SUP’AIR EVOLUTION helmet chin guard assembly.
Fitting the ching uard takes time, care and patience. It’s a 10 minute job, not a 2 minute job!
1. Ear pads should be removed before fitting the chin-
guard :
Unfasten both poppers and slide the earpad sandwiched in
between the helmet shell and liner.
2. Next remove the self adhesive carbon-lookalike stickers
above the ear pad, on the outside of the helmet shell. They
will not be used again and can be discarted.
Removing the sticker reveals 2 mounting holes on each side of
the helmet.
3. Place a metal insert in each hole : the threaded insert
section is pushed through the hole between the shell and the
lining to properly position it. Do not push the insert all the way
through the hole; as it will be completely inserted following the
procedure found in section 5. At this point it is only pre-positio-
ned.
Thank you for choosing and purchasing the EVOLUTION helmet and its chin guard. We are pleased to
join you in our common paragliding passion.

Page 2
4. Carefully fit the chin guard to the helmet while making
sure the chin strap stays on the inside of the helmet. The chin
strap tab is tucked in between the shell and the lining.
5. Secure the chin guard using the 4 black screws : catch
a few threads before tightening the screws completely. When
ready to tighten the screws, the insert is positioned inside the
receiving hole. During this sequence, be certain for the insert
not to spin on itself. You can prevent the spin by using a flat
screwdriver and applying pressure to increase resistance on
the bolt.
Tighten using the provided wrench. Be careful not to push the
inside bolt back and not to tighten the screws too much. They
should be fastened snugly but not excessively to the point
where they would damage the chin guard.
The assembly is done and you can now enjoy flying!
