Sunsea AIoT SIMCom SIM7070 TE Series User manual

SIM7070 Series _TE Kit
User Guide
SIMCom Wireless Solutions Limited
Building B, SIM Technology Building, No.633, Jinzhong Road
Changning District, Shanghai P.R.China
Tel: [phone]
[e-mail]
www.simcom.com

SIM7070X TE Kit User Guide V1.01
www.simcom.com 2/12
Document Title:
SIM7070 Series TE kit User Guide
Version:
1.01
Date:
2020-05-13
Status:
Release
Document Control ID:
SIM7070 Series-TE kit User Guide_V1.01
GENERAL NOTES
SIMCOM OFFERS THIS INFORMATION AS A SERVICE TO ITS CUSTOMERS, TO SUPPORT
APPLICATION AND ENGINEERING EFFORTS THAT USE THE PRODUCTS DESIGNED BY SIMCOM.
THE INFORMATION PROVIDED IS BASED UPON REQUIREMENTS SPECIFICALLY PROVIDED TO
SIMCOM BY THE CUSTOMERS. SIMCOM HAS NOT UNDERTAKEN ANY INDEPENDENT SEARCH
FOR ADDITIONAL RELEVANT INFORMATION, INCLUDING ANY INFORMATION THAT MAY BE IN THE
CUSTOMER’S POSSESSION. FURTHERMORE, SYSTEM VALIDATION OF THIS PRODUCT
DESIGNED BY SIMCOM WITHIN A LARGER ELECTRONIC SYSTEM REMAINS THE RESPONSIBILITY
OF THE CUSTOMER OR THE CUSTOMER’S SYSTEM INTEGRATOR. ALL SPECIFICATIONS
SUPPLIED HEREIN ARE SUBJECT TO CHANGE.
COPYRIGHT
THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION WHICH IS THE PROPERTY
OF SIMCOM WIRELESS SOLUTIONS LIMITED COPYING, TO OTHERS AND USING THIS DOCUMENT,
ARE FORBIDDEN WITHOUT EXPRESS AUTHORITY BY SIMCOM. OFFENDERS ARE LIABLE TO THE
PAYMENT OF INDEMNIFICATIONS. ALL RIGHTS RESERVED BY SIMCOM IN THE PROPRIETARY
TECHNICAL INFORMATION ，INCLUDING BUT NOT LIMITED TO REGISTRATION GRANTING OF A
PATENT , A UTILITY MODEL OR DESIGN. ALL SPECIFICATION SUPPLIED HEREIN ARE SUBJECT TO
CHANGE WITHOUT NOTICE AT ANY TIME.
SIMCom Wireless Solutions Limited
Building B, SIM Technology Building, No.633 Jinzhong Road, Changning District, Shanghai P.R.China
Tel: [phone]
Email: [e-mail]
For more information, please visit:
https://www.simcom.com/download/list-863-en.html
For technical support, or to report documentation errors, please visit:
https://www.simcom.com/ask/or email to: [e-mail]
Copyright © 2020 SIMCom Wireless Solutions Limited All Rights Reserved.

SIM7070X TE Kit User Guide V1.01
www.simcom.com 3/12
Version History
Date
Version
Description of change
Author
2019-08-16 1.00 Origin Zhaosen
2020-05-13 1.01 Update document template
Tu Hongjun
Tu Hongjun

SIM7070X TE Kit User Guide V1.01
www.simcom.com 4/12
Contents
Version History..............................................................................................................................................3
Contents .......................................................................................................................................................4
Figure Index..................................................................................................................................................5
SCOPE.........................................................................................................................................................6
1. Detail description of TE..........................................................................................................................7
2. TE Accessory.........................................................................................................................................8
3. Installing TE on SIMCom EVB Board ....................................................................................................9
4. TE KIT USB Driver Installation.............................................................................................................10
5. Using SIMCom Serial Port Tool ...........................................................................................................12

SIM7070X TE Kit User Guide V1.01
www.simcom.com 5/12
Figure Index
FIGURE1: TE VIEW......................................................................................................................................7
FIGURE 2: TE ACCESSORY........................................................................................................................8
FIGURE 3: TE AND SIMCOM-EVB ACCESSORY.......................................................................................9
FIGURE 4: SIM7070 DEVICES RECOGNIZED BY THE OPERATING SYSTEM......................................10
FIGURE 5: BROWSE FOR THE DRIVERS................................................................................................ 11
FIGURE 6: ALL DRIVERS INSTALLED...................................................................................................... 11
FIGURE 7: SIMCOM SERIAL PORT TOOL INTRODUCTION ...................................................................12

SIM7070X TE Kit User Guide V1.01
www.simcom.com 6/12
SCOPE
THIS DOCUMENT DESCRIBES HOW TO USE SIM7070 Series-TE TO DO TEST; USER CAN GET
USEFUL INFO ABOUT THE SIMCOM-EVB QUICKLY THROUGH THIS DOCUMENT.
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME.
As SIM7070 Series EVB kit including SIM7070 Series -TE kit + SIMCOM_EVB kit, so customer should
refer to this SIM7070 Series -TE kit user guide document and SIMCOM_EVB KIT_User Guide
document together.
NOTE

SIM7070X TE Kit User Guide V1.01
www.simcom.com 7/12
1. Detail description of TE
Figure1: TE View
Attachment Label Description
A Module
C
Micro USB Connector
D GNSS Antenna Connector
E Main Antenna Connector
F TE module orientation mark (must be the same as the marking direction on
SIMCOM-EVB)
G
Connector (Connect to SIMCOM-EVB)
H Connector (Connect to SIMCOM-EVB)
P
Unused

SIM7070X TE Kit User Guide V1.01
www.simcom.com 8/12
2. TE Accessory
Figure 2: TE Accessory
Attachment Label Description Quantity
M
GNSS Antenna 1
N Main Antenna 1
The main antenna is included in the SIMCOM_EVB KIT.
NOTE

SIM7070X TE Kit User Guide V1.01
www.simcom.com 9/12
3. Installing TE on SIMCom EVB Board
TE Kits are compatible with EVB Boards and they fitted like on the following figure.
Figure 3: TE and SIMCOM-EVB Accessory
When install SIM7070 Series -TE to SIMCOM-EVB, please keep orientation mark (F) aligned on TE
and EVB.
NOTE

SIM7070X TE Kit User Guide V1.01
www.simcom.com 10/12
4. TE KIT USB Driver Installation
When USB Cable plugged in a PC and connected as shown on the figure TE View – C: Micro USB Port”
There should be several SimTech SIM7070 Series devices listed under other devices in Device
manager like the follow figure.
Figure 4: SIM7070 Devices Recognized by the Operating System
Please right click on each of the “SimTech SIM7070” devices and select “Update driver”. Please select
“Browse my computer for driver software”. Please click “Browse” and manually search and point to the
driver folder “SIM7070_SIM7080 _SIM7090 Series Windows USB Driver_V1.00” and confirm by clicking
“Next”.

SIM7070X TE Kit User Guide V1.01
www.simcom.com 11/12
Figure 5: Browse for the drivers
Please repeat same procedure for each of the listed “SimTech 7070” devices under “Other devices” until
getting listed three SimTech devices under “Ports (COM & LPT) , one SimTech device under Modems and
one SimTech device under Network Adapters as shown on the figure.
Figure 6: All drivers installed
After driver installs, Ports can use for purposes bellow;
USB Ports Description
SimTech HS-USB AT Port 9205 AT Command Communication Port
SimTech HS-USB Diagnostics 9205
Software Debug and FW Update Port
SimTech HS-USB NMEA 9205 GNSS NMEA Output Port

SIM7070X TE Kit User Guide V1.01
www.simcom.com 12/12
5. Using SIMCom Serial Port Tool
SIMCom has a serial port tool to test modules with AT Commands. Serial Port Tool can communicate with
modules after opening COM Ports on list. On following figure, every section of serial tool can be seen.
Figure 7: SIMCom Serial Port Tool Introduction
Also, SIMCom Serial Port Tool may take some log records and save these command lists to use later again.
Tool has a 3 CMD List sections and holds AT Commands with their notes and saves under .ini format on PC
to import it back.
Driver: SIM7070_SIM7080_SIM7090 Series Windows Driver_V1.00 and Serial Port Tool: SIMCom
Serial Port Tool_V2.6 obtained from local agents or SIMCom FAE.
NOTE
