Sunmaster XS6500 Original operating instructions

Quick installation Sunmaster XS6500 English
Mastervolt International B.V, P.O.Box 22947, NL-1100 DK Amsterdam, The Netherlands. Tel.: [phone] Email: [email protected] Web: www.mastervolt.com v1.0 070507EN
6Close the connection compartment; Steps:
1 Tighten the two Philips screws (a)
2 Tighten the cable glands (b)
a
b
4 Loosen the two Phillips screws (a) and the two
clips (b) at the bottom side of the cabinet. Then
remove the bottom plate of the Sunmaster.
.b
.a
See chapter 3.6 for specifications of the solar
system. Make sure the DC-Switch is in the
OFF position. Then connect the string cabling
to the Sunmaster
7
Please turn page for commissioning instructions
SOLAR 1 SOLAR 2
3 Fix the mounting bracket to the wall
Then place the Sunmaster over the mounting
bracket and then move it downwards until it is
locked by the mounting bracket
This section provides a brief overview
of a basic stand-alone installation of
the Sunmaster XS6500. 5See chapter 3.4 for specifications of the AC
wiring. Feed the AC wiring through the left
hand cable glad of the bottom plate and
connect the wiring to the screw terminals
1
However; please review the entire manual for
additional features and connection diagrams and to
ensure best performance and years of trouble-free
service.
All electrical systems (DC and AC)
must be disconnected from any
power source during the entire
installation! Use isolated tools!
2
Read safety instructions (chapter 2
of the user’s manual)

Commissioning Sunmaster XS6500 English
Mastervolt International B.V, P.O.Box 22947, NL-1100 DK Amsterdam, The Netherlands. Tel.: [phone] Email: [email protected] Web: www.mastervolt.com v1.0
070507EN
Now the Sunmaster switches on. This may
take up to 5 minutes.
See user’s manual for operation instructions
8
7
Confirm your selection by
pressing S3 (or cancel by
pressing S4)
S4
S3
If a wrong country code was entered, you can start the
procedure over again by pressing S2 and S4
simultaneously for three seconds.
6
If the correct country code is shown
(example: Italy), press S2 to select
S2
5
Press S4 repeatedly to scroll
through the country codes
S4
1
To check the correct operation of the Sunmaster,
commissioning should be carried out during daytime
only
4 Select the applicable country code from the
table below
Country code Allowed to be used in
DEFAULT
GERMANY 1P Germany, Austria
GERMANY 3P Germany
SPAIN Spain
ITALY Italy
KOREA South Korea
NETHERLAND Netherlands
ENGLAND United Kingdom
FRANCE France
BELGIUM Belgium
AUSTRALIA Australia
GREECE Greece
USA 240V USA (Split Phase 240V)
USA 208V USA (Three phase 208V)
TAIWAN Taiwan
Check all wiring. If the wiring is OK:
2 1 Switch on the AC grid
2 Move the DC-switch of the solar array to
the ON position (or “1”-position)
3
S1 S2
S3 S4
After +/- 10 seconds COUNTRY is shown
on the display
