Super SOCO TS User manual

USER INSTRUCTIONS 2
DESCRIPTION OF COMPONENTS AND PARTS 3-4
OPERATION GUIDE 5-8
RIDING GUIDE 9
CHECKS BEFORE RIDING 10-11
BATTERY USE INSTRUCTIONS 12-14
MAINTENANCE-15
ROUTINE CLEANING AND MAINTENANCE-16-17
GEBRAUCHSANWEISUNGEN 18
SCHEMA GLOBAL DE LA MOTO 19
KOMPONENTEN- UND TEILEBESCHREIBUNG 20
BENUTZERHAN DBUCH 21-24
MANUEL D'UTILISATION 25
FAHRANLEITUNG 26-27
ANWEISUNGEN ZUR BATTERIEANWENDUNG 28-30
WARTUNG 31
GÄNGIGE PROBLEME UND FEHLERBEHEBUNGSMETHODEN 32-40
INSTRUCTIONS D'UTILISATION 41
SCHEMA GLOBAL DE LA MOTO 42
DESCRIPTION DES COMPOSANTS ET DES PIECES 43
MANUEL D'UTILISATION 44-50
INSTRUCTIONS D'UTILISATION DE LA BATTERIE 51-53
MANUEL D’ENTRETIEN 54
PROBLEMES COURANTS ET METHODES DE DEPANNAGE 55-56
GARANTIES 57-63
CONTENTS INDICE
CONTENUTI
INHALT
SOMMAIRE
MANUAL DEL USUARIO-64
DESCRIPCION DE LOS COMPONENTES Y PIEZAS 65-66
GUIA DE FUNCIONAMIENTO 67-71
PUESTA EN MARCHA PARA LA CONDUCCION 72-73
INSTRUCCIONES DEL USO DE LA BATERIA 74-76
MANTENIMIENTO-77
PROBLEMAS COMUNES Y MÉTODOS DE SOLUCIÓN DE PROBLEMAS 78-79
INSTRUCCIONES DE SEGURIDAD 80
DESCRIZIONE DEI COMPONENTI E DELLE PARTI 81-82
OPERAZIONI PER LA GUIDA 83-86
LA GUIDA 87-90
ISTRUZIONI PER L’USO DELLA BATTERIA 91-92
MANUTENZIONE 93
PROBLEMI COMUNI E METODI DI RISOLUZIONE 94-95
ASSISTENZA POST-VENDITA 96
LE GARANZIE 97-100
ISTRUZIONI PER ALTRI ARTICOLI NON COPERTI DA TRE GARANZIE 101-102
디렉토리
부품 설명 103
계기판-104
수납 상자와 시트 열기 105
메인 스위치 106
시동 방법 107-108
배터리 충전 방법 109-111
1

USER INSTRUCTIONS
Safety Instructions
Welcome to the family of SOCO owners! We will guide you to know every function for the right and safe use
of TS smart electric bikes. To ensure your safety, please read this manual carefully before riding and make sure
you are always following the requirements below:
Fully understand the information in (.his manual, including but not limited to the relevant instructions, precautions and warnings.
Fully understand the operation and contingency measures of TS smart electric bikes.
Be fully aware of warning labels of TS smart electric bikes.
SOCO will take any responsibility resulting from the unauthorized modification, failure to use original spare parts, or installation
of components that affect the performance and safety of the bike.
Please contact the SOCO Customer Service Center if you have any questions about this bike. We are at our service at any time.
Wish you safe and pleasant riding experience!
To ensure the safety of you and others, please make sure to observe the following matters:
Do not ride after you take medications which may affect your riding ability, drink alcohol, or when you are unwell.
Observe traffic regulations and traffic signs and confirm the surrounding road conditions and bike conditions at any time, so
as to actively avoid danger.
Wear safety equipment, such as helmet, and appropriate protective clothing if necessary, such as gloves and boots.
Perform a basic check each time before riding, so as to confirm the light, brake, tread and tire pressure and check other
parts for looseness or abnormal noise, and regularly go to SOCO Service Center for maintenance.
In order to ensure the safety of you and others, please DO NOT use high beam in good lighting conditions. The continuous
use of high beam will cause the visual disturbance to vehicles and pedestrians on the opposite side, thus affecting normal
driving.
Please do not make or answer any call during riding, which is likely to cause traffic accidents.
2

Headlamp
Rearview mirror
Storage box
Saddle Tail lamp
Rear license
bracket
Brake cylinder
Winker
Rear brake lever
Instrument panel
Rear brake lever
Speed control handlebar
Right-handlebar switch set
Left-handlebar switch set
Front shock
absorber
Spoke-type
aluminum hub
Brake disc
FOC vector controller
Adjustable pedal
Electronic side stand
Brake disc
Electric motor
Rear swingarm
SIDE VIEW TOP VIEW
SCHEMATIC DIAGRAM OF COMPONENTS AND PARTS
DESCRIPTION OF COMPONENTS AND PARTS
3

Speed / fault code
Display current speed When
fault indicator goes on, fault
code will be displayed.
Display current output current.
Display current battery level
Display current battery level.
Display current gear
Display current
ambient temperature
Display current time
Display the total mileage.
Display the temperature under
current operating conditions.
Real-time current
Power display bar
Ambient temperature Power display
Gear display
Distance per charge/
trip distance/
rotating speed
Clock
Total mileage
Controller temperature
Cruising Gear, corresponding to the number “2”
Sport Gear, corresponding to the number “3”
Fault Charging Data connection
Economical Gear, corresponding to number ”1”
High beam indicator, indicating high beam on.
Parking indicator, indicating the parking state.
Winker indicator, flashing in synchronization with the
left and right winker.
The charge indicating lamp lights up when less than
ten electricity remains.
The start indicator lights up when the motor
can be started.
DIAGRAM OF INSTRUMENT PANEL
DESCRIPTION OF COMPONENTS AND PARTS
RANGE Remaining distance per charge. RPM Current riding distance.
TRIP Current rotating speed.
TURN ON SWITCHING ADJUSTMENT MODE
1. Press the high beam switch for 3 times
(i.e., the high beam indicator flashes for 3 times) in continuous time such as 4 seconds;
2. At this time, the current display mode
(driving range/ single mileage/ revolving speed) is flashing, indicating that the motor
has entered the adjustment mode;
SWITCH THE DISPLAY UNIT (KM AND MILE, KM/H AND MPH)
Retract the side stand, and enable the switching adjustment mode. Toggle the "parking
brake handle switch" from OFF (P gear indicator on) to ON (in 2 seconds), and then to
OFF, thus switching the display units (km and mile, km/h and mph); toggle the "parking
brake handle witch" from OFF to ON (in more than 2 seconds), and then to OFF, thus
turning on the LCD backlight. (Remarks: now the brightness is fixed at the brightest level).
DISPLAY SWITCHING (DRIVING RANGE / SINGLE MILEAGE / REVOLVING SPEED)
Turn on switching adjustment mode, and turn on or off the high beam switch to toggle
the display mode (driving range / single mileage / revolving speed) once.
Cycle the switching in this way.
4

OPERATION GUIDE
SMART REMOTE CONTROLLER OPERATIONSTART BUTTON
High/low beam switch button
Winker button
Horn button
Press up to turn on the high beam.
Press down to turn on the low beam.
Dial to the left side to turn on the left winker.
Dial to the right side to turn on the right winker.
Press to make a sound and release to stop.
Headlamp button
Parking button
Gear shift button
Dial up to to turn on the headlamp.Turn downward to AUTO
to automatically turn on the headlights.The headlights turn on
automatically according to the brightness of the environment.
Dail down to to turn off the headlamp.
Parking button has two modes: press to park the bike and
parking indicator P goes on; and press again to exit the parking
status.
The bike has three modes,
i.e., 1 "eco", 2 "cruise", and 3 "sport". Dial rightwards for "eco",
middle for "normal"and left for "sport".
5

OPERATION GUIDE
OPEN THE STORAGE BOX AND SADDLEHOW TO OPERATE THE PHYSICAL
HANDLEBAR LOCK
After unlocking the bike with the Smart Remote Controller,
press the start button, and the bike will be in the “Powered”
state; press it again to turn off the bike.
With the advanced Smart Remote Controller, you can easily
lock or unlock your TS smart electric bike by simply pressing
the button within 50 meters.
Center Letter blinks；
Protected
Center Letter stays on；
Standby
Outer-ring light stays on；
Power-on
Lock button
Unlock button
1. Lock button. When the bike is in the [Static State], press
the lock button, and the start button flashes. The bike enters
the [Locked State].
2. Unlock button. Press the unlock button, and the start
button stays on. The bike enters into the [Unlocked State].
6

OPERATION GUIDE
OPEN THE STORAGE BOX AND SADDL
After the bike stops, turn the handlebar to the far
left, insert the key into the physical handlebar lock,
and rotate it rightwards to lock the bike.
Insert the key and rotate it rightwards, and the
storage box will be opened when you hear a [Click]
sound.
Insert the key and rotate it leftwards to open the
saddle. Basic tools are provided inside saddle.
Insert the key into the physical handlebar lock, and
rotate it leftwards to unlock the bike.
How to lock
the bike
How to Unlock
the bike
7

OPERATION OF AIR SWITCH
OPERATION OF ADJUSTABLE PEDAL
As the protection switch for the main power of TS smart electric bike,
the air switch will automatically disconnect to ensure safety when the
bike circuit is abnormal or the current caused by short circuit exceeds
the set safe value
TIPS： In order to protect your safety, please turn off the air
switchwhen cleaning, storing the bike for a long time, or
re-moving the battery pack.
The original adjustable pedal provides three riding modes,
and can be adjusted for comfort.
Open the saddle and take out the included Allen wrench;
Unscrew the nut under the pedal;
Adjust the pedal to the appropriate position
(three positions) and tighten the nut.
OPERATION GUIDE
8

RIDING GUIDE
CHECKS BEFORE RIDING
Make sure to check the following items before riding a TS Smart Electric Bike, which will guarantee your safety on the road.
1.Whether the handlebar is stable and flexible when turning.
2.Whether the switches on the right and left handlebars can work normally.
3.Whether the speed control handle can work normally.
Make sure the tire pressure is normal. The suggested tire pressure is 20-25psi for front wheel and 26-32 psi for rear wheel.
4.Check tire surface for cracks, damage, wear, and foreign matter puncture or attachment
5.Whether the tread depth is sufficient (>0.8 mm).
6.Whether any fault warning light on the instrument panel goes on after being powered.
7.Whether the battery is fully charged.
8.Whether the head and tail lights, brake lights and winkers can work normally.
9.Whether the horn can work normally.
10.Whether the rear mirrors are clean. Adjust them to the appropriate angle.
11.Whether the brake oil is sufficient, and whether the handlebars and brake system can work normally.
12.For any abnormality or operational concern, please contact SOCO Customer Service Center.
9

CHECKS BEFORE RIDING
CHECKS BEFORE RIDING
Make sure to check the following items before riding a TS Smart Electric Bike, which will guarantee your safety on the road.
2.Put on the helmet, ride the TS, and retract the electronic side stand.
10

CHECKS BEFORE RIDING
Press the "Start" button, and the bike and the enters
the button to exit the parking state, "Powered" state.
Press the "Parking" button to exit the oarking state,
and the parking indicator goes off
Gently turn the handlebar to ride on the road. TIPS:
Before riding, make sure the electronic side stand retracted and rotate the handlebar
to ensure that the handlebar lock is closed.
If the parking button is pressed when riding, the bike will be dis- energized. So DO
NOT press it when riding for avoiding danger caused by the sudden loss of power.
If the electronic side stand is extended when riding, the bike will be dis- energized. So
DO NOT extend the electronic side stand when riding for avoiding danger caused by
the sudden loss of power.
The bike must be fully stopped before starting. In case of abnormality during riding,
please ride carefully or push it to a safe place. DO NOT try restarting the bike during
riding or on the lane so as to avoid danger.
11

BATTERY USE INSTRUCTIONS
How to charge the battery
on the bike
Insert the main charger plug into the charging port of the bike.
Insert the chargers AC power plug into the socket, and the battery starts charging when the charger indicator turns red.
The battery is fully charged if the charger indicator turns from red to green.
12

CHARGING METHODS
How to charge the battery
off the bike
Open the storage case, close the air switch and take out the storage. Disconnect the main battery plug.
Insert the key into the anti-theft battery lock and rotate it rightwards
to remove the battery from the bike.
Insert the main plug of the charger into the battery charging port,
and then insert the AC power plug of the charger into the socket
The green lights of the charger will flash in turn when charging normally.
13

BATTERY USE INSTRUCTIONS
Cuando la batería este completamente cargada,
los indicadores de carga estarán en color verde.
STORAGE, MAINTENANCE AND TRANSPORTATION
Please charge the battery to half-saturation state when storing or transporting it (after the battery is discharged, charge it for 3
hours). Place it in a dry and ventilated place;
Battery and charger should be kept in a clean, dry, and ventilated place. Keep them away from corrosive materials, power
source and heat source;
Storage conditions: ambient temperature -20-35 °C, humidity < 65% RH;
When storing the charger, please disconnect it from the battery.
TIPS:
Do not expose the battery to water, and prevent it from being damped
by water or rained
Charge temperature: 0-45 °C, discharge temperature: -20-45 °C;
Battery capacity will be reduced when placed in a low-
temperature environment;
Charge the battery when you use it, but make sure to charge it before
the capacity is lower than 20%. When it is not used
for a long time, please remove it from the bike;
TIPS:
Short circuit of the cathode and the anode at the battery's input.
Keep it away from children, fire and heat source. It is strictly forbidden to
throw it into the fire;Violent movements, shock and extrusion are prohibited;
Only the specified charger can be used, and other chargers are prohibited
tocharge the battery;
This product has been subject to strict inspection before leaving factory,
and it is strictly prohibitedto dismantle it. Please contact our company's
after-sales department for any question.
14

MAINTENANCE
ROUTINE CLEANING AND MAINTENANCE
Cleaning： Please use clean water and neutral detergent to clean it, and use soft cloths and sponges to clean the surface;
it is prohibited to use metal brushes, sandpaper or the like to clean it, in order not to scratch the parts surface. After cleaning,
dry it with soft cloths.
TIPS:
Please disconnect the air switch before cleaning.
Do not use strong water jet to directly wash it, so as to avoid the default of mechanical parts caused by water invasion.
REGULAR INSPECTION AND MAINTENANCE
The new bike must be subject to the first inspection and maintenance in the SOCO Service Center when it reaches 1,000 km
or two months (whichever comes first).
The bike is recommended to be subject to regular inspection and maintenance in the SOCO Service Center at every 3,000 km
or six months (whichever comes first).
Regular maintenance can enhance the service life and driving safety of the TS smart electric bike. Please refer to the following
suggestions and take care of your bike.
Storage: try to park it in a dry and cool room to reduce the exposure to sun and rain and avoid the reduction of servicelife due
to corrosion of parts.
When left unused for a long time, please turn off the air switch and disconnect the power supply circuitto prevent over
discharging.
After long-term storage, please fully charge it before use.
TIPS:
Please disconnect the air switch before cleaning.
Do not use strong water jet to directly wash it, so as to avoid the fault of mechanical parts caused by being damped.
15

ROUTINE CLEANING AND MAINTENANCE
Regular maintenance can improve the service life and driving safety of the TS smart electric bikes. Please refer to the fol-lowing
suggestionsand take care of your bike.
Failure
The bike has no electricity, and the start
button does not shine
When turning the speed regulating steering
handle-bar, the motor does not turn after being
powered
Speed is slow or mileage is short
Battery cannot be charged
Low battery
Side stand is not retracted
Parking key is not closed
Brake handle does not reach the right position
Steering handlebar failure
The controller plug is loose
Controller failure
Low battery
Under-inflated tire
Heavily overloaded
Brake pads interference
Battery aging or normal scrap
Poor contact of the main plug of the charger
Do not use the correct charger
Battery aging or normal scrap
Charge the battery
Put away the side stand
Close the parking key
Place the brake handle at the right position
Change handlebar
Re-plug controller
Change controller
Check whether the main plug is in a right place
Use the special charger of the SOCO
Change battery
Battery is poorly connected
Air switch is not turned on
Connect the battery properly at its main plug
Turn on the air switch
Causes Solutions
Charge the battery
Inflate the tire, and check the tire pressure before
riding
Foster a good habit, and keep the appropriate load
Change the brake pads and check the brake
systembefore riding
Change battery
16

Failure
The instrument panel shows 99
The instrument panel shows 98
The instrument panel shows 97
The instrument panel shows 96
The instrument panel shows 95
The instrument panel shows 94
The instrument panel shows 93
The instrument panel shows 92
The instrument panel shows 91
The instrument panel shows 90
The instrument panel shows 89
The instrument panel shows 88
The instrument panel shows 87
Controller communication failure
The controller stops working (possibly over current,
blocking, under pressure, over temperature )
Controller pauses operation (possibly over current,
blocking, under pressure, over temperature)
Controller power tube failure
Controller Hall sensor failure
Controller handlebar failure
Battery communication failure
Charging over voltage
Bateria a alta Temperatura
Battery at high temperature
Low temperature charge
Low temperature discharge
Abnormal network connection
Please contact after-sales service or dealer
Please stop for a while and then start again
Please contact after-sales service or deale
Please contact after-sales service or dealer
Please check the handlebar wire,
or change it in the after-sales service
Please check whether the charging interface is in
a right place or contact after-sales service or dealer
Please stop charging, and check the charger
Please stop charging, and check the charger
Please stop charging and riding
If the instrument keeps showing 90,
please stop riding
Park the bike indoor or in a warm place,
and wait for a moment
Park the bike indoor or in a warm place,
and wait for a moment
Go to an open area or contact
after-sales service or dealer
Causes Solutions
ROUTINE CLEANING AND MAINTENANCE
17

GEBRAUCHSANWEISUNGEN
Sicherheitshinweise
Sollten Sie Fragen zu diesem Fahrrad haben wenden Sie sich bitte an den SOCO Kundenservicecenter.
Wir sind stets für Sie da. Wir wünschen Ihnen eine sichere und angenehme Fahrt!
Zu Ihrer eigenen Sicherheit und die der anderen, sollten Sie folgende Punkte beachten:
• Fahren Sie nicht unter Einfluss von Medikamenten, die Ihre Fahrtüchtigkeit beeinträchtigen können, unter Einfluss von Alkohol
oder wenn Sie si
• Halten Sie sich an Verkehrsregeln und Verkehrshinweise und achten Sie stets auf den Straßenzustand und den Zustand des
Fahrrads, um Gefahren aktiv zu vermeiden.
• Tragen Sie Schutzausrüstungen, wie einen Helm und gegebenenfalls entsprechende Schutzkleidung, wie Handschuhe und
Stiefel.
• Führen Sie vor jeder Inbetriebnahme eine Basiskontrolle durch, um Lichter, Bremse, Tritt und Reifendruck zu überprüfen,
prüfen Sie alle Teile auf ihren Sitz, ungewöhnliche Geräusche und bringen Sie es regelmäßig zur Wartung zum SOCO
Servicecenter.
•Zu Ihrer eigenen Sicherheit und die der anderen, sollten Sie bei guten Lichtverhältnissen KEIN Fernlicht anwenden. Die
durchgehende Anwendung von Fernlicht führt bei entgegenkommendem Verkehr und Fußgängern zu optischen Störungen und
beeinträchtigt das normale Fahren.
•Während der Fahrt sollten Sie keine Anrufe machen oder annehmen, da dies leicht zu Verkehrsunfällen führen kann.
• Machen Sie sich vollständig mit den Information dieses Handbuchs vertraut, einschließlich jedoch ohne Einschränkung, aller
Vorkehrungen und Warnungen.
• Machen Sie sich vollständig mit dem Betrieb und den Notfallmaßnahmen der TS Smart Elektrofahrräder vertraut.
• Machen Sie sich mit den Warnhinweisen der TS Smart Elektrofahrräder vertraut.
• SOCO übernimmt keine Verantwortung für unbefugte Anpassungen, dem Anwenden von nicht originalen Teilen oder der
Installation von Komponenten, die die Leistung und Sicherheit des Fahrrads beeinträchtigen.
Willkommen bei einer Familie von SOCO-Besitzern ! Wir führen Sie durch alle Funktionen, für eine ordnungs-
gemäße und eine sichere Anwendung des TS Smart Elektrofahrrads. Lesen Sie dieses Handbuch zu Ihrer
Sicherheit vor dem Fahren sorgfältig durch und folgen Sie stets den unten stehenden Vorschriften:
18

SCHEMA GLOBAL DE LA MOTO
19

SCHALTEN SIE DEN ANPASSUNGSSCHALTMODUS EIN
Verbleibende Reichweite der Ladung
Aktuelle Drehzahl
AKtuell zurückgelegte Entfernung.
ANZEIGEEINHEIT UMSCHALTEN(KM UND MEILEN,KM/H UND MPH)
Fahren Sie den Ständer ein und aktivieren Sie den Anpassungsschaltmodus. Schalten
Die den „Parkbremsen-Lenkerschalter" von AUS (P Ganganzeige an) auf AN (in 2
Sekunden) und dann auf AUS, wodurch die Anzeigeeinheiten (km und Meilen, km/h und
mph) verändert werden;schalten Sie den „Parkbremsen-Lenkerschalter" von AUS auf AN (in
mehr als 2 Sekunden) und dann auf AUS, wodurch die LCD-Hintergrundbeleuchtung
aktiviert wird. (Hinweis: Die Helligkeit befindet sich nun auf höchster Stufe)
SCHALTMÖGLICHKEITEN ANZEIGEN
(REICHWEITE EINFACHER KILOMETERSTAND, DREHUNGEN)
Schalten sie den Anpassungsschaltmodus ein und schalten Sie den Fernlichtknopf
ein oder aus, um in der Anzeige hin- und herzuschalten (Reichweite, einfacher
Kilometerstand, Drehungen). Schalten Sie auf diese Weise weiter
1. Halten Sie den Fernlichtknopf durchgehend für etwa 4 Sekunden gedrückt,
bis die Anzeige 3 Mal geblinkt hat;
2. Nun blinkt der aktuelle Anzeigemodus (Reichweite, einfacher Kilometerstand, Drehungen).
Der Motor befindet sich im Anpassungsmodus
ANZEIGEN
ARMATURENBRETT-SCHEMA
KOMPONENTEN- UND TEILEBESCHREIBUNG
Geschwindigkeit / Fehlercode
Umgebungstemperatur
uhr
Gesamtfahrleistung
Aktuelle Geschwindigkeit.
Wenn die Fehleranzeige aufleuchtet,
wird auch der Fehlercode angezeigt.
Zeigt den aktuellen Ausgangsstrom
an.
Anzeige aktueller Batteriestand
Anzeige aktueller Batteriestand.
Aktueller Gang
Anzeige der aktuellen Umgebungstemperatur
Aktuelle Uhrzeit
Anzeige der Gesamtfahrleistung.
Temperaturanyeige bei aktuellen
Betriebsbedingungen
Echtzeit-Ausgangsstrom
Leistungsanzeigebalken
Leistungsanzeige
Gang-Anzeige
Spargang, entspricht der Nummer „1"
Schongang, entspricht der Nummer „2"
Sportgang, entspricht der Nummer „3"
Fehler
Fernlichtanzeige zeigt an, dass das Fernlicht
eingeschaltet ist
Parkanzeige zeit den Parkstatus an
Blinkeranzeige, blinkt gleichzeitig mit dem
linken und rechten Blinker
Die Ladestandanzei ge leuchtet auf, wenn weni
ger als zehn Prozent der Ladung verbleiben
Die Betriebsanzeige leuchtet auf, wenn der
Motor in Betrieb genommen werden kann
Ladt Datenverbindung
Temperaturkontrolle Reichweite pro Ladung,
Fahrtabstand, Drehzahl
20
