sunair RCU-9310B User manual

TM-8129000504
REMOTE CONTROL UNIT
for
RT-90008 HF/SSB
TRANSCEIVER
RCU-93108
OPERATION AND MAINTENANCE
MANUAL
fj® SUNAIR 3005 Southwest Third Avenue, Fort Lauderdale, Florida 33315-3312

WARRANTY POLICY
GROUND AND MARINE PRODUCTS
Sunair Electronics warrants each equipment manufactured by it to be free from defects in
material or workmanship, under normal use for the lesser of one (1) year from the date of
installation or 15 months from date of shipment
by Sunair.
Sunair will repair or replace, at its option, any defective equipment or component of the
equipment returned to
it at its factory, transportation prepaid, within such warranty period.
No reimbursement will be made for non-factory repair charges.
(
This warranty is void if equipment is modified or repaired without authorization, subject to
misuse, abuse, accident, water damage or other neglect, or has its serial number defaced
or removed. (
THIS WARRANTY IS ESPECIALLY IN LIEU OF ANY AND ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTY OF MERCHANT-
ABILITY OR FITNESS FOR A PARTICULAR PURPOSE. The obligation and responsibility
of Sunair shall
be limited to that expressly provided herein and Sunair shall not be liable for
consequential or other damage or expense whatsoever therefore or by any reason thereof.
Sunair reserves the right
to make changes in design or additions to or improvements in its
equipment without obligation
to install such additions or improvements in equipment
theretofore manufactured.
,,® SUNAIR ELECTRONICS, INC.
(

0 @
Ql
P:AI.A.T
~
Mtc/AUX
~I
~
K!Y I I
e
Oo
0
e
I QJ [!] 0 f;i\jj El ~
000 [';ij@J~
000 rrm[;JEJ
I I ~~~ II:U:-11 ~.l:'
I I 0
~~o OFFo 0
D D
RCU-9310
REMOTE CONTROL
UNIT
0
"
"
~
I
RCU-8310 l e
e
OPERATION AND MAINTENANCE
MANUAL
FOURTHEDITIONFEBRUARY28,1997
Page change
1: 03/24/99
Page change 2: 08/26/99

PRODUCT SERVICE:
In case of difficulty please contact the Sunair
ProductSeNiceDepartment, betweenthehours
of 8:00 AM and 5:00
PM or write to:
Product SeNice Dept.
Sunair Electronics, Inc.
3101 SW Third Avenue
Ft. Lauderdale, FL 33315-3389
U.S.A.
Telephone:
Fax:
E-Mail:
[phone]
[phone]
[e-mail]
TRAINING:
Sunair offers training programs of varying
lengths covering operation, service, and
maintenance of all Sunair manufactured
equipment. For details please contact the
Product Support Department.
(
(

f
I
r
, I
TABLE of CONTENTS
Section Description
GENERAL INFORMATION
1.1 SCOPE OF MANUAL
1.2 PURPOSE OF EQUIPMENT
1.3 GENERAL DESCRIPTION
1.4 TECHNICAL SPECIFICATIONS
1.5 ENVIRONMENTAL SPECIFICATIONS
1.6 EQUIPMENT SUPPLIED
1.7 OPTIONS AVAILABLE
II INSTALLATION
2.1 GENERAL
2.2 UNPACKING
AND INSPECTION
2.3 RETURN OF EQUIPMENT TO FACTORY
2.4 GENERAL INSTALLATION AND MOUNTING
INFORMATION
2.4.1 GENERAL INSTALLATION
2.4.2 BASE STATION INSTALLATION
2.4.3 RACK INSTALLATIONS
Ill OPERATION
3.1 GENERAL
3.2 PRIMARY OPERATIONS
ISUNAIR RCU-9310 I
Page
1-1
1-1
1-1
1-2
1-2
1-3
1-3
2-1
2-1
2-1
2-2
2-2
2-9
2-9
3-1
3-3
3.2.1 REMOTE TRANSCEIVER SET UP FOR MODE, AGC
AND TRANSMIT POWER 3-3
3.2.2 ESTABLISHING
AN OPERATING FREQUENCY 3-5
3.2.3 TRANSMIT TUNING 3-6
3.2.4 ANTENNA COUPLER TUNING 3-6
3.2.5 MANUAL TUNING 3-6
3.2.6 PANEL LIGHTING 3-7
3.2.7 OPERATING WITH PRESET CHANNELS 3-7
3.2.8 MANUAL CHANNEL SCANNING 3-8

ISUNAIR RCU-9310 I
TABLE of CONTENTS (Cont. .. ) (
Section Description
Page
\
3.2.9 LOADING PRESET CHANNEL FREQUENCIES 3-10
3.2.10 BFO OPERATION 3-12
3.3 EQUIPMENT SET UP 3-13
3.3.1 BITE (Built in Test Equipment) 3-13
3.3.1.1 REMOTE CONTROL UNIT SELF-TEST (LOCAL BITE) 3-14
3.3.1.2 TRANSCEIVER TEST (REMOTE BITE)
3-15
3.3.2 METER FUNCTIONS 3-17
3.3.3 SPEAKER ON/OFF FUNCTION 3-19
3.3.4 'MHz' or 'kHz' FREQUENCY DISPLAY 3-20
3.3.5 TIME DISPLAY 3-20
3.3.6 'I/O' PORT SET UP 3-22
3.3.7 ADDRESS AND SOFTWARE REVISION LEVEL 3-25
3.3.8
'CW KEY AND FILTER OPTIONS 3-26
3.3.9 LINE AUDIO SELECTION 3-27
3.4 ADVANCED OPERATIONS 3-28 (
3.4.1 RECEIVER SCANNING 3-28
3.4.2 AUTOMATIC LINK ESTABLISHMENT (ALE)
PROGRAMMING
3-31
3.4.2.1 GENERAL
3-31
3.4.2.2 ESTABLISHING ALE-I D's
3-32
3.4.3 AUTOMATIC LINK ESTABLISHMENT (ALE)
OPERATION 3-36
3.4.4 SOUNDING
3-41
3.4.5
NET CALL 3-44
3.4.5.1 PLACING A NET-CALL
3-44
3.4.6 ALL CALL 3-46
3.4.7 BREAK LINK COMMAND 3-47
3.4.8 OPTIONS 3-48
3.4.8.1 L YNCOMPEX
3-48
3.4.8.2 DATA FILTER
3-49 (
ii

ISUNAIR RCU-9310 I
TABLE of CONTENTS (Cont...)
Section Description Page
3.4.8.3 RADIO SECURITY 3-49
3.4.8.4 PRE-SELECTOR 3-50
IV
THEORY OF OPERATION
4.1
REMOTE CONTROL UNIT-TRANSCEIVER INTERFACE
AND INTERACTION
4-1
4.2 REMOTE CONTROL UNIT
4-1
4.2.1 FRONT PANEL ASSEMBLY 3A1
4-3
4.2.2 CPU ASSEMBLY 3A2A1 4-3
4.2.2.1 GENERAL 4-3
4.2.2.2 MICROPROCESSOR U2 4-3
4.2.2.3 ERASABLE PROGRAMMABLE READ-ONLY
MEMORY (EPROM) U13 and U14 4-3
4.2.2.4 ELECTRICALLY ERASABLE PROGRAMMABLE READ
ONLY MEMORY (EEPROM) US
4-4
4.2.2.5 STATIC RANDOM ACCESS MEMORY (SRAM) U3 4-4
4.2.2.6 OPTIONAL SMART WATCH U14(A) 4-4
4.2.3 OPTOCOUPLER ASSEMBLY 3A2A 1A 1 4-4
4.2.4 AUDIO/REMOTE AUDIO ASSEMBLIES
3A2A2/3A2A4 4-4
4.2.5 1/0 ASSEMBLY 3A2A3 4-5
4.2.6 POWER SUPPLY ASSEMBLIES 3A3, 3A3A 1,
and 3A3A2 4-6
v
FAULT ISOLATION/MAINTENANCE AND REPAIR
5.1
GENERAL
5-1
5.2 DISASSEMBLY 5-1
5.2.1 TOP OR BOTTOM COVER REMOVAL
5-1
5.3 TEST
SETUP
5-1
5.3.1 PRELIMINARY
5-1
5.4 BITE 5-1
5.4.1 PRELIMINARY 5-1
5.4.2 COMMON MODULES 5-4
iii

ISUNAIR RCU-9310 I
TABLE of CONTENTS (Cont...) (
Section Description Page
5.4.2.1 FRONT PANEL FAULT 5-4
5.4.2.2 CPU FAULT 5-4
5.4.2.3 110 FAULT 5-5
5.4.2.4 AUDIO FAULT 5-5
5.4.2.5 POWER SUPPLY FAULT 5-6
5.5 TROUBLESHOOTING WITH SELF-SURVEILLANCE BITE 5-6
5.5.1 AC POWER SUPPLY 5-6
5.5.2 INSTALLATION OF NEW BACKLIGHTING DEVICES
FOR FRONT PANEL LCD'S 5-12
5.6 TEST EQUIPMENT REQUIRED OR EQUIVALENT 5-16
5.7 TEST AND ALIGNMENT 5-16
5.7.1 TRANSMIT REMOTE AUDIO 5-16
5.7.2 RECEIVE REMOTE AUDIO 5-20
5.7.3 SOFTWARE SWITCH SETTING CHECKS 5-23
5.8 SCHEMATICS AND PARTS LISTS 5-25 (
(
iv

ISUNAIR RCU-9310 I
TABLE of ABBREVIATIONS
ADDR Address
AGC Automatic Gain Control
ALC Automatic Level Control
AM Amplitude Modulation
AME Amplitude Modulation Equivalent
AMP/AMPL Amplifier
ARQ Automatic Request
AUD Audio
AUTO Automatic
AUX Auxiliary
BAUD A variable unij of data transmission speed (bits
per second)
BELL U.S. Telephone standards
BFO Beat Frequency Oscillator
BITE Built In Test Equipment
BAD Board
CH /CHAN /CHLJCHN Channel
CLR Clear
CMOS Complementary Metal Oxide Semiconductor
CPLR Coupler
CPU Computer
CW Carrier Wave
dB Decibel
dBm Decibels referred to 1 milliwatt across 600 ohms
DSBSC Double Sideband Suppressed Carrier
DSP Display
DUART Dual Asynchronous Receive/Transmit
EEPROM Electrically Erasable and Programmable Read
Only Memory
EPROM Electrically Programmable Read Only Memory
EMI Electromagnetic Radiation Interference
ENTR Enter
FAX Facsimile
FEC Forward Error Correction
FREQ Frequency
FSK Frequency Shift Keying
FWD Forward
GAP Group
HF High Frequency
Hz Hertz
IC Integrated Circuit
IF Intermediate Frequency
1/0 lnpui/Output
IONCAP Ionospheric Communications Analysis
and Prediction
kHz Kilohertz
kW Kilowatt
ISB Independent Sideband
LCD Liquid Crystal Display
LCL Local
LED Light Emitting Diode
LK Link
LO Local Oscillator
LP/LPX Lincompex
LRU Lowest Repairable Unit
LSB Lower Sideband
LT Light
LVL Level
MAN Manual
M CH Manual Channel
MED Medium
MHz Megahertz
MIC Microphone
MIL-STD Milijary Standard
MNL Manual
ms Millisecond
MTTR Mean Time To Repair
MTR Meter
NAR Narrow
0.0. Olive Drab
PA Power Amplifier
PC Printed Circuit
PEP Peak Envelope Power
PLL Phase-Locked Loop
P/N Part Number
PNL Panel
POSTSL Post-Selector
PRESEL Pre-Selector
PTT Push-To-Talk
PWR Power
RCV/RX Receive
REFL Reflected
REV Revision
RF Radio Frequency
RFI Radio Frequency Interference
RFL Reflected
RMT Remote
RS232 Computer control, hardwired upto50feetmaximum
RS422 Computer control, hardwired up to 4000 feet
maximum
RS485 Computer control, hardwired for multiple users
RlTY Radio Teletype
SEL Select
SLO Slow
S MTR Signal Strength Meter
SPKR Speaker
SPLX Simplex
SRAM Static Random Access Memory
SSB Single Sideband
TCXO Temperature Controlled Crystal Oscillator
TGC Transmit Gain Control
THO Total Harmonic Distortion
TTL Transistor Transistor Logic
TX/XMT Transmit
USB Upper Sideband
UTC Universal Time
VCO Voltage Controlled Oscillator
VHF Very High Frequency
VRMS Volts Root Mean Square
VSWR Voltage standing Wave Ratio
W Watt
WPM Words Per Minute
• Asterisk indicates function selected
v

ISUNAIR RCU-9310 I
LISTING of FIGURES (
Section Description Page
II INSTALLATION
Figure 2.4.1.1 RCU-9310 Outline Dimensions and Connector
Locations. 2-4
Figure 2.4.1.2 Interconnection
of RCU-931 0 Remote Control
Unit and RT-9000 Transceiver. 2-5
Figure 2.4.1.3 FSK, RS-232, RS-422,
or RS-485
Wiring Diagrams. 2-6
Figure 2.4.1.4 RCU-9310 Remote Audio to RT-9000 Audio
Wiring Diagram. 2-7
Figure 2.4.1.5 RCU-9310 Audio to External Data Modems Wiring
Diagram. 2-8
Figure 2.4.3 Installation
of RCU-9310 in Equipment Rack. 2-9
Ill OPERATION (
Figure 3.1.1 Front Panel Controls for the RCU-9310. 3-1
Figure 3.1.2 Operational Display Information Location. 3-2
Figure
3.2.1
RCU-9310 Remote Control Display Screens. 3-4
Figure 3.2.2 RCU-9310 Operating Controls. 3-5
Figure 3.2.5 RCU-9310 Operating Controls. 3-7
Figure 3.2.7 RCU-9310 Operating Controls. 3-8
Figure 3.2.8 RCU-931 0 Operational Controls. 3-9
Figure 3.2.9.1 RCU-9310 Channel Loading Controls. 3-10
Figure 3.2.9.2 RCU-931 0 'Feature Display'.
3-11
Figure 3.2.10 RCU-9310 Displays, with BFO Enabled. 3-12
Figure 3.3.1.1 RCU-9310 Feature Menu, BITE Selection. 3-13
Figure 3.3.1.2 RCU-9310 BITE Submenu. 3-14
Figure 3.3.2.1 RCU-9310 Operational Displays. 3-17
Figure 3.3.2.2 RCU-9310 Feature Menu Select Display. 3-17
Figure 3.3.2.3 RCU-9310 Feature Menu Select Display. 3-18 (
Figure 3.3.2.4 RCU-9310 Feature Menu Select Display. 3-18
Figure 3.3.3 RCU-9310 Feature Menu Select Display. 3-19
vi

Section
ISUNAIR RCU-9310 I
LISTING of FIGURES (Cont. .. )
Description Page
Figure 3.3.4 RCU-931 0 Operating Controls. 3-20
Figure 3.3.5.1 Feature Menu Display. 3-20
Figure 3.3.5.2 Time Display and Time Set Display. 3-21
Figure 3.3.5.3 Time Display. 3-21
Figure 3.3.5.4 'Set-Time' Display. 3-22
Figure 3.3.6.1 RCU-931 0 110 Port Connector. 3-22
Figure 3.3.6.2 Feature Menu Display
of Port 'A' Selection Menu. 3-23
Figure 3.3.6.4 Port 'A' Conditioning Menu. 3-24
Figure 3.3.6.5 Baud Rate Display. 3-24
Figure 3.3.6.6 Baud Rate Selection Menu 1. 3-24
Figure 3.3.6.7 Baud Rate Selection Menu
2. 3-25
Figure 3.3.7.1 Address and Revision Level Display. 3-25
Figure 3.3.7.2 Feature Menu for Selection ofAddress. 3-26
Figure 3.3.8 Feature Menu Display for Selection of 'CW' Options. 3-27
Figure 3.3.9.1 RCU-9310 Feature Menu Select Display. 3-28
Figure 3.3.9.2 Line Audio Selection Menu Display. 3-28
Figure 3.4.1.1 Operational Display for Channelized Mode. 3-29
Figure 3.4.1.2 Feature Menu Display for 'SCAN' Select
Key. 3-29
Figure 3.4.1.3 Feature Menu Display for 'SCAN' Function. 3-30
Figure 3.4.1.4 Feature Menu Display for 'SCAN LOAD' Select Key. 3-30
Figure 3.4.2.2.1 RCU-9310 Feature Menu Display. 3-32
Figure 3.4.2.2.2 Feature Menu Display for 'ALE-ID' Select
Key. 3-33
Figure 3.4.2.2.3 RCU-9310 Display for 'SLOT PS' Programming.
Figure 3.4.2.2.4 RCU-9310 Display for 'SELF ID' Programming.
Figure 3.4.2.2.5 Feature Display for 'CALL ID' Select Key.
Figure 3.4.3.1 Operational Display for 'ALE' Function.
Figure 3.4.3.2 ALE Calling Menu.
Figure 3.4.3.3 Feature Display for 'Select Group'.
Figure 3.4.3.4 Operational Display for 'CALL ID' Selection.
Figure 3.4.3.5 Operational Display of the Station Being Called.
3-33
3-34
3-35
3-37
3-37
3-38
3-39
3-39
vii

ISUNAIR RCU-9310 I
Section
IV
v
viii
LISTING of FIGURES (Cont. .. )
Description Page
Figure 3.4.3.6 Operational Display of Link with Station Being Called. 3-40
Figure 3.4.3.7 Operational Display on Called Station after a Link. 3-41
Figure 3.4.4.1 ALE Calling Menu. 3-41
Figure 3.4.4.2 Sounding Menu.
Figure 3.4.4.3 Operational Display at Sounding Station.
Figure 3.4.4.4 Operational Display
on Network Stations Receiving
Sound.
Figure 3.4.4.5 Sounding Timer Menu.
3-42
3-42
3-43
3-43
Figure
3.4.7.1 Break Link Keys. 3-48
Figure
3.4.8.1 'SECURE' Feature Menu. 3-48
Figure 3.4.8.
1.1 Lycompex Feature Menu Display. 3-48
Figure 3.4.8.1.2 Lycompex Control Feature
Menu Display. 3-49
Figure 3.4.8.5.1 Feature
Menu Display for Pre-selector Selection. 3-50
THEORY OF OPERATION
Figure 4.1 RCU-9310 Remote Control Unit Block Diagram.
FAULT ISOLATION/MAINTENANCE AND REPAIR
4-2
Figure
5.2. 1.1 Top/Bottom and Card Cage Covers Removal. 5-2
Figure 5.4.1.1 RCU-9310 Feature Menu, BITE Selection. 5-3
Figure 5.4. 1.2 RCU-931 0 BITE Submenu. 5-3
Figure 5.4.1 .3 Top View RCU-931 0 LRU 'Fault Indicators'. 5-5
Figure
5.4.2.1 Major Assembly Locations. 5-8
Figure 5.4.2.2 Removal of Front and Rear Panel and Major
Assemblies Locations. 5-9
Figure 5.4.2.3 Removal/Replacement
of CPU 3A2A1 and
1/0 3A2A3. 5-10
Figure 5.4.2.4 Removal/Replacement of 1/0 3A2A3 or
FSK 3A2A3A
1. 5-11
Figure 5.5.2.1 Removal and Installation of Front Panel PC
Assembly. 5-13
Figure 5.5.2.2 Removal
and Installation of LCD Assembly. 5-14
(
(

ISUNAIR RCU-9310 I
LISTING of FIGURES (Cont. .. )
Section Description Page
Figure 5.5.2.3 Installation of Backlighting Devices. 5-15
Figure 5.7.1.1 RCU-931 0 Stand Alone Audio Test Set Up. 5-18
Figure
5. 7.1.2 Top View RCU-931 0 Alignment Adjustment
Locations. 5-18
Figure
5. 7.1.3 Transmit Path Audio A. 5-19
Figure 5. 7.2.1 RCU-931 0 Stand Alone Audio Test Set Up. 5-21
Figure 5.7.2.2 Receive Path Audio A. 5-22
Figure
5.8 RCU-9310 Assemblies and Subassemblies. 5-25
Figure 5.8.1 Final Tested RCU-931 0, Chassis Assembly 3A3,
and Connector Kit. 5-27
Figure 5.8.2
PC Assembly, Front Panel 3A1A 1, page 1 of 6. 5-28
Figure 5.8.3 PC Assembly, Mother Board 3A2A5, page 1 of 4. 5-34
Figure 5.8.4
PC Assembly, CPU 3A2A 1, page 1 of 8. 5-38
Figure 5.8.5
PC Assembly, OPTOCOUPLER 3A2A1A1,
page 1 of 3. 5-46
Figure 5.8.6 PC Assembly, Audio 3A2A2, page 1 of 9. 5-49
Figure
5.8. 7 PC Assembly, Audio Remote 3A2A4, page 1 of 2. 5-58
Figure 5.8.8
PC Assembly, 1/0 Board 3A2A3, page 1 of 4. 5-60
Figure 5.8.9 PC Assembly, FSK Modem 3A2A3A1, page 1 of 2. 5-64
Figure 5.8.1 0 AC/DC Power Supply Chassis and Interconnect
Diagram, page 1 of 1. 5-67
Figure
5.8.11 PC Assembly, 28V Regulator, 5 Amp 3A3A 1,
page 1 of 2. 5-68
Figure 5.8.12 PC Assembly, 5/12V Regulators 3A3A2,
page 1 of 2.
Figure 5.8.13 PC Assembly, Audio Connectors 3A3A3,
page 1 of
2.
5-70
5-72
ix

(
ITHIS PAGE INTENTIONALLY LEFr BLANK.I (
(

ISUNAIR RCU-9310 I
SECTION I
GENERAL INFORMATION
1.1 SCOPE OF MANUAL
This manual contains informationnecessaryto install, operate, and maintainthe RCU-931 0 Remote Control Unit.
Installation information is in Section II. Operating Instructionsare in Section Ill. Theory of Operation is in Section
IV. Maintenance and Repair Procedures are in Section
V. Information in this manual applies to all equipment
configurations, unless otherwise stated in the text or illustrations.
1.2 PURPOSE OF EQUIPMENT
The RCU-931o Remote Control Unit is designed to provide complete operational control of a remotely-located
RT-9000 Transceiver.
The RCU-9310 allows
an operator at a remote site to access and perform all transceiver primary functions:
selecting the transmission mode and power level; establishing operating frequencies; automatically tuning the
transmitter and associated antenna coupler; manual tuning; and loading, scanning, and operating with preset
frequency channels.
The RCU-9310 also enables the remote operatorto perform several non-operational, periodic, functions related
to equipment setup and maintenance. Diagnostictests--tothe lowest repairable unit (LRU) -- can be selectively
executed on both the transceiver and the remote control unit itself. Other functions include: selection of CW
keying speed and filtering options; connection ofexternal devicestothetransceiver'saudio inputand outputlines;
local I/O portconditioning; transceivermemorydump(i.e., clearing all preprogrammed channels); andtransceiver
metering at the remote control panel.
In addition, the RCU-931 o allows the remote operator to access and use the transceiver's advanced automated
functions: receiver scanning
of preprogrammed channels; programming and execution of Automatic Link
Establishment (ALE) operations; "sounding" (broadcasting to selected stations in a predefined network); and
"network call" (broadcasting to all stations in a network).
1.3 GENERAL DESCRIPTION
The RCU-931o is intended for useon table tops or in base station 19-inch rack installations. However, its rugged
package makes the RCU-9310 adaptable to various environments. Internally, the RCU-9310 is designed with
the service technician in mind. Built-in test equipment (BITE), with descriptive front-panel readouts, and .
modularized plug-in assemblies rnake the MTTR (Mean Time To Repair) less than fifteen (15) minutes. LEDs
located on the assemblies allow the technician to pinpoint faulty modules immediately. The RCU-931 0 is
lightweight for its capability, weighing only 20 pounds. Available in Olive Drab (OD) or Grey, the RCU-931 0 is
compatiblewith most radio station colorschemes. (If a particular colorotherthan ODor Greyisrequired, contact
the Sunair Marketing Department for information concerning changes
to the standard colors.)
The RCU-9310 has a simple, easily understood, front panel that duplicates the functions of the RT-9000
Transceiver. Firsttimeuserscanoperatetheequipmentwithoutextensivetraining. Thewide screen liquid crystal
display (LCD)
is continuously updated by the microprocessor with operational status such as Frequency,
Channel, Mode, BFO, AGC, Power, Local or Remote Control. The LCD also contains a bar graph meter which
selectivelyindicatessignal strength,forward RF power, reverse RFpowerand Remotetransmitand receiveaudio
1-1

ISUNAIR RCU-9310 I
The built-in-test routines include power amplifier and antenna coupler status in plain English messages which
appearin the display. Softkeys and a softkey menu LCD display selected options such as Time,
CW Filter, etc.
The softkeys also provide access to remote control configuration, meter selection, speaker control and other
operating features not found on the front panel keyboard.
1.4 TECHNICAL SPECIFICATIONS
REMOTEINTERFACE: RS232/422/485FSKTone.
I NOTE: IMustbehardwired between RCU-9310and RT-9000(A)formodeselected.
TRANSCEIVERINTERFACE: Transmitand receive audio, 0dBm adjustableinto 600 ohms.
BITE: Faultisolatedto module level(LRU), descriptivereadoutonfront panel and individualmoduleindication.
INPUT POWER: +26VDC ±15%; 120/240VAC±15%;
AC/DCAuto Changeover.
AUDIO OUTPUT: 5 Watts into internal speaker< 5% THO; Two selectable lines, at ·20 dBm to +1 0 dBm into
600 ohms; Headset, lowimpedance.
SQUELCH: Syllabic.
AUDIO INPUT: Microphone, aux. connector, and two selectable 600 ohm lines at -20 dBm to +10 dBm.
SIZE: (CM): 15.2H X 45.3W X 26.04L.
(INCHES) 5.96H X 17.83W X 10.25L
WEIGHT: (KG): 9.1
(LBS): 20
CONSTRUCTION: Modular plug-in assemblies.
1.5 ENVIRONMENTAL SPECIFICATIONS
TEMPERATURE: -30'C to +50'C.
HUMIDITY: 100% at 50'C.
RAIN: MIL-STD-8100, Method 506.2.
SHOCK: MIL-STD-8100, Method 516.3.
VIBRATION: MIL-STD-8100, Method 514.3.
Page change 2: 8/26/99
1-2
(
(
(

ISUNAIR RCU-9310 I
1.6 EQUIPMENT SUPPLIED
The following is a Jist ofequipment, with appropriate Sunair part numbers, supplied with the RCU-931 0 Remote
Control Unit.
SUPPLIED EQUIPMENT:
RCU-931 0 Remote Control Unit
Hand Held Microphone Assembly
Operation and Installation Manual
Mating Connector Kit
Power
Cord Assembly, 115VAC
or Power
Cord Assembly, 230VAC
1.7 OPTIONS AVAILABLE
SUNAIR MODEL /PART NUMBERS:
8078001291 O.D.
8078001258 GRAY
8076000602
8078000502
8078000499
8076002095
8076002192
The following
is a list ofoptional equipment or accessories available foruse with the RCU-931 0 Remote Control
Unit.
OPTIONAL EQUIPMENT/ACCESSORIES: SUNAIR MODEL/PART NUMBERS:
Headset 0840200005
Headset (Lightweight) 1010690027
CW
Key with Phone Plug 5024000994
Handset Assembly 8076000793
Desktop Microphone 8076000891
Shroud Kit for Rackmounting 1004770014 O.D.
1004770022 GRAY
Power
Cord Assembly, DC 8101002294
Real-Time Clock (Smart Watch) 1011190010
Phone Line Interface 8078500092
12/28 VDC Converter PS-9015 8078600097
Cable Assembly Audio
and Control (made to length) 8078004591
Field Module Kit 8078905092
Audio
to External Data Modems Cable Assembly 8076004594
1-3

ISUNAIR RCU-9310 I
(
lrHIS PAGE INTENTIONALLY LEFT BLANK.! (
(
1-4
I

I SUNAIR RCU-9310 I
SECTION II
INSTALLATION
2.1 GENERAL
Section II contains all necessary instructions for unpacking, inspection, and, if required, reshipment of the
equipment
or parts. Information regarding location and mounting considerations, power requirements, ground
system hookups, and cabling considerations is also provided.
2.2 UNPACKING AND INSPECTION
As soon as you have received your unit(s), unpack and inspect all components and accessories. Check the
packing list to be sure you have received all items ordered, and that all items necessary for operation have been
ordered. INOTE: I Be sure to retain the carton(s) and associated packing materials
should it
be necessary to reship the equipment.
Do not accept a shipment when there are visible signs
of damage to the cartons until a complete inspection is
made. Ifthere is a shortage ofitemsorany evidence
of damage, insist on a notation to that effect on the shipping
papersbeforesigning the receiptfrom the carrier. Ifconcealed damage
is discovered afterthe shipment has been
accepted, notify the carrier immediately in writing and await his inspection before making any disposition ofthe
shipment. A full reportofthedamageshould also be forwarded to Sunair'sProductServices Department. Please
be sure to include the following information for prompt service:
a) ORDER NUMBER.
b) MODEL AND SERIAL NUMBER.
c) NAME OF TRANSPORTATION AGENCY.
d) APPLICABLE DATES.
Upon receipt of this information, Sunair will make arrangements for repair or replacement.
2.3 RETURN OF EQUIPMENT TO FACTORY
The shipping carton for the RCU-931 0 has been designed to protect the equipment during shipment. The
container and its associated packing materials should
be used to reship the equipment.
When necessary to return equipment to Sunair for warranty or non-warranty repair,
an authorization number is
required. This numbercan be obtained from our Product Services Department: TELEPHONE: [phone],
FACSIMILE: [phone].
If the original shipping carton is not available, be sure to carefully pack each unit separately, using suitable
cushioning material where necessary. Very special attention should
be given to providing enough packing
material around connectors and other protrusionsfrom the unit. Rigid cardboard should be placed atthe corners
of the equipment to protect against denting. DO NOT USE DUNNAGE (e.g., STYROFOAM PEANUTS) FOR
PACKING PROTECTION; it may allow the unit
to shift while being shipped, and, therefore, become damaged.
2-1

ISUNAIR RCU-9310 I
When returning subassemblies orcomponentsfor repair or replacement, be sure to packeach separately, using
suitable cushioning material. (
Shipment to be made PREPAID consigned to:
Sunair Electronics, Inc.
Product Services Department
3101 SW Third Avenue
Fort Lauderdale, Florida 33315-3389
U.S.A
Plainly mark with indelible ink all mailing documents as follows:
US Goods Returned For Repair
Value For Customs- $(Amt.)
Mark ALL SIDES of the package:
INOTE: I FRAGILE -ELECTRONIC EQUIPMENT!
Before shipping, carefullyinspectthe package to be sure it is marked
properly and is securely wrapped.
2.4 GENERAL INSTALLATION AND MOUNTING INFORMATION
Satisfactory operation of this equipment will depend upon the care and thoroughness taken during installation.
12.4.1 GENERAL INSTALLATION I
2-2
For installation and operation with KW equipment, modems, and other peripherals, use this manual in
conjunction with their respective operating manuals
for complete installation information.
Before starting installation, carefully plan equipment locations to ensure that the operating environment is
suitable and that adequate access for maintenance is provided.
If operated on DC power, check for correct polarity before applying power.
The RCU-9310 RemoteControl Unitand RT-9000Transceiverare interconnected asshown in Figure2.4.1.2.
INOTE: I Figure2.4.1.2 illustratesthedirectcabling methodforinterconnecting
the remote control unit and transceiver. While other interface
methods may
be employed, the relationship between remote control
unit and transceiver signals must be maintained.
(
(
