SUNON Five-layer Open Bookcase User manual

Please read this manual carefully before any operation
and keep it properly for future use.
Five-layer Open Bookcase
Assembly Manual

1
3
4
5
6
7
78
8
8
Panels
Panel List
Panels NumbersSize
6
Top Board（×1）
915*295*25mm
4
3
Side Boards（×2）
1480*294*25mm
77
Back Boards（×2）
1484*435*5mm
8 8 8
Movable Shelf Panels（×3）
862*272*18mm
1
Bottom Board（×1）
863*273*18mm
2
Base Panel（×1）
70*863*18mm
5
Fixed Shelf Panel（×1）862*273*8mm
01 02
2
Keep all parts out of the children’s reach.
WARNING
You need to have a crosshead screwdriver beforehand.
Place all the panels on a clean and smooth surface, such as a rug or
carpet, to prevent them from being scratched.
Don’t tighten screws or bolts until all the pieces are fitted.
It is recommended to have 2 persons to complete the assembly.
If you have any issue regarding the product, please contact us at
[email protected].
Make sure that all parts in your product package, including panels and
accessories, match up with those listed in the Panels & Accessories list.
NOTE
CONTACT US
crosshead screwdriver Not included in package.
NOTE
In case of any doubts,contact Sunon.
3
Handle with care,protective layer is required.
2
Safe carriage,multi-people are needed.
1
Assembly Manual

Assembly Instructions
Accessories List
Three-in-one Connector
15*32mm
A
（×13+1）
Three-in-one Connector
15*32mm
A
（×1）
Three-in-one Connector
15*32mm
A
A
C
（×8）
Pan Head Self Tapping
Screw
M3*16mm
D
（×12+1）
Back-board Slot
/
G
1
（×1）
Adjusting Pin
M8*21mm
E
（×4）
Shelf Support
5*15mm
F
（×12）
Three-in-one Connector
Cover
17.8*4.5mm
B
（×13+1）
Dowel
8*40mm
C
（×13+1）
Wood Pin
8*40mm
C
（×10）
Step 1：
Fit and fasten the Base Panel on the Bottom Board.
Step 2：
Fit and fasten the Bottom Board and fixed Panel with two Side Panels.
03 04
4
3
5
1
22
Assembly Manual

A
G
G
D
E
E
E
C
Roundhead Self-tapping
Screw
M3*16mm
D
（×12）
Back Board Slot
H1479
G
（×1）
Adjusting Pin
M8*21mm
E
（×4）
Three-in-one Connector
15*32mm
A
（×4）
Wood Pin
8*40mm
C
（×4）
Step 3：
Insert Back Board along with side slot,and connect them with
Back board slot.
05 06
6
4
3
5
1
7
7
7
7
E
Assembly Manual
Step 4：
Fit and fasten the Top Board with Side Panels.

Movable Shelf Support
5*15mm
F
（×12）
Cover for Three-in-one
Connector
17.8*4.5mm
B
（×13）
Step 5：
Put the Movable Shelf Panels in wherever you want.
Step 6：
07 08
Finished as below.
8
8
8
F
F
F
Assembly Manual
