Sunlover SL8-RTS User manual

SL8-RTS – INSTRUCTIONS
Page 1 of 4
CONTROLLER MOUNTING:
The controller enclosure must be f rmly attached to a nearby sol d f xture by e ther the two mount ng lugs or d rect
attachment though the controller. If mount ng through the controller ensure the power cord s d sconnected from
the ma ns supply then remove the enclosure front cover by turn ng the four corner locks so each arrow po nts to
the ‘O’ marked on the front cover. Insert two mount ng screws d agonally through the oval holes n the enclosure,
ref t front cover and turn the four corner locks to the ‘I’ pos t on.
The power cable s 1.8m long and should be plugged d rectly nto a general power outlet, not nto an extens on
lead.
CIRCULATING PUMP(S):
The solar c rculat ng pump plugs nto the r ght hand 240Vac socket marked as SOLAR PUMP. The F ltrat on pump
plugs nto the left hand 240Vac socket marked as AUXILIARY.
The AUX ON. LED w ll be l t when the f ltrat on pump s operat ng and the SOLAR ON LED w ll be l t f the solar
pump s operat ng. The maximum allowable combined current for both pumps is 10 AMPS @ 2400W
Th s controller can be conf gured for the solar pump to be ndependent (std) or n ser es w th the f ltrat on pump
(retro-f t) for ser es retro-f t the solar pump s plumbed v a a T-p ece after the f lter.
TEMPERATURE SENSORS:
For retro-f t systems the pool sensor must be f tted n the suct on l ne before the take off Tee f tt ng for the solar
boost pump. For ndependent (standard) systems the pool sensor must be f tted nto the suct on l ne of the solar
boost pump, preferably n a pos t on out of d rect sunl ght. It s recommended that a 14.5mm hole be dr lled n the
PVC p pe, th s can be carr ed out us ng a Dontek PD01 gr nd ng dr ll or a small p lot hole can be dr lled and a
14.0mm dr ll-b t used sp nn ng n a counter clockw se d rect on to m n m ze the chance of shatter ng p pe. Insert
the grommet nto the p pe and gently push n the black sensor barb. The green sensor plug s to be f tted to the
plug socket marked POOL.
Roof sensor must be f tted nto a small p ece of rubber collector mater al away from the ma n collector but on the
same aspect. Keep n m nd that t s of the utmost mportance to keep the roof sensor cable as short as poss ble
as th s w ll ass st n the longev ty of the sensor and controller n the event of electr cal storm act v ty and power
surges. Sensor cables must not be run parallel to power cables and run lengths should be less than 50m. Cable
t es should be used to fasten the sensor cable to the cold water nlet p pe mak ng sure that the t es are
approx mately 10mm from PVC f tt ngs. Cable t es should be t ghtened only f rm, over t ghten ng can cause breaks
n the outer PVC f not careful. If the cable s to be run under ground a condu t should be used to protect the w re
and there s to be no cable jo ns w th n, condu t ends must be sealed to prevent water ngress Any excess cable
should be removed and re-fitted ensuring that the wire ends are tinned with solder The sensor plug s to be f tted
to the r ght hand socket marked ROOF.
DESCRIPTION:
The SL8-RTS s a solar controller that heats us ng a solar collector.
Solar & F ltrat on are all controlled by the t me clock and the r relevant sett ngs, heat ng s performed to the
temperature l m t plus ½°C and once that temperature s ach eved heat ng w ll no re-occur unt l the temperature
drops below the des red l m t by ½°C or unt l the 3 hour sample per od has elapsed and the temperature s at or
below the l m t. Th s controller s des gned for standalone operat on or for a retro-f t nstallat on where separate
plumb ng for the solar pump s not ava lable. In retro-f t the solar can be locked to f ltrat on to control the level of
chlor nat on.
SETTINGS MENU:
All tems on the LCD that flash are adjustable tems, use the Up or Down buttons to mod fy the adjustable tem.
Press Enter to accept the adjustable value.
To enter the SETTINGS MENU push e ther the up or down buttons and the follow ng w ll be d splayed;
SETTINGS MENU
1) MANUAL MODE
All menu tems are shown below, use the Up or Down buttons to scroll to d fferent tems n the menu;
SETTINGS MENU
1) MANUAL MODE
2) FILTER TIMER
3) TEMPERATURES
4) SOLAR MODE
5) SYSTEM SETUP
6) SAVE & EXIT
1) MANUAL MODE
MANUAL PUMP 24HR
UP=ON DOWN=OFF
MANUAL MODE allows you to manually set the aux pump (f ltrat on) to ‘on’ by press ng the Up button or ‘off’ by
press ng the Down button. In manual mode the heater and solar pump and valve are sw tched off.
Press ng Enter w ll return you to the SETTINGS MENU. You can also keep press ng Enter to toggle the f lter pump
from ‘on’ to ‘off’ and v ce versa. If any of the buttons are not pushed then the un t returns to automat c operat on
after 24 hours.

SL8-RTS – INSTRUCTIONS
Page 2 of 4
2) FILTER TIMER
When the FILTER TIMER s selected the follow ng s d splayed;
SINGLE CYCLE
DUAL CYCLE
Select SINGLE CYCLE or DUAL CYCLE, S ngle Cycle runs the f ltrat on once per day, Dual Cycle runs the f ltrat on
tw ce per day.
S ngle & Dual cycle sub menu; Dual cycle sub menu;
FILTER CYCLE FILTER CYCLE 2 d FILTER CYCLE 2 d FILTER CYCLE
START TIME x:xx END TIME x:xx START TIME x:xx END TIME x:xx
Adjust the start t me and end t me for f lter cycle 1; f dual cycle was selected then also adjust the start and end
t me for the 2nd cycle.
Note1: that if dual cycle is selected, take care not to overlap the 2nd filter times with the first filter times as the
result will be one cycle per day
Note2: If a 24 hour filtration is required then set a single cycle with the start & end times the same (E g 12:00 –
12:00)
Note3: If the unit is configured as a retro-fit and solar is not locked to the filter pump (i e filter timer and/or aux
heating requirements) then any solar gain will force the filter pump to also turn on
Note4: Aux heater requirements will also override the filtration timer
Note5: In winter mode the 2
nd
filter cycle does not run
**Factory Default is ON, SINGLE CYCLE from 09:00 to 17:00
3) TEMPERATURE
TEMPERATURE
SOL LIMIT xx.x°
When you enter the TEMPERATURE menu you may adjust the solar heater temperature l m t sett ng (SOL LIMIT).
4) SOLAR MODE
MODE MODE MODE
SUMMER MODE AUTO WINTER MODE TROPICAL MODE
SUMMER MODE s the normal operat on of heat ng the sw mm ng pool.
TROPICAL MODE s selected f you w sh to cool the sw mm ng pool, the solar pump w ll run f the roof temperature
s colder than the pool unt l SOL LIMIT s obta ned; note that th s s most l kely to occur at n ght. Select ng trop cal
mode also gnores solar lockout t mes and lock to f lter sett ngs.
WINTER MODE, when selected you w ll be prompted to select the start month of w nter and the start month of
summer, the purpose of the w nter mode of operat on s for off-season ma ntenance or f pool heat ng s not
requ red (AWAY MODE). Th s s a better opt on than turn ng off the controller as t w ll flush treated pool water
through the solar system as well as prolong pump bear ng and mechan cal seal l fe. The pump w ll run for 3
m nutes each day from between 10:00 and 16:00 prov d ng the roof temperature s equal or greater than the
pool, but f that cond t on does not occur a solar system flush w ll be forced to occur at 16:00.
**Factory default for solar mode is SUMMER MODE
5) SYSTEM SETUP
4 opt ons are ava lable under system setup, SET SYSTEM CLOCK, FACTORY SETTINGS, INSTALLER SETUP,
TEMPERATURE LOG a d EXIT.
EXIT - w ll return you to 5) SYSTEM SETUP w th no changes.
SET SYSTEM CLOCK – allows you to adjust calendar and t me of day.
FACTORY SETTINGS – restores ALL the sett ngs to the factory default state.
TEMPERATURE LOG – Logs m n/max temperatures & t me, NO support s offered for th s feature.
INSTALLER SETUP –
Th s sub-menu s for nstallers ONLY, plumb ng conf gurat on, valve use, lock solar to f lter pump, solar start and
end t me, start and end temperature d fferent als can all be adjusted.
PLUMBING CONFIG: - Two opt ons are ava lable;
Independent – Solar pump has ts own suct on & return l nes and operates w thout overr d ng the f ltrat on pump,
when th s plumb ng conf gurat on s selected you can then choose when the hour the solar pump s allowed to start
and the hour at wh ch t s forced to stop, you can also choose to mod fy the d fferent als, the start d fferent al s
the temperature r se the roof needs above the pool temperature to start the pump, the end d fferent al stops the
pump when the roof drops below the pool temperature plus the end d fferent al.
Ser es Retro – th s s where the solar pump s n ser es w th the f ltrat on pump, when th s plumb ng conf gurat on
s selected you can then select wether to lock the solar operat on to the f lter pump (locks to the f lter t mer) or f
not you can choose the start and end hour of the solar, you can then choose to mod fy the d fferent als (as
descr bed for Independent systems)
SETTING THE PLUMBING CONFIGURATION TO THE WRONG SETTINGS MAY DAMAGE PUMPS AND/OR
PLUMBING!
**Factory default for installer setup is plumbing set to series retro-fit, locked to filter, solar allowed to start at
09:00, forced to end at 17:00, Start Differential of 8°C End differential of 4°C

SL8-RTS – INSTRUCTIONS
Page 3 of 4
) SAVE & EXIT
When th s menu s selected, push Enter to save ALL sett ngs, the un t w ll return to normal automat c operat on.
Note: If any of the menu tems are left unattended for 3-4 m ns the menu w ll t me out and automat cally save all
sett ngs and return to operat on.
The ENTER/MANUAL button
FOR MANUAL MODE
PRESS ENTER NOW
Press ng the Enter button once w ll d splay the above message for ~3 seconds, to prevent acc dental manual mode
f ENTER s not pressed aga n w th n the 3 second per od then the controller w ll revert to automat c operat on (and
t w ll cancel any pump lockout delays).
If Enter s pressed for a second t me w th n a 3 second per od, the d splay w ll nd cate you have entered Manual
mode, operat on s the same as manual mode n the sett ngs menu w th the only d fference be ng the t meout
value s 4 Hours.
NOTES.
1. If a sensor fault s detected the SL8 w ll d splay wh ch sensor and what the fault s.
2. Should power be nterrupted for any reason, the SL8 w ll resume normal operat on when power s restored, all
nformat on w ll have been kept.
3. Temperature sensors used w th th s un t are D g tal and are accurate to 0.5 Deg. C, no cal brat on s requ red.
4. The sensor cable w th the th n trace s the pos t ve and s usually f tted to the r ght hand s de of the green plug,
ncorrect polar ty w ll be d splayed.
5. The heater nterlock sw tch ng s used the max mum load s 5A at 32Vac max.

SL8-RTS – INSTRUCTIONS
Page 4 of 4
WARRANTY
This product is covered by a limited 3 year warranty against component failure or
faulty workmanship from the date of installation.
A faulty unit should be returned in the first instance to the dealer from which the
unit was purchased.
Damage to the unit due to misuse, power surges, lightning strikes or installation
that is not in accordance with the manufacturer’s instruction may void the
warranty.
Warranty does not cover travel costs to or from installation site. nit must be
returned to manufacturer for repairs.
If the power cord is damaged, do not use the controller; return the unit to the
supplier for repair.
Customer Record. (To be retained by the customer);
Dealer/Installer Name ___________________________
Serial Number ___________________________
Date Installed ___________________________
For service assistance phone S NLOVER HEATING
VIC 03 9887 2131
NSW 02 9838 0000
QLD 07 5597 7360
Factory 6
62 Parkhurst Drive, 7-9 Activity Crescent,
Knoxfield 3153 Molendinar 4214
Victoria Australia Queensland Australia
nit 2
20-22 Foundry Road,
Seven Hills 2147
NSW Australia
www.sunloverheating.com.au
