Product(Code:(1036T(/1037T/1038T!
Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!
Visit!us!at!www.tqbbrands.com.au!
OWNER’S(MANUAL(
PRODUCT(CODE:(1036T/1037T/1038T
ULTRASONIC(PARTS(CLEANER(
Product!
Code!
Tank!Size!
(mm)!
Unit!Size!
(mm)!
Volume!
(L)!
Ultrasonic!
Power!
Ultrasonique!
Frequency!
Heating!
Power!
1036T!
300x155x150!
330x180x310!
6!
150W!
40kHz!
300W!
1037T!
330x300x150!
360x330x310!
13!
300W!
40kHz!
400W!
1038T!
500x300x200!
550x330x360!
27!
500W!
40kHz!
500W!

Product(Code:(1036T(/1037T/1038T!
!Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!Page!2!
Visit!us!at!www.tqbbrands.com.au!
!
WARNING(
(
IMPORTANT:((READ(ALL(INSTRUCTIONS(BEFORE(USE!
!
((((WARNING!!
!
The!instructions!and!warnings!contained!in!this!manual!should!be!read!and!understood!before!
using!or!operating!this!equipment.!Do!not!allow!anyone!to!use!or!operate!this!equipment!until!
they! have! read! this! manual! and! have! developed! a! thorough! understanding! of! how! this!
equipment!works.!Failure!to!observe!any!of!the!instructions!contained!in!the!manual!could!result!
in! severe! personal! injury! to! the! user! or! bystanders,! or! cause! damage! to! the! equipment! and!
property.!Keep!this!manual!in!a!convenient!and!safe!place!for!future!reference.!
!
Whilst!every!effort!has!been!made!to!ensure!accuracy!of!information!contained!in!this!manual,!
the! TQB! Brands! Pty! Ltd!policy! of! continuous! improvement! determines! the! right! to! make!
modifications!without!prior!warning.!
!
!
!
!
CONTENT(
!
WARNING!.....................................................................................................................................!2!
CONTENT!......................................................................................................................................!2!
SAFETY!INSTRUCTIONS!.................................................................................................................!3!
ASSEMBLY,!OPERATION,!PREVENTITIVE!MAINTENANCE!.............................................................!4!
WARRANTY!...................................................................................................................................!9!
! !

Product(Code:(1036T(/1037T/1038T!
!Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!Page!3!
Visit!us!at!www.tqbbrands.com.au!
!
!
SAFETY(INSTRUCTIONS(
(
(
((SAFETY(OPERATING(INSTRUCTIONS((
(
While!the!machine!is!working!normally,!ultrasonic!and!tank!syntony!gives!a!well-proportioned!
sound,!and!no!shudder!on!the!surface!of!the!water,!yet!there!is!spray!made!by!the!tiny!bubbles.!
If!there!are!discontinuous!surges,!please!add!or!release!a!little!of!washing!solution!in!the!tank,!
stopping!the!surges!is!better!for!the!objects!cleaning.!
!
Please!read!the!following!very!carefully!as!failure!to!comply!may!invalidate!your!guarantee.!
!
û DO!NOT!run!the!cleaner!continuously!for!more!than!30!minutes!at!a!time,!as!doing!so!
can!damage!the!internal!components.!
û DO!NOT!operate!the!unit!without!fluid!in!the!tank.!Always!ensure!the!fluid!is!no!higher!
than!the!max!mark.!!Always!ensure!there!is!a!minimum!depth!of!7cm.!
û DO!NOT!drop!any!item!into!the!tank!as!this!may!cause!damage!to!the!transducer.!!
ü Always!place!the!items!gently!into!the!tank!and!use!the!basket!whenever!possible.!
ü The!more!items!that!you!place!in!your!cleaning!bath!the!less!efficient!it!will!clean.!It!is!
not!advised!to!overlap!items.!Always!allow!plenty!of!clear!space!between!the!items.!
ü Keep!the!lid!on!during!use.!This!will!prevent!splashes!and!reduce!evaporation!of!the!
fluid.!
ü Always!wear!suitable!protective!clothing,!gloves!and!goggles.!
û DO!NOT!immerse!the!machine!or!power!cord!in!water!or!other!liquid.!
û DO!NOT!touch!the!unit!if!the!machine!has!fallen!into!water!during!operation.!Remove!
the!power!plug!from!the!socket!first.!
ü UNPLUG!the!power!source!while!filling!or!emptying!the!tank.!
û DO!NOT!spray!water!or!liquid!over!the!device!and!the!control!panel!
û DO!NOT!operate!the!cleaner!without!proper!grounding.!
û DO!NOT!place!the!device!on!a!soft!surface,!where!the!vents!could!be!blocked.!
ü Upon!completion!of!the!cleaning!cycle,!turn!the!heater!dial!off!and!isolate!the!machine!
from!the!electrical!supply.!
ü Take!care!when!adding!or!removing!items!from!the!cleaning!tank!as!the!fluid!is!likely!
to!be!hot!and! displaced!fluid!can!damage! the!internal!components.!!Any!displaced!
fluid!must!be!dried!up!immediately.!
ü In!the!event!of!failure/emergency,!disconnect!the!mains!supply!by!removing!the!plug!
from!the!mains!socket.!
ü When! servicing,! use! only! Tradequip!identical! replacement! parts.! Use! of! any! other!
parts!will!void!the!warranty.!!Ensure!the!Ultrasonic!Parts!Cleaner!is!disconnected!from!
power!before!servicing.!
ü Use! the! right! product! for! the! job.! There! are! certain! applications! for! which! the!
Ultrasonic!Parts!Cleaner!was!designed.!Do!not!modify!the!Ultrasonic!Parts!Cleaner!and!
do!not!use!the!Ultrasonic!Parts!Cleaner!for!a!purpose!for!which!it!was!not!intended.!!
! !

Product(Code:(1036T(/1037T/1038T!
!Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!Page!4!
Visit!us!at!www.tqbbrands.com.au!
!
!
ASSEMBLY,(OPERATION,(PREVENTITIVE(MAINTENANCE(
1. FEATURES(
The!Tradequip!Ultrasonic!Parts!Cleaner.!
- Normal!and!soft!power!control!to!resolve!the!cleaning!blind!spot.!
- Stainless!steel!housing,!tank!and!lid.!
- Pressed!tank!without!welded!joints!for!better!waterproof.!
- Cooling!fan.!
- Moisture-proofed!PCB.!
- Industrial!grade!IC!&!ultrasonic!transducer.
Ultrasonic! cleaning! is! based! on! the! cavitation! effect!
caused! by! high! frequency! ultrasonic! wave! vibration!
signal!in!the!fluid.!!Microscopic!bubbles!are!formed,!and!
they! implode! violently! causing! the! cavitation!which!
creates!an!intense!scrubbing!action!on!the!small!enough!
to! penetrate! microscopic! crevices,!cleaning!them!
thoroughly! and! consistently.!Ultrasonic! cleaning! is!
extremely! effective! at! removing! dirt! and! grime! which!
would! normally! require! tedious! manual! cleaning! by!
hand.!!This!unit!can!be!used!to!clean!a!wide!variety!of!
instruments!and!mechanical!parts!such!as!carburettors,!
returning!them!to!almost!“like!new”!condition!without!
damage!to!delicate!parts.!!
!
2. ASSEMBLY(
Unpacking:!!after! removing! the! packing! material,! make! sure! the! product! is! in! perfect!
condition! and! that! there! are! no! visible! damaged! parts.!!!The! packaging! materials!
(Polyethylene!bags,! polystyrene! etc.),! must! be! disposed! of! in! an! appropriate! refuse!
collection!container.!!Recycle!cardboard.!
!
1. Place!the!cleaner!on!a!flat,!clean!surface!where!the!cooling!fans!will!receive!adequate!
ventilation!and!ensure!all!controls!are!set!to!off.!!
2. Ensure!the!drain!tap!is!in!the!closed!position.!
3. Ensure!the!power!lead!is!securely!plugged!into!the!cleaner!and!that!no!part!of!the!lead!
is!likely!to!come!into!contact!with!moisture.!
4. Carefully!fill!at!least!1/2!of!the!tank!with!a!solvent!solution.!For!demanding!cleaning!
we! recommend! a! small! amount! of! washing! up! liquid,! this! will! help!increase! the!
cleaning!performance.!The!cleaner!is!now!ready!for!use.!
!
Contents:(
Main!Machine,!Lid,!Power!Cord,!Outlet!Filter,!Mesh!Basket.!
!
!

Product(Code:(1036T(/1037T/1038T!
!Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!Page!5!
Visit!us!at!www.tqbbrands.com.au!
!
3. BEFORE(USE(
Prior!to!each!use!conduct!a!visual!inspection!by!checking!for!abnormal!conditions,!such!as!
cracked!joins!and!damaged,!loose,!or!missing!parts.!
!
Items&Not&Suitable&for&Ultrasonic&Cleaning&
Soft!Jewellery:!Pearls,!emerald,!ivory,!coral.!Agate,!sea!turtle!shells,!etc.!
Welded,!Plated!and!Glued!Items:!Welded!or!plated!metal!items,!glued!items.!
Watches:!Except!diver’s!watches!with!depth!rating!over!50m(150ft).!
Others:!Ceramic,!camera!filters!with!pre-existing!cracks.
!
Cleaning(Solutions:!
WARNING(:!Strong!acid!or!alkaline!cleaning!solution!will!cause!corrosion,!rust!and!even!
puncture!of!tank!or!machine!body.!To!overcome!this!problem,!dilute!to!mild!PH!solution!or!
request!for!tank!made!of!specific!grade!of!stainless!steel!like!SUS304.!
!
*Warning: For use with aqueous (water) based solutions only. Petroleum based cleaning fluids are harmful
and will damage the pump and void the warranty.!
!(

Product(Code:(1036T(/1037T/1038T!
!Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!Page!6!
Visit!us!at!www.tqbbrands.com.au!
!
4. OPERATION(
(
1. Select!your!cleaning!solution;!fill!at!least!½!of!solution!into!the!tank.!!Do!not!exceed!the!
filling!line.!!Note:&Do&not&use&alcohol,&gasoline&or&flammable&solutions.!!Doing!so!could!
cause!a!fire!or!explosion.!Use!only!water-based!solutions.!
!
2. Place!the!items!into!a!basket,!then!slowly!lower!the!basket!into!tank.!Do!not!allow!items!to!
contact!the!tank!bottom!(solution!should!cover!the!items).!
!
Power!switch!(C)!!-!Plug!the!machine!into!grounded!outlet.!
Turn!on!the!power!switch!on!back!side!of!the!machine.!The!timer!and!heating!indicator!
light!up.!
!
! !
Louver!
!
!
Socket!
!
Power!Switch!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
3. Select!Ultrasonic!power!Normal!or!Soft!(G!&!H)!to!suit!item!to!be!cleaned.!!Normal!power!
(G)!operates!at!100%!and!Soft!power!(H)!operates!at!50%!for!delicate!applications.!
!
4. Turn!the!“Heater”!dial!(A)!clockwise!to!adjust!the!heating!temperature!from!20℃!to!80℃.!!
The!pre-set!temperature!light!will!illuminate!for!3!seconds!to!start!heating,!the!LED!light!
bar!will!display!the!ambient!temperature!and!rise!until!the!desired!!temperature!is!reached.!!
Heating!will!automatically!stop,!the!light!of!the!pre-set!temperature!will!continue!to!blink,!!
the!LED!light!bar!below!the!pre-set!temperature!all!light!off!and!heating!indicator!light!up.!
!
5. Turn!the!‘Heater”!dial!anti!clockwise!to!reduce!the!temperature.!!To!stop!heating,!turn!the!
dial!anti!clockwise!to!off!until!heating!indicator!light!up!again.!

Product(Code:(1036T(/1037T/1038T!
!Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!Page!7!
Visit!us!at!www.tqbbrands.com.au!
!
Note:(
- The!temperature!control!has!13!increments>!20,!25,!30,!35,!40,!45,!50,!55,!60,!65,!70,!
75,!80℃.!
- Heating!will!automatically!start!again!when!the!actual!temperature!drops!3℃!below!
the!pre-set!temperature.!
- To!achieve!the!best!cleaning!result,!the!recommended!solution!temperature!is!40℃-
60℃.!Warm!water!and!dish!washing!liquid!can!soften!grease!and!improve!cleaning!
result.!
- If!the!pre-set!temperature!is!below!the!ambient!temperature,!the!heating!will!not!
start.!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
6. Turn!the!“Timer”!dial!(B)!clockwise!to!set!timer!from!0-30!minutes.!The!pre-set!timer!light!
will!blink!for!3!seconds!and!LED!light!bar!below!pre-set!timer!will!illuminate.!!
7. As!cleaning!cycle!is!completed,!the!timer!indicator!will!diminish.!!
8. Turn!the!dial!counter-clockwise!to!reduce!the!ultrasonic!cleaning!cycle!time.!
9. To!stop!ultrasonic!immediately,!turn!dial!counter-clockwise!to!off.!
Note:((Timer!9!increments!from!1,!2,!3,!4,!5,!15,!20,!25,!30mins(
!
10. Commence!Operation:!!Once!the!timer!has!been!set!the!Ultrasonic!Parts!Cleaner!will!start!
operating.!
Note:(During!ultrasonic!cleaning!cycle,!you!should!notice!a!“sizzling”!noise.!This!is!normal!
and!means!the!cleaner!is!working!correctly.!
!
11. Cease!Operation:!!When!the!cleaning!cycle!is!complete!turn!the!Timer!Dial!and!the!Heating!
Dial!to!the!“OFF”!position,!the!Ultrasonic!Parts!Cleaner!will!stop!operating!and!the!timer!
and!heating!indicator!will!illuminate.!
!
12. Clean!Up:!!Turn!off!the!power!switch!on!the!back!of!the!machine.!!Unplug!the!power!cord,!
open!the!lid!and!retrieve!the!basket!and!the!items.!!Empty!the!tank!and!clean!both!the!
outside!and!inside!of!the!machine!with!clean!and!dry!cloth!for!next!use.!Keep!the!drainage!
valve!closed.!
!
!

Product(Code:(1036T(/1037T/1038T!
!Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!Page!8!
Visit!us!at!www.tqbbrands.com.au!
!
13. Cleaning!Options:!
General!Cleaning:!!! Use!only!tap!water!at!an!operating!temperature!of!50℃!.!
Enhanced!Cleaning:! Add!a!few! drops! of! standard! washing! up! liquid,! ! liquid! soap,!or!
detergent! into! the! water.! Other! non-acidic! cleaning! agents! can!
also!be!used.!
!
Note:!!Any!spillages!should!be!mopped!up!immediately,!to!minimise!safety!hazards.!
!
(
5. STORAGE(
This!Ultrasonic!Parts!Cleaner!should!always!be!stored!in!a!dry!location!on!a!level!surface.!!
Disconnect!240V!power!supply!and!empty!the!cleaning!fluid!into!a!separate!container.!
(
6. MAINTENANCE(
Disconnect!power!prior!to!any!maintenance!
Inspect!the!general!condition!of!the!Ultrasonic!Parts!Cleaner!checking:!!
- For!loose!hardware!
- Misalignment!of!binding!or!parts,!cracked,!bent,!or!broken!parts,!and!
- Any!other!condition!that!may!affect!the!Ultrasonic!Parts!Cleaners!safe!operation!
!
7. SERVICE(&(REPAIR(
Any!Ultrasonic!Parts!Cleaner!found!damaged!in!any!way,!or!found!to!be!worn!or!operates!
abnormally!should!be!removed!from!service!until!repaired!by!an!authorised!service!agent.!!
Owners! and! /! or! operators! should! be! aware! that! repair! of! this! product! may! require!
specialised!equipment!and!knowledge.!!Only!authorised!parts,!labels!and!decals!shall!be!
used!on!this!equipment.!!Annual!inspection!of!the!Ultrasonic!Parts!Cleaner!is!recommended!
and! can! be! made! by! an! authorised! repair! facility! to! ensure! that! your! equipment! is! in!
optimum! condition! and! that! the! equipment! has! the! correct! decals! and! safety! labels!
specified!by!the!manufacturer.!
!
!
!
!
!
! !

Product(Code:(1036T(/1037T/1038T!
!Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!Page!9!
Visit!us!at!www.tqbbrands.com.au!
!
WARRANTY(
!
Tradequip!products! have! been! carefully! tested! and! inspected! before! shipment! and! are!
guaranteed!to! be!free!from! defective!materials!and!workmanship! for!a!period! of!12!months!
from!the!date!of!purchase!except!where!tools!are!hired!out!when!the!guarantee!period!is!ninety!
days!from!the!date!of!purchase.!
!
Should! this! piece! of! equipment!develop! any! fault,! please! return! the! complete! tool! to! your!
nearest! authorised! warranty! repair! agent! or! contact! TQB! Brands! Pty! Ltd! Warranty! team! –!
[e-mail].!
!
If! upon! inspection! it! is! found! that! the! fault! occurring! is! due! to! defective! materials! or!
workmanship,!repairs!will!be!carried!out!free!of!charge.!!This!guarantee!does!not!apply!to!normal!
wear!and!tear,!nor!does!it!cover!any!damage!caused!by!misuse,!careless!or!unsafe!handling,!
alterations,!accident,!or!repairs!attempted!or!made!by!any!personnel!other!than!the!authorised!
TQB!Brands!Pty!Ltd!repair!agent.!
!
This!guarantee!applies!in!lieu!of!any!other!guarantee!expressed!or!implied!and!variations!of!its!
terms!are!not!authorised.!
!
Your!TQB!Brands!Pty!Ltd!guarantee!is!not!effective!unless!you!can!produce!upon!request!a!dated!
receipt!or!invoice!to!verify!your!proof!of!purchase!within!the!12!month!period.!
!
!
Consumer(Guarantee((
Our!goods!come!with!a!guarantee!that!cannot!be!excluded!under!the!Australian!Consumer!Law.!
You!are!entitled!to!a!replacement!or!refund!for!a!major!failure!and!compensation!for!any!other!
reasonably! foreseeable! loss! or! damage.! You! are! also! entitled! to! have! the! goods! repaired! or!
replaced!if!the!goods!fail!to!be!of!acceptable!quality!and!the!failure!does!not!amount!to!a!major!
failure.
!
!
!
!
!
!
TQB!Brands!Pty!Ltd!!!!1/40!Metrolink!Circuit!!Campbellfield!!Vic!3061!
!
!
!
!
!
!

Product(Code:(1036T(/1037T/1038T!
!Made!in!China!to!TQB!Brands!Pty!Ltd!specifications!Page!10!
Visit!us!at!www.tqbbrands.com.au!
!
!
!
Another!great!product!“Made!for!the!Trade”!
!
!
!
Visit!www.tqbbrands.com.au!for!full!details!
!
