Sunquest 2000S User manual

Ultraviolet radiation. Follow instructions. Avoid overexposure. As with
natural sunlight, overexposure can cause eye and skin injury and
allergic reactions. Repeated exposure may cause premature aging of the skin and skin cancer.
WEAR PROTECTIVE EYEWEAR; FAILURE TO MAY RESULT IN SEVERE BURNS OR
LONGTERM INJURY TO THE EYES. Medications or cosmetics may increase your sensitivity
to the ultraviolet radiation. Consult physician before using sunlamp if you are using medications
or have a history of skin problems or believe yourself especially sensitive to sunlight. If you do
not tan in the sun, you are unlikely to tan from the use of this product. Children, the elderly, or
fair skinned people who always burn easily and either never tan or tan minimally should not use
this equipment.
To use, lie down under the canopy and pull down toward your body maintaining at least 2 inch-
es (5.1 centimeters) between your body and the wire grill, otherwise overexposure may occur.
Do not use without the wire grill in place. Untanned persons should not tan on consecutive
days during their first week of tanning. Never tan more than once a day. Tanning normally
appears after the first few sessions and maximizes after approximately four weeks. Tan once
or twice per week thereafter to maintain appearance. Persons already having a base tan may
begin at advanced levels corresponding to the extent of their base tan.
Skin Type:
ISensitive Skin (Burns easily and severely and does not tan.)
II Light Skin (Burns easily and severely and tans minimally.)
III Normal Skin (Burns moderately and tans average.)
IV Dark Skin (Burns minimally, tans easily and above average.)
New lamps emit approximately 10% more ultraviolet radiation during the first 50 hours of
operation. Recommended tanning times should therefore be reduced by approximately 10%
during that period.
WARNING:• Read these instructions before using this sunlamp product. • All persons in the
room should wear protective eyewear when lamps are on. Recommended eyewear: provided
eyeshields or equivalent eyewear as defined under 21 CFR 1040.20. Other types of eyewear
may not provide adequate protection. Failure to use protective eyewear may result in severe
burns or other eye injury. If discomfort develops, discontinue use and consult a physician.
ONLY THE FOLLOWING LAMPS HAVE BEEN CERTIFIED FOR USE IN THE 2000S:
DARK TAN™ Wolff® Model DT71-T12-100W BI-PIN
THIS EQUIPMENT MUST BE EARTH GROUNDED.
This product is in conformity with performance standards for sun lamp
products under 21 CFR PART 1040.20 and ANSI/UL Standard 482.
DANGER
88465
DISCONNECT POWER CORD BEFORE ATTEMPTING TO CLEAN, RELAMP,
OR ENGAGE IN THE MAINTENANCE OF THIS PRODUCT.
RECOMMENDED EXPOSURE TIMES IN MINUTES
Level 1/Week 1 Level2Level3Level4 Subsequent
Skin Type: 1st-3rd Sessions Maximum
I Sensitive NOT RECOMMENDED FOR TANNING
II Light 3 6 9 12 15
III Normal 4 7 11 15 15
IV Dark 5 9 13 15 15
MAXIMUM EXPOSURE TIME IS 15 MINUTES
WARNING
Wear protective eyewear.
Failure to may result in severe burns or longterm injury to
the eyes.
DANGER
Shock hazard.
Disconnect power before servicing or removing any
protective covers.
Do not operate this device near water or while you
are wet.
DANGER
Some medications may increase your sensitivity to ultraviolet
light. It is recommended that you consult a physician before
using this sunbed if taking any medication or if you suspect
that your skin might be especially sensitive to sunlight.
CAUTION
Air from the room is used to cool the sunbed. Maximum
ambient room temperature should be 80°F. Place your
sunbed no closer than 6” from any wall. Make sure nothing
obstructs the airflow into the sunbed’s endcaps or out of the
fan openings. A poorly ventilated room may cause the unit to
become hot and cause discomfort to the user.
Electrical Requirements
Your sunbed operates from a 120V AC source. You should have a
NEMA 5-15R electrical outlet (like the one shown below) installed in
the room in which you will use the unit. The outlet should be on a
dedicated circuit capable of providing 15 Amp service. We recom-
mend installation by a professional electrician. The outlet must be
earth grounded.
15 AMP NEMA #5-15R
RECEPTACLE
Unpacking and Inspection
Your suntanning canopy comes in a single cardboard carton, fully
assembled. Pull back the plastic sheet and, with a helper, grasp the
canopy and pull it from the carton bottom, leaving the plastic wrap
and the carton packaging. Do not try to lift the unit with the plastic still
on as it may slip. You should also find a pair of safety goggles.
Inspect the unit and make sure it is free from any visible damage.
Report the extent of any damage to the transportation company.
27956-01A
WARNING
DO NOT unbuckle handling strap with unit upside-down.
Always place on floor with wheels down.
Failure to may result in injury from rapidly opening stand.

Transporting
Your sun canopy comes with a handling strap attached on the swivel
arm, this strap should be used when transporting the sun canopy.
• Lower the sun canopy to its fully closed position by pressing
down on the swivel arm.
Note! Do not press down on the canopy itself, as this action causes
added stress to the canopy structure.
• Buckle the handling strap around the swivel arm and base tube as
shown.
• One person can now roll the sun canopy by lifting
one end.
Note! When maneuvering the canopy to
go through a doorway tilt the
canopy so that the swivel arm
is down.
Using Your Sunbed
Before you tan
Before using your sunbed, please note the following important pre-
cautions.
• Your skin should be free of cosmetics, tanning oils, or other body
lotions prior to tanning except for those specifically made for use
with tanning devices. However, do not remove natural body oils by
bathing or showering immediately before tanning.
• This unit intended for individual use. Only one pair of eyewear is
included.
Exposure Times
Follow the guidelines for skin type and exposure times as shown in
the table in the Safety Information. Untanned persons should not tan
on consecutive days during their first week of tanning. Never tan
more than once a day. Tanning normally appears after the first few
sessions and maximizes after approximately four weeks. Tan once or
twice per week thereafter to maintain appearance. Persons already
having a base tan may begin at advanced levels corresponding to the
extent of their base tan.
Operation
Your sunbed is designed for individual use. Always wear the safety
goggles supplied with your sunbed or another approved pair of gog-
gles, as defined under 21 CFR 1040.20. Regular sunglasses do not
provide adequate protection from ultraviolet light.
Step 1 Release the buckle on the handling strap and raise the canopy
by lifting the swivel arm. Extend the canopy to its fully open
position.
Step 2 Put on your goggles. Set the timer (on top of the canopy) to
the desired number of minutes (after first determining the
proper time period from the table in the Safety Information).
The lamps will turn on as soon as you move the rotary dial
from the “0” position.
Step 3 Lie on a bed or cot and position the canopy over your body.
Grasp the canopy at its edges, near its center pivoting point,
and pull toward your body. For best results position the
canopy close to your body, but no closer than two inches.
Step 4 When the timer reaches 0, the lamps will automatically turn off.
Timer Maintenance
Your sun canopy is equipped with a backup shut-off timer which will
automatically turn off the canopy in the unlikely event of a malfunc-
tion of the primary timer. This important safety feature also prevents
the user from resetting the timer before the end of the pre-set maxi-
mum time interval. The electronic timer limiting circuit is automati-
cally reset each time the primary timer is turned to the OFF position.
Annually, or whenever your sunbed is re-lamped, check the operation
and accuracy of the timer system as follows.
1Obtain an accurate watch capable of measuring in seconds. Set
the timer to the maximum time. Using the watch, time how long
the lamps remain on. The lamps should shut off within plus or
minus 10% of the maximum timer interval.
2Set the timer to the maximum time. Wait ten minutes, then turn
the knob back to the maximum time position. The electronic time
limiting circuit should turn the lamps off at an elapsed time equal
to approximately 10% beyond the maximum timer interval, even
though the primary timer continues to show time left.
Contact your place of purchase if your timer does not operate proper-
ly, or if you experience difficulty with these tests.
CAUTION
Do not perform these tests with a person in the sunbed.
Doing so may lead to overexposure which can cause
eye and skin injury and allergic reactions.
LIFT THIS END
HANDLING STRAP
WARNING
DO NOT unbuckle handling strap with unit upside-down.
Always place on floor with wheels down.
Failure to may result in injury from rapidly opening stand.

Care and Maintenance
Thorough Periodic Cleaning
The cooling fans draw air through the unit and will cause a dust
buildup on the fans, lamps and reflector. This will reduce the tanning
effectiveness of the unit. When a dust buildup is observed, it is neces-
sary to thoroughly clean the inside of the unit.
1Remove the metal grill and lamps as described in Replacing
Lamps.
2With a soft cloth, wipe the entire length of each lamp.
3Clean both sides of the grill with a non-ammonia disinfectant
cleaner.
4Wipe the reflector with a clean damp cloth.
5Re-install the lamps and grill.
6Use a vacuum to clean the cooling fans.
Mechanical Inspection
Inspect the unit’s mechanical integrity every 400-500 hours of use.
• Inspect the unit’s fasteners verifying that all are firmly in place.
• Inspect the gas spring for signs of wear. Lift and lower the canopy
a few times and then leave in the fully open position. Replace gas
springs that will not hold the canopy in the fully open position
when raised.
• Inspect the timer as indicated in Timer Maintenance.
• Inspect the AC power cord and its connections.
Replacing Lamps
To be assured of maximum tanning effectiveness, change lamps after
approximately 800-1000 hours of use. Tanning will continue after this
time but at a slower rate. To ensure trouble-free operation of your
sunbed, replace the lamp starters whenever the lamps are replaced.
Step 1 To remove the metal grill you must remove either endcap.
The endcaps are held in place by four Phillips-head screws.
Slide the grill out of the canopy as shown below.
Step 2 Grasp a lamp at one end and at the middle, then turn the
lamp a quarter turn. The lamp may then be gently removed
from its holder.
Step 3 To reinstall a lamp, insert the pins located on the ends of the
lamp into the slots on top of the lamp holder and turn the
lamp a quarter turn.
Step 4 Slide the grill back into the canopy and
secure the endcap.
Recommended Replacement Lamps
We recommend using the lamps speci-
fied in the Safety Information on the other side. Use of
uncertified lamps is a violation of Federal regulations and
will void your warranty. These lamps have an average life of
800-1000 hours of effective tanning use. Lamps used longer
than that begin to lose their effectiveness even though they will
continue to light.
Swivel Adjustment
Over time you may notice your sun canopy does not hold its position
when tanning. Where the swivel arm enters the canopy, under the
canopy cover, is a bracket that controls the rotation friction of the unit.
Step 1 Remove the endcaps from the canopy. They are held in
place by four screws each.
Step 2 Remove the two screws at the back of the unit that hold the
canopy cover to the power bracket. You may then pry the
cover up enough to gain access to the bracket (shown
below).
Step 3 To adjust the rotation friction simply turn the nuts on the
bracket (clockwise to tighten and counter-clockwise to
loosen).
Reverse the above instructions to put your canopy back together
Only swivel arm, bracket and
side profile shown for clarity.
WARNING
Shock hazard.
Disconnect power before removing
any protective covers.

Problem Troubleshooting
Solution
Lamps fail to light
1. Check source of AC power. Reset circuit breaker or replace
fuse if necessary.
2. Make sure the unit is plugged into outlet.
3. Make sure timer dial is turned to a number past 0.
One or more lamps fail to light
1. Check that lamp is installed correctly.
2. Switch unlit lamp with a lamp that lights. If the new lamp
lights and the old lamp still does not, replace old lamp.
3. If replacing lamp does not remedy problem, contact your
service representative.
Canopy fails to stay in the up or down position
Gas springs should hold the canopy fully up as well as
allow it to rest fully closed. If the canopy is left up for an
extended period of time it may creep down. This is consid-
ered normal. Keep the canopy closed when not in use.
Replace gas spring when it no longer has sufficient power
to hold the canopy up when raised.
Sunbed does not stay lit
1. Check source of AC power. Reset circuit breaker or replace
fuse if necessary.
2. Check timer system per maintenance instructions in this
guide. Contact your service representative.
2000S
Size
Weight 89
Electrical -
Voltage (AC) 120
Amperage 10
Circuit Breaker (Amps) 15
Outlet (NEMA standard) 5-15R
Main Lamps DARK TAN™ 100W
Ballasts 100W Electronic
Timer System Electro-mechanical
Max. Exposure Time 15minutes
Back-up Timer Redundant Solid-State
18 MONTH “BRONZE MEDAL”WARRANTY
Your ETS Distributor (including ETS, LLC if purchased directly), through a manufacturer’s
warranty, warrants your tanning unit to be free of structural defects in material and work-
manship, under normal use, for its lifetime. Your ETS Distributor will, at its discretion, repair
any structural defect which materially affects the performance of the tanning unit, or replace
the tanning unit.
For eighteen (18) months following the purchase date of your tanning unit, your ETS
Distributor will provide replacements for parts that prove to be defective in material or
workmanship, with the following exceptions: gas springs are warranted against manufac-
turer’s defects for a period of one (1) year; ballasts are warranted against manufacturer’s
defects for a period of six (6) months; fluorescent lamps, lamp starters and cracked or bro-
ken endcaps are warranted against manufacturer’s defects for a period of ninety (90) days;
blue and clear filter glass (for face tanners) are warranted against manufacturer’s defects for
a period of thirty (30) days; acrylics are warranted against manufacturer’s defects for a peri-
od of ninety (90) days following the purchase date of your tanning unit.
Labor costs associated with repair or replacement work covered by this warranty will be
reimbursed for repair or replacement work required to be performed for a period of thirty
(30) days following the purchase date of your tanning unit. Normal wear and tear, damage
from misuse or abuse, damage incurred in transit or damages resulting from unauthorized
repairs or modifications are not covered by this warranty. Warranty coverage does not
include cosmetic abnormalities such as scratches, nicks, dents, or other cosmetic changes
that do not materially interfere with the function of the tanning unit.
THIS 18 MONTH “BRONZE MEDAL” WARRANTY IS EXPRESSLY MADE IN LIEU OF
ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WAR-
RANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
WHICH ARE HEREBY DISCLAIMED. No one has the authority to change or modify this
18 Month “Bronze Medal” Warranty in any respect. To obtain service under this 18 Month
“Bronze Medal” Warranty, contact your authorized ETS Distributor (or ETS, LLC if pur-
chased directly). Proof of purchase, including serial number, is required.
IN NO EVENT SHALL YOUR DISTRIBUTOR OR THE MANUFACTURER BE LIABLE AT
LAW OR IN EQUITY FOR ANY LOSS, LIABILITY, DAMAGE OR EXPENSE IN AN
AMOUNT IN EXCESS OF THE PURCHASE PRICE RECEIVED, OR FOR LOSS OF USE OR
PROFITS, LOSS OF TIME, INCONVENIENCE, RENTAL OR SUBSTITUTE PRODUCTS,
LOSS OF BUSINESS, LOSS OF INCOME, OR ANY OTHER INCIDENTAL, INDIRECT, SPE-
CIAL OR CONSEQUENTIAL DAMAGES. Some states do not allow the exclusion or limita-
tion of incidental or consequential damages, and the above limitation or exclusion will not
apply to residents of some states. This 18 Month “Bronze Medal” Warranty gives you specific,
legal rights and you may have other rights which may vary from state to state.
All warranty service must be performed by an authorized service person using only ETS
authorized replacement parts. Use of non-authorized parts may void your warranty. All labor
charges must be authorized by your ETS Distributor prior to the start of repairs and must not
exceed the established rates and time allotment policies established by your ETS Distributor. If
your tanning unit must be returned for service, all freight charges shall be at your expense.
Contact your ETS Distributor for the authorized Service Center nearest you. This warranty is
serial number specific and only applies to tanning units purchased through an authorized ETS
Distributor. This warranty is extended to the individual or legal entity whose name appears on
the original sales document and may not be transferred to any other individual or legal entity.
This warranty is void if the tanning unit is modified in any manner from its original design.
1•800•449•3605
7445 Company Drive
Indianapolis, IN 46237-9296
To obtain warranty service contact your place of purchase. Proof of
purchase, including serial number, is required for verification.
Contact ETS, LLC only if you purchased your equipment directly.
Proudly manufactured in the U.S.A.
