Sunlight Supply SUN SYSTEM Series Manual

Technical Information Guide
Revised 09/1/08
www.sunlightsupply.com • www.nationalgardenwholesale.com

Page 2
IMPORTANT PRODUCT INFORMATION
READ IMMEDIATELY
KEEP ORIGINAL PACKAGING – ALL RETURNS NEED TO BE IN THE ORIGINAL
PACKAGING IN ORDER TO AVOID PRODUCT DAMAGE DURING SHIPPING.
ANY DAMAGE TO PRODUCTS NOT IN THEIR ORIGINAL PACKAGING WILL
NOT BE COVERED UNDER WARRANTY.
SAFETY FIRST!
FAILURE TO OBSERVE THE FOLLOWING SAFETY WARNINGS MAY RESULT IN SERIOUS INJURY.
IN ADDITION, FAILURE TO OBSERVE THESE SAFETY WARNINGS WILL RESULT IN A WAIVER OF
ALL LIABILITIES ON SUNLIGHT SUPPLY®, INC. AND WILL VOID ALL WARRANTIES.
WARNING:
• Iftheexteriorofthelampisdamaged,replacelampimmediately.
• Disconnectpowerbeforere-lamping.
• Whenre-lamping,makesurelamphastimetocoolbeforetouching.
• Makesurepowercordandlampcordareconnectedproperly.
• DoNOThangbypowercordorlampcord.
• DoNOTmakecontactwiththeinteriorofthesocketwhilethepowerison.
• DoNOToperatethelightsystemsinwetlocations.
• DoNOTplugthissystemintoasupplyvoltageotherthanwhatisinstructedontheballast.
• DoNOTattempttoopen,rewireorrecongureanycomponentsofthelightsystem.Itwillvoidthewarrantyandcould
causeseriousinjuryordeath.
• Theseproductsoperateatveryhightemperatures.Keepawayfromchildren.
• Donotplugorunplugalampcordwhiletheballastisturnedon.
• Donotusewithgenerators.Warrantywillbevoided.
• TheLitePipe™,SunTube™andDigitalFusion™allneedtobeaircooled.
• Glassrequiredinreectorswhenusingmetalhalide(MH)lampsforULlistingto
apply.Notrequiredwithhighpressuresodium(HPS)lamps.
REMOTE MVP™ SYSTEMS SETUP:
(SUN SYSTEM®1, 6 & 7)
1.Removethesystemfromtheboxalongwithalladditionalparts.
2.FirstattachtheMVP™(MultiVoltPowercord)tothesystemandmakesureitproperlylatches.(SeeFig.1onnext
page)
3. Switchable Units:WhenusingaSS-6MH/HPS(MetalHalide/HighPressureSodium)switchableunit,switchthesystem
totheMHsidetorunaMetalHalidelamporHPStorunaHighPressureSodiumlamp.ForaSS-61000switchable,select
theHPSoptionoftheballastbypushingthebottomoftheswitchsothattheredpartoftheswitchisvisible.Pressthetop
partoftheswitchforMH.ASS-6400switchableismarkedHPS400fortheHPSsideandMH400fortheMHside.
4.Connectthesockettothehangingreector(seereectorsetupFig.4).Ifthelampcordisincludedwiththe
reector,skipthisstep.
Fig. 2

Page 3
TheCWA(ConstantWattageAutotransformer)utilizesasingleCOMMONwire,whichiscommontoalltapsonthe
ballast.Also,whenanytapontheballastisenergized,alltapsbecomeenergizedtothatpotential.Forexample,
whenasystemispluggedinto120volt,theunused240volttapisstillenergizedtoapproximately240volt.
Rewiringtheballastfrom120voltto240voltonlyrequiresthechangeofasinglewire.Additionallythereisa
requiredchangeontheoppositesideofthepowercord,whichischangingtheplugfromastandard120voltplug
(NEMA5-15P)toastandard240voltplug(NEMA6-15P).Thissoundssimple,butinrealityitisnotthateasy.
Thisrequiresreplacingthe120voltpowercordfora240voltpowercordinmostcases.WedesignedourMVP™
toreducethehassle,expenseandpotentialsafetyhazards.
Technical informaTion
Sun Systems®
by Sunlight Supply® , Inc.
CAUTION
CONNECT POWER
CORD TO SYSTEM
BEFORE PLUGGING
INTO POWER SOURCE
THAT’S IT!
STEP 2
PLUG IN
240 VOLT
POWER CORD
STEP 1
UNPLUG
120 VOLT
POWER CORD
5.Nowconnectthelampcordtotheremoteballast(Fig.2).Makesuretoattachthesecurement
earstotheplug.
6.Carefullyscrewtheproperlampintothesocket.Refertolampinginstructionsontheballast.
7.ForSS-6unitsmakesuretoselectthepropersettingontheballasttomatchthelampthat
isbeingused.MakesuretheswitchisproperlysetforeitherMHorHPStypelamp(Fig.3).
8.Lastly,turnthesystemonbypluggingthepowercordintotheproperNEMAcongured
receptacle.
9.YoumustuseaproperlyratedMVP™cord(120or240volt)forthepowerthatyouareusing.If you energize this ballast
with 240 volt power while using a 120 volt MVP™ cord (by cutting the plug off), you will “fry” the ballast and
void the warranty. If you want to run this ballast with 240 volt power, you must purchase a 240 volt MVP™ cord
separately.
Fig. 3
Fig. 1
™
BULB INFORMATION:
Proper Bulb Care
Bulbsshouldbereplacedeveryyeartomaintainmaximumlumenoutput.Ifalampfailsto
reachbrightness,pleasecontactyourretailstore.
Fluorescent fixtures
Iftherearebulbsthatwillnotre,tryswappingthebulbsaroundforothersthatareworking.
Thiswillhelpdetermineifthebulbsaredefective.

Page 4
REFLECTOR SETUP:
1.See(Fig.5)forattachingthesocketonreectorswhichdonotincludethesocket.
2.Somereectorswillcomewithabuilt-insocketassembly,whileothersyouwillneedtopurchase
oneseparately.
3.Ifthereectordoesnothaveabuiltinsocket,useasocketassemblythatissoldseparately.
ChoosefromProductNo.903055or903060.
4.Somereectorsincludeglass.Forotherreectorsitmaybepurchasedseparatelyifyouchoose
touseit.Typicallypeopleuseglasstocontrolairmovementthroughthereectorduringair
cooling.Thisalsoprotects/containstheenvironmentofyourgrowarea.Glassisnotrequired
whenusingHPSlampsfortheULlistingtoapply.ItisrequiredforMHlampsforthislisting
toapply.Theglassinstallationprocesswillvarybyreectortype.Itis,although,avery
 simpleprocessforallSunSystemreectors.
5.Useaneyeboltorsomeothermeansofhangingsecurelyfromtheceiling.
6.V-Hangers(Fig.6)areusedtohangthereector.
7.SunLifts,#710125,GrowYo-Yo,#710129(Fig.7)orjackchainmaybeusedto
 adjustthehangingheight.
ENCLOSED SYSTEMS SETUP:
(SUN SYSTEM®2, 3 & 4)
1.Removethesystemfromtheboxalongwithalladditionalparts.
2.Thesesystemsdonotrequiremuchsetup.Carefullyscrewtheproperlampinto
thesocket,refertolampinginstructionsonballast.
3.HangthextureusingtheV-hangersprovided.
4.(On/offswitchshouldbeintheoffposition.)PlugtheunitintotheproperNEMA
conguredreceptacle.
5.Turnthextureonusingtheon/offswitch.Somesystemsmaynot
includethisfeature.
Fig. 6
Fig. 7
Fig. 4b
Fig. 5
REMOTE SMART VOLT™ SYSTEMS SETUP:
(SUN SYSTEM®10, BUDGET GRO™, HARVEST PRO™ & ELITE)
1.Removethesystemfromtheboxalongwithalladditionalparts.
2.TheSmartVolt™systemscomestandardwiththe120voltSmartVolt™powercord.The
HarvestPro™andHarvestPro™ElitehavethePowerPointer™voltageselector.TheSun
System®10andBudgetGro™havethePowerSlider™voltageselector.Makesureitison
the120voltoptiontoplugintheprovidedcord.TochangethevoltageontheHarvestPro™
&HarvestPro™Elite,simplypulloutandtwist180º(Fig.4a).FortheSunSystem®10&
BudgetGro™,slidethedoortothemarked240voltside(Fig.4b).Tousethe240voltyoumustpurchasethe240volt
SmartVolt™powercord(#903082or#903084)separately.
3.Followsteps4through6ontheRemoteMVP™SystemsSetup.
4.Lastly,turnthesystemonbypluggingthepowercordintotheproperNEMAconguredreceptacle.
5.YoushoulduseaproperlyratedSmartVolt™cord(120or240volt)forthepowerthat
 youareusing.If you energize this ballast with 240 volt power while the female end of
the power cord is plugged into the 120 volt receptacle you will “fry” the ballast and
void the warranty. If you want to run this ballast with 240 volt power, you should
purchase a 240 volt Smart Volt™ cord separately.
Fig. 4a

Page 5
LINEAR FLUORESCENT SETUP:
(TEK-LIGHT™, NEW WAVE®, READY FIT®& SUN BLAZE®)
1.Removethesystemfromtheboxalongwithalladditionalparts.
2.Hangtheunitusingtheeyebolts,V-hangersandjackchainprovided(Optional
cablehangersystemscanbepurchasedseparately).
3.Insertlamps(refertolabelonproductforcorrectlamp)intothesystem.Todothis,
slidebothendsofthelampintothelampholdersandrotatethelamp90ºineither
direction(Fig.8a).FortheReadyFit®T5unscrewthewaterproofprotectiveplastic
covercounterclockwise.Theprotectivecoverwillhavetogodirectlyontothelamp
beforeinsertingintothelampholder(Fig.8b).Insertlampandrotate90ºineither
directionandslidethewaterproofprotectivecoverbackonandtighten.
4.SomeNewWave®&SunBlaze®modelshavethecapabilitytobedaisychained
together.Donotexceed7.5ampsonanyxtureschainedtogether.Donotdaisy
chainmorexturestogetherthanwhatisspeciedonthexture.Chainingmore
xturestogetherthanspeciedwillvoidthewarrantyonallxtures.
REFLECTOR MOUNTING HEIGHTS
AgeneralguidelinefortheproperhangingheightofanH.I.D.lampwouldbe12”-48”dependingonwattage(seebelow).
Makesuretocheckforexcessiveheatatthetopofyourplantsbyplacingyourhand(palmdown)overyourplants.Ifthetop
ofyourhandishot,youneedtomoveyourlampuphigher.Ifthelightsourceistooclosetoyourplants,youcanburnthem.
Rememberthatasyourplantsgrowyouwillneedtoadjusttheheightofyourlamp.
Pleasekeepinmindthatthelatestair-cooledreectors,liketheSuperSun®2allowyoutoplacehigherwattagebulbscloser
toplantsthanwaspossibleinthepast.
Whenyouraisethelightup&awayfromyourplants,youneedtobeawarethatthelightlevelstoyourplantswillbesigni-
cantlyreduced.
Aslightmovesawayfromitssource(thelamp)itdiminishesasfollows:1/Distance2.Forexample:1ft.=1000FTC,2ft.=
250FTC,3ft.=111FTC,4ft.=63FTC,5ft.=40FTC,&6ft.=28FTC(FTC=footcandle).
Fixture Type Max # Chained
Sun Blaze®22 12
Sun Blaze®24 6
Sun Blaze®44 5
Sun Blaze®48 3
Fixture Type Max # Chained @ 120V Max # Chained @ 240V
New Wave®28 5 9
New Wave®44 5 8
New Wave®48 3 5
Fig. 8b
Fig. 8a
COMPACT FLUORESCENT SETUP:
(SUN SYSTEM®8 & BRIGHT WING
®
)
1.Seereectorsetupsectionforhanginginstructions.
2.Inserttheself-ballastedcompactuorescentlamp.
3.DoNOTscrewthelampinbyholdingontotheglasstubes,holdontotheplasticbasetoscrewthelampin.
4.Iftheunithason/off switches make sure these are in the off position beforepluggingthesystemintotheoutlet.

Page 6
TROUBLESHOOTING… IF YOUR FIXTURE DOES NOT WORK:
1. CHECKYOURELECTRICALSOURCE:Makesuretheunitispluggedinproperlyandthatthebreakerisnottripped
 orfuseblown.
2. CHECKTHELAMP:Makesurethelampisscrewedinalltheway.
3. FORT5FLUORESCENTFIXTURES:Checktoensurelampsareproperlylockedintoplace.Thisisaccomplishedby
 turningthelamps¼turnineitherdirection.
4. Tryadifferentlampifyouhaveoneavailable.Makesureunitisunpluggedwhenchanginglamps.
5. Makesureyouhavethecorrectlampforyourballast,i.e.anHPSlampwillnotignitewithaMHballast.
6.MVP™(MultiVoltPowerCord):WhenusingaMVP™plug,onlyusetheonedistributedwiththeunitor
 purchasedatoneofourAuthorizedRetailers.DONOTmakeanychangestothePowerCord.ThiswillVOID
 thewarranty.
Potential Fixture FAQ’s
Symptom: My ballast is humming but the light isn’t coming on.
Solution: Theremaybeacoupleofreasonsforthis:1)thelampisnotscrewedintightenough,or2)thelamp
isdefective.Pleaseallow5-10minutesforlampstoinitiallyignite.Ifthisdoesnotsolvetheproblem,returnthe
unittothedealerfortesting.
HEIGHT ADJUSTMENTS FOR VARIOUS WATTAGES
LOW WATT SYSTEM
MEDIUM WATT SYSTEM
HIGH WATT SYSTEM
Minimum 12” - 24”
Minimum 12” - 36”
Minimum 18” - 48”
COVERAGE AREA
AuorescentxturecanbeplacedmuchclosertoplantsthananH.I.D.xturebecauseitproducesverylittleheat.
Youshouldplaceyouruorescentlightsasclosetothetopsofyourplantsasyoucanwithoutexcludingtheoutside
perimeterofyourgarden.
H.I.D. AVERAGE COVERAGE AREA BY WATTAGE
150/175 watts covers approximately 2’ x 2’ area
250 watts cover approximately 3’ x 3’ area
400 watts covers approximately 4’ x 4’ area
600 watts covers approximately 6.5’ x 6.5’ area
1000 watts covers approximately 8’ x 8’ area
NOTE: Coverage area may be reduced if this is your primary light source.

Page 7
Symptom: My ballast makes an excessive amount of noise.
Solution:Keepinmindthatthehigherthewattage,thelouderthehummingnoiseemitted.However,ifthenoise
levelisextreme,thetransformermayhavecomeloose.Inthiscase,theballastunitshouldbereturnedtoSunlight
Supply®,Inc.forrepairifitisstillunderwarrantyandhasbeenusedundernormaloperatingconditions.
Symptom: Every time I turn on the light fixture, the circuit breaker trips.
Solution:Youmayhavetoomanyappliancesonthiscircuit.Anormalhome’scircuithasonly15ampsavailable.
TheseH.I.D.lightsuseupto10ampsperunit.Pleasemakesureyouarenotoverloadingthecircuitwithtoomany
appliancesand/orlights.Note:Thestickerontheballastwillstatethenumberofampsrequiredbythatparticular
unit.Ifyoudorequiremorelights/appliancestoallberunoffthesamecircuit,youshouldconsultanlicensed
Electrician.
Symptom: I turned off my HID light and now it won’t come back on.
Solution:Yourlampmaytakeupto20minutestocooldownbeforeitcanberedupagain.Fluorescentlamps
shouldbealmostimmediate.
Symptom: My lamp has small pieces of glass inside of it.
Solution:Itiscommonforsmallpiecesofglasstobreaklooseinsidethelamps;thiswillnotaffectthelamps
output.Ifthereisacrackorholeintheouterglass,itshouldbereplaced.
IF NONE OF THE ABOVE PROCEDURES HELP, PLEASE CONTACT
THE RETAIL STORE WHERE YOU PURCHASED THE UNIT.
How do I know my lamps are functioning normally?
FACTS about HID and FLUORESCENT LAMPS:
• ItmaytakeHIDorT5uorescent10-15minutestocometofullbrightness.
• HID:Duringtherstfewhoursofuse,thelightfromthelampmightoscillate.
• HID:Thelightwilldecreaseinintensityduringthelifeofthelamp.
• HID:Duringthersthours,intensityofthelightmayuctuatesomewhat,whichisnormal.Howeverafteritreaches
 100hoursof“burnin”time,willcontinueevenlytheremainderofit'slife(withnormalagingreduction).
• Both:AveragelifeofaMH(metalhalide)lampis12,000hoursfora1000wattlampand20,000hoursfora400
 wattlamp.TheratedhourlifeofaHPSlampis24,000hours.Mostuserschoosetoreplacelampsbeforethey
 ceasetooperateduetolumenlossandspectralshift.T5uorescentlampsofferaratedhourlifeof20,000hours
 andhaveamuchslowerlumenlossandspectralshiftthanHIDlamps.
POWER USAGE:
Onaverage,alightsystemwillincreaseyourelectricitycostfrom$8to$20permonth—theexactamountdepends
onthesizeofthesystemandthenumberofhoursoperated.However,sincethesegrowlightsaresoenergyef-
cient,youaregettinghugeamountsoflight(andgrowingpower)foryourmoney!Makesureyourgrowroom’s
powercircuitcanhandlethepowerdraw.Forsafetyreasons,donotexceed75%oftheratedabilityofthefuse/
breaker(forexample:usenomorethan15ampsona20ampcircuit).Tocalculateyourcost,multiplythebulb
wattageXhoursofoperationanddivideby1000.Thisgureisthenumberofkilowatthoursofelectricityconsumed.
(Example:a400wattbulbrunningfor18hourswilluse7.2kilowatthours).Checkyourpowerbillforthecostof
eachkilowatthour.Thenmultiplythenumberofkilowatthoursbythecostofakilowatthour(K/hr)toarriveat
thecostpermonthtorunthelightinyourarea.

Page 8
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX117WATTS*÷1000X$.04PERKWHX30DAYS=$.84
6HRSX30DAYS $0.84 $1.26 $1.68 $2.11 $2.53 $2.95 $3.37 $3.79 $4.21 $4.63 $5.05 $5.48
8HRSX30DAYS $1.12 $1.68 $2.25 $2.81 $3.37 $3.93 $4.49 $5.05 $5.62 $6.18 $6.74 $7.30
10HRSX30DAYS $1.40 $2.11 $2.81 $3.51 $4.21 $4.91 $5.62 $6.32 $7.02 $7.72 $8.42 $9.13
12HRSX30DAYS $1.68 $2.53 $3.37 $4.21 $5.05 $5.90 $6.74 $7.58 $8.42 $9.27 $10.11 $10.95
14HRSX30DAYS $1.97 $2.95 $3.93 $4.91 $5.90 $6.88 $7.86 $8.85 $9.83 $10.81$11.79 $12.78
16HRSX30DAYS $2.25 $3.37 $4.49 $5.62 $6.74 $7.86 $8.99 $10.11$11.23$12.36$13.48 $14.60
18HRSX30DAYS $2.53 $3.79 $5.05 $6.32 $7.58 $8.85 $10.11 $11.37$12.64$13.90 $15.16 $16.43
*A108wattlightingxtureuses117wattsperhour.For use with the Tek-Light™ 42, New Wave
®
42 & Ready Fit
®
4 ft.
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX165WATTS*÷1000X$.04PERKWHX30DAYS=$1.19
6HRSX30DAYS $1.19 $1.78 $2.38 $2.97 $3.56 $4.16 $4.75 $5.35 $5.94 $6.53 $7.13 $7.72
8HRSX30DAYS $1.58 $2.38 $3.17 $3.96 $4.75 $5.54 $6.34 $7.13 $7.92 $8.71 $9.50 $10.30
10HRSX30DAYS $1.98 $2.97 $3.96 $4.95 $5.94 $6.93 $7.92 $8.91 $9.90 $10.89 $11.88 $12.87
12HRSX30DAYS $2.38 $3.56 $4.75 $5.94 $7.13 $8.32 $9.50 $10.69$11.88$13.07$14.26 $15.44
14HRSX30DAYS $2.77 $4.16 $5.54 $6.93 $8.32 $9.70 $11.09 $12.47$13.86$15.25$16.63 $18.02
16HRSX30DAYS $3.17 $4.75 $6.34 $7.92 $9.50 $11.09 $12.67 $14.26$15.84$17.42 $19.01 $20.59
18HRSX30DAYS $3.56 $5.35 $7.13 $8.91 $10.69$12.47 $14.26 $16.04$17.82$19.60$21.38 $23.17
*A150wattlightingxtureuses165wattsperhour.For use with the Sun System
®
4 & Sun System HPS 150.
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX52WATTS*÷1000X$.04PERKWHX30DAYS=$.37
6HRSX30DAYS $0.37 $0.56 $0.75 $0.94 $1.12 $1.31 $1.50 $1.68 $1.87 $2.06 $2.25 $2.43
8HRSX30DAYS $0.50 $0.75 $1.00 $1.25 $1.50 $1.75 $2.00 $2.25 $2.50 $2.75 $3.00 $3.24
10HRSX30DAYS $0.62 $0.94 $1.25 $1.56 $1.87 $2.18 $2.50 $2.81 $3.12 $3.43 $3.74 $4.06
12HRSX30DAYS $0.75 $1.12 $1.50 $1.87 $2.25 $2.62 $3.00 $3.37 $3.74 $4.12 $4.49 $4.87
14HRSX30DAYS $0.87 $1.31 $1.75 $2.18 $2.62 $3.06 $3.49 $3.93 $4.37 $4.80 $5.24 $5.68
16HRSX30DAYS $1.00 $1.50 $2.00 $2.50 $3.00 $3.49 $3.99 $4.49 $4.99 $5.49 $5.99 $6.49
18HRSX30DAYS $1.12 $1.68 $2.25 $2.81 $3.37 $3.93 $4.49 $5.05 $5.62 $6.18 $6.74 $7.30
*A48wattlightingxtureuses52wattsperhour.For use with the New Wave
®
22, Sun Blaze
®
22 & Ready Fit
®
2 ft.
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX104WATTS*÷1000X$.04PERKWHX30DAYS=$.75
6HRSX30DAYS $0.75 $1.12 $1.50 $1.87 $2.25 $2.62 $3.00 $3.37 $3.74 $4.12 $4.49 $4.87
8HRSX30DAYS $1.00 $1.50 $2.00 $2.50 $3.00 $3.49 $3.99 $4.49 $4.99 $5.49 $5.99 $6.49
10HRSX30DAYS $1.25 $1.87 $2.50 $3.12 $3.74 $4.37 $4.99 $5.62 $6.24 $6.86 $7.49 $8.11
12HRSX30DAYS $1.50 $2.25 $3.00 $3.74 $4.49 $5.24 $5.99 $6.74 $7.49 $8.24 $8.99 $9.73
14HRSX30DAYS $1.75 $2.62 $3.49 $4.37 $5.24 $6.12 $6.99 $7.86 $8.74 $9.61 $10.48 $11.36
16HRSX30DAYS $2.00 $3.00 $3.99 $4.99 $5.99 $6.99 $7.99 $8.99 $9.98 $10.98 $11.98 $12.98
18HRSX30DAYS $2.25 $3.37 $4.49 $5.62 $6.74 $7.86 $8.99 $10.11$11.23$12.36 $13.48 $14.60
*A96wattlightingxtureuses104wattsperhour.For use with the New Wave
®
24 & Sun Blaze
®
24.

Page 9
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX234WATTS*÷1000X$.04PERKWHX30DAYS=$1.68
6HRSX30DAYS $1.68 $2.53 $3.37 $4.21 $5.05 $5.90 $6.74 $7.58 $8.42 $9.27 $10.11 $10.95
8HRSX30DAYS $2.25 $3.37 $4.49 $5.62 $6.74 $7.86 $8.99 $10.11$11.23$12.36$13.48 $14.60
10HRSX30DAYS $2.81 $4.21 $5.62 $7.02 $8.42 $9.83 $11.23 $12.64$14.04$15.44 $16.85 $18.25
12HRSX30DAYS $3.37 $5.05 $6.74 $8.42 $10.11$11.79 $13.48 $15.16$16.85$18.53 $20.22 $21.90
14HRSX30DAYS $3.93 $5.90 $7.86 $9.83 $11.79$13.76 $15.72 $17.69$19.66$21.62 $23.59 $25.55
16HRSX30DAYS $4.49 $6.74 $8.99 $11.23$13.48$15.72 $17.97 $20.22$22.46$24.71 $26.96 $29.20
18HRSX30DAYS $5.05 $7.58 $10.11$12.64$15.16$17.69 $20.22 $22.74$25.27$27.80 $30.33 $32.85
*A216wattlightingxtureuses234wattsperhour.For use with Tek-Light™ 44, New Wave
®
44 & Sun Blaze
®
44.
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX275WATTS*÷1000X$.04PERKWHX30DAYS=$1.98
6HRSX30DAYS $1.98 $2.97 $3.96 $4.95 $5.94 $6.93 $7.92 $8.91 $9.90 $10.89 $11.88 $12.87
8HRSX30DAYS $2.64 $3.96 $5.28 $6.60 $7.92 $9.24 $10.56$11.88$13.20$14.52$15.84 $17.16
10HRSX30DAYS $3.30 $4.95 $6.60 $8.25 $9.90 $11.55 $13.20 $14.85$16.50$18.15$19.80 $21.45
12HRSX30DAYS $3.96 $5.94 $7.92 $9.90 $11.88$13.86 $15.84 $17.82$19.80$21.78 $23.76 $25.74
14HRSX30DAYS $4.62 $6.93 $9.24 $11.55$13.86$16.17 $18.48 $20.79$23.10$25.41 $27.72 $30.03
16HRSX30DAYS $5.28 $7.92 $10.56$13.20$15.84$18.48 $21.12 $23.76$26.40$29.04 $31.68 $34.32
18HRSX30DAYS $5.94 $8.91 $11.88$14.85$17.82$20.79 $23.76 $26.73$29.70$32.67 $35.64 $38.61
*A250wattlightingxtureuses275wattsperhour. For use with Sun System
®
2 & 4.
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX460WATTS*÷1000X$.04PERKWHX30DAYS=$3.31
6HRSX30DAYS $3.31 $4.97 $6.62 $8.28 $9.94 $11.59 $13.25 $14.90 $16.56 $18.22 $19.87 $21.53
8HRSX30DAYS $4.42 $6.62 $8.83 $11.04$13.25$15.46 $17.66 $19.87 $22.08 $24.29 $26.50 $28.70
10HRSX30DAYS $5.52 $8.28 $11.04 $13.80$16.56$19.32 $22.08 $24.84 $27.60 $30.36 $33.12 $35.88
12HRSX30DAYS $6.62 $9.94 $13.25 $16.56$19.87$23.18 $26.50 $29.81 $33.12 $36.43 $39.74 $43.06
14HRSX30DAYS $7.73 $11.59 $15.46 $19.32$23.18$27.05 $30.91 $34.78 $38.64 $42.50 $46.37 $50.23
16HRSX30DAYS $8.83 $13.25 $17.66 $22.08$26.50$30.91 $35.33 $39.74 $44.16 $48.58 $52.99 $57.41
18HRSX30DAYS $9.94 $14.90 $19.87 $24.84$29.81$34.78 $39.74 $44.71 $49.68 $54.65 $59.62 $64.58
*A400wattlightingxtureuses460wattsperhour.For use with Sun System
®
1, 2, 4, 6, 10 Harvest Pro™ & Harvest Pro™ Elite.
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX196WATTS*÷1000X$.04PERKWHX30DAYS=$1.41
6HRSX30DAYS $1.41 $2.12 $2.82 $3.53 $4.23 $4.94 $5.64 $6.35 $7.06 $7.76 $8.47 $9.17
8HRSX30DAYS $1.88 $2.82 $3.76 $4.70 $5.64 $6.59 $7.53 $8.47 $9.41 $10.35$11.29 $12.23
10HRSX30DAYS $2.35 $3.53 $4.70 $5.88 $7.06 $8.23 $9.41 $10.58$11.76$12.94$14.11 $15.29
12HRSX30DAYS $2.82 $4.23 $5.64 $7.06 $8.47 $9.88 $11.29 $12.70$14.11$15.52 $16.93 $18.35
14HRSX30DAYS $3.29 $4.94 $6.59 $8.23 $9.88 $11.52 $13.17 $14.82$16.46$18.11 $19.76 $21.40
16HRSX30DAYS $3.76 $5.64 $7.53 $9.41$11.29$13.17 $15.05 $16.93$18.82$20.70 $22.58 $24.46
18HRSX30DAYS $4.23 $6.35 $8.47 $10.58$12.70$14.82 $16.93 $19.05$21.17$23.28$25.40 $27.52
*A175wattlightingxtureuses196wattsperhour.For use with the Sun System
®
4

Page 10
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX680WATTS*÷1000X$.04PERKWHX30DAYS=$4.90
6HRSX30DAYS $4.90 $7.34 $9.79 $12.24$14.69$17.14$19.58$22.03$24.48$26.93 $29.38 $31.82
8HRSX30DAYS $6.53 $9.79 $13.06$16.32$19.58$22.85$26.11$29.38$32.64$35.90 $39.17 $42.43
10HRSX30DAYS $8.16 $12.24 $16.32$20.40$24.48$28.56$32.64$36.72$40.80$44.88 $48.96 $53.04
12HRSX30DAYS $9.79 $14.69 $19.58$24.48$29.38$34.27$39.17$44.06$48.96$53.86 $58.75 $63.65
14HRSX30DAYS $11.42 $17.14 $22.85$28.56$34.27$39.98$45.70$51.41$57.12$62.83 $68.54 $74.26
16HRSX30DAYS $13.06 $19.58 $26.11$32.64$39.17$45.70$52.22$58.75$65.28$71.81 $78.34 $84.86
18HRSX30DAYS $14.69 $22.03 $29.38$36.72$44.06$51.41$58.75$66.10$73.44$80.78 $88.13 $95.47
*A600wattlightingxtureuses680wattsperhour.For use with Sun System
®
1, 10, Harvest Pro™ & Harvest Pro™ Elite.
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX1100WATTS*÷1000X$.04PERKWHX30DAYS=$7.92
6HRSX30DAYS $7.92 $11.88$15.84$19.80$23.76$27.72$31.68 $35.64 $39.60 $43.56 $47.52 $51.48
8HRSX30DAYS $10.56$15.84 $21.12$26.40$31.68$36.96$42.24 $47.52 $52.80 $58.08 $63.36 $68.64
10HRSX30DAYS $13.20$19.80 $26.40$33.00$39.60$46.20$52.80 $59.40 $66.00 $72.60 $79.20 $85.80
12HRSX30DAYS $15.84$23.76 $31.68$39.60$47.52$55.44$63.36 $71.28 $79.20 $87.12 $95.04 $102.96
14HRSX30DAYS $18.48$27.72 $36.96$46.20$55.44$64.68$73.92 $83.16 $92.40 $101.64$110.88$120.12
16HRSX30DAYS $21.12$31.68 $42.24$52.80$63.36$73.92$84.48 $95.04 $105.60$116.16$126.72$137.28
18HRSX30DAYS $23.76$35.64 $47.52$59.40$71.28$83.16$95.04$106.92$118.80$130.68$142.56$154.44
*A1000wattlightingxtureuses1100wattsperhour.For use with Sun System®1, 6, 10, Harvest Pro™ & Harvest Pro™ Elite.
POWER COST ESTIMATION GUIDE PER MONTH (ASSUMES 30 DAY MONTH)
COSTPERKW/HR 4¢ 6¢ 8¢ 10¢ 12¢ 14¢ 16¢ 18¢ 20¢ 22¢ 24¢ 26¢
HRS.PERDAYX30DAYS EXAMPLE:6HRSX468WATTS*÷1000X$.04PERKWHX30DAYS=$3.37
6HRSX30DAYS $3.37 $5.05 $6.74 $8.42 $10.11$11.79 $13.48 $15.16$16.85$18.53$20.22 $21.90
8HRSX30DAYS $4.49 $6.74 $8.99 $11.23$13.48$15.72 $17.97 $20.22$22.46$24.71 $26.96 $29.20
10HRSX30DAYS $5.62 $8.42 $11.23 $14.04$16.85$19.66 $22.46 $25.27$28.08$30.89$33.70 $36.50
12HRSX30DAYS $6.74 $10.11 $13.48 $16.85$20.22$23.59 $26.96 $30.33$33.70$37.07$40.44 $43.80
14HRSX30DAYS $7.86 $11.79 $15.72 $19.66$23.59$27.52 $31.45 $35.38$39.31$43.24$47.17 $51.11
16HRSX30DAYS $8.99 $13.48 $17.97 $22.46$26.96$31.45 $35.94 $40.44$44.93$49.42$53.91 $58.41
18HRSX30DAYS $10.11$15.16 $20.22 $25.27$30.33$35.38 $40.44 $45.49$50.54$55.60$60.65 $65.71
*A432wattlightingxtureuses468wattsperhour.For use with Tek-Light™ 48, New Wave
®
48 & Sun Blaze
®
48.
