Sunfull 1002-ARM Guide

Instruction for installation
Suitable gateway type（1 network port 2 serial port）
Model:BAC1002-ARM MOD1002-ARM HUB1002-ARM SNMP1002-ARM
1.0 software configuration step (refer to the relevant configuration software operation manual)
please confirm the following:
- the configuration project is correct;
- upload engineering files to the gateway (note not download works)
- simulation test to collect data;
2.0 gateway graphic
Wall type installation gateway size:129mm×109mm×27mm(L×W×H) weight：200g
Guide rail installation gateway size: 129mm×86mm×34mm(L×W×H) weight：200g
Power: AC/DC 9~24V (rated power 5 W);（V+ , V-）
Gateway:
3.0 wiring description:
Ethernet network: if the network port protocol is used, the default IP address is 192.168.1.88.
Reset: when the user forgets the gateway IP address, the user can press the Reset button until the
gateway "tick" and the network port temporarily restore the default IP address, and then log in
192.168.1.88 to check the original IP address of the gateway.(the operation takes effect immediately,
and fails after power failure)
RS485 interface: 2 total isolation RS485 interface A (+) B negative (-)
RS232 interface: 2 full isolation RS232 interface (note: reusing relationship with RS485)
Rx (2) TX (3) GND (5)
DB9-M Gateway RX (2) ~~ device TX (3)
Gateway TX (3) ~~ device RX (2)
Gateway GND (5) ~~ equipment GND (5)
DB9-F Gateway RX (2) ~~ device RX (2)
Gateway TX (3) ~~ device TX (3)
Gateway GND (5) ~~ equipment GND (5)
4.0 login gateway Web server
The network line receives the Ethernet, the default IP address: 192.168.1.88 login user name:
admin password: admin123456
Note: download gateway configuration software after entering the web server, please refer to the
PDF document under the Help folder for specific operation.
5.0 common problems
Question 1: how to change the IP address?
Answer 1: gateway factory default IP address 192.168.1.88, subnet mask 255.255.255.0, default

gateway 192.168.1.1.
Users to use for the first time with a computer and gateway with cable local docking, then change the
IP address to the computer and the gateway within the same network segment in able to ping the
gateway IP address, open a browser and enter the gateway IP address 192.168.1.88, can login gateway
Web server, as shown above in the "front-end ports set" column set IP address.
Q2: what if the project files are saved in the computer?
Answer 2: login gateway, WEB page "download file" to have the last project file backup, download
can.
Q3: what is the difference between different models of the gateway hardware?
Answer 3: the main models are as follows:
Model
Hardware Parameter
Interfaces
Supported
Points
Supported Port
1002-LITE
CPU：240MHz
Memory：32M
1 ethernet
2 serial ports
256
2 RS485 & 2
RS232
1002-ARM
CPU：240MHz
Memory：32M
1 ethernet
2 serial ports
256
2 RS485 & 2
RS232
2004-LITE
CPU：400MHz
Memory：64M
2 ethernets
4 serial ports
1024
4 RS485
2004-ARM
CPU：400MHz
Memory：64M
2 ethernets
4 serial ports
1024
4 RS485
2004-A9
CPU：1.4GMHz
Memory：512M
2 ethernets
4 serial ports
2048
4 RS485
1022-1U
CPU：400MHz
Memory：DDR2
1 ethernets
4 serial ports
1024
4 RS485
Sunfull Gateway model
BACnet Gateway:BAC1002-LITE (economical),BAC1002-ARM,BAC2004-LITE(economical),
BAC2004-ARM, BAC2004-A9
Modbus Gateway: MOD1002-LITE (economical), MOD1002-ARM, MOD2004-LITE (economical),
MOD2004- ARM, MOD2004-A9
Modbus Hub Gateway: HUB1002- ARM, HUB2004-ARM
SMS Alarm Gateway: HMI2004-A9-GPRS
SNMP Gateway: SNMP1002- ARM, SNMP2004-ARM
IEC104 Gateway: IEC 2004-ARM
WEB Configuration Gateway: HMI2004-A9-GW
Sunfull WEB Touch Panel series
Basic version: W7-1041
Gateway version: W7-1041-GW, W10-1041-GW, W15-1041-GW
Sunfull Software Gateway
OPC transfer BACnet: O2B- Softkey, O2B-USBkey
OPC transfer Modbus: O2M- Softkey, O2M-USBkey
OPC transfer Modbus- cloud: O2M-WEB- Softkey, O2M-WEB-USBkey
OPC transfer IEC104: O2I-Softkey、O2I-USBkey
OPC transfer SMS: O2S-Softkey、O2S-USBkey
OPC transfer Web: O2W-Softkey、O2W-USBkey
OPC transfer SNMP: OtS-Softkey、OtS-USBkey
Sunfull OPC server
OPC server: X2O- Softkey, X2O-USBkey
OPC server: OPCHub
Sunfull Free Software
BACnetScan scanning tool, MBUS scanning tool, Niagara interface, and WEBS interface
