SUNON UP1 User manual

Suite 150, Building 525 Technology Drive, Irvine, CA.92618
sunonglobal.com 949-337-8838 [email protected]
Assembly Instruction for UP1
Height-Adjustable Desk
Please read this manual carefully before any operation
and keep it properly for future use

These drawings identify the parts included with your Height Adjustable Desk. Some of these parts are
considered by regulatory bodies to be criftical components. If any parts shown here do not match
your order, please contact Sunon at 949-337-8838
Dismantling Schematic
1Cantilevers
(x2)
2Stretcher bar
(x1)
3Beams
(x2)
4Stretcher bar for control box
(x1)
9LED control handset
(x1)
5Leg columns
(x2)
6Desk Foot
(x2)
7Cable Box Cap
(x1)
8Control box
(x1)
Hardware
(Optional)
(Optional)
23 16 11
M6x14 M6x10 ST5x20
2 21
ST4.2x16 Power Cable Controller Cable
10 1
Cable Buckle M4 Allen Wrench
A1 A2 A3
D E
A4 B C
1
2
3
M
69.5

M4 Allen Wrench
(x1)
M6x10
(x8)
B
1
1.Slide leg columns into place and attach with 8 M6x10 screws.
2.Match inside holes first and lightly tighten at this point.
AM4 Allen Wrench
(x1)
2
1. Insert Cantilevers on each end, lifting the leg a bit, if needed, to ease into a flush fit. Tab
into place (fit is snug).
2. Using 4 M6x14 screws, tighten all 4 holes lightly. Once level, go back through and
tighten each screw completely.

3
Attach feet using 8 M6x14 screws. Match all 4 holes first to confirm fit before tightening completely.
M4 Allen Wrench
(x1)
4
1. Adjust to desired width, once at correct width.
2. Attach the beams using M6x10 screws.

5
1. To attach the worksurface, start by laying the worksurface down on the floor with the top down.
2. Lay the base assembly upside down on top of the worksurface.
3. Double check to ensure that the base is properly positioned on the underside of the worksurface
pre-drill screw holes, and then attach with M6x14 screws.
4. Attach the Handset on the underside of the worksurface.
M4 Allen Wrench
(x1)
(Optional)
6
1. Make sure that the both side motors plugs into the control box ports.
2. Connect power plug after the motors and handset are connected properly.
3. Reset the base by holding the down arrow button until it reaches its lowest height.
4. Attach the steel cable cap to desired area to secure cables and wires.
Power Cable
Controller Cable
ST4.2x16

Reset abnormality protection
1
2
3
M
69.5
3 level
default heights setting
up/down
desk height
1
2
3
M
69.5
long press for 5S
1
2
3
M
69.5
long press for 2S
1
2
3
M
69.5
long press for 2S
Note
Advice
Please make sure there is no obstacle during the operation, and there
is a gap between desk and wall. And all wires are long enough to allow
the up-down of desk.
Please set up as 1 the most comfortable height when you sit down,
and set up as 2 the most comfortable height when you stand up. For
the other one heights, you can choose whatever you like.
When there is something wrong with controller reported, the
digital tube shows E07-E09, Even if it has access to power after a power cut-off, it will still
give an error notice no matter what button you press.
Operation
After pressing for 5s and digital tube shows RST, release the
button and press the down button, reset will be activated.
Set up upper limit position
Press M button, the digital tube shows“S-”, then release the
button. Press the up button, the digital tube will flashonce,
release the button. Press M button again for 2s, the digital tube
shows“999”. The upper limit position has been set.
Set up lower limit position
Press M button, the digital tube shows“S-”, release the button.
Press the down button. The digital tube will flash once. Release
the button. Press down M button again for 2s, the digital tube
shows“000”. The lower limit position has been set.

1
2
3
M
69.5
long press for 5S
1
2
3
M
69.5
Normal problems and solutions
1
2
3
M
69.5
long press for 5S
Centimeter/inch display switch
Under the reset condition(digital tube shows RST), long
press“M”for 5s, you can switch between inch display
and cm display.
When it shows “10.3”, the height after reset will be
shown in cm;
When it shows“10.4”, the height after reset will be shown
in inch.
Sensitivity setting on
retreating upon obstacle
Under the reset condition (the digital tube showsRST), long
press the up button for 5S, the sensitivity can be adjusted.
switch display
“10.5”--10kg
“10.6”--15kg
“10.7”--20kg
Setting of memory position
Press M button, it shows“S-”, select and press one of the
memory buttons, current height will be remembered.
Use up/down button to get the desirable height, then
repeat the following action.
1. If your desk has the following issues, please try resetting:
• Working abnormality
• Hand controller shows RES (reset)
• Hand controller shows error (E07,E08), but motor drive wire is well connected.
2. If it shows HOT (hot), please cut off the power and allow it to cool off for 20 minutes.
1
2
3
M
69.5
long press for 8S
1
2
3
M
69.5
long press for 5S
1
2
3
M
69.5
long press for 5S
1
2
3
M
69.5
long press for 2S
Delete limit position
Press M button, the digital tube shows“S-”, release the
button. Press M button again for 2S, it shows“555".
The upper and lower limits have been deleted.
Lock
Press M button, the digital tube shows “S-”, long
press M button for 5S, the digital tube shows numbers.
Press M button for 3S, it shows LOC. The buttons on the
handcontroller are locked.
Unlock
Under the LOC condition, long press M button for 8S, it shows
numbers. Buttons on hand controller are unlocked.
Revise lowest height
Under the reset condition, it shows RST. Long press“M”button
for 5S, it shows the height after reset and twinkles. Press up or
down button to adjust to the appropriate height. 5S after
releasing the button, the digital tube will go back to RST,
which means the amendment is successful.
Switch between memory inching
/continuous moving
Under the reset condition (digital tube shows RST) Long press
button“1”for 5s, switch inching and continuous moving.
When it shows“10.1”, continuous moving.
When it shows“10.2”, inching moving.
