SUNON UP1 User manual

UP1
User Manual
Height-Adjustable Desk

Thank you
for choosing
Sunon Furniture!
02

Before adjusting the desk height, make sure that there is no object
to obstruct the movement of the desk during the entire height-ad-
justing process, there is at least 1” (25mm) between the desk and
the wall, and all the cables are long enough to allow for
free-movement of the desk within the adjustment range.
Pictures presented here are for illustration purposes only,your product may look different
depending on the desk type.
Note
Digital Display Height Storage Buttons
Height-adjusting Buttons Setting (Memory) Button
1
2 4
3
Programmable control panel
Outline drawing
25mm
25mm
Wall
Desk
C.
A.
B.
User ManualUP1 Height-Adjustable Desk
0201

Press and hold the down arrow to
lower the desk.
Press and hold the up arrow to
raise the desk.
Table of Contents 01. Adjust Desk Height
02
01
03
Save a Height Position
Adjust Desk Height
Overwrite a Save Height Position
04 Set Upper Stop
05 Set Lower Stop
06 Clear Lower and Upper Stops
07 Lock Control Buttons
08 Unlock Control Buttons
09
Hard Reset the Programmable Control
10
12
13
Enter into Reset Mode
Switch Between Inches and Centimeters
11
Switch Modes in Which Desk Travels
to a Saved Height
Adjust Sensitivity to an Obstruction
14
Troubleshooting
Adjust the desk to a desired height (refer to “01. Adjust desk
height”).
Press “M” button and release
it when the display reads “S-”.
Suggestion：For your convenience，it is recommended to assign
“1” button to the height at which you feel most comfortable when
sitting . “2” button to the height at which you feel most comfortable
when standing.“3”“4” buttons could be assigned to any height you
desire.
02. Save a Height Position
2
1
s-
Press one of the four height storage buttons to assign and save
the current height position to it.
3
User ManualUP1 Height-Adjustable Desk
0403

If you want to adjust the saved height that has been assigned to a
specific height storage button, just follow instructions specified in “02.
Save a height position” and the previous saved height will be
overwritten by the current desk height.
Press and hold the up arrow to raise the desk to a desired height
（refer to “01. Adjust the desk height”）.
Press “M” button and release it
when the display reads “S-”.
Hold down the “M” button for 2
s until the display reads “999”,
which indicates the upper stop
is set successfully.
Hold down up arrow until the
display starts to blink.
Lower the desk to a desired height（refer to “01. Adjust desk
height”）.
Press “M” button and release it
when the display reads “S-”.
Hold the down arrow until the
display starts to blink.
Hold down “M” button for 2 s
until the display reads “000”,
which indicates lower stop is set
successfully.
03. Overwrite a Save Height Position
04. Set Upper Stop
05. Set Lower Stop
s-
s-
Press and hold for 2 s
000
Press and hold for 2 s
999
1
1
2
3
4
2
3
4
s-
s-
06. Clear Lower and Upper Stops
Press “M” button and release it
when the display reads “S-”.
s-
1
User ManualUP1 Height-Adjustable Desk
06
05

Press and hold “M” button for 8 s
when the control buttons are locked,
until the screen reads current desk
height, which indicates control
buttons are unlocked successfully.
If the desk doesn’t respond to any button operation even when the
control buttons are unlocked, the desk perhaps needs to be hard
reset.
Follow the steps below to perform hard resetting:
Press and hold down arrow
for 5 s until the display reads
“RST”.
Note: Hard resetting will not wipe the stored height position.
07. Lock Control Buttons
08. Unlock Control Buttons
09. Hard Reset the Programmable Control
Hold down “M” button for 2 s until
the display reads “555”, which
indicates the upper and lower
stops are cleared successfully.
Press and hold “M” button for 5 s until “S-” shown on the display
turns into display of current desk height.
Hold down “M” button for
another 3 s until the screen reads
“LOC”, which indicates control
buttons are locked successfully.
Press and hold for 2 s
555
Press and hold for 3 s
Press and hold for 8 s
Current height
95
Press and hold for 5 s
RST
Press and hold for 5 s
5- 95
Current height
11
2
2
Lower the desk to the lower stop.
Press and hold the down arrow for
5 s until the screen reads “RST”,
which indicates that the reset
mode is turned on successfully.
Hold down the down arrow
until the display reads the
current desk height.
10. Enter into Reset Mode
Press and hold for 5 s
RST
Current height
78
2
2
1
User ManualUP1 Height-Adjustable Desk
0807

To exit the reset mode, press
and hold the down arrow
until the display reads the
current desk height.
There are two modes in which the desk can travel to a saved
height: the intermittent movement mode and the continuous
movement mode.
In the intermittent movement mode, to adjust the desk to a saved
height, you need to press and hold a height storage button until
the desk stops adjusting itself. In the continuous movement mode,
just press a height storage button and the desk will adjust to the
saved height automatically.
Mode switch: By default, the desk is the continuous movement
mode ; However, you can switch between the two modes
following the steps below:
Enter into the reset mode (refer to “10. Enter into the reset
mode”).
Hold down the “1” button for 5 s to switch between intermit-
tent and continuous movement modes:
The readout of “10.1” denotes continuous movement mode,
and “10.2” denotes intermittent movement mode.
By default, the display reads in centimeters.
Hold and press the “2” button for 5 s to switch between inches
and centimeters: the readout of “10.3” denotes reading in
inches, and “10.4” denotes reading in centimeters.
11. Switch the Mode in Which the Desk Travels to
a Saved Height
12. Switch Between Inches and Centimeters
Current height Press and hold
78
2
2
3
1
Enter into the reset mode (refer to “10. Enter into the reset mode”).
1
Press and hold for 5 s
10.1
Press and hold for 5 s
10.2
10.1 10.2
User ManualUP1 Height-Adjustable Desk
Press and hold for 5 s
10.3
Press and hold for 5 s
10.4
10.3 10.4
1009

14. Troubleshooting
Following issues could be resolved by hard resetting the
table (refer to “06. Hard reset the programmable control”):
If the display reads “H01”,
which indicates system
overheating, please power off
the table for at least 20 mins.
If the display reads “E13”,
please power off the table
and power on it again.
13. Adjust the Sensitivity to an Obstruction
Press and hold for 5 s
The desk will automatically stop and retract slightly when sensing
an obstruction. There are three adjustable levels of sensitivity to an
obstruction .
Follow the steps below to adjust the sensitivity:
Hold and press the up arrow for 5 s to switch between three
levels of sensitivity:
User ManualUP1 Height-Adjustable Desk
RES E07
E13
H01
Enter into the reset mode (refer to “10. Enter into the reset mode”).
resistance＞10kg
resistance＞15kg
resistance＞20kg
Three level of Sensitivity switch
10.5
The table doesn’t respond to any button operation.
The display reads “RES”, “E07” or “E08”.
2
2
3
1
1
10.6
10.5
10.7
1211
