Sunjoy S-DN096-C1 User manual

Folding Wood Adirondack Chair
Assembly Instructions
Item# S-DN096-C1

ASSEMBLY INSTRUCTIONS
Our clear, easy-to-follow, step-by-step instructions will guide you through the project
from start to finish.
DO NOT assemble this item alone for your safety. Two people are necessary for
smooth & safe installation.
Item identification: For ease of identification, all parts are labeled to correspond to the
step number in which the part is used.
IMPORTANT:
CAUTION:
Read following instructions carefully before using chair.
-Chair holds maximum of 225 lbs.
-Keep fingers away from hinged area of chair.
-Do not stand on chair or sit on the arms.
-This chair is designed for use by only one person at a time.
-Use chair on a flat, not-slippery surface only.
1. Keep all children and pets away from assembly area. Children and pets should be
supervised while product is being assembled.
2. The assembled product should be located at least 6 feet (2 m) from any
obstruction such as fence, garage, house, overhanging branches, laundry lines or
electrical wires.
3. This unit is heavy. Do not assemble this item alone. 2 people are recommended
for safe assembly.
4. Some parts may contain sharp edges. Wear protective gloves if necessary during
assembly.
5. When assembling and using this product, basic safety precautions should always
be followed to reduce the risk of personal injury and damage to equipment. Please
read all instructions before assembly and use.
6. For outdoor use only.
7. Check all bolts for tightness before and during usage.
8. Please check your state and local regulations prior to purchasing. Some
jurisdictions may require permits for installation and use of this product. Some special
procedures may be valid in your area.

Parts list
No.
DESC.
Qty
A
Chair back
1
B
Seat board
1
C1
Right leg
1
C2
Left leg
1
D1
Left armrest
1
D2
Right armrest
1
E
Front connector
1
F
Connector
2
G
Wood dowel
2
AA
M4*35 Bolt
4
BB
M6*50 Bolt
4
CC
M6*50 Bolt
2
DD
M6*50 Bolt
4
EE
Flat washer M6
6
FF
Nut M6
6
GG
Steel plug
4
HH
Wrench
1
Step 1:
Connect front connector (E) and left leg / right leg
(C1/C2) by bolts (AA) and screwdriver (not included).
Don’t tighten the bolts at this stage.
Step 2:
Insert wood dowels (G) into the holes of left leg / right
leg (C1/C2); connect seat board (B) to left leg / right leg
(C1/C2) by bolt (BB), flat washer (EE), nuts (FF), as
shown. Use screwdriver (not included) and wrench
(HH); don’t tighten the bolts and nuts at this stage.
Chair Assembly Step

Step 3:
Firstly, insert steel plugs (GG) into the hole of chair back
(A), then insert bolt (DD) into the hole of connector (F) to
reach the slot of steel plug (GG) and fix bolt (BB)
through the hole of connector (F) and seat board (B) by
nut (FF) and screwdriver (not included) and wrench
(HH), don’t tighten them in this step.
Step 4:
Insert steel plugs (GG) into the hole of chair back (A), and
then connect chair back (A) and left armrest / right armrest
(D1/D2) by bolts (DD), flat washer (EE) and screwdriver
(not included) as Fig 1, don’t tighten bolts. Connect left
armrest / right armrest (D1/D2) and left leg / right leg
(C1/C2) by bolts (CC), flat washers (EE), nuts (FF) and
screwdriver (not included) and wrench (HH) as Fig 2.
Lastly, tighten all bolts.

Customer Service:
Sunjoy Group warrants to the original purchaser that this item is free from defects in
workmanship and materials of your item provided the item was factory-sealed at the
time of purchase and is maintained with care and used only for personal, residential
purposes. The item is warranted to be free from defects in material or workmanship
for a period of 6 months. Should any manufacturing defect arise within this warranty
period, Sunjoy Group will repair or replace (at our option) any defective
merchandise upon proof of purchase; however, transportation and delivery costs, as
well as labor and material charges to remove or replace parts, remain the
responsibility of the purchaser. A purchaser of an "open box," previously-returned, or
"clearance" item, as well as original purchasers outside of the warranty period, may
obtain replacement parts from Sunjoy Group for products in current production, at
nominal cost.
If you are within the return policy that most stores have, you do have the option of
returning this item back to the store which you bought it from for an exchange of the
same item, or a refund of the purchase.
If you are within or beyond the return policy that most stores have, and need tech.
assistance or replacement parts, please call Sunjoy Group at 1(866) 578-6569 from
8:00 am EST to 8:00 pm PST or e-mail to [e-mail] or visit
www.sunjoyonline.com to place your order or fax your parts replacement order form
together with the purchase receipt to 1 [phone] for assistance.
