USER’S
MANUAL
586/6x86 EmbeddedCard
W/VGA&LCDFlatPanel
W/SCSI/SSD
PC-550

Copyright Notice
PC-550 P5/6x86 Embedded Card
WITH VGA/SCSI/SSD
OPERATION MANUAL
COPYRIGHT NOTICE
This operation manual is meant to assist both Embedded Computer manu-
facturers and end users in installing and setting up the system. The infor-
mation contained in this document is subject to change without any notice.
This manual is copyrighted 1998. (Revised Edition: Feb. 26, 2002). You may
not reproduce or transmit in any form or by any means, electronic or
mechanical, including photocopying and recording.
ACKNOWLEDGEMENTS
All trademarks and registered trademarks mentioned herein are the property of
their respective owners.

Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual ......................................................... 1-2
1-2 System Specification ....................................................... 1-3
1-3 Safety Precautions ........................................................... 1-6
CHAPTER 2 HARDWARE CONFIGURATION
2-1 Jumper & Connector Quick Reference Table ............... 2-2
2-2 Component Locations ................................................... 2-3
2-3 How to Set Jumpers ...................................................... 2-4
2-4 CPU Type & Clock Selection ....................................... 2-6
2-4-1 Intel 75/90 CPU Type & Clock Jumper Setting .............................. 2-6
2-4-2 Intel 100/120 CPU Type & Clock Jumper Setting .......................... 2-7
2-4-3 Intel 133/150 CPU Type & Clock Jumper Setting ........................... 2-8
2-4-4 Intel 166/200 CPU Type & Clock Jumper Setting ........................... 2-9
2-4-5 Intel MMX-166/200/233 CPU Type & Clock Jumper Setting .......... 2-10
2-4-6 Cyrix P-120/150/166 CPU Type & Clock Jumper Setting ................ 2-11
2-4-7 Cyrix MMX-166/200 CPU Type & Clock Jumper Setting ............... 2-12
2-4-8 Cyrix MMX-233/266 CPU Type & Clock Jumper Setting ............... 2-13
2-4-9 Cyrix 6x86L-120/150/166 CPU Type & Clock Jumper Setting .........2-14
2-4-10 AMD K5-75/90/100 CPU Type & Clock Jumper Setting ............... 2-15
2-4-11 AMD K5-120/133/166 CPU Type & Clock Jumper Setting ........... 2-16
2-4-12 AMD K6-166/200/233 CPU Type & Clock Jumper Setting ........... 2-17
2-5 RS232/422/485 (COM2) Selection ............................... 2-18
2-6 AT Keyboard or PS/2 Mouse Selection ........................ 2-19
2-7 SSD Memory Mapping Selection ................................. 2-19
2-8 COM1 Connector .......................................................... 2-20
2-9 COM2 Connector .......................................................... 2-20
2-10 Keyboard Connector ..................................................... 2-21
2-11 External Keyboard Connector ....................................... 2-21
2-12 Reset Connector ............................................................ 2-21
2-13 Floppy Disk Drive Connector ....................................... 2-22
2-14 Hard Disk Drive Connector .......................................... 2-23
2-15 Hard Disk Drive LED Connector .................................. 2-25
2-16 Power LED & KeyLock Connector .............................. 2-25
2-17 Panel Inverter Delay-power Connector ......................... 2-25

Contents
2-18 LCD Panel Connector ................................................... 2-26
2-19 VGA CRT Connector ................................................... 2-27
2-20 Power Connector ........................................................... 2-27
2-21 Printer Connector .......................................................... 2-28
2-22 External Speaker Connector .......................................... 2-29
2-23 SCSI Connector ............................................................ 2-29
2-24 Memory Installation ..................................................... 2-31
2-25 Solid State Disk Socket ……………………..………... 2-32
2-26 Universal Serial Bus Connector ……………………… 2-33
CHAPTER 3 SOFTWARE UTILITIES
3-1 Introduction …………..................................................... 3-2
3-2 VGA Driver Utility ……………………………………. 3-2
3-3 Flash BIOS Update ......................................................... 3-5
3-4 SCSI Driver Utility ……………………………………. 3-7
3-5 Watchdog Timer Configuration ..................................... 3-8
CHAPTER 4 GREEN PC FUNCTION
4-1 Power Saving Block Diagram ......................................... 4-2
4-2 CPU Doze Mode ............................................................. 4-2
4-3 System Standby Mode .................................................... 4-2
4-4 System Suspend Mode .................................................... 4-3
CHAPTER 5 AWARD BIOS SETUP
5-1 Introduction ..................................................................... 5-2
5-2 Entering Setup ................................................................. 5-3
5-3 The Standard CMOS Setup Menu .................................. 5-4
5-4 The BIOS Features Setup Menu ..................................... 5-8
5-5 Chipset Features Setup .................................................... 5-11
5-6 Power Management Setup .............................................. 5-12
5-7 PNP/PCI Configuration .................................................. 5-14
5-8 Load BIOS Defaults ........................................................ 5-15
5-9 Load Setup Defaults ........................................................ 5-15
5-10 Integrated Peripherals ................................................... 5-16

Contents
5-11 Password Setting ........................................................... 5-17
5-12 IDE HDD Auto Detection ............................................. 5-18
5-13 HDD Low Level Format ............................................... 5-21
5-14 Save & Exit Setup ......................................................... 5-22
APPENDIX A EXPANSION BUS
PC-104 Connector Pin Assignment .......................................... A-2
ISA Bus Pin Assignment .......................................................... A-3
PCI Bus Pin Assignment .......................................................... A-4
APPENDIX B TECHNICAL SUMMARY
Interrupt Map ............................................................................ B-2
RTC & CMOS RAM Map ....................................................... B-3
Timer & DMA Channels Map .................................................. B-4
I/O & Memory Map ................................................................. B-5
APPENDIX C TROUBLE SHOOTING
Trouble Shooting for Error Messages ...................................... C-2
Trouble Shooting for POST Code ............................................ C-4

Page:1-1
INTRODUCTION
This chapter gives you the information for PC-550. It also outlines
the System specification.
Section includes:
!About This Manual
!System Specifications
!Safety precautions
Experienced users can skip to the chapter 2 on page
2-1 for Quick Start.
CHAPTER
1

Chapter 1 Introduction
Page: 1-2 PC-550 USER
′
S MANUAL
1-1. ABOUT THIS MANUAL
Thank you for purchasing our PC-550 P5/6x86 Embedded Card with
VGA/SCSI/SSD, which is fully PC / AT compatible. The PC-550 provides
faster processing speed, greater expandability and can handle more task than
before. This manual is designed to assist you how to install and set up the
system. It contents five chapters. The user can apply this manual for
configuration according to the following chapters :
Chapter 1 Introduction
This chapter introduces you the background of this manual, and the speci-
fication for this system. Final in this chapter will indicate you how to avoid the
damages for this Embedded CPU Card.
Chapter 2 Hardware Configuration
This chapter outlines the components' locations and their functions. In the end
of this chapter, you will know how to set jumper and how to configure this
card to meet your own needs.
Chapter 3 Software Utilities
Helpful information that informs you the proper installations of the VGA &
SCSI driver. And also how to Flash BIOS. It also describes the Watchdog-
timer function.
Chapter 4 Green PC Function
This chapter explains the Green PC functions concisely.
Chapter 5 Award BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
Appendix A Expansion Bus
This Appendix introduces you the expansion bus for PC-104, ISA Bus and
PCI Bus.
Appendix B Technical Summary
This section gives you the information about the Technical maps.
Appendix C Trouble Shooting
This section outlines the error messages and offers you methods to solve the
problems.

Chapter 1 Introduction
PC-550 USER
′
S MANUAL Page: 1-3
1-2. SYSTEM SPECIFICATION
!
!!
!CPU :
Intel, AMD, Cyrix.
54C/55C/M1/M2/K5/K6.
320/321 pin PGA socket.
75/90/100/120/133/166/200/233/266MHz clock generator.
2.8V/2.9V/3.2V/3.3V/3.5V voltage regulator.
!
!!
!MEMORY :
Up to 256MB, EDO/FPM DRAM
Four 72-pin SIMM socket on board.
!
!!
!CACHE :
L1 Cache (depended on CPU type).
L2 Cache on board 512K. (256K optional)
!
!!
!REAL-TIME CLOCK / CALENDAR :
CMOS data back up from BIOS set or BIOS default.
Dallas DS 12887 Real Time Clock.
!
!!
!BIOS :
Award, Flash BIOS for plug & play function.
Easy update 128/256KB flash EEPROM.
Support Green Function .
Support S/IO Setup.
!
!!
!KEYBOARD CONNECTOR :
PC/AT type mini DIN connector.
Support PC/AT Keyboard or PS/2 Mouse by jumper selection.
5 pin External keyboard connector.
!
!!
!BUS SUPPORT :
External ISA / PCI BUS.
Internal PCI Bus, for VGA, IDE, & SCSI.
External PC-104 BUS.

Chapter 1 Introduction
Page: 1-4 PC-550 USER
′
S MANUAL
!
!!
!DISPLAY :
Support SVGA for CRT & Panel.
Support 32bits PCI Local Bus.
VGA BIOS combines in 128/256KB flash ROM together with system BIOS.
Support 15 pin connector 1024 x 768 (256 colors) resolution on SVGA
Monitor.
Support 2 MB Video memory (1 MB optional).
Support 41 pin connector 640 x 480, 800 x 600 resolutions on LCD Panel.
Panel support Mono, Color STN, TFT, EL.
SVGA & Panel Display simultaneously.
!
!!
!WATCHDOG :
I / O port 0443H to Enable watchdog.
I / O port 0441H to Disable watchdog.
Time-out timing select 0 / 2 / 4 / 6 / 8 / 10 / 12 / 14 / 16 / 18 / 20 / 22 / 24 / 26 /
28 / 30 sec +/- 25%.
!
!!
!IDE INTERFACE :
Two IDE ports, Support up to four Enhanced IDE devices.
!
!!
!FLOPPY DISK DRIVER INTERFACE :
Support up to two Floppy Disk Drivers, 3.5" and 5.25" (360K / 720K / 1.2M /
1.44M / 2.88M).
!
!!
!DISK-ON-CHIPS SOCKET :
Supports up to 72MB.
!
!!
!UNIVERSAL SERIAL BUS :
Supports up to two USB ports.
!
!!
!SERIAL PORT :
Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte
FIFOs. COM1 = RS232. COM2 = RS232/422/485.
MIDI Compatible.
Programmable Baud Rate Generator.
!
!!
!PARALLEL PORT :
SPP, ECP, EPP Function.
Bi-direction parallel port.

Chapter 1 Introduction
PC-550 USER
′
S MANUAL Page: 1-5
!
!!
!GREEN FUNCTION :
Software supported by BIOS setup.
Hardware supported by switch control.
!
!!
!LED INDICATOR :
System power.
Hard Disk access.
Turbo and green function mode.
!
!!
!PC-104 BUS EXPANSION & SPEED :
ISA 8MHz
PC-104 8MHz
PCI Bus 33MHz
!
!!
!DMA CONTROLLER :
82C37 x 2
!
!!
!DMA CHANNELS :
7
!
!!
!INTERRUPT CONTROLLERS :
82C59 x 2
!
!!
!INTERRUPT LEVELS :
15
!
!!
!OPERATING TEMPERATURE :
0 to 60°C.
!
!!
!SYSTEM POWER REQUIREMENT :
DC Voltage: +5V, minimum +4.75V, maximum 5.25V.
DC Ampere: 15A.
!
!!
!BOARD DIMENSION :
338.5mm x 122mm
!
!!
!BOARD NET WEIGHT :
0.4 Kg.

Chapter 1 Introduction
Page: 1-6 PC-550 USER
′
S MANUAL
1-3. SAFETY PRECAUTIONS
Follow the messages below to avoid your systems from damage:
1. Avoid your system from static electricity on all occasions.
2. Prevent electric shock. Don‘t touch any components of this card when the
card is on. Always disconnect power when the system is not in use.
3. Disconnect power when you change any hardware devices. For instance,
when you connect a jumper or install any cards, a surge of power may
damage the electronic components or the whole system.

Page 2-1
HARDWARE
CONFIGURATION
** QUICK START **
Helpful information details you the jumper & connector settings, and
components locations.
Section includes :
!Jumper & Connector Quick Reference Table
!Components‘ Locations
!Configuration and Jumper settings
!Connector Pin Assignments
CHAPTER
2

Chapter 2 Hardware Configuration
Page: 2-2 PC-550 USER
’
S MANUAL
2-1 JUMPER & CONNECTOR QUICK REFERENCE TABLE
CPU Type & Clock Selection ................................ JP2, JP4
CPU Voltage Selection .......................................... JP8, JP9
RS232/422/485 (COM2) Selection ........................ JP7
Keyboard or PS/2 Mouse Selection ................…... JP6
SSD Memory Mapping Selection .......................... JP12
COM1 Connector ................................................... COM1
COM2 Connector ................................................... COM2
Keyboard or PS/2 Mouse Connector ..................... DIN
External Keyboard Connector ............................... EXKB
Reset Connector ..................................................... JP10
Floppy Disk Drive Connector ................................ FDD
Hard Disk Drive Connector ................................... IDE1, IDE2
Hard Disk Drive LED Connector .......................... HDL
Power LED & KeyLock Connector ....................... KBL
LCD Panel Connector ............................................ LCD
VGA CRT Connector ............................................ VGA
Power Connector ................................................... PWR
Printer Connector .................................................. PRT
External Speaker Connector .................................. SPK
SCSI Connector ..................................................... SCSI1,ULTRA
Memory Installation ...............................................
.............................................. SIMM1, SIMM2
SIMM3, SIMM4
SSD Socket ......................…………...................... SSD
Universal Serial Bus Connector …………………. USB

Chapter 2 Hardware Configuration
PC-550 USER
’
S MANUAL Page: 2-3
2-2 COMPONENT LOCATIONS
12887
SIMM 2
PWR
EXKB
KB
BIOS
SIMM 1
SIO
COM 1 VGA
DIN
VRAM VRAM
SIMM 3
SIMM 4
UltraWideSCSISCSIII
IDE1
IDE2
FDDPRT
COM2
Panel
PC104
Triton
HX
Triton
HX
Pentium
6x86
CPU
64x32
64x32
54C/55C
12
1
2324
12
56
1
JP10
34
68
1
3540
40
39
391
2
2
1
33
34
1
21
6
5
10
1
6
1
59
6
1
5
6
10
11
15
5
6
3
1
2
4
JP7
USB
1
25
6
JP2
KBL
RST
SSD
JP6
27
8
1
JP8
1
25
6
JP4
JP1
JP3
JP11
SPK
25
6
1
JP12
HDL
1
GRN
1
JP9
27
8
1
JP13
1
610
5
PC-550 Connector, Jumper and Component locations

Chapter 2 Hardware Configuration
Page: 2-4 PC-550 USER
’
S MANUAL
2-3 HOW TO SET JUMPERS
You can configure your board by setting jumpers. A jumper consists of two or
three metal pins with a plastic base mounted on the card, and a small plastic
“cap”( with a metal contact inside) to connect the pins. So you can set up your
hardware configuration by “open” or “close” the pins.
The jumper can be combined into sets which called jumper blocks. When the
jumpers are all in the block, you have to put them together to set up the
hardware configuration. The figure below shows how this looks.
JUMPERS AND CAPS
If a jumper has three pins, for examples, labelled PIN1, PIN2, and PIN3. You
can connect PIN1 & PIN2 to create one setting and shorting. You can either
connect PIN2 & PIN3 to create another setting. The same jumper diagrams are
applied all through this manual. The figure below shows what the manual
diagrams look and what they represent.

Chapter 2 Hardware Configuration
PC-550 USER
’
S MANUAL Page: 2-5
JUMPER DIAGRAMS
JUMPER SETTINGS

Chapter 2 Hardware Configuration
Page: 2-6 PC-550 USER
’
S MANUAL
2-4 CPU TYPE & CLOCK SELECTION
JP2 : Bus Frequency Ratio Selection
JP4 : CPU Clock Selection
JP8, JP9 : CPU Voltage Selection
The jumper settings are as follow :
2-4-1 Intel 75/90 CPU type & clock Jumper setting
CPU
TYPE
CPU
CLOCK
Jumper Setting
(Pin closed)
JP2 JP4 JP8 JP9
JUMPER
ILLUSTRATION
Intel
Pentium
75Mhz
50Mhz 1-3
2-4
3-5
4-6
1-2
5-6
7-8
1-2
3-4
Intel
Pentium
90Mhz
60Mhz 1-3
2-4
1-3
4-6
1-2
5-6
7-8
1-2
3-4

Chapter 2 Hardware Configuration
PC-550 USER
’
S MANUAL Page: 2-7
2-4-2 Intel 100/120 CPU type & clock Jumper setting
CPU
TYPE
CPU
CLOCK
Jumper Setting
(Pin closed)
JP2 JP4 JP8 JP9
JUMPER
ILLUSTRATION
Intel
Pentium
100Mhz
66Mhz 1-3
2-4
2-4
3-5
1-2
5-6
7-8
1-2
3-4
Intel
Pentium
120Mhz
60Mhz 1-3
4-6
1-3
4-6
1-2
5-6
7-8
1-2
3-4

Chapter 2 Hardware Configuration
Page: 2-8 PC-550 USER
’
S MANUAL
2-4-3 Intel 133/150 CPU type & clock Jumper setting
CPU
TYPE
CPU
CLOCK
Jumper Setting
(Pin closed)
JP2 JP4 JP8 JP9
JUMPER
ILLUSTRATION
Intel
Pentium
133Mhz
66Mhz
1-3
4-6
2-4
3-5
1-2
5-6
7-8
1-2
3-4
Intel
Pentium
150Mhz
60Mhz
3-5
4-6
1-3
4-6
1-2
5-6
7-8
1-2
3-4

Chapter 2 Hardware Configuration
PC-550 USER
’
S MANUAL Page: 2-9
2-4-4 Intel 166/200 CPU type & clock Jumper Setting
CPU
TYPE
CPU
CLOCK
Jumper Setting
(Pin closed)
JP2 JP4 JP8 JP9
JUMPER
ILLUSTRATION
Intel
Pentium
166Mhz
66Mhz 3-5
4-6
2-4
3-5
1-2
5-6
7-8
1-2
3-4
Intel
Pentium
200Mhz
66Mhz 2-4
3-5
2-4
3-5
1-2
5-6
7-8
1-2
3-4
