Sungale Cloud Frame User manual

MODEL: CPF716
Cloud Frame
For ongoing product improvement, this manual issubject to modification without prior notice.
User's Manual

Before Operation
Product Introduction
Safety Precautions
2
3
5
Basic Operation
Insert a memory card
6
Connect to the computer
7
10
Advanced Operation
11
12
16
11
Customer Management
Support
FAQs
6
Connect Power
Status Icon Briefing
WiFi Setup
Google Account
Google Play Store
My Cloud Album
Online Videos
19
27
Social Media
27
28
Local Photos
Local Videos
Tips
9
15
Online Photos
17
Dropbox
33
Settings Menu Overview
33
33
Wireless
18
29
Troubleshooting
Instructions 5
Register your cloud frame
Link WIFI
8

Features
Specifications
Product Introduction
Before Operation
2
Use the internet to load,manage, and share your favoritephotos with family,
friends, and businesses, on this7" Cloud Frame.
Build up your own cloudalbums, manage slide shows remotely
Enjoy 20GB free cloud storagespace
View photos you stored inyour cloud storage
View photos stored in yourmicroSD cards
Store your most precious photosin internal memory and displaythem
Share photos with your familyand friends via internet
Support display multimedia
Intuitive touch screen give alloperations on your fingers
Wireless link to internet automatically
Display size: 7 inch LED
TouchScreen: Yes
Multimedia support: Photo /Video / Audio
Built-in Wireless: 802.11b/g/n
Built-in Battery: Yes
Memory Card: microSD
USB type: 1x MicroUSB OTG
Power Adaptor Input: 110~240V; Output: 5V

Before Operation
3
Safety Precautions

Before Operation
4
Safety Precautions

Befor Operation
Instructions
5
Plug the Power Adaptorinto the micro USB portand also into a Power Outlet.
1. MicroSD card solt: Insert one of the microSD cardseach time.
2. Back: Return to the previous page.
3. Micro USB port: Connect this unit to your computerby USB cable, and read
U-disk by USB cable.
4. Earphone jack: Insert the earphone, then can enjoyyour personal time.
5. Power: Press and hold on for morethan 3 seconds to turn onor turn off the unit.
One quick press to turn thescreen on and off.
6. Speaker
MicroSD card slot
Micro USB port
Earphone jack
Back
Power on/off
Speaker
1
2
3
4
5
6
Connect Power

MicroSD card is compatible withthis unit.
Insert a memory card
6
Connect the Cloud DPF to the computer
Use the USB cable toconnect the Cloud Frame toa computer.
Basic Operation
MicroSD
Card

7
Basic Operation
Link Wi-Fi
After power-on, the screen will appeara prompt to ask you tolink to Wi-Fi, follow
below instructions to link your frameto the internet.
Step 1. Step 2.
Select the WiFi button to the"ON" position.
Select your network, put in your
password, and then click "connect".
Step 3.
Note: AWiFi internet connection is
required in order to registerand use
your frame as well as accessthe online
features available.
Tap "Settings"button on the prompt.
Not connected to internet, please click
"Settings"to link to internet.
Settings
Not connected to internet, please click
"Settings"to link to internet.
Settings

Before Operation
8
Now you need to registeryour frame by going tothe website
"https://cloud.sungale.com" on your computer, tablet or smart phone.
After Wi-Fi is connected, tap"My Cloud Album" on home screen, below message
will appear to remind youto use the Serial Numberin the block to register
your cloud frame.
Register Your Cloud Frame
Thanks for purchasing. This is a cloud
device, please use your mobile phone or
computer to register your cloud frame.
Your device's Serial Number is
SK00A-00000-XXXX-XXXX-XXXX
OK
From the website, Click "SignUp", then click "Activate your Cloud Product".
You willbe prompted to register theframe by providing the serialnumber from
your frame as well assome basic personal information, then click "register" button.
You needto go to the emailbox you used for registrationto pick up your activating
code and enter into onyour computer, then, the screen will notify you that you
have registered successfully.

9
Status Icon Briefing
Basic Operation
1
4
2 3
5
6
9
8
7
2
3
4
5
6
7
8
9
My Cloud Album: Toload and manage photos in cloudstorage space.
1
Online Photos: Toreview or download photos from online providers.
Local Photos: Display or review the photos storedin internal memory or SD card.
Online Videos: Access videos from onlinevideo providers.
Local Videos: Play or view the videos storedin internal memory or SD card.
Social Media: Access Social Media from online socialproviders.
Wireless: Under wireless surrounding, the photoscan be transferred to this
frame from other wireless compatibledevices.
Settings: Choose from four icons including Browser, all Apps, Files,and
Settings to adjust frame's featuresand functions.
Dropbox: Share your photos.

Select the WiFi button to the"ON"
position.
Select your network, put in your
password, and then click "connect".
Step 3. Step 4.
Step 1.
Step 2.
Select the "Settings" menu icon.
You shouldautomatically be prompted to setup your WiFi connection during the frame
registration process, but if you everneed to connect to a newWiFi network, follow
below instructions:
To setupthe WiFi Connection on your
photo frame, click "Settings" from
the home screen.
Note: AWiFi internet connection is requiredin order to register and useyour frame
as well as access the onlinefeatures available.
10
WiFi Setup
Advanced Operation

Step 1.
Step 2.
Step 3.
Go to the Settings menu, andscroll
down to "+Add account", and click it.
Click "Google" under the add an
account menu.
Click "Existing" if you currently
have a gmail email account and
put in your email and password.
Click "New" to setup a gmail
email account.
Google Play Store
A GoogleAccount will allow you to accessthe Google Play Store forAPP downloads,
and Google applications.
Once you have setup your GoogleAccount, you can accessPlay Store to download
and manage apps.
Advanced Operation
11
Online Account Setup Part1: Google Account

The My Cloud Albumtab gives you access to allthe photos you have stored inyour free
Cloud Frame storage. You must go back to thewebsite "https://cloud.sungale.com"
to add photo albums and slideshows into this section.
Website required Steps:
Advanced Operation
Online Features Part 2: My Cloud Album
Step 1:
Step 3:
Step 4:
Login into your account
Select "Manage Album"
and then select "Add New
Album", name your album,
and click "OK" to save it.
Step 2:
Select "Manage Account"
go to manage page.
Move the cursor to the new
album you just created, click
"Manage Album" and click
the cloud icon to add photos.
12

Advanced Operation
Online Features Part 2: My Cloud Album
Step 6:
Step 7:
Click "Back to AlbumList"
go back to ManageAlbum
page.
When all photos uploaded,
click "Close" button to close
the upload page, you'll see
your photos have been
uploaded.
Step 8:
Move the cursor to an album
that you want to send toyour
cloud frame, then click "Push
Album to Cloud Frame" button.
13
Step 5:
Click "Add Photos" button,
choose photos from your
computer and click "StartAll"
button to upload photos.

Advanced Operation
Online Features Part 2: My Cloud Album
Cloud Frame Steps:
To accessand view these photos, click"My Cloud Album". Select the album and
photos you wish to view.
Note: Photos in My CloudAlbum will automatically play based onthe settings you
have setup from the website.
Tip: For instructions on creatingcloud albums and adjusting settings, loginto your
account at "http://cloud.sungale.com" and select Supportor Video Setup Tutorial
at the top of the page.
Step 9:
Select your frame and click
"OK" button, now your have
sent an album to your frame.
Now, You or your friends
and loved ones can see the
photos you shared to the
cloud frame.
14

Select the "+" symbol in the lower
right corner to enter the online
storage back list.
Select "YES"to download
Select any Hub to install and
download to your frame.
Select "YES"to install
The Online Photos tab gives youaccess to numerous online Photo Hubs.
To accessthese Photo Hubs select
Online Photos.
After the installation is complete, yourHub
will be available on the frontscreen. You
can now select and use it.
Advanced Operation
15
Online Features Part 3: Online Photos

Advanced Operation
16
Online Features Part 4: Online Videos
To accessthese Video Hubs
select Online Videos.
Select the "+" symbol in the lower
right corner to enter the online
storage back list.
Select any Hub to install and
download to your frame.
After the installation is complete, your
Hub will be available on thefront
screen. Youcan now select and use it.
The Online Videos tab givesyou access to a numerous amountof online Video Hubs.
Select "YES"to download Select "YES"to install

Your framehas been pre-installed with Dropbox, apopular file sharing service right
from the home screen.
Click "Dropbox" from the home screen, and loginto your Dropbox account.
Now you can browse and selectthe photos and videos you wantto download into
your frame.
Note: Downloaded Pictures and Videosfrom Dropbox will be placed inthe Local
Photos or Local Videos areaof Frame depending on the file.You canonly view files
from Dropbox and cannot run slideshowswithin the APP. Youmust first download into
local memory. See"Local Photos" for slideshow instructions.
Tip: By adjusting your Dropboxsettings on your smart phone, youwill automatically
be able to send any photoyou take to your Dropbox account. This will offeran easy
way of downloading photos to yourframe.
Advanced Operation
17
Online Features Part 5: Dropbox

The Social Media tab gives youaccess to numerous online Social MediaHubs.
Select the "+" symbol in the lower
right corner to enter the online
storage back list.
Select "YES"to download
Select any Hub to install and
download to your frame.
Select "YES"to install
To accessthese Social Media Hubs select
Social Media.
After the installation is complete, yourHub
will be available on the frontscreen. You
can now select and use it.
Facebook Twitter
Facebook Twitter Facebook Twitter
Facebook
Advanced Operation
18
Online Features Part 6: Social Media

Advanced Operation
19
Online Features Part 7: Wireless
Click "Wireless" from the home screen, and into"SHAREit" APP.
Android Device
1. The sending device andthe frame need to be onthe same WiFi Network.
2. Download the APPfrom Google Play Store on yourSmart Phone or Tablet.
3. Once installed, open it andcreate a profile to use includinga name and image.
You willalso need to open theAPP on your Cloud Frameand create a profile too.
4. On your Phone, click"send" and on the frame, click "receive".
In receiving mode, your frame shouldlook like the below.
