SunSynk SYNK-16K-SG01LP1 User guide

SUNSYNK MAX
INSTALLER MANUAL
v.15 PLEASE RETAIN FOR
FUTURE REFERENCE
SYNK-16K-SG01LP1
www.sunsynk.com
[email protected]
[email protected]

SAFETY 3
General Safety 3
Symbols/Safety Signs 3
Safety Instructions 5
Product Disposal 5
PRODUCT INTRODUCTION 6
Product Overview 6
Product Size 7
Product Features 8
Basic System Architecture 9
TECHNICAL SPECIFICATIONS 10
INSTALLATION 12
Parts List 12
Selecting the Mounting Area 13
Mounting the Inverter 14
Battery Connection 15
Function Port Denition 17
Battery Temperature Sensor Connection 18
Connecting the AC 19
Recommended AC Surge Protector 20
PV Connection 21
PV Module Selection 21
PV Module Wiring 21
PV Protection 22
Installing the CT Coil 23
Earth Connection (MANDATORY) 24
Meter Connection 26
CHiNT Meter 26
Eastron Meter (SDM120CT) 26
Wiring System for Inverter 27
Typical Application of Diesel Generator 28
Single-Phase Parallel Connection 29
Single-Phase Parallel Connection - Diesel
Generator 30
Three-Phase Parallel Inverter 31
OPERATION 32
Switching ON/OFF 32
Display 32
LED Indicators 32
Function Buttons 32
LCD Operation Flow Chart 33
Home Page 34
Status Page 34
System Flow Page 35
Setup Page 36
Basic Setup 37
Set Time (Clock) 37
Set Company Name / Beeper / Auto dim 37
Factory Reset and Lock Code 38
Inverter Remote Control 39
Battery Setup Page 39
Generator & Battery Page 40
Battery Discharge Page 42
Setting Up a Lithium Battery 44
Program Charge & Discharge Times 51
Grid Supply Page 54
Paralleling Inverters Advanced Settings 58
Connecting the DRM’s 61
Advanced Function Setup 62
Solar Power Generated 62
Grid Power 63
Advanced Settings for Wind Turbines 64
Advanced Settings for Auxiliary Load 65
OPERATING MODES 68
Mode I: Basic 68
Mode II: With Generator 68
Mode III: With Aux Load 69
Mode IV: AC Couple 69
FAULT CODES 71
COMMISSIONING 75
Start-Up / Shutdown Procedure 75
Inverter Commissioning Info 75
GDFI Fault 76
MAINTENANCE 76
APPENDIX A 77
APPENDIX B 78
APPENDIX C 78
APPENDIX D 78
APPENDIX E 78
Table of Contents

SUNSYNK MAX | Installer Manual3
SAFETY
This device should only be used in accordance with the instructions within this manual and in compli-
ance with local, regional, and national laws and regulations. Only allow this device to be installed, oper-
ated, maintained, and repaired by other people who have read and understood this manual. Ensure the
manual is included with this device should it be passed to a third party.
DO NOT allow minors, untrained personnel, or person(s) suering from a physical or mental impairment
that would aect their ability to follow this manual, install, maintain or repair this device.
Any untrained personnel who might get near this device while it is in operation MUST be informed that it
is dangerous and instructed carefully on how to avoid injury.
General Safety
Symbols/Safety Signs
This symbol indicates information that if
ignored, could result in personal injury,
physical damage or even death due to
incorrect handling.
CE mark is attached to the solar invert-
er to verify that the unit follows the
provisions of the European Low Voltage
and EMC Directives.
Risk of burn. Keep the equipment well-ventilated.
Risk of electric shock.
DO NOT touch the terminal or remove
the shell within 5 minutes after discon-
necting all power.
The UKCA marking is used for products
placed on the market in Great Britain
(England, Scotland and Wales). The
UKCA marking applies to most prod-
ucts for which the CE marking could be
used.
5min
This product's batteries contain an ex-
plosive, self-reactive material that could
blow up when heated.
Do not disassemble or alter the battery
in any way. Do not strike or puncture
the battery.
KG
The Battery is heavy and can cause inju-
ry if not handled safely.
ONLY qualied personnel should install
or perform maintenance work on the
units.
Be careful when touching the inverter!
It is an electrical product with risk of
electric shock and heating.
Warranty Void if Seal is Broken
Do not place near open re or incin-
erate. Do not use near heaters or hot
temperature sources.
Keep the product out of reach of chil-
dren!
Do not stand on. Avoid unsuitable shoes for installing
and operating the inverter.
Do not step or put any objects onto the
battery.
Do not drop, deform, or impact the
battery.

SUNSYNK MAX | Installer Manual4
1Single Phase. 3Three Phase.
Protective Conductor Terminal or Earth
Ground Terminal. Rechargeable.
Do not submerge the battery in water or
expose it to moisture or liquid Keep out of reach of children, animals,
and insects.
Do not expose the product to sunlight. Inverter DC to AC.
Li-ion Battery. KG Net Weight in Kilograms.
BATTERY INPUT
Battery Discharge Voltage, Battery
Discharge Current, Input Voltage Type,
Battery Discharge Power.
PV INPUT
PV Input Voltage, Number of MPPT's,
MPPT Input Current & Max PV ISC.
Direct Current. Indicates that this product is recyclable.
AC OUTPUT
Output Voltage, Input Voltage Type, Ac
Output Rated Current, Max AC Current,
Output Frequency, Max AC ISC, Power
Factor & AC Output Rated Power.
CONTINUOUS OUTPUT
CURRENT
Maximum Continuous Output Current,
Output Frequency and Voltage, & AUX
(programmable AC output on battery
SOC).
Charging. Discharging.
Follow the indicated temperatures. TEMPERATURE
Ambient, Min & Max.
MANUAL DOWNLOAD
Download the latest version of the
instruction manual by scanning the QR
code.
WARRANTY REGISTRATION
Scan the QR code to access our web-
site and sign up for the manufacturer’s
warranty.
Do not dispose the device, accesso-
ries, and packaging with regular waste.
Follow local ordinances or contact the
manufacturer for disposal guidance.
Refer to the operating instructions.
Contact the supplier within 24 hours if
there is anything wrong. In case of leak-
age contact with eyes or skin, imme-
diately clean with water and seek help
from a doctor.

SUNSYNK MAX | Installer Manual5
Safety Instructions
This chapter contains important safety and operating instructions. Read and keep this manual for future
reference.
Before using the inverter, please read the instructions and warning signs of the battery and correspond-
ing sections in the instruction manual.
Do not disassemble the inverter. If you need maintenance or repair, take it to a professional service
center.
Improper reassembly may result in electric shock or re.
To reduce the risk of electric shock, disconnect all wires before attempting any maintenance or cleaning.
Turning o the unit will not reduce this risk.
Never charge a frozen battery.
For optimum operation of this inverter, please follow the required specications to select the appropri-
ate cable size. It is very important to operate this inverter correctly.
Be very cautious when working with metal tools on or around batteries. Dropping a tool may cause a
spark or short circuit in batteries or other electrical parts, even causing an explosion.
Please strictly follow the installation procedure when you want to disconnect AC or DC terminals.
Please refer to this manual's "Installation" section for details.
Grounding instructions - this inverter should be connected to a permanent grounded wiring system. Be
sure to comply with local requirements and regulations to install this inverter.
Never cause AC output and DC input to short-circuit. Do not connect to the mains when DC input short
circuits.
Product Disposal
DO NOT dispose this product with domestic waste!
Electrical devices should be disposed of in accordance with regional directives on electronic and/ or elec-
tronic-waste disposal. In case of further questions, please consult your supplier. In some cases, the supplier
can take care of proper disposal.
WARNING
HIGH LIFE RISK DUE TO FIRE OR ELECTROCUTION.
Sunsynk Max can only be installed by a qualied licensed electrical contractor. This is not a DIY
product.

SUNSYNK MAX | Installer Manual6
1
2
3
4
5
8
9
10
11
12
13
14
15
7
6
1. Inverter Indicators 6. Modbus (RS-485) Port 11. PV Input
2. LCD Display 7. Parallel Port 12. Generator Input
3. Function Buttons 8. Battery Input Connectors 13. Load
4. DC Switch 9. Function Port 14. Grid
5. Power On/O Button 10. Battery (CANBus) Port 15. WiFi Interface
PRODUCT INTRODUCTION
This multifunctional inverter combines the functions of an inverter, solar charger and battery charger to oer
uninterruptible power support with a portable size. Its comprehensive LCD display oers user-congurable
and easily accessible button operations such as battery charging, AC/solar charging, and acceptable input
voltage based on dierent applications.
Product Overview

SUNSYNK MAX | Installer Manual7
Product Size
Inverter Size
763.00 798.40
859.50
464.00
302.00
490.81
464.00
497.81
10.00
15.00
401.00
200.50
10.00
22. 00
376.00
668.00
282.00
302.00

SUNSYNK MAX | Installer Manual8
Product Features
INTERACTIVE
Supporting WIFI monitoring and 2 strings of each MPP trackers
Smart settable three stages MPPT charging for optimized battery performance.
Visual power ow screen
Time of use function.
Smart Load Function.
Parallel / multi invert function grid-tied and o-grid
COMPATIBLE
Compatible with main electrical grid voltages or power generators
Self-consumption and feed-in to the grid
Auto restart while AC is recovering
CONFIGURABLE
Fully programmable controller
Programmable supply priority for battery or grid
Programmable multiple operation modes: on-grid/o-grid & UPS
Congurable battery charging - current/voltage based on the application
Congurable AC / solar / generator charger priority by LCD setting
SECURE
Overload/over-temperature/short-circuit protection
Smart battery charger design for optimized battery protection
Limiting function installed to prevent excess power overow to grid

SUNSYNK MAX | Installer Manual9
Basic System Architecture
The following illustration shows basic application of this inverter.
It also includes following devices to have a complete running system.
Generator or utility
PV modules
Consult with your system integrator for other possible system architectures depending on your require-
ments.
This inverter can power all kinds of appliances in home or once environment, including motor type applianc-
es such as refrigerator and air conditioner.

SUNSYNK MAX | Installer Manual10
TECHNICAL SPECIFICATIONS
Model SYNK-16K-SG01LP1
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range 40~60V
Max. Charge Current 290A
Max. Discharge Current 290A
Charging Curve 3 Stages/Equalization
External Temperature Sensor Yes
Charging Strategy for Li-Ion Battery Self-Adaptation to BMS
PV String Input Data
Max. DC Input Power 20800W
Max PV Input Voltage 370V (125~500V)
MPPT Range 150V~425V
Start-up Voltage 125V
PV Input Current 26A + 26A + 26A
Max. PV Isc 44A + 44A + 44A
No. of MPPT / Strings Per MPPT 3 / 2+2+2
AC Output Data
Max. On-Grid AC Power 16000W
Max. O-Grid AC Power 17600W
Max. AC Output Apparent Power 16000VA
Peak Power (o-grid) 2 times of rated power, 10 S
AC Output Rated Current 72.7/69.6A
Max AC Current 80/76.5A
Max Continuous AC Passthrough 100A
Power Factor 0.8 leading to 0.8 lagging
Output Frequency and Voltage 50Hz/60Hz; 220/230Vac (single phase)
Grid Type Single-Phase
Current Harmonic Distortion THD < 3% (of nominal power)
DC Current Injection < 0.5% In
Eciency
Max. Eciency 97.60%
Euro Eciency 96.50%
MPPT Eciency > 99%
Protection
Integrated
PV Arc Fault Detection, PV Input Lightning Protection, Anti-islanding
Protection, PV String Input Reverse Polarity Protection, Insulation
Resistor Detection, Residual Current Monitoring Unit, Output Over
Current Protection, Output Shorted Protection
Surge Protection DC Type II / AC Type II
Over Voltage Category DC Type II / AC Type III

SUNSYNK MAX | Installer Manual11
Certications and Standards
Grid Regulation EN 50549-1, AS-NZS 4777.2, NRS 097-2-1; Additional connections
available upon request
EMC / Safety Regulation IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
General Data
Operating Temperature Range -40~60°C, >45°C Derating
Cooling Smart cooling
Noise <50dB
Communication with BMS RS485; CAN
Net Weight 52kg
Gross Weight 60kg
Size 464W×763H×282D mm (Excluding connectors and brackets)
Protection Degree IP65
Installation Style Wall-mounted
Warranty 5 years

SUNSYNK MAX | Installer Manual12
Parts List
INSTALLATION
Check the equipment before installation. Please make sure nothing is damaged in the package. You should
have received the items in the following package:
Parallel communication
cable x1
Hybrid inverter
x1
L-type Hexagon wrench
x1
Stainless steel anti-collision
bolt M8×80
x3
Battery temperature sensor
x1
User manual x1 Data Logger x1
Sensor Clamp
EU x1
Combined terminal wrench
x1
Magnetic ring for battery
x 1
Magnetic ring for BMS
communication cable
x 1

SUNSYNK MAX | Installer Manual13
Selecting the Mounting Area
This Sunsynk MAX is designed for outdoor use (IP65).
DO NOT install the inverter in the following areas:
Areas with high salt content, such as the marine environment. It will deteriorate the metal parts and pos-
sibly lead to water/dampness penetrating the unit.
Areas lled with mineral oil or containing splashed oil or steam such as found in kitchens. It will deterio-
rate plastic parts of the unit, causing those parts to fail or allow water/damp to penetrate the unit.
Areas that generate substances that adversely aect the equipment, such as sulphuric gas, chlorine gas,
acid, or alkali. These can cause the copper pipes and brazed joints to corrode and fail to conduct elec-
tricity reliably.
Areas that can cause combustible gas to leak, which contains suspended carbon-bre or ammable
dust, or volatile inammable such as paint thinner or gasoline.
Areas where there may be gas leaks and where gas may settle around the unit as this is a re risk.
Areas where animals may urinate on the unit or ammonia may be generated.
High altitude areas (over 2000 metres above sea level).
Environments where precipitation or humidity are above 95%.
Areas where the air circulation is too low.
Please AVOID direct sunlight, rain exposure, snow laying up during installation and operation. Before con-
necting all wires, please take o the metal cover by removing screws as shown below:
Considering the following points before selecting where to install:
Please select a vertical wall with load-bearing capacity for installation, suitable for installation on concrete
or other non-ammable surfaces, installation is shown below.
Install this inverter at eye level in order to allow the LCD display to be read at all times.
The ambient temperature is recommended to be between -40~60ºC to ensure optimal operation.
Be sure to keep other objects and surfaces as shown in the diagram to guarantee sucient heat dissipa-
tion and enough space to remove wires.
Install the indoor unit on the wall where the oor height is higher than 1600mm.
For proper heat dissipation, allow a clearance of approximately 500mm to the side, 500mm above and
below the unit, and 1000mm to the front of the unit.

SUNSYNK MAX | Installer Manual14
≥500mm
≥500mm
Mounting the Inverter
Choose the recommended drill head (as shown below pic) to drill 4 holes in the wall, 82-90mm deep.
1. Use a proper hammer to t the expansion bolt into the holes.
2. Carry and hold the inverter, ensure the hanger aims at the expansion bolt, and x the inverter on the
wall.
3. Fasten the screw head of the expansion bolt to nish the mounting.
WARNING
For proper air circulation to dissipate heat, allow a clearance of approx. 50cm to the side and approx.
50cm above and below the unit. And 100cm to the front.
WARNING
Risk of injury (Heavy Object).
Remember that this inverter is heavy so users must be careful in handling the unit during installation
especially when mounting or removing it from a wall.

SUNSYNK MAX | Installer Manual15
Battery Connection
For safe operation and compliance, a separate DC over-current protector or disconnect device is required
between the battery and the inverter. In some applications, switching devices may not be required but
over-current protectors are still required. Refer to the typical amperage in the table below for the required
fuse or circuit breaker size.
Model Wire Size Cable (mm2) Torque Value (max.)
16kW 1/0 AWG 53 12.5N.m
12 mm
82~90mm
[(3.23 in.)to(3.54 in.)]
(0.47 in.)
WARNING
All wiring/connecting must be performed by qualied personnel. Before making the nal DC con-
nection or closing the DC Breaker/disconnection device, ensure the inverter unit is wired correctly. A
reverse-polarity connection on the battery will damage the inverter.

SUNSYNK MAX | Installer Manual16
Please follow below steps to implement battery connection:
1. Please choose a suitable battery cable with correct connector which can well t into the battery termi-
nals.
2. Use a suitable screwdriver to unscrew the bolts and t the battery connectors in, then fasten the bolt by
the screwdriver, make sure the bolts are lightened with torque of 12.5 N.M in clockwise direction.
3. Make sure polarity at both the battery and inverter is correctly connected.
4. In case of children touch or insects go into the inverter, please make sure the inverter connector is fas-
ten to waterproof position by twist it clockwise.
20mm
88.7mm
For 16kW model, battery
connector screw size: M8
16mm
8.5mm
DC Battery Input
Pass the battery power cable
through the magnetic ring and
wrap it around the magnetic
ring two times.
Pass the BMS communication cable
through the magnetic ring and wrap
it around the magnetic ring four times.
WARNING
Reverse Polarity.
Before making the nal DC connection or closing DC breaker/disconnect, be sure positive(+) must be
connect to positive(+) and negative(-) must be connected to negative(-). Reverse polarity connection
on battery will damage the inverter.

SUNSYNK MAX | Installer Manual17
Function Port Denition
ParallelParallel
Battery
CANBus
Modbus
RS-485
Batt Temp
Sensor
1 2 3 4 5 6 7 8 9 10 B B + - 1516 19 20
TEMP (1,2): battery temperature sensor for
lead acid battery.
CT-L1 (3,4): current transformer (CT1) for
“zero export to CT”mode clamps
on L1 when in split phase system.
CT-L2 (5,6): current transformer (CT2) for
“zero export to CT”mode clamps
on L2 when in split phase system.
Gen_Start_relay (7,8): dry contact signal for startup
the diesel generator.
When the "GEN signal" is active, the open
contact (GS) will switch on (no voltage output).
Gen_ON_relay (9,10): reserved.
RSD_short signal: reserved.
RSD_voltage signal: reserved.
RSD 12V_out 15+16-: reserved.
ATS: 230V output port when inverter is on.
Note: Normally only 1pcs CT is needed only,
and the secondary side of the CT should
be connected to 5&6 port (CT-L2).
CT -L2
CT -L1
Gen start-up
N/O Relay
Inverter
GS (diesel generator startup signal)
relay
coil
open
contact
G S
Modbus (RS-485): RS-485 port for Meter
communication.
Battery (CANBus): CAN port for battery
communication.
Parallel: Parallel communication port 1
(CAN interface).
Parallel: Parallel communication port 2
(CAN interface).
Batt_Temp_in:1,2
CT_L1_in:3,4
CT_L2_in:5,6
Gen_Start_relay:7,8
Gen_ON_relay:9,10
RSD_short signal:B B
RSD_voltage signal:+ -
RSD_12V_ out:15+,16-
ATS_240:19,20
Neutral
Earth
Bond
240V Coil

SUNSYNK MAX | Installer Manual18
Battery Temperature Sensor Connection
Without a remote temperature sensor, lead-acid batteries may undercharge or overcharge depending on
the ambient temperature of the installation environment. This may result in a re hazard.
1 2
Temp. sensor
Inverter

SUNSYNK MAX | Installer Manual19
Connecting the AC
GEN/AUX Generator connection.
GRID This works like a conventional grid-tied inverter. It is both an input and output connection
for non-essential load and supply.
LOAD Connection of essential loads such as lighting, security systems, and Internet
Please follow the steps below to implement GRID, LOAD, and GEN port connections:
1. Before making GRID, LOAD, and GEN port connections, make sure to turn o the AC breaker or discon-
nector rst.
2. Remove a 10mm sleeve from each wire, unscrew the bolts, insert the wires according to the polarities
indicated on the terminal block and tighten the terminal screws. Ensure the connection is complete.
3. Then, insert AC output wires according to the polarities indicated on the terminal block and tighten the
terminal. Make sure to connect corresponding N wires and PE wires to related terminals as well.
4. Ensure the wires are securely connected.
5. Check that the AC power source is isolated before attempting to connect it to the inverter. Insert AC out-
put wires according to the polarities indicated on the terminal block and tighten the terminal screws. Be
sure to connect the corresponding N wires and PE wires to the correct terminals and ensure the wires
are securely connected.
Before connecting to grid, please install a separate AC breaker between inverter and grid. Also, it is recom-
mended that installs an AC breaker between backup load and inverter. This will ensure the inverter can be
securely disconnected during maintenance and fully protected from over current.
There are three terminal blocks with “Grid” “Load”and “GEN” markings. Please do not misconnect input and
output connectors.
Model Wire Size Cable (mm2) Torque Value (max.)
16kW 2AWG 35 18.6N.m
WARNING
All wiring and cable sizes must comply with your particular country’s wiring regulations and Codes of
Practices. Ensure that suitable disconnection devices and RCDs are tted.

SUNSYNK MAX | Installer Manual20
Recommended AC Surge Protector
