper U-channel:
a. Remove the protective tape from the gasket.
b. Insert the gasket (adhesive side up) into the upper U-channel.
3.1.4 Replacing Power Supplies
The Sun Fire E4900 and Sun Fire 4800 systems have three power supplies located in
the front—PS0, PS1, and PS2.
Upper U-channel
Lower U-channel
EMI Gasket
Lower U-channel (detail)

Chapter 3 Upgrading a Sun Fire E4900 or Sun Fire 4800 System 3-5
1. Attach a wrist or foot strap and connect the ESD strap to the system.
2. Loosen the two captive screws, located at the top and bottom of the power supply.
3. Unlock the ejectors by pulling the ejector levers outward.
4. Remove the power supply and set it aside.
5. Remove the protective cover from the new power supply connector, if applicable.
Note – Check the connector for any bent pins or damage. Also check the connector
on the system chassis backplane.
6. Pull the ejector levers outward on the new power supply.
7. Insert the power supply into the slot and firmly seat it.
8. Push both the levers inward to lock the power supply into place.
9. Tighten the two captive screws.
10. Repeat Steps 2-9 for each of the remaining power supplies.
Caution – Do not mix old and new power supplies.
PS0
Ejectors
PS1
PS2

3-6 Sun Fire E4900 and Sun Fire 6800/4800 Systems Power Supply and Fan Tray Upgrade Guide • June 2006
3.1.5 Replacing Fan Trays
The FT0 and FT2 fan trays are located in the rear of the system. FT1 is located in the
front.
1. Attach a wrist or foot strap and connect the ESD strap to the system.
2. Remove the front bezel on the FT1 fan tray by snapping it off.
FT0 and FT2 do not have bezels.
3. Loosen the captive screws on the fan tray.
4. Lift the fan tray out and set it aside.
5. Remove the protective cover from the fan tray connector, if applicable.
Note – Check the connector for any bent pins or damage. Also check the connector
on the system chassis backplane.
6. Slide the new fan tray into the slot.
7. Tighten the captive screws.
8. Replace the FT1 front bezel.
FT0 FT2
FT1
Sun Fire E4900/4800 System–rear Sun Fire E4900/4800 System–front
