SunMaxx Solar TitanPower Plus-SU2 Collector User manual

SunMaxx Solar | Flush Mounting
ConnectMaxx Mounting Systems
Installation Instructions
TitanPower Plus-SU2 Collector
Flush Mounting

SunMaxx Solar | Flush Mounting
General mounting and security advice
To avoid optical interferences (fog, condensate) the TitanPower Plus-SU2 collector must be mounted at an
angle between 35 and 75 degrees. For the collector warranty to apply this must be applied.
Statics:
An adequate load capacity of the roof construction must be taken in consideration, because the connection
parts are fixed to the roof structure. In case of specific loads, high wind and/or snow pressures the valuation
of an expert has to be obtained. Please observe the local codes and rules for roof installations.
Lightning protection:
All metallic parts of the solar system must be connected to the ground by a copper cable with an area of at
least 16mm2(AWG 5). If lightning protection is already in place the collector system can be connected
directly to it.
Protection against dirt and injury:
Never carry collectors at the pipe ends. Keep dry and clean! Don’t store collectors outdoors!
Rinsing, filling and maintenance:
During installation and setup of the collectors keep them covered to prevent damages. Please consider the
national rules and manufacturer instructions for the use of propylene glycol. Use only water-glycol mixtures
that are appropriate for solar thermal systems.
Operating parameters, maintenance:
The recommended operating pressure should be in a range between 36.3 and 43.5 PSI. The volumetric flow
rate is suggested between 5.28 and 18.5 gallons per 10.76 square feet per hour. Highest approved working
pressure is 47 psi. Solar collectors are usually maintenance-free but the solar system should be checked for
damages and irregularities yearly by a solar thermal installer.
Transport and handling:
Carry collectors with the glass side facing up. Don’t damage the pipe ends. Don’t throw any materials at the
glass plate and be careful of the glass edges. Never touch pipes in case of solar radiation to avoid the risk of
a severe burn
General:
The references shown make no pretence on completeness. In all cases you must comply with the national
rules for mounting, installing and operation of a solar system.

SunMaxx Solar | Flush Mounting
Technical data
TitanPower Plus-SU2:
Dimensions: 79.4 x 38.78 x 3.03inch
Gross area: 21.42ft²
Aperture area: 20.17ft²
Dry Weight: 74.96 lbs
Liquid capacity: 0.26 gallons
Area needed for collector field
Attention: Circumferential additional approximately 5.91”of space is needed
Pressure Loss
Tm=20°C
Flow [l/h]
0
50
100
150
200
250
Pressure Loss [Pa]
0
564
1168
1811
2493
3215
Number of Collectors
Field Length
[inch]
1
38.78
2
78.82
3
118.86
4
158.89
5
198.94
6
238.98
7
279.02
8
319.06
9
359.09
10
399.13
TitanPower Plus-SU2
985mm / 38.78inch
2017mm / 79.4inch
TitanPower Plus-SU2
32mm 1.26inch
2017mm / 79.41inch
Field Length

SunMaxx Solar | Flush Mounting
Flush Mounting Parts List
Component quantites vary depending how many collectors are being installed in series.
Component SKU
Description
ConnectMaxx-15100096
Socket Head Cap Screw M8x22
ConnectMaxx-18000305
End Cap PP, 40x40mm
ConnectMaxx-74010701-2120
Mounting Rail Medium 40x40, 7ft length
ConnectMaxx-74011003
Rail Connector Fixed for 40x40mm
ConnectMaxx-74022601
Adjustable Clamping Plate
ConnectMaxx-77000500
Standard Roof Mount
ConnectMaxx-77000501
Standard Roof Mount Flashing
ConnectMaxx-72201701
Rail Clamping Washer
ConnectMaxx-SDS25412
Simpson Strong drive screw 1/4x4.5 in

SunMaxx Solar | Flush Mounting
Installing Mounting Hardware
Step 1: Plotting Mounting Coordinates
Step 2: Mounting Roof Hooks
Step 3: Attaching Rails
Step 4: Mounting the Collectors
Step 5: Connecting the Universal Connect Set
Step 6: Inserting Temperature Sensors
Roof Hooks represent an essential component of our universal roof mounting hardware. If installed correctly, the roof hook
flashing system provided by SunMaxx
Is waterproof
Is in compliance with all codes put forth by the National Roofing Contractors Association
Is secure against insects and vermin
Is capable of supporting TitanPower Plus-SU2 or ThermoPower VHP collectors at all recommended tilt angles
Will not reduce fire resistance below code
Will isolate roof and construction materials from the high temperatures generated by the collector array
Step 2: Attaching the Roof Hook to the Roof
*Roof hooks must be installed no more than 48” apart along each rail*
a. Locate the first rafter and place the roof hook on the roof. Loosen the shingle above the roof hook and
temporarily set the flashing in place. This is to make sure the placement of the roof hook is
accommodating.
b. Using the Simpson Strong Drive screws, fasten the roof hook atop the shingle. There is no need to pre-
drill holes.
c. Once again, loosen the shingle above and move flashing in place. There is no need to fasten the
flashing down with roofing nails, but using roofing caulk is optional.
d. Repeat steps 1a through 1c making sure not to exceed 48” spans.
Step 1: Plotting Mounting Coordinates
a. Decide the best position for the collector array based on shading, aesthetics, wind factors, etc.
b. Determine your collector field length using the chart on page 3
c. Taking the rafters in consideration, mark the collector field length on the roof where the top rail will
be installed. A standard chalk line should work well. Be sure to mark a level line for aesthetics.
d. Measure down the roof 79.41 inches (2017mm) from the upper line and mark a second line parallel to
the first. These two lines represent where each roof hook will be aligned and the rails will be installed.
79.41 inches
Do Not exceed 48“
1c
1d

SunMaxx Solar | Flush Mounting
Step 3: Attaching the Rails
a. Set the rail in position. The upper rail will be attached to the bottom side of the roof hook. The
lower rail will be attached to the upper side of the roof hook.
b. Place the clamping plate between the rail and roof hook. Make sure the sliding channel is face-up
and the grooved channel is facing the roof hook. Press the clamping plate into the grooved
channels.
c. Screw the M8 x 22mm socket bolt into the channel, attaching the rail to the roof hook.
d. Repeat 2a through 2c for each roof hook, making sure the rail is level.
e. Connect two rails by using the Rail Connect and M8 x 22mm bolts and attach the end caps
2b
2c
In cases where the flashing does not fit under
the above shingle, it may be necessary to
notch out the shingle.

SunMaxx Solar | Flush Mounting
3b
3c
3d
3a

SunMaxx Solar | Flush Mounting
3e
Step 4:Mounting the collectors
a. Position panel(s) on the rails.
b. If there is more than one panel, loosely connect them together. Make sure to include the graphite washer.
c. Once the panel(s) are in the desired position, attach the adjustable clamping plate to the panel using the
Hex bolts included on the ends of the collector.
d. Attach the adjustable clamping plate to the rail, using the M8x22mm bolts.
e. Make sure to return and tighten the connections between the panels.
4b
4a

SunMaxx Solar | Flush Mounting
Step 5: Connecting the Universal Connect Set
a. Left to Right - Piping from bottom left to top right
b. Right to Left - Piping from bottom right to top left.
**The Hot Supply from the collector should be the shortest pipe run**
5a
Top Left of Collector
Top Right of Collector
4c
4d

SunMaxx Solar | Flush Mounting
Bottom Left of Collector
Bottom Right of Collector
5b
Top Left of Collector
Top Right of Collector
Bottom Left of Collector
Bottom Right of Collector

SunMaxx Solar | Flush Mounting
Step 6: Inserting Temperature Sensor
a. Lightly assemble stainless steel compression nut and attach to the temperature sensor well. Insert
temperature sensor and tighten the compression nut so that the sensor wire is sealed.
